- Page 1 Stairlift OWNER’S MANUAL (To Be Retained by Owner After Installation by Authorized Savaria Dealer) Part No. 001022 23-m10-2015...
- Page 2 IMPORTANT Ensure that only an authorized Savaria Dealer installs and services the Savaria K2 Stairlift. Under no circumstances is anyone other than a dealer with Savaria training and authorization to install, adjust, or service any mechanical or electrical device on this equipment. Failure to follow this warning can result in safety system compromises or defeat;...
-
Page 3: Table Of Contents
Maintenance Record ..........15 Part No. 001022, 23-m10-2015 K2 Stairlift Owner’s Manual... -
Page 4: To Ensure Safe Operation
Prior to operation, make sure that all areas in and around the lift are clear of any obstructions. • We recommend that you test your keys and emergency stop button (if equipped) every month. K2 Stairlift Owner’s Manual Part No. 001022, 23-m10-2015... -
Page 5: Description
1. DESCRIPTION Figure 1 shows the exterior components of the K2 Stairlift. Figure 1 Flip-up seat Adjustable armrests (swivel out, up/down Backrest adjustable) UP/DOWN toggle switch Key switch Retractable seat belt Seat swivel handle ON/OFF switch Diagnostic Folding LEDs (behind... -
Page 6: Specifications
Charges on standard household power (110 VAC) Charging Charge stations positioned at top and bottom of rail Full up and down travel on power interruption (full Emergency operation battery backup) Warranty 36 months K2 Stairlift Owner’s Manual Part No. 001022, 23-m10-2015... -
Page 7: Features
There may be an optional emergency stop button located on the left arm. Pressing this button will stop the unit immediately. Overspeed Brake The overspeed brake that will engage and stop the lift if the normal downward travel speed is exceeded. Part No. 001022, 23-m10-2015 K2 Stairlift Owner’s Manual... -
Page 8: Key Switch And Power Switch
ON/OFF power switch to the ON position. NOTE Do NOT turn off the power switch after each trip. Turning off the power switch stops the batteries from charging and this action will eventually drain the batteries. K2 Stairlift Owner’s Manual Part No. 001022, 23-m10-2015... -
Page 9: Operation
In the event of an emergency, you can press the optional red Emergency Stop button located on the arm of the chair. The stairlift will stop immediately. Once the emergency is dealt with, release the button to restore normal operation. Part No. 001022, 23-m10-2015 K2 Stairlift Owner’s Manual... -
Page 10: Emergency Manual Operation
2 Remove the access cover on the lower side of the unit. To do this, place a flat blade screwdriver carefully under the corner of the cover and gently pry out to pop the cover off. Figure 3 K2 Stairlift Owner’s Manual Part No. 001022, 23-m10-2015... - Page 11 6 When movement of the carriage is complete, call your Authorized Dealer for service assistance. DO NOT turn the main power back on. Part No. 001022, 23-m10-2015 K2 Stairlift Owner’s Manual...
-
Page 12: Troubleshooting And Maintenance
Make sure the stairlift is either all the way up or all the way down at the charging contact. It will beep continuously if it is not at a charging contact. If the beeping continues, contact your authorized Savaria dealer. Stairlift stops and won’t restart If the stairlift runs to either end of the stairway and then stops and won’t restart,... -
Page 13: Diagnostic Leds
Middle and left LEDs on Right-hand obstruction (or ready to run left) Middle LED on Obstruction, both right-hand and left-hand All LEDS off Safety circuit fault All LEDs on Ready to run left or right Part No. 001022, 23-m10-2015 K2 Stairlift Owner’s Manual... -
Page 14: Maintenance
Check the operation of the overspeed brake. Every 6 months Lubricate the trolley rollers with silicone spray or WD As required (if lubricant. squeaking occurs) Lubricate the seat swivel system using wheel bearing grease. As required K2 Stairlift Owner’s Manual Part No. 001022, 23-m10-2015... -
Page 15: Maintenance Record
Maintenance Record Date Time Reason for Call Comments Dealer Part No. 001022, 23-m10-2015 K2 Stairlift Owner’s Manual... - Page 16 Authorized Savaria Dealer Savaria™ K2 Stairlift OWNER’S MANUAL Part No. 001022 Copyright 2015 Savaria Corporation Elevators and Lifts www.savaria.com Sales 2 Walker Drive Brampton, Ontario, L6T 5E1, Canada Tel: (905) 791-5555 Fax: (905) 791-2222 Toll Free: 1-800-661-5112...
