Page 1 Machine Types:...
Page 3: Table Of Contents
Contents Safety information ..Chapter 1. General information ..1 Chapter 2. Server setup road map . . . 3 Chapter 3. Product overview ..5 Chapter 6.
Page 4 Chapter 7. Troubleshooting and diagnostics ....87 Chapter 8. Getting information, help, and service ....93 Index.
Page 5: Safety Information
Safety Information Safety Information Safety Information Safety Information afety Informa on Safety Information Safety Information 製品をご使用になる前に、Lenovo Web サイトに掲載されているマルチリンガルの Safety Information (安全上の注意) を読んで理解してください。 제품을 사용하기 전에 Lenovo 웹 사이트의 다국어 Safety Information (안전 정보)를 주의 깊게 읽어 보십시오. Safety Information...
Page 6 Safety Information Safety Information Safety Information Safety Information Safety Information 在使用产品之前，请务必先阅读和了解 Lenovo Web 站点上的多语言 Safety Information《安全信息》。 Safety Information Safety Information Safety Information Safety Information Safety Information 使用本產品之前，請務必先閱讀及瞭解 Lenovo 網站上多國語言版本的Safety Information（安全資訊）。 Safety Information Safety Information afety Informa on Lenovo Important:...
Page 7 Statement 1 DANGER Electrical current from power, telephone, and communication cables is hazardous. To avoid a shock hazard: Do not connect or disconnect any cables or perform installation, maintenance, or reconfiguration of this product during an electrical storm. Connect all power cords to a properly wired and grounded electrical outlet. Ensure that all power cord connectors are securely and completely plugged into receptacles.
Page 8 Statement 3 CAUTION: When laser products (such as CD-ROMs, DVD drives, fiber optic devices, or transmitters) are installed, note the following: • Do not remove the covers. Removing the covers of the laser product could result in exposure to hazardous laser radiation. There are no serviceable parts inside the device. •...
Page 9 Statement 6 CAUTION: If you install a strain-relief bracket option over the end of the power cord that is connected to the device, you must connect the other end of the power cord to a power source that is easily accessible in case it needs to be disconnected.
Page 10 Statement 11 CAUTION: The following label indicates a potential heat hazard. Statement 12 DANGER Overloading a branch circuit is a potential fire hazard and a shock hazard under certain conditions. To avoid these hazards, ensure that your system electrical requirements do not exceed branch current ratings at the installation site.
Page 11 Statement 16 CAUTION: To reduce the risk of electric shock or energy hazards: • This equipment must be installed by trained service personnel in a restricted-access location, as defined by your local electrical code and the latest edition of IEC 60950. •...
Page 12: Products That Are Not Assessed
Statement 20 CAUTION: A lithium ion battery is provided. To avoid possible explosion, do not burn the battery. Replace the battery only with the Lenovo-approved part. Recycle or discard the battery as instructed by local regulations. Products that are not assessed...
Page 13: Chapter 1. General Information
Chapter 1. General information Introduction Product name Machine type and model (MT-M) Serial number (S/N) Date of purchase...
Page 14: Server Documentation
Server documentation Printed documents Read Me First Electronic documents Safety Information Lenovo Limited Warranty Lenovo License Agreement Documentation Safety, Warranty, and Support Information User Guide...
Page 15: Chapter 2. Server Setup Road Map
Chapter 2. Server setup road map...
Page 17: Chapter 3. Product Overview
Chapter 3. Product overview Server package Features Personal Systems Reference Microprocessor ™ Memory Power supply Note: Fans...
Page 18 Internal drives Note: Expansion slots Input/Output (I/O) features Video subsystem Ethernet connectivity...
Page 19 Reliability, availability, and serviceability Security features Note: Basic system management features...
Page 20: Specifications
Specifications Dimensions Weight Environment Electrical input Software ThinkServer EasyStartup ThinkServer EasyStartup...
Page 21 ThinkServer EasyUpdate Firmware Updater BIOS update utilities RAID configuration utilities Lenovo ThinkServer Diagnostics Lenovo ThinkServer Diagnostics Lenovo ThinkServer Power Planner Lenovo ToolsCenter Suite CLI Locations...
Page 22 Machine type, model, and serial number label Figure 1. Machine type, model, and serial number label Front view of the server...
Page 23: Rear View Of The Server
Figure 2. Front view of the server Rear view of the server...
Page 24 Figure 3. Rear connector locations Connector Description Note:...
Page 25: Locating Parts On The System Board
Connector Description Locating parts on the system board Figure 4. System board part locations...
Page 26: Internal Components
Internal components Figure 5. Component locations Internal drives...
Page 27 Figure 6. Drive bay locations...
Page 29: Chapter 4. Turning On And Turning Off The Server
Chapter 4. Turning on and turning off the server Turning on the server Turning off the server Statement 5 CAUTION: The power control button on the device and the power switch on the power supply do not turn off the electrical current supplied to the device. The device also might have more than one power cord.
Page 31: Chapter 5. Configuring The Server
Chapter 5. Configuring the server Using the Setup Utility program Starting the Setup Utility program Viewing information in the Setup Utility program Main System Summary Installed Memory Advanced CPU Setup Devices ATA Drive Setup...
Page 32: Setup Utility Program Interface
Setup Utility program interface Notes: Main menu Main Main Devices menu Devices Devices Serial Port Setup USB Setup ATA Drive Setup...
Page 33 Video Setup Audio Setup Network Setup Advanced menu Advanced Advanced Notes: Enabled Disabled Advanced CPU Setup Intel Manageability Intel SIPP Support CPU CRID Support Chipset CRID Support Security menu Security Notes: Enabled Disabled Security Administrator Password Power-On Password Set Administrator Password Set Power-On Password Chassis Intrusion Detection Security...
Page 34 Power menu Power Power After Power Loss Enhanced Power Saving Mode Power Intelligent Cooling Engine (ICE) Automatic Power On Startup menu Startup Startup Enter Primary Boot Sequence Automatic Boot Sequence Error Boot Sequence Enabled Disabled Boot Mode Boot Priority Option Keys Display Enabled Disabled Option Keys Display Style...
Page 35: Setting The System Date And Time
Exit menu Exit Exit Exit Save Changes and Exit Discard Changes and Exit Load Optimal Defaults OS Optimized Defaults Setting the system date and time Main System Time & Date Using passwords Password considerations...
Page 36 Power-On Password Administrator Password Setting, changing, and deleting a password Security Set Power-On Password Set Administrator Password Note: Erasing lost or forgotten passwords (clearing CMOS)
Page 37: Configuring The Tpm Function
Configuring the TPM function Security TCG Feature Setup TCG Security Features TPM Support Active Selecting a startup device Note: Note: Startup Exiting from the Setup Utility program Exit ➙ Save Changes and Exit Exit ➙ Discard Changes and Exit Exit ➙ Load Optimal Defaults Updating or recovering the BIOS...
Page 38 Updating (flashing) the BIOS Notes: Recovering from a BIOS update failure...
Page 39 Using the ThinkServer EasyStartup program ThinkServer EasyStartup ThinkServer EasyStartup Features of the ThinkServer EasyStartup program...
Page 40: Starting The Thinkserver Easystartup Program
ThinkServer EasyStartup Starting the ThinkServer EasyStartup program User Guide ThinkServer EasyStartup Note: ThinkServer EasyStartup Next Agree Notes: Compatibility notes User Guide Home...
Page 41 Compatibility notes User Guide Hardware list Install operating system Download drivers ThinkServer EasyStartup Note: About Using the ThinkServer EasyStartup program on a Windows operating system ThinkServer EasyStartup ThinkServer EasyStartup Note: ThinkServer EasyStartup ThinkServer EasyStartup ThinkServer EasyStartup ThinkServer EasyStartup...
Page 42 Note: Configuring RAID Note: About RAID RAID 0 RAID 1...
Page 43: Creating Raid Volumes
RAID 5 RAID 10 Configuring the system BIOS to enable onboard SATA RAID functionality Note: Devices ➙ ATA Drive Setup Configure SATA as RAID Mode Creating RAID volumes Create RAID Volume Name RAID Level Stripe Size Capacity Exit...
Page 44 Deleting RAID volumes Delete RAID Volume Exit Resetting disks to non-RAID Reset Disks to Non-RAID Exit Updating the firmware Notes:...
Page 45 Using the Firmware Updater program Note:...
Page 47: Chapter 6. Installing, Removing, Or Replacing Hardware
Chapter 6. Installing, removing, or replacing hardware Guidelines Precautions...
Page 48 Handling static-sensitive devices Attention: Notes:...
Page 49 Note: System reliability guidelines Working inside the server with the power on Attention: Removing the server cover Attention:...
Page 50: Removing And Reinstalling The Front Bezel
CAUTION: Turn off the server and wait three to five minutes to let the server cool before removing the server cover. Figure 7. Removing the server cover Removing and reinstalling the front bezel Attention:...
Page 51 Figure 8. Removing the front bezel...
Page 52 Figure 9. Reinstalling the front bezel What to do next: Installing, removing, or replacing hardware Notes: Attention:...
Page 53: Installing Or Removing The Ethernet Card
Installing or removing the Ethernet card Attention: ThinkServer EasyStartup Note: My Computer Properties Hardware Device Manager Network adapters Update Driver... Install the software automatically (Recommended) Next What to do next: Installing or removing a memory module Note: Memory module installation rules...
Page 54 Figure 10. Memory slots on the system board Note: Table 1. Memory module installation rules DIMM DIMM1 DIMM2 DIMM3 DIMM4...
Page 55 Installing a memory module Attention: Notes: Figure 11. Opening the retaining clips of the memory slots Note:...
Page 56 Note: Figure 12. Installing a memory module What to do next: Removing a memory module Attention: Note:...
Page 57 Figure 13. Removing a memory module What to do next: Installing the 2.5-inch solid-state drive or hard disk drive Attention: Note:...
Page 58 Figure 14. Installing the 2.5-inch drive into the drive adapter Figure 15. Installing the 2.5-inch drive with the drive adapter into the hard-disk-drive bracket...
Page 59: Replacing The Primary Hard Disk Drive
What to do next: Replacing the primary hard disk drive Attention: Note: Figure 16. Removing the primary hard disk drive...
Page 60 Figure 17. Installing the hard disk drive into the bracket Figure 18. Installing the primary hard disk drive...
Page 61: Installing Or Replacing The Secondary Hard Disk Drive
Figure 19. Connecting a SATA hard disk drive What to do next: Installing or replacing the secondary hard disk drive Attention: Note:...
Page 62 Figure 20. Removing the secondary hard disk drive Figure 21. Installing the hard disk drive into the bracket...
Page 63: Installing Or Removing The Tertiary Hard Disk Drive
Figure 22. Installing the secondary hard disk drive Figure 23. Connecting a SATA hard disk drive Installing or removing the tertiary hard disk drive Note: Installing the tertiary hard disk drive Attention:...
Page 64 Note: Figure 24. Installing the hard disk drive into the drive conversion bracket Figure 25. Installing the retainer on the side of the bracket...
Page 65 Figure 26. Installing the drive conversion bracket into the secondary optical drive bay Figure 27. Connecting cables to the hard disk drive...
Page 66 Figure 28. Connecting the cable of the fan for the tertiary hard disk drive What to do next: Removing the tertiary hard disk drive Attention:...
Page 67 Figure 29. Removing the drive conversion bracket Figure 30. Removing the hard disk drive out of the drive conversion bracket...
Page 68 What to do next: Installing or removing the slim optical drive and the fourth hard disk drive Note: Installing the slim optical drive and the fourth hard disk drive Attention: Figure 31. Installing the slim optical drive conversion board...
Page 69 Figure 32. Installing the slim optical drive retainer Figure 33. Installing the slim optical drive into the cage Figure 34. Securing the slim optical drive in the cage...
Page 70 Figure 35. Sliding the hard disk drive into the cage Figure 36. Installing the screws to secure the hard disk drive in the cage Figure 37. Installing the cage retainer...
Page 71 Figure 38. Sliding the cage into the optical drive bay Note: Figure 39. Connecting the cable of the fan for the fourth hard disk drive...
Page 72 What to do next: Removing the slim optical drive and the fourth hard disk drive Attention: Note: Figure 40. Removing the cage with the slim optical drive and the fourth hard disk drive...
Page 73 Figure 41. Removing the slim optical drive from the cage Figure 42. Removing the slim optical drive retainer...
Page 74: Installing Or Replacing A Pci Card
Figure 43. Removing the hard disk drive from the cage What to do next: Installing or replacing a PCI card Attention:...
Page 75 Figure 44. Opening the PCI card latch...
Page 76 Notes: Figure 45. Opening the PCI card retaining clip Figure 46. Removing a PCI card Note:...
Page 77 Figure 47. Installing a PCI card Note: Figure 48. Closing the PCI card retaining clip What to do next:...
Page 78: Installing Or Replacing The Optical Drive
Installing or replacing the optical drive Attention: Figure 49. Removing the optical drive...
Page 79 Figure 50. Installing the optical drive Figure 51. Connecting a SATA optical drive What to do next: Installing or replacing an internal RDX drive Attention:...
Page 80 Notes: Figure 52. Removing the RDX drive...
Page 81 Figure 53. Installing the RDX drive Figure 54. Connecting the RDX drive What to do next:...
Page 82: Replacing The Power Supply Assembly
Connecting an external tape drive Attention: Notes: Figure 55. Connecting the external tape drive Replacing the power supply assembly Attention:...
Page 83 DANGER Hazardous moving parts. Keep fingers and other body parts away. CAUTION: Never remove the cover on a power supply or any part that has the following label attached. Hazardous voltage, current, and energy levels are present inside any component that has this label attached.
Page 84 Figure 56. Removing the screws that secure the power supply assembly Figure 57. Removing the power supply assembly Note:...
Page 85: Replacing The Heat Sink And Fan Assembly
What to do next: Replacing the heat sink and fan assembly Attention: CAUTION: Turn off the server and wait three to five minutes to let the server cool before removing the server cover.
Page 86 Note: Figure 58. Removing the heat sink and fan assembly Notes: Note: What to do next:...
Page 87: Replacing The Front Audio And Usb Assembly
Replacing the front audio and USB assembly Attention: Figure 59. Removing the front audio and USB assembly What to do next:...
Page 88: Replacing The Front Fan Assembly
Replacing the front fan assembly Attention: Note: Figure 60. Removing the front fan assembly...
Page 89: Replacing The Rear Fan Assembly
Figure 61. Installing the front fan assembly What to do next: Replacing the rear fan assembly Attention:...
Page 90 Note: Figure 62. Removing the rear fan assembly...
Page 91: Replacing The Microprocessor
Figure 63. Installing the rear fan assembly What to do next: Replacing the microprocessor Attention: CAUTION: The heat sink and microprocessor might be very hot. Turn off the computer and wait three to five minutes to let the computer cool before removing the computer cover.
Page 92 Note: Figure 64. Accessing the microprocessor Figure 65. Removing the microprocessor...
Page 93 Notes: Figure 66. Installing the microprocessor...
Page 94: Replacing The System Board Battery
What to do next: Replacing the system board battery Attention: DANGER Danger of explosion if battery is incorrectly replaced. When replacing the lithium coin cell battery, use only the same or an equivalent type that is recommended by the manufacturer. The battery contains lithium and can explode if not properly used, handled, or disposed of.
Page 95: Completing The Parts Replacement
Figure 67. Removing the old system board battery Figure 68. Installing the new system board battery Note: What to do next: Completing the parts replacement...
Page 96: Connecting The Cables
Figure 69. Reinstalling the server cover Note: Connecting the cables Attention:...
Page 97 Connecting external devices Note: Safety, Warranty, and Support Information Updating the server configuration Installing security features Note: Integrated cable lock Kensington Padlock Password protection...
Page 99: Diagnostics
Chapter 7. Troubleshooting and diagnostics Troubleshooting procedure Basic troubleshooting tables ThinkServer EasyStartup program problems Note:...
Page 100: Optical Drive Problems
Symptom Action ThinkServer EasyStartup ThinkServer EasyStartup Optical drive problems Notes: Symptom Action...
Page 101: Hard Disk Drive Problems
Symptom Action Hard disk drive problems Note: Action Symptom...
Page 102 Symptom Action Memory module problems Notes: Action Symptom Keyboard, mouse, or USB device problems...
Page 103 Symptom Action...
Page 105: Chapter 8. Getting Information, Help And Service
Chapter 8. Getting information, help, and service Information resources Using the documentation ThinkServer Web site Lenovo Support Web site...
Page 106: Help And Service
Help and service Before you call Calling for service Problem determination Hardware repair Engineering Change management...
Page 107 Using other services Warranty Purchasing additional services...
Page 109: Appendix A. Notices
Appendix A. Notices Lenovo (United States), Inc. 1009 Think Place - Building One Morrisville, NC 27560 U.S.A. Attention: Lenovo Director of Licensing...
Page 110 Trademarks Important notes Recycling information...
Page 111: Battery Return Program
Battery return program Battery recycling information for the United States and Canada Battery recycling information for the European Union Notice: Disposing of lithium batteries and battery packs from Lenovo products...
Page 112: Particulate Contamination
Disposing of battery packs from Lenovo products Requirements for Batteries Containing Perchlorate Battery recycling information for Taiwan Recycling information for Brazil Declarações de Reciclagem no Brasil Descarte de um Produto Lenovo Fora de Uso Particulate contamination Attention:...
Page 113: Important Weee Information
Table 2. Limits for particulates and gases Contaminant Limits Method of Testing General Ventilation Air-Cleaning Devices for Removal Efficiency by Particle Size Environmental conditions for process measurement and control systems: Airborne contaminants Important WEEE information...
Page 114 WEEE information for Hungary Restriction of Hazardous Substances Directive (RoHS) China RoHS...
Page 115 Turkish RoHS India RoHS European Union RoHS Ukraine RoHS...
Page 116 Taiwan BSMI RoHS declaration German Ordinance for Work gloss statement...
Page 117: Export Classification Notice
Export classification notice Electronic emission notices Federal Communications Commission (FCC) Statement Industry Canada Compliance Statement United Kingdom telecommunications safety requirement European Union - Compliance to the Electromagnetic Compatibility Directive...
Page 118 Warning: German Class A compliance statement Deutschsprachiger EU Hinweis: Hinweis für Geräte der Klasse A EU Richtlinie zur Elektromagnetischen Verträglichkeit Deutschland: Einhaltung des Gesetzes über die elektromagnetische Verträglichkeit von Betriebsmittein Zulassungsbescheinigung laut dem Deutschen Gesetz über die elektromagnetische Verträglichkeit von Betriebsmitteln, EMVG vom 20. Juli 2007 (früher Gesetz über die elektromagnetische Verträglichkeit von Geräten), bzw.
Page 119 Korea Class A compliance statement Russia Electromagnetic Interference (EMI) Class A statement Taiwan Class A compliance statement Lenovo product service information for Taiwan Eurasian compliance mark Japan VCCI Class A compliance statement Japanese statement for ac power consumption for JEITA harmonics...
Page 120 Japanese statement of compliance for products less than or equal to 20 A per phase for JEITA harmonics guideline...
Page 121: Index
Index...
