Page 62: Safety Precautions
www.freeservicemanuals.info It`s free All over the world 1. Safety precautions General guidelines An isolation transformer should always be used during the servicing of a receiver whose chassis is not isolated from AC power line. Use a transformer of adequate power rating as this protects the technician from accidents resulting in personal injuryfrom electrical shocks.
Page 63: About Lead Free Solder (Pbf)
www.freeservicemanuals.info It`s free All over the world Hot check circuit Insulation test Connect an insulation tester between an exposed metallic part and A.C. line. Apply 1080VAC/60Hz for 1 second. Confirm that the current measurement is 0.5mA ~ 2.0mA. Repeat test with other metallic exposed parts.
Page 64 www.freeservicemanuals.info It`s free All over the world CAUTION - Pb free solder has a higher melting point than standard solder. Typically the melting point is 50 ~ 70 °F (30 ~ 40 °C) higher. Please use a high temperature soldering iron and set it to 700 ± 20 °F (370 ± 10 °C). - Pb free solder will tend to splash when heated too high (about 1100 °F or 600 °C).
Page 65: Important Safety Tests
www.freeservicemanuals.info It`s free All over the world 3. Important safety tests Measuring H.V. The anode caps are cemented to the CRTs. To gain access for high voltage measurement, remove the red CRT’s anode lead from the flyback transformer distributor. Grasp the anode lead protective cap at its bottom and squeeze it against thelocking cap body inside, rotate 1/4 turn counter clockwise and pull the anode lead sleeve out of the FBT distributor.
Page 66: Service Notes
www.freeservicemanuals.info It`s free All over the world high voltage distributor on FBT. DVM and power supply connection 5. Connect the 15 ~ 25 V DC variable power supply positive lead to D34 or IC802 pin 2 (D Board) and negative lead to heat sink of Q551 or D825 Procedures: 1.
Page 67 www.freeservicemanuals.info It`s free All over the world holes in the board to mount standard transistors or diodes. Some chips capacitor or resistor board solder pads may have holes through the board,however the hole diameter limits standard resistor replacement to 1/8 watt. Standard capacitor may also be limited for the same reason. It is recommended that identical components be used.
Page 68 www.freeservicemanuals.info It`s free All over the world 1. Remove the solder from all of the pins of a Flat IC by using a desolder braid 2. Put the iron wire under the pins of the Flat IC and pull it in the direction indicated while heating the pins using a soldering iron.
Page 69 www.freeservicemanuals.info It`s free All over the world 6. Check with a magnifier for solder bridge between the pins or for dry joint between pins and soldering pads. To remove a solder bridge, use a de solder braid as shown in the figure below IMPORTANT To protect against possible damage to the solid state devices due to arcing or static discharge, make certain that all ground wires are...
Page 70: Ptv Location Of Controls
www.freeservicemanuals.info It`s free All over the world 5. PTV Location of controls...
Page 71: Receiver Feature Table
It`s free All over the world 6. Receiver feature table FEATURE/MODEL PT-53WX53G / PT-53WX53G/PT-47WX53G / PT- 47WX53G CHASSIS AP825 MICRO 256K MENU LANGUAGE ENG/SPAN/FR CLOSE CAPTION V-CHIP (USA/CANADA CHANNEL INFO BANNER VIDEO INPUT SKIP SKIP CHANNEL COUNT PIP (1T), 2T PIP (2T), 2T SPLIT...
Page 72 It`s free All over the world FEATURE/MODEL PT-53WX53G / PT-53WX53G/PT-47WX53G / PT- 47WX53G BASS/BALANCE/TREBLE CONTROL AI SOUND SURROUND SPATIALIZER/BBE A/V IN (REAR/FRONT) 4(3/1) A/V PROGRAM OUT AUDIO OUT (FAO: F, VAO:V) F, V COMPONENT INPUT (Y, Pb, Pr) S-VHS INPUT (REAR/FRONT)
Page 73 www.freeservicemanuals.info It`s free All over the world FEATURE/MODEL PT-47WX33G PT-47WXC43G BASS/BALANCE/TREBLE CONTROL AI SOUND SURROUND SPATIALIZER/BBE A/V IN (REAR/FRONT) 4(3/1) 4(3/1) A/V PROGRAM OUT AUDIO OUT (FAO: F, VAO:V) F, V F, V COMPONENT INPUT (Y, Pb, Pr) S-VHS INPUT (REAR/FRONT) HDMI/HDCP INPUT DVI/HDCP DVI/HDCP...
Page 74 www.freeservicemanuals.info It`s free All over the world FEATURE/MODEL PT-4743G CHASSIS AP825 MICRO 256K MENU LANGUAGE ENG/SPAN/FR CLOSE CAPTION V-CHIP (USA/CANADA CHANNEL INFO BANNER VIDEO INPUT SKIP SKIP CHANNEL COUNT PIP (1T), 2T PIP (2T), 2T SPLIT 2T SPLIT REMOTE CONTROL (W/LIGHT) EUR7603Z90 CRT SUPPLIER MDDA (CENTAUR)
Page 75: Board Description Table
www.freeservicemanuals.info It`s free All over the world 7. Board description table BOARD PART NUMBER DESCRIPTION A-BOARD TNP2AH045 MAIN CHASSIS D-BOARD TNP2AH046 POWER SUPPLY * DC-BOARD TNPAA120 CONVERGENCE CIRCUIT * DV-BOARD TNP2AA114 DVI BOARD * DG-BOARD TNP2AA126 PIP PROCESSING, SPLIT, SEARCH, FORMATS LB-BOARD TNP2AA147 BLUE PRT...
Page 76 www.freeservicemanuals.info It`s free All over the world Note: For additional information for this remote please refer to the owner’s manual section remote operation, listed on the parts list section. 9. Location of controls (EUR7613Z40 remote)
Page 77: Auto Diagnosis Feature
www.freeservicemanuals.info It`s free All over the world Note: For additional information for this remote please refer to the owner’s manual section remote operation, listed on the parts list section. 10. Auto diagnosis feature This receiver incorporates a new self diagnosis feature. With this new feature will be easier for the technician to detect the failures.
Page 78 This PTV has a feature that allows to clone convergence and main EEPROM data adjustments from a PTV to other by connecting a jig to the PTV set. A jig part number TXFJIG01SER, is available through Matsushita/Panasonic Services. Preparation: To connect this jig, remove the lower back cover as instructed on disassembly for service section on this service manual and insert the jig into A10 connector located on the A-Board.
Page 79 www.freeservicemanuals.info It`s free All over the world - EXT to copy from jig to internal EEPROM. 5. Then select from and press ACTION on remote: - 480i_p format - 1080i format - Z480i format (480i ZOOM mode) - NOT USE to back up data - ALL to copy all convergence data from internal EEPROM - D480i (default factory preset) - D1080i (default factory preset)
Page 80: Chassis& Boards Layout (Location Of Main Components)
www.freeservicemanuals.info It`s free All over the world NOTE: All the measurements are in DC with a digital multimeter, color bar pattern, picture settings normalized and sound set to minimum. 13. Chassis& boards layout (location of main components) Chassis and boards layout...
Page 81 www.freeservicemanuals.info It`s free All over the world A-BOARD...
Page 82 www.freeservicemanuals.info It`s free All over the world D-BOARD...
Page 83 www.freeservicemanuals.info It`s free All over the world R-BOARD VIEW DC-BOARD TOP VIEW www.manualscenter.com...
Page 84 www.freeservicemanuals.info It`s free All over the world DC-BOARD BOTTOM VIEW DV-BOARD...
Page 85 www.freeservicemanuals.info It`s free All over the world DG-BOARD TOP VIEW DG-BOARD BOTTOM VIEW...
Page 86: Disassembly For Service
www.freeservicemanuals.info It`s free All over the world 14. Disassembly for service NOTE: Board ground wires may have to be disconnected to disassemble some boards. All ground wires must be reconnected using jumper leads, if necessary, before power is applied to PTV for service. Speaker grille removal Some models come with three pieces (sides for speakers and center cover);...
Page 87 www.freeservicemanuals.info It`s free All over the world Keyboard and front A/V inputs removal 1. Remove the speaker grille. 2. Unplug the connectors from the keyboard and front A/V inputs assemblies. Remove the screws from the control panel and tilt the front panel assembly upward and release it from the front cabinet.
Page 88 www.freeservicemanuals.info It`s free All over the world Back cabinet removal 1. Remove the back lower cover. (Detailed previously). 2. The top back cover (plastic shell) is secured with (14) screws around its perimeter. See figure for screws location. 3. Be careful not to damage the mirror secured to the underside of the back cover.
Page 89 www.freeservicemanuals.info It`s free All over the world Screen frame removal 1. Remove the speaker grille. Disconnect the cables leading to the keyboard and the AV panels and remove the keyboard and AV panel assembly. The assembly is secured by three (3) screws. 2.
Page 90 www.freeservicemanuals.info It`s free All over the world 4. Remove the horizontal barrier panel at the back of the cabinet. 5. Unplug connectors (K1, G1 and speaker connectors) and pull out the main chassis block. Note: Main chassis block can be serviced either in normal position or laying on its back (protect hookup terminal from damage).
Page 91: Chassis Assembly
www.freeservicemanuals.info It`s free All over the world 14.1. Chassis assembly The chassis assembly shown in figure includes all the electrical and optical (light box) components Chassis front view A-Board 1. A-Board is secured to the chassis tray with five screws. 2.
Page 92 www.freeservicemanuals.info It`s free All over the world D-Board 1. D-Board is secured to the chassis tray with five screws. 2. The D-Board is mated to the A-Board by four connectors (female side of connectors): D1, D2, D3 & D4. To remove this board, unplug the connectors on the A-Board pulling from the sides of each connector.
Page 93 www.freeservicemanuals.info It`s free All over the world NOTE: This board is non-serviceable. Except for JK002 (DVI AUDIO CONNECTOR) and JK002 (DVI CONNECTOR) / When removing this board pull carefully. DC-Board 1. Plugs onto the D-Board at the D21, D22 and D23 (DC1, DC2 and DC3 respectively) connectors.
Page 94 www.freeservicemanuals.info It`s free All over the world To facilitate CRT replacement, the complete CRT mounting chassis does not need to be removed. 1. Remove the main chassis block from the cabinet. 2. Remove the optical bracket metal cover (rear side) by removing (6) screws from back, (2) screws from top, and (2) screws from each side.
Page 95 www.freeservicemanuals.info It`s free All over the world Focus pack location 8. Release CRT anode lead from CRT chassis wire clamp and all other wires from holders. 9. Loosen a screw that secures the DY and remove it from the CRT neck. Caution: To insure protection against x ray radiation, the lens must be mounted in place at all times when power is applied to the PTV...
Page 96 www.freeservicemanuals.info It`s free All over the world 2. Lay CRT face down on a soft cloth. 3. Note position of yoke with centering tabs and remove from defective CRT. 4. Remove CRT DAG ground from defective CRT. Mount it on the replacement CRT exactly as it was on the defective CRT.
Page 97: Ptv Screen Assemblies
www.freeservicemanuals.info It`s free All over the world The optical block mounting has holes to allow for the different size projection screens. These mounts will adjust to projection screens. If the optical block is removed for service or is replaced, it is important that the correct mounting holesare used.
Page 98: B+ Voltages Table
www.freeservicemanuals.info It`s free All over the world 15. B+ voltages table Preparation: Set the following controls - Picture to Normal - Bright to Normal - Volume to MIN (0) Procedure: 1. Apply a NTSC COLOR BAR pattern 2. Connect the negative lead of the digital voltmeter to TPGND1 (cold ground).
Page 99 www.freeservicemanuals.info It`s free All over the world 16. CRT Set Up CAUTION: Insure yoke plugs on the A Board are reconnected before turning the PTV ON to prevent damage to the horizontal output transistor and/or CRTs. 1. Connect test generator to the antenna terminal and set for a monoscope pattern.
Page 100 VOL (RIGHT/LEFT);press ACTION, to save press ACTION again or OTHER to exit without saving. Procedure: NOTE: 1080i, 480p, 480i pattern can be obtained from Panasonic’s TU-DST51 set top box DTV decoder. 1. Enter to service mode and set the following default DATA NTSC NTSC...
Page 101 (use for minor adjustment or for final adjustment, for complete adjustment see following section.) Electrical Adjustment NOTE: 1080i, 480p, 480i pattern can be obtained from Panasonic’s TU-DST51 set-top box DTV decoder. 1. Apply a NTSC crosshatch with dots pattern Lens focus adjustment...
Page 102 www.freeservicemanuals.info It`s free All over the world 6. Repeat steps for green only. 7. Set VIDEO “C_OFF” DAC from 00 to 03, and project only blue. 8. Repeat steps for blue only. 16.2.1. Focus - Optical lens adjustment Optical adjustments NOTE: This adjustment normally should not require resetting unless the lens has been replaced or adjustment has changed.
Page 103: Electronic Adjustments
This adjustment is intended to correct the horizontal position of the picture NOTE: 1080i, 480p, 480i pattern can be obtained from Panasonic’s TU-DST51 set-top box DTV decoder. 1. Apply a NTSC pattern that lets adjust the image to correct vertical size (see above note).
Page 104 All over the world 17.3. Centering magnets adjustment NOTE: 1080i, 480p, 480i pattern can be obtained from Panasonic’s TU-DST51 set-top box DTV decoder. Procedures: 1. Apply a NTSC crosshatch pattern with dots. 2. Set VIDEO “C_OFF” DAC from 00 to 01 to project only green.
Page 105 This adjustment is intended to make the picture vertically proportional (top, center and bottom) for NTSC mode NOTE: 1080i, 480p, 480i pattern can be obtained from Panasonic’s TU-DST51 set-top box DTV decoder. 1. Apply a NTSC pattern that lets adjust the image to correct vertical linearity (see above note).
Page 106 This adjustment is intended to correct the vertical size of the picture for HD 1080i mode. NOTE: 1080i, 480p, 480i pattern can be obtained from Panasonic’s TU-DST51 set top box DTV decoder. 1. Apply a HD 1080i pattern that lets adjust the image to correct vertical...
Page 107 This adjustment is intended to correct the vertical size of the picture for NTSC ZOOM mode NOTE: 1080i, 480p, 480i pattern can be obtained from Panasonic’s TU-DST51 set top box DTV decoder. 1. Apply a NTSC pattern that lets adjust the image to correct vertical size (see above note) 2.
Page 108 This adjustment is intended to correct the horizontal position of the picture for NTSC mode NOTE: 1080i, 480p, 480i pattern can be obtained from Panasonic’s TU-DST51 set-top box DTV decoder. 1. Apply a HD 1080i pattern that lets adjust the image to correct horizontal position of the image.
Page 109 It`s free All over the world 1080i, 480p, 480i pattern can be obtained from Panasonic’s TU-DST51 set-top box DTV decoder. Procedure: 1. Apply a NTSC pattern that lets adjust the image to correct curved sides (see above note) 2. Set VIDEO “C_OFF” DAC from 00 to 01 to project only green.
Page 110 This adjustment is intended to adjust horizontal size of the picture for NTSC mode. NOTE: 1080i, 480p, 480i pattern can be obtained from Panasonic’s TU-DST51 set-top box DTV decoder. 1. Apply a NTSC pattern that lets adjust the horizontal size.
Page 111 17.18. White balance adjustment NOTE: 1080i, 480p, 480I pattern can be obtained from Panasonic’s TU-DST51 set-top box DTV decoder. Prior to this adjustment, perform sub-contrast adjustment. This adjustment requires that the service use skills in observing what a screen without color should look like (white picture).
Page 112 17.19. NTSC Color adjustment (TINT, B-Y_G, R-Y_A) NOTE: 1080i, 480p, 480i pattern can be obtained from Panasonic’s TU-DST51 set-top box DTV decoder. This adjustment requires that the servicer use its skills in observing what a colorbar pattern should looks like.
Page 113 17.20. 1080i Color adjustment (TINT, B-Y_G, R-Y_A) NOTE: 1080i, 480p, 480i pattern can be obtained from Panasonic’s TU-DST51 set-top box DTV decoder. 1. Set same settings as NTSC adjustment 2. Apply a 1080i signal, and repeat adjustments as from step 2 in NTSC adjustment.
Page 114 www.freeservicemanuals.info It`s free All over the world sure that color is not set so that it appears dull and washed out. Look for natural colors, try to adjust the picture to appear as a normalphotograph. 17.22. MTS circuit adjustment Note: It is important to adjust the MTS circuit in the order shown below.
Page 115 www.freeservicemanuals.info It`s free All over the world Procedure: 1. Set PTV to Stereo Mode (in the audio menu). 2. Apply the following signal from the RF signal generator: / Video: 100 IRE flat field, 30% modulation. / Audio: 300Hz, 30% modulation, stereo (left only) (70dB ±...
Page 116: Convergence Adjustment
EEPROM copy jig can be used to back-up the data before to performadjustments. NOTE: 1080i, 480p, 480i pattern can be obtained from Panasonic’s TU-DST51 set-top box DTV decoder. IMPORTANT NOTICE: It is strongly recommended to first read and understand the following section prior to make any adjustment.
Page 117 www.freeservicemanuals.info It`s free All over the world Procedure: Apply the convergence alignment template to the PTV screen frame to converge the green raster only. Remove the convergence alignment template following this alignment. The red and blue rasters can then be aligned to the green raster. Raster Set-Up: 1.
Page 118 www.freeservicemanuals.info It`s free All over the world 12. Press “TV/VIDEO” key on remote to enter “OSD_POS” mode. 13. Press “5” key on remote so that monoscope pattern appears (superimpose mode) 14. Move cursor by pressing VOL right - left and CH up - down so that cursor center overlap monoscope pattern center 15.
Page 119 When “7” is pressed and the data is saved, it will overwrite the factory default. 18.1. Coarse adjustment mode (COARSE) NOTE: 1080i, 480p, 480i pattern can be obtained from Panasonic’s TU-DST51 set-top box DTV decoder. NOTE: It is strongly recommended to first read and understand the following section prior to make any adjustment.
Page 120 www.freeservicemanuals.info It`s free All over the world 2. Press “2” repeatedly and apply the pattern of border and cross. 3. Press RECALL to display values 4. Adjust size so that the line of the border closes to the screen frame at top, bottom, left and right, by pressing CH up-down and VOL right-left “SIZE”...
Page 121 www.freeservicemanuals.info It`s free All over the world “PIN” mode adjustment 13. Press “7” then “ACTION” key on remote to save changes 14. Adjust by pressing VOL right-left (see figure) 15. Press “7” then “ACTION” key on remote to save changes “CORNER”...
Page 122 www.freeservicemanuals.info It`s free All over the world horizontal line center match with the marks on screen frame, if linearity is not good enough, repeat adjustments. 19. Enter to “STATIC” mode by pressing TV/VIDEO. 20. Press “1” or “3” repeatedly until green and red only are shown. 21.
Page 123 www.freeservicemanuals.info It`s free All over the world 27. Enter to SIZE “R-SIZE” mode by pressing TV/VIDEO 28. Adjust so that the line on the border closes to the screen frame at top, bottom, left and right (see figure) 29. Enter to PIN “R-PIN” mode by pressing TV/VIDEO 30.
Page 124 www.freeservicemanuals.info It`s free All over the world 18.2. Fine adjustment mode (FINE) (convergence) NOTE: It is strongly recommended to first read and understand the following section prior to make any adjustment. / Convergence adjustment must be perform for 480i-p (same for interlace & progressive), ZOOM 480i and 1080i.
Page 125 www.freeservicemanuals.info It`s free All over the world PRESS BUTTON 1(go) or change color view 3(back) change pattern 4 (only FINE change crossed sections mode) overlap save data copy from clear POWER exit RECALL display values R-TUNE cycle colors TV/VIDEO change mode TV/VIDEO (3 switch convergence mode (FINE/ secs)
Page 126 www.freeservicemanuals.info It`s free All over the world right - left and CH up - down. PROCEDURE: 1. To Enter to “G-EASY” mode (for green): - Select “EASY” DAC - Press POWER on remote - Press TV/VIDEO (repeatedly) to select mode. - Press R-TUNE (repeatedly) to select color 2.
Page 127 www.freeservicemanuals.info It`s free All over the world 11. To move the cursor press MUTE on the remote (cursor flashes), then move the cursor to any of the positions for “EASY” mode 12. This adjustment may help to make rounded lines become straight lines.
Page 128 www.freeservicemanuals.info It`s free All over the world 20. When slightly adjustment is needed, use “ORIG. POINT” mode. 21. To enter to “G-ORIG. POINT” (for green) mode press TV/VIDEO. 22. With “ORIG. POINT”, the adjustment data changes by 1 step, this allows more detail in the adjustment.
Page 129 www.freeservicemanuals.info It`s free All over the world 29. Perform adjustments for red so that red overlaps green, do not move green. 30. Press “1 or 3” on the remote until yellow (red and green) and blue appears, do not move green or red. 31.
Page 130 www.freeservicemanuals.info It`s free All over the world 2. Confirm that horizontal and vertical center of the picture is located in the center of the screen. 3. Check that the image is proportional horizontally and vertically, proportion is different on every aspect. 18.4.
Page 131: Service Mode (Electronic Controls)
It`s free All over the world TXFQD04ESER1 for 56” is available through Matsushita/Panasonic Services 19. Service Mode (electronic controls) This receiver has electronic technology using the IC bus concept. It performs as a control function and it replaces many mechanical controls. Instead of adjusting mechanical controls individually, many of the control functions are now performedby using “on screen display menu”.
Page 132 For some adjustments is required to perform adjustment for each format; convergence adjustment must be performed for 480i-p (same for interlace & progressive),ZOOM 480i and 1080i. A 1080i, 480p, 480i pattern can be obtained from Panasonic’s TU-DST51 set-top box DTV decoder. 19.2. Exiting the service mode: This PTV goes out from service mode when it is unplugged or turned OFF.
Page 133 www.freeservicemanuals.info It`s free All over the world 19.3. Service adjustment default values for items REGISTER DESCRIPTION FORMAT NTSC 480i ZOOM 1080i COLOR COLOR B_Y-G MAGENTA TINT ADJ TINT TINT R_Y-A YELLOW TINT ADJ BRIGH SUB-BRIGHTNESS 01 F6 CONT SUB-CONTRAST CUT-R RED CUT-OFF 02 00 CUT-B...
Page 134 www.freeservicemanuals.info It`s free All over the world Important notice: Since Widescreen 16:9 and non-widescreen 4:3 PTVs use the same light box, for this reason is important to set it to the correct version (16:9 or 4: 3). To check this plese see “Instructional flow chart for format aspect switching”...
Page 135 www.freeservicemanuals.info It`s free All over the world 19.5. Instructional flow for service mode...
Page 136 www.freeservicemanuals.info It`s free All over the world...
Page 137: Conductor Views
www.freeservicemanuals.info It`s free All over the world 20. Reference of PDF links color 21. Conductor views...
Page 138: Block Diagrams
www.freeservicemanuals.info It`s free All over the world 21.1. A-Board 1 of 2 21.2. A-Board 2 of 2 21.3. D-Board 1 of 2 21.4. D-Board 2 of 2 21.5. DG-Board top view 1 of 4 21.6. DG-Board top view 2 of 4 21.7.
Page 139: Schematic Diagrams
www.freeservicemanuals.info It`s free All over the world 22.2. Video block diagram 23. Schematic diagrams 23.1. Schematic diagrams notes...
Page 140 www.freeservicemanuals.info It`s free All over the world...
Page 141 www.freeservicemanuals.info It`s free All over the world 23.2. Notas de los diagramas esquematicos...
Page 142 www.freeservicemanuals.info It`s free All over the world www.manualscenter.com...
Page 143 www.freeservicemanuals.info It`s free All over the world 23.3. A-Board schematic 1 of 4 23.4. A-Board schematic 2 of 4 23.5. A-Board schematic 3 of 4 23.6. A-Board schematic 4 of 4 23.7. D-Board schematic 1 of 5 23.8. D-Board schematic 2 of 5 23.9.
Page 144: Parts Location
www.freeservicemanuals.info It`s free All over the world 23.27. Voltages 23.28. Waveforms 24. Parts location 25. Parts list 25.1. Description of abbreviations guide...
Page 145 www.freeservicemanuals.info It`s free All over the world 25.2. Parts list Ref. No. Part No. Part Name & Description Remarks CAPACITORS C002 TCJ2VC1H220J CAP C 22PF-J-50V C003 TCJ2VC1H220J CAP C 22PF-J-50V C004 F2A1H4R7A162 CAP E 4.7UF-50V C005 F2A1H2R2A162 CAP E 2.2UF-50V C006 ECA0JM332E CAP E 3300UF-6.3V...
Page 146 www.freeservicemanuals.info It`s free All over the world Ref. No. Part No. Part Name & Description Remarks C306 F2A2E100A025 CAP E 10UF-250V C307 ECKR1H103ZF5 CAP C .01UF-Z-50V C312 ECKC3D102KBN CAP C 1000PF-K-2KV C313 ECKR2H102KB5 CAP C 1000PF-K-500V C331 F2A1H470A162 CAP E 47UF-50V C332 ECKR1H103ZF5 CAP C .01UF-Z-50V...
Page 147 www.freeservicemanuals.info It`s free All over the world...
Page 148 www.freeservicemanuals.info It`s free All over the world Ref. No. Part No. Part Name & Description Remarks C526 F2A2E101A026 CAP E 100UF-250V C527 ECKR2H102KB5 CAP C 1000PF-K-500V C528 F2A1H470A162 CAP E 47UF-50V C531 ECA160V33UE CAP E 33UF/160V C533 ECKR2H101KB5 CAP C 100UF-K-500V C535 ECA1EM471E CAP E 470UF-25V...
Page 149 www.freeservicemanuals.info It`s free All over the world Ref. No. Part No. Part Name & Description Remarks C852 ECA1EM101B CAP E 100UF-25V C854 F2A1C101A159 CAP E 100UF-16V C855 ECJ2VF1H104Z CAP C .1UF-Z-50V C876 ECJ3VF1H224Z CAP C .22UF-Z-50V C877 ECA0JM221B CAP E 220UF-6.3V C878 EEUFC1V561B CAP E 560UF-35V...
Page 150 www.freeservicemanuals.info It`s free All over the world...
Page 151 www.freeservicemanuals.info It`s free All over the world Ref. No. Part No. Part Name & Description Remarks C1103 TCJ2VB1C104K CAP C .1UF-K-16V C1105 ECJ2VF1C105Z CAP C 1.0UF-Z-16V C1112 TCJ2VF1H103Z CAP C .01UF-Z-50V C1113 ECEA1CKA101B CAP E 100UF-16V C1502 ECQE6104KFB CAP P 100UF-K-100V C1503 ECQE6104KFB CAP P 100UF-K-100V...
Page 152 www.freeservicemanuals.info It`s free All over the world...
Page 153 www.freeservicemanuals.info It`s free All over the world Ref. No. Part No. Part Name & Description Remarks C2361 TCJ2VB1H471K CAP C 470PF-K-50V C2362 TCJ2VB1H471K CAP C 470PF-K-50V C2363 TCJ2VB1H682K CAP C 6800PF-K-50V C2364 ECJ3VB1H104K CAP C .1UF-K-50V C2365 ECJ3VB1H104K CAP C .1UF-K-50V C2367 ECQB1H224JF3 CAP P .22UF-J-50V...
Page 154 www.freeservicemanuals.info It`s free All over the world...
Page 155 www.freeservicemanuals.info It`s free All over the world Ref. No. Part No. Part Name & Description Remarks C3034 ECJ2VF1C105Z CAP C 1.0UF-Z-16V C3035 F2A1C101A159 CAP E 100UF-16V C3036 F2A1C101A159 CAP E 100UF-16V C3037 ECJ2VF1C105Z CAP C 1.0UF-Z-16V C3038 ECJ2VF1C105Z CAP C 1.0UF-Z-16V C3039 ECJ2VF1C105Z CAP C 1.0UF-Z-16V...
Page 156 www.freeservicemanuals.info It`s free All over the world...
Page 157 www.freeservicemanuals.info It`s free All over the world Ref. No. Part No. Part Name & Description Remarks C3106 TCJ2VB1H102K CAP C 1000PF-K-50V C3109 TCJ2VB1H102K CAP C 1000PF-K-50V C3110 TCJ2VB1H102K CAP C 1000PF-K-50V C3111 TCJ2VB1H102K CAP C 1000PF-K-50V C3112 ECJ2VF1H104Z CAP C .1UF-Z-50V C3113 ECJ2VF1H104Z CAP C .1UF-Z-50V...
Page 158 www.freeservicemanuals.info It`s free All over the world...
Page 159 www.freeservicemanuals.info It`s free All over the world Ref. No. Part No. Part Name & Description Remarks D407 MA3X152K0L DIODE D409 MA3X152K0L DIODE D410 MA3X152K0L DIODE D411 MA3X152K0L DIODE D451 B0EAKC000003 DIODE RECTIFIER D452 B0EAKC000003 DIODE RECTIFIER D453 B0EAKC000003 DIODE RECTIFIER D454 B0EAKC000003 DIODE RECTIFIER...
Page 160 www.freeservicemanuals.info It`s free All over the world Ref. No. Part No. Part Name & Description Remarks D885 MA2062-BTP DIODE D886 MA2120-ATP DIODE D887 MA2062-BTP DIODE D895 MA2C165001VT DIODE D902 MA2C18800E DIODE D933 MA2C18800E DIODE D953 B0ZAZ0000047 DIODE D962 MA2C18800E DIODE D973 B0ZAZ0000047 DIODE...
Page 161 www.freeservicemanuals.info It`s free All over the world Ref. No. Part No. Part Name & Description Remarks F801 K5D632AD0002 FUSE 6.3A/125V INTEGRATED CIRCUITS IC451 C1AA00000521 VERTICAL OUT IC701 AN6914S-E1 INT CKT IC801 AN8029 INT CKT IC802 C0EAS0000025 INT. CKT. IC804 B0EBKM000016 DIODE RECTIFIER IC805 AN78M12LB...
Page 162 www.freeservicemanuals.info It`s free All over the world Ref. No. Part No. Part Name & Description Remarks L510 EXCELDR25V FERRITE BEAD L511 EXCELDR25V FERRITE BEAD L515 EXCELDR25V FERRITE BEAD L516 EXCELDR25V FERRITE BEAD L555 ELH5L718 COIL L701 ELESN100KA COIL PEAKING 10UH L702 EXCELSA35T FERRITE BEAD...
Page 163 www.freeservicemanuals.info It`s free All over the world Ref. No. Part No. Part Name & Description Remarks L2502 ELESN100JA COIL PEAKING 10UH L3003 ELESN102JA COIL PEAKING 1000UH L3006 ELESN102JA COIL PEAKING 1000UH L3008 ELESN560JA COIL PEAKING 56UH L3009 ELESN100JA COIL PEAKING 10UH L3010 ELESN560JA COIL PEAKING 56UH...
Page 164 www.freeservicemanuals.info It`s free All over the world...
Page 165 www.freeservicemanuals.info It`s free All over the world Ref. No. Part No. Part Name & Description Remarks Q907 2SA720TA TRANSISTOR Q931 2SD601ARTX TRANSISTOR Q932 2SD601ARTX TRANSISTOR Q933 2SD601ARTX TRANSISTOR Q934 2SA720TA TRANSISTOR Q935 2SC1318ATA TRANSISTOR Q936 2SC1318ATA TRANSISTOR Q937 2SA720TA TRANSISTOR Q938 2SB1321ARA TRANSISTOR...
Page 166 www.freeservicemanuals.info It`s free All over the world...
Page 167 www.freeservicemanuals.info It`s free All over the world Ref. No. Part No. Part Name & Description Remarks Q3013 2SD601ARTX TRANSISTOR Q3014 2SD601ARTX TRANSISTOR Q3015 2SD601ARTX TRANSISTOR Q7006 2SD601ARTX TRANSISTOR Q7007 2SD601ARTX TRANSISTOR Q7060 2SB709ARTX TRANSISTOR Q7061 2SD601ARTX TRANSISTOR RELAYS RL801 K6B1ADA00010 RELAY RL802 K6B1ADA00010...
Page 168 www.freeservicemanuals.info It`s free All over the world Ref. No. Part No. Part Name & Description Remarks R345 ERDS2TJ470T RES C 47-J-1/4W R347 ERG7ZJ272 RES M 2.7K-J-7W R348 ERDS2TJ563T RES C 56K-J-1/4W R349 ERDS2TJ821T RES C 820-J-1/4W R350 ERG12SJ101P RES M 100-J-1W R351 ERDS1FJ330P RES C 33-J-1/2W...
Page 169 www.freeservicemanuals.info It`s free All over the world Ref. No. Part No. Part Name & Description Remarks R472 ERDS2TJ331T RES C 330-J-1/4W R501 ERJ6GEYJ104V RES M 100K-J-1/10W R502 ERJ6GEYJ680V RES M 68-J-1/10W R503 ERG2FJ180H RES M 18-J-2W R504 ERG3FJ271H RES M 270-J-3W R505 ERG1SJ120P RES M 12-J-1W...
Page 170 www.freeservicemanuals.info It`s free All over the world Ref. No. Part No. Part Name & Description Remarks R822 ERJ6GEYJ222V RES M 2.2K-J-1/10W R832 ERD75TAJ825 RES C 8.2MEG-J-3/4W R833 ERJ6GEYJ101V RES M 100-J-1/10W R835 ERDS2TJ101T RES C 100-J-1/4W R836 ERJ6GEYJ101V RES M 100-J-1/10W R839 ERJ6GEYJ222V RES M 2.2K-J-1/10W...
Page 171 www.freeservicemanuals.info It`s free All over the world Ref. No. Part No. Part Name & Description Remarks R946 ERQ14AJ100P RES F 10-J-1/4W R947 ERQ14AJ220P RES F 22-J-1/4W R948 ERDS2FJ122T RES C 1.2K-J-1/2W R949 ERDS2TJ103T RES C 10K-J-1/4W R950 ERDS2TJ683T RES C 68K-J-1/4W R951 ERDS2TJ683T RES C 68K-J-1/4W...
Page 172 www.freeservicemanuals.info It`s free All over the world...
Page 173 www.freeservicemanuals.info It`s free All over the world Ref. No. Part No. Part Name & Description Remarks R1516 ERJ6GEYJ101V RES M 100-J-1/10W R1517 ERJ6ENF3571V RES M 3.57K-F-1/10W R1518 ERG2SJD333L RES M 33K-J-2W R1519 ERDS2TJ101T RES C 100-J-1/4W R1520 ERDS2TJ221T RES C 220-J-1/4W R1521 ER0S2THF1500 RES M 150-F-1/4W...
Page 174 www.freeservicemanuals.info It`s free All over the world...
Page 175 R2367 ERJ12YJ101U RES M 100-J-1/2W R2368 ERJ6ENF5232V RES M 5.32K-F-1/10W R2371 ERJ6ENF1201V RES M 1.2K-F-1/10WW / PT-53WX53G, PT-47WX53G, / PT-47WXC43G, PT- 4743G, / PT-56WX53G R2372 ERJ6ENF1201V RES M 1.2K-F-1/10WW / PT-53WX53G, PT-47WX53G, / PT-47WXC43G, PT- 4743G, / PT-56WX53G R2451 ERJ6GEYJ681V...
Page 176 www.freeservicemanuals.info It`s free All over the world Ref. No. Part No. Part Name & Description Remarks R3007 ERJ6GEYJ102V RES M 1K-J-1/10W R3008 ERJ6GEYJ750V RES M 75-J-1/10W R3009 ERDS2TJ221T RES C 220-J-1/4W R3010 ERJ6GEYJ221V RES M 220-J-1/10W R3011 ERDS2TJ221T RES C 220-J-1/4W R3012 ERJ6GEYJ562V RES M 5.6K-J-1/10W...
Page 177 www.freeservicemanuals.info It`s free All over the world...
Page 178 www.freeservicemanuals.info It`s free All over the world Ref. No. Part No. Part Name & Description Remarks R3064 ERJ6GEYJ221V RES M 220-J-1/10W R3065 ERJ6GEYJ221V RES M 220-J-1/10W R3069 ERJ6GEYJ221V RES M 220-J-1/10W R3070 ERJ6GEYJ221V RES M 220-J-1/10W R3071 ERJ6GEYJ561V RES M 560-J-1/10W R3072 ERJ6GEYJ561V RES M 560-J-1/10W...
Page 179 www.freeservicemanuals.info It`s free All over the world...
Page 180 ASSY PRT (GREEN) / PT-47WX53G, PT-47WXC43G, / PT-4743G, PT- 47WX33G TXFCRT26GSER ASSY PRT (RED) / PT-47WX53G, PT-47WXC43G, / PT-4743G, PT- 47WX33G TXFCRT27GSER ASSY PRT(BLUE) / PT-53WX53G, PT-56WX53G TXFCRT28GSER ASSY PRT(GREEN) / PT-53WX53G, PT-56WX53G TXFCRT29GSER ASSY PRT(RED) / PT-53WX53G, PT-56WX53G M002...
Page 181 INNER BARRIER BOARD / PT-56WX53G TKD2AX2572S INNER BARRIER BOARD / PT-53WX53G, PT-47WX53G, / PT-47WXC43G, PT-4743G, / PT-47WX33G TKU2AA03201 LOWER BACK COVER / PT-53WX53G, PT-47WX53G, / PT-47WXC43G, PT -4743G, / PT-47WX33G TKU2AA03401 LOWER BACK COVER / PT-56WX53G EASJ6PH05A3 SPEAKER (TWEETER) / PT-53WX53G, PT-56WX53G...
Page 182 M007 TMM2AE10171 GROMMET SQUARE ACCESORIES M008 TQB2AA0470-1 OWNERS MANUAL M009 EUR7603Z90 REMOTE CONTROL / PT-53WX53G, PT-47WX53G, / PT-4743G, PT- 56WX53G M010 EUR7613Z40 REMOTE CONTROL / PT-47WXC43G, PT-47WX33G M011 UR76EC0303A BATTERY COVER REMOTE CONTROL / PT-47WX53G, PT-4743G, / PT- 56WX53G, PT-53WX53G...

This manual is also suitable for:

Pt-56wx53g Pt-47wx53g Pt-47wx33g Pt-47wxc43g Pt-4743g

Panasonic PT-53WX53G Service Manual

Quick Links

Related Manuals for Panasonic PT-53WX53G

Summary of Contents for Panasonic PT-53WX53G

This manual is also suitable for:

Table of Contents
