CD/DVD Player
Operating Instructions
DVP-S525D
© 1999 by Sony Corporation
3-867-038-41(1)
1
2
3
4
5
6
7
8
9
0

Advertisement

Table of Contents
loading

Related Manuals for Sony DVP-S525D

Summary of Contents for Sony DVP-S525D

  • Page 1 3-867-038-41(1) CD/DVD Player Operating Instructions DVP-S525D © 1999 by Sony Corporation Downloaded From DvDPlayer-Manual.com Sherwood Manuals...
  • Page 2 WARNING Welcome! To prevent fire or shock Precautions Thank you for purchasing the Sony CD/ DVD Player. Before operating the unit, hazard, do not expose the please read this manual thoroughly and Safety unit to rain or moisture. retain it for future reference.

  • Page 3: Table Of Contents

    ABLE OF CONTENTS About This Manual 4 Settings and Adjustments 41 This Player Can Play the Following Discs 4 Precautions 6 Using the Setup Display Notes on Discs 6 Setup Display Item List 43 Setting the Language for Display and Sound Getting Started 7 (LANGUAGE SETUP) Settings for Display (SCREEN SETUP)

  • Page 4: About This Manual

    DVP–8306 CD/DVD PLAYER AC 110V 60Hz Your DVD player has a region code printed on the back of the unit and will only play DVDs SONY CORPORATION MADE IN JAPAN 3-444-464-01 that are labeled with identical region codes. DVDs labeled will be also played on this unit.
  • Page 5 Terms for discs Discs that the player cannot play The player cannot play discs other than the ones listed in the • Title table on page 4. CD-R, CD-ROMs including PHOTO CDs, data The longest sections of a picture or a music piece on a DVD; a sections in CD-EXTRAs, DVD-ROMs etc., cannot be played.

  • Page 6: Precautions

    • Do not use solvents such as benzine, thinner, If you have any questions or problems concerning your commercially available cleaners or anti-static spray player, please consult your nearest Sony dealer. intended for vinyl LPs. Downloaded From DvDPlayer-Manual.com Sherwood Manuals...

  • Page 7: Getting Started

    Getting Unpacking Started Check that you have the following items: • Audio/video connecting cord (1) • S video cord (1) • Remote commander (remote) RMT-D108O (1) This section describes how to hook up • R6 (size AA) batteries (2) the CD/DVD player to a TV (with audio/video input jacks) and/or an Inserting batteries into the remote AV receiver (amplifier).

  • Page 8: Tv Hookups

    TV Hookups This connection is for listening to the sound through TV Required cords speakers (2ch – L, R). Refer to the instructions supplied Audio/video connecting cord (supplied) (1) with the component to be connected. S video cord (supplied) (1) When connecting the cords, be sure to match the color-coded cord to the appropriate jacks on the components: Yellow (video) to Yellow, Red (right) to Red and White (left) to White.
  • Page 9 If you connect the player to a monitor or Setups for the player projector having component video input Some setups are necessary for the player depending on connectors that conform to output signals from the TV or other components to be connected. the COMPONENT VIDEO OUT (Y, C /B-Y, C /R-Y)

  • Page 10: Receiver (Amplifier) Hookups

    Receiver (Amplifier) Hookups This connection is for listening to the sound through Required cords speakers connected to a receiver (amplifier such as an Audio connecting cord (not supplied) (1) integrated stereo amplifier, a receiver having a built-in S video cord (supplied) (1) Dolby Pro Logic decoder, etc.).
  • Page 11 If you have a digital component such as a If you have an audio component with a built-in receiver (amplifier) with a digital connector, DAT DTS decoder, Dolby Digital decoder or MPEG or MD decoder Connect the component via the DIGITAL OUT OPTICAL or Connect the component via the DIGITAL OUT OPTICAL or COAXIAL connector using an optical or coaxial digital COAXIAL connector using an optical or coaxial digital...

  • Page 12: 5.1 Channel Surround Hookups

    OPTICAL or COAXIAL connector using an optical or coaxial digital connecting cord (not supplied), see page 11. system using the DCS (Digital Cinema Sound) method that Sony developed. The VES system realize surround sound only with front speakers. For details on the VES Setups for the player mode, see page 32.
  • Page 13 S VIDEO IN CD/DVD player S VIDEO COMPONENT VIDEO OUT LINE OUT 5.1CH OUTPUT R–AUDIO 1–L VIDEO 1 FRONT REAR CENTER DIGITAL OUT /B–Y C /R–Y OPTICAL COAXIAL PCM/DTS/ R–AUDIO 2–L VIDEO 2 WOOFER DOLBY DIGITAL (AC-3) AV Receiver DIGITAL TV/LD VIDEO 2 VIDEO 1...

  • Page 14: Selecting The Language For On-Screen Display

    Selecting the Language for On-Screen Display Select “FRANÇAIS” using >/ ., then pr e ss ENTER. You can select the language for the setup display, the Control Menu display or the messages displayed on the CHOIX DE LA LANGUE screen. Default setting is “ENGLISH.” ECRANS: FRANÇAIS MENU DVD :...

  • Page 15: Playing Discs

    Playing Discs Playing Discs Depending on the DVD or VIDEO CD, some This chapter describes how to play a operations may be different or restricted. Refer to the DVD/CD/VIDEO CD. instructions supplied with your disc. 1/u (POWER) § · This player conforms to the PAL color system. When you play a disc recorded in the NTSC color system, the player outputs the video signal or the setup display etc.
  • Page 16 Playing Discs Operation You can turn on the player using the remote Press 1/u (POWER) when the indicator above the 1/u (POWER) Stop Press p. button on the front panel is lit in red. Pause Press P. Notes Resume play after pause Press P or ·.

  • Page 17: Playing At Various Speeds/Frame By Frame

    Playing at Various Speeds/Frame by Frame When you play back a CD/VIDEO CD Using the click shuttle and the JOG button/indicator on the player, you can play back a DVD/CD/VIDEO CD at 2) Fast forward (Faster than “1)”) < various speeds or frame by frame. Each time you press 1) Fast forward JOG, it changes between shuttle mode and jog mode.

  • Page 18: Resuming Playback From The Point Where You Stopped The Disc (Resume Play)

    Playing at Various Speeds/Frame by Frame Resuming Playback from the Point Where You Stopped the Disc (Resume To play the disc frame by frame changing Play) the playback speed (Jog mode) The player stores the point where you stopped the disc Press JOG.

  • Page 19: Using The Menu For Each Dvd

    Using the Menu for Each Using the title menu A DVD is divided into long sections of a picture or a music piece called “titles.” When you play a DVD which Notes contains several titles, you can select the title you want •...

  • Page 20: Playing Video Cds With Pbc Functions (Pbc Playback)

    Using the Menu for Each DVD Playing VIDEO CDs with PBC Functions (PBC Playback) Using the DVD menu Some DVDs allow you to select the disc contents using the menu. When you play these DVDs, you can select the When playing VIDEO CDs with PBC functions (Ver. 2.0 language for the subtitles, the language for the sound, etc., discs), you can enjoy simple interactive operations, using the DVD menu.

  • Page 21: Using The Front Panel Display

    Using the Front Panel Display Going back to the menu screen You can check information about the disc, such as the total Press ˆRETURN, =, or +. number of the titles or the tracks or remaining time, using the front panel display. When playing VIDEO CDs with PBC functions PBC playback starts automatically.
  • Page 22 Using the Front Panel Display Playing time and number When playing VIDEO CDs with PBC functions of the current chapter The current scene number is displayed instead of the current track number and the current index number. In this case, the Digital DISC TITLE CHAPTER...

  • Page 23: Using Various Functions With The Control Menu

    Using Various Using the Control Menu Display Z Functions with Using the Control Menu display, you can select the start the Control point, play in a order you like, change the angles, set for Digital Cinema Sound, etc. Menu The items are different depending on the kind of disc. For details on each Control Menu display item, see pages 26 to 40.
  • Page 24 Using the Control Menu Display Select the item you want using >/., then press / Note Some Control Menu display items require operations other than or ENTER. selecting the setting. For details on these items, see the relevant pages. 1 2 ( 2 7 ) 1 8 ( 3 4 ) C 0 1 : 3 2 : 5 5 To cancel using the Control Menu display on the...

  • Page 25: Control Menu Item List

    Control Menu Item List (page 34) (DVD only) (page 26) PROGRAM TITLE You can play the contents of the disc in the order you (DVD only) (page 26) CHAPTER want by arranging the order of the titles, chapters or (VIDEO CD/CD only) (page 26) tracks on the disc to create your own program.

  • Page 26: Searching For The Title/Chapter/Track/Index/Scene

    Searching for the Title/Chapter/Track/Index/Scene You can search by selecting the title/chapter/track/ Press / or ENTER. index/scene. “ ” is changed to “— — .” Select “TITLE,” “ CHAPTER,” “ TRACK”, “INDEX” or “SCENE” after pressing DISPLAY. 1 2 ( 2 7 ) –...

  • Page 27: Checking The Playing Time And Remaining Time

    Checking the Playing Time Selecting a Start Point and Remaining Time Using the Time Code You can check the playing time and remaining time of the You can search by inputting the time code. current title/chapter/track and the total remaining time Select “TIME/TEXT”...

  • Page 28: Checking The Information Of The Disc

    Selecting a Start Point Using the Time Code Checking the Information of the Disc Input the time code using the number buttons, then press ENTER. The player starts searching. To cancel the number, press CLEAR before pressing ENTER. You can check the DVD TEXT or CD TEXT of the disc on the TV screen and the front panel display.

  • Page 29: Changing The Sounds

    Changing the Sounds Z With DVDs recorded with multilingual sounds, you can Displaying the audio information of the select the language you want while playing the DVD. disc With multiplex CDs or VIDEO CDs, you can select the sound from the right or left channel and listen to the When you select “AUDIO,”...

  • Page 30: Displaying The Subtitles

    Changing the Sounds Displaying the Subtitles The display examples are as follows: •PCM (stereo) With DVDs on which subtitles are recorded, you can turn C 0 1 : 3 2 : 5 5 1: ENGLISH the subtitles on and off whenever you want while playing the DVD.

  • Page 31: Changing The Angles

    Changing the Angles Z Select the number of the angles using the number With DVDs on which various angles (multi-angles) for a buttons or >/., then press ENTER. scene are recorded, you can change the angles. For example, while playing a scene of a train in motion, you The angle is changed to the selected angle.

  • Page 32: Setting For Digital Cinema Sound

    Setting for Digital Cinema Sound Z Select the mode to enjoy multi channel surround sound Effects of each item such as Dolby Digital and MPEG. Even if you connect only front speakers, Virtual Enhanced Outputs all channel signals recorded on the disc. For Surround lets you enjoy 3D sound by using 3D sound example, outputs 2-channel signals for stereo sound of the imaging to create virtual rear speakers from the sound of...
  • Page 33 Notes • Each item of “VES” is effective on only discs on which a multi- channel soundtrack is recorded. Some discs do not have rear sound. In this case, you cannot get the 3D surround effect. • When you select an item, the sound cuts off for a moment. •...

  • Page 34: Creating Your Own Program (Program Play)

    Creating Your Own Program (Program Play) Press /. You can play the contents of the disc in the order you want by arranging the order of the titles, chapters or “01” is highlighted. It is ready to set the first title or tracks on the disc and create your own program.
  • Page 35 pWhen playing a VIDEO CD or CD To cancel the programmed order Select the track you want to program. To cancel all the titles, chapters or tracks in the programmed order, select “ALL CLEAR” in Step 2. Total time of the To cancel the selected program, select the program using programmed tracks >/.

  • Page 36: Playing In Random Order (Shuffle Play)

    Playing in Random Order (Shuffle Play) You can set Shuffle Play during stop You can have the player “shuffle” titles or tracks and play After selecting the item of “SHUFFLE,” press ·. them in a random order. The playing order may differ The player starts Shuffle Play.

  • Page 37: Playing Repeatedly (Repeat Play)

    Playing Repeatedly Repeating a Specific (Repeat Play) Portion (A˜B Repeat) You can play all the titles/tracks on a disc or a single title/ You can play a specific portion of a title, chapter, track chapter/track. repeatedly. This is useful when you want to memorize In Shuffle or Program Play mode, the player repeats the lyrics.
  • Page 38 Repeating a Specific Portion (A˜B Repeat) When you reach the ending point (point B), press Setting a portion for A˜B repeat ENTER again. The setting points are displayed and the player starts Select “SET/” in “A-B REPEAT.” repeating this specific portion. The A˜B REPEAT setting display appears.

  • Page 39: Checking The Play Information

    Checking the Play Information Z You can check the play information on the bit rate, bit rate Displays of each item history or the portion where the disc is played (layer). BIT RATE While playing a disc, the approximate bit rate of the playback picture is always displayed by Mbps (Mega bit per second) and the audio by kbps (Kilo bit per second).
  • Page 40 Checking the Play Information LAYER Appears when the DVD has dural layers Indicates the approximate point where the disc is playing. If it is a dual-layer DVD, the player indicates which layer is being read. For details on the layers, see page 60 (DVD). Downloaded From DvDPlayer-Manual.com Sherwood Manuals...

  • Page 41: Settings And Adjustments

    Settings and Using the Setup Display Adjustments Using the setup display, you can do the initial setup, adjusting the picture and sound quality, setting the various outputs, etc. You can also set a language for the This chapter describes how to set and subtitles and the setup display, limit playback by children, how to adjust using the on-screen SET etc.
  • Page 42 Using the Setup Display Select the main item you want using >/., and Select the setting you want using ?/>/.//, then then press ENTER. press ENTER. The selected main item is highlighted. SCREEN SETUP TV TYPE: 16:9 LANGUAGE SETUP 16:9 SCREEN SAVER: OSD: ENGLISH...

  • Page 43: Setup Display Item List

    Setup Display Item List Default settings are underlined. CUSTOM SETUP (page 46) LANGUAGE SETUP (page 44) ENGLISH AUTO PLAY FRANÇAIS TIMER DEUTSCH DEMO1 ITALIANO DEMO2 ESPAÑOL DIMMER BRIGHT NEDERLANDS DARK DANSK SVENSKA PAUSE MODE AUTO SUOMI FRAME NORSK PARENTAL CONTROL / PORTUGUÊS DVD MENU ENGLISH...

  • Page 44: Setting The Language For Display And Sound (Language Setup)

    Setting the Language for Display and Sound (LANGUAGE SETUP) Z pAUDIO Select “LANGUAGE SETUP” after pressing SET UP. “LANGUAGE SETUP” allows you to set various Switches the language for the sounds. languages for on-screen display or sound. • ORIGINAL: the language given priority in the disc Default settings are underlined.

  • Page 45: Settings For Display (Screen Setup)

    Settings for Display (SCREEN SETUP) Z pSCREEN SAVER Select “SCREEN SETUP” after pressing SET UP. “SCREEN SETUP” allows you to set the display according Turns on and off the screen saver. If you turn on the to the playback conditions. screen saver, the screen saver image appears when you Default settings are underlined.

  • Page 46: Custom Settings (Custom Setup)

    Custom Settings (CUSTOM SETUP) Z Select “CUSTOM SETUP” after pressing SET UP. Limiting Playback by Children (Parental “CUSTOM SETUP” allows you to set the playback Control) conditions. Select “CUSTOM SETUP” after pressing SET UP. Default settings are underlined. Playing some DVDs can be limited depending on the age of users.
  • Page 47 pWhen you have already entered a password Select “STANDARD” using >/., then press /. The display for confirming the password appears. Skip CUSTOM SETUP Step 2. PARENTAL CONTROL CUSTOM SETUP LEVEL: STANDARD: PARENTAL CONTROL CHANGE PASSWORD Enter password, then press ENTER To set, press , then...
  • Page 48 Custom Settings (CUSTOM SETUP) To return to the normal screen Standard Code number Press SET UP. Austria 2046 To turn off the Parental Control function and play Belgium 2057 the DVD after entering your password Canada 2079 Set “LEVEL” to “OFF” in Step 7, then press ·. China 2092 To change the password...

  • Page 49: Settings For Sound (Audio Setup)

    Settings for Sound (AUDIO SETUP) pTRACK SELECTION Select “AUDIO SETUP” after pressing SET UP. “AUDIO SETUP” allows you to set the sound according Gives the sound track which contains the highest number to the playback conditions. of the channels priority when you play a DVD on which Default settings are underlined.
  • Page 50 Settings for Sound (AUDIO SETUP) Notes pMPEG • When you play the sound tracks with 96 kHz sampling Selects output MPEG AUDIO signals via the DIGITAL frequency, the output signals from the DIGITAL OUT OUT OPTICAL and COAXIAL connectors. You cannot (OPTICAL, COAXIAL) are converted to 48 kHz (sampling select this item when you set “DIGITAL OUT”...

  • Page 51: Speaker Set Up

    Speaker Set Up Notes on playing the DTS sound tracks on a CD Select “SPEAKER SETUP” after pressing SET UP. • Do not play the DTS sound tracks without connecting the To obtain the best possible surround sound, first specify player to an audio component having a built-in DTS decoder.
  • Page 52 Speaker Set Up Notes pLEVEL • When you select an item, the sound cuts off for a moment. You can vary the level of each speaker as follows. Default • The cut off frequency for the subwoofer is fixed at 100 Hz. adjustments are in the parentheses.

  • Page 53: Controlling The Tv Or The Av Receiver (Amplifier) With The Supplied Remote

    • If you enter a new code number, the code number previously entered will be erased. • When you replace the batteries of the remote commander, the code number may reset to 01 (Sony). Reset the appropriate code number. Downloaded From DvDPlayer-Manual.com Sherwood Manuals...
  • Page 54 Hold down 1/u (POWER), and enter your AV ENTER TV/VIDEO receiver’s manufacturer’s code (see the table below) using the number buttons. Then release TV PROG 1/u (POWER). Manufacturer Code number Sony 91(default), 88, ENTER Denon 84, 85, 86 Kenwood 92, 93 Onkyo 81, 82, 83...

  • Page 55: Additional Information

    If you experience any of the following difficulties while using the player, use this troubleshooting guide to help you remedy the problem. Should any problem persist, consult your nearest Sony dealer. Power The power is not turned on. / If the indicator above the 1 /u (POWER) button is not lit, check that the AC power cord is connected securely.
  • Page 56 Troubleshooting The numbers or letters of 5 characters are The sound loses stereo effect when you play a displayed on the front panel display. VIDEO CD or a CD. / Self-diagnosis function was activated. See the / Set “AUDIO” to “STEREO” in the Control Menu table in page 58 and treat the player appropriately.
  • Page 57 The disc tray does not open and “LOCKED” is stops playback at the signal. displayed on the front panel display. Stopping playback, Search, Slow-motion Play, / Contact your Sony dealer or local authorized Sony Repeat Play, Shuffle Play or Program Play, etc., service facility. cannot be done.

  • Page 58: Self-Diagnosis Function

    •To prevent the player from malfunctioning, the self-diagnosis function has worked. Exx (xx is any number) /When you contact your Sony dealer or local authorized Sony service facility, give the 5-character service number. (example: E:61:10) Downloaded From DvDPlayer-Manual.com Sherwood Manuals...

  • Page 59: Specifications

    Specifications CD/DVD player General Laser Power requirements Semiconductor laser Signal format system 220 – 240 V AC, 50/60 Hz PAL/(NTSC) Power consumption 17 W Dimensions (approx.) Audio characteristics 430 × 95 × 305 mm (w/h/d) incl. projecting parts Frequency response Mass (approx.) DVD (PCM 96 kHz): 2 Hz to 44 kHz (±1 3.4 kg...

  • Page 60: Glossary

    Digital Cinema Sound (DCS) (page 32) to the status of the picture. The general name of technology that Sony developed to The audio data is recorded in Dolby Digital as well as in enjoy the surround sound in a home. To enjoy the PCM, allowing you to enjoy more real audio presence.
  • Page 61 Title (page 5) The longest sections of a picture or a music piece on a DVD; a movie, etc., for a picture piece on video software; or an album, etc., for a music piece on an audio software. Each title is assigned a title number enabling you to locate the title you want.

  • Page 62: Language Code List

    Language Code List For details, see page 30, 44. The language spellings conform to the ISO 639: 1988 (E/F) standard. Code Language Code Language Code Language Code Language 1027 Afar 1186 Scots Gaelic 1350 Malayalam 1513 Siswati 1194 Galician 1352 Mongolian 1028 Abkhazian...

  • Page 63: Index To Parts And Controls

    Index to Parts and Controls Refer to the pages indicated in parentheses for details. Front Panel 9 !º !¡ !™ !£ !¢ !∞ !§ !¶ !• !ª @º @¡ @™ @£ 1 g (remote sensor) (7) !¡ JOG button/indicator (17) Accepts the remote control signals.
  • Page 64 Index to Parts and Controls Rear Panel LINE OUT S VIDEO COMPONENT VIDEO OUT 5.1CH OUTPUT FRONT REAR CENTER R–AUDIO 1–L VIDEO 1 DIGITAL OUT /B–Y C /R–Y OPTICAL COAXIAL PCM/DTS/ R–AUDIO 2–L VIDEO 2 WOOFER DOLBY DIGITAL (AC-3) 1 DIGITAL OUT (OPTICAL) connector (11) Connects to an audio component using the optical digital connecting cord.
  • Page 65 9 AUDIO button (29) Remote Changes the sound while playing a DVD or VIDEO !º ANGLE button (31) Changes the angles when playing a DVD. !¡ ' /7 STEP buttons (16) !¶ Play a disc frame by frame. !™ =/+PREV/NEXT buttons (16) !•...

  • Page 66: Index

    Index Numerics F, G SHUFFLE 36 Shuffle Play 36 4:3 LETTER BOX 45 Fast Forward 17 SIZE 51 4:3 PAN SCAN 45 Fast Reverse 17 Slow-motion Play 16, 17 5.1 Channel Surround 12, 32 Front panel display 21 SPEAKER SETUP 51 16:9 45 Speakers H, I, J, K...
  • Page 67 Downloaded From DvDPlayer-Manual.com Sherwood Manuals...
  • Page 68 Sony Corporation Printed in Malaysia Downloaded From DvDPlayer-Manual.com Sherwood Manuals...
