Hold the battery so that the black tab on the front edge
of the battery is up and facing the door latch (this tab
helps you pull the battery out). Place the back edge
in first, gently pushing it underneath the two battery
catches. Rotate the front edge down until it is in position.
!
CAUTION: Do not set the battery pack straight down.
Damage to the unit could occur.
4. Replace the door and press down on it until the latch
pops into the locked position.
5. Attach the appropriate plug for your country into the
AC wall charger and plug into a wall socket. Plug the
other end into the DC power jack on the FC-5000.
Note: Use the AC wall charger that came with the FC-
5000 or an approved charger. See Appendix C, Wall
Charger Warnings, for details.
6. Charge the battery pack at room temperature (68° F or
20° C) for 6 hours (for the first charge). While the battery
pack is charging, the red LED blinks. When it is fully
charged and external power is applied, the red LED is
solid.
Note: If you have an optional internal battery as well as
a removable battery, the FC-5000 will not recognize the
internal battery until the FC-5000 is being charged and
is powered on.
Black Tab
