Summary of Contents for Asko T700

Page 1 ASKO SERVICE ACADEMY Service Manual for the Series of Tumble Dryers BUILT TO LAST LONGER...
Page 2 INTRODUCTION You have in your hand the ASKO Service Manual for the new generation of tumble driers, that are friendly to the environment in both their manufacture and their use. This new generation of tumble driers has been designed for ease of servicing. By this we mean that it's a simple job, for example, to replace a damaged side panel.
Page 3: Safety Regulations
SAFETY REGULATIONS SAFETY REGULATIONS GENERAL • The electrical and plumbing installations shall be carried out by a qualified electrician and plumber respectively. SERVICE WARNING Always switch off the main electrical power supply when dismantling and assembling the washing machine. • Always use an earthed EMC wristband when working with electrical components, such as panel printed circuit boards and electronic control units.
Page 4: Specifications
SPECIFICATIONS SPECIFICATIONS PRINCIPAL DIMENSIONS Height: 850 mm Width: 595 mm Depth: 585 mm Weight: T700 39 kg T720 47 kg T760 39 kg T780 47 kg VOLUME/CAPACITY Drum volume 111 litres Drying capacity - EU: 5.0 kg Drying capacity - AU: 5.0 kg...
Page 5: The Drying Process
THE DRYING PROCESS THE DRYING PROCESS T700: Air at room temperature is heated by the heating element and drawn into the drum, where it ex- tracts the dampness from the clothes. The ridges in the drum prevent the clothes from sticking to each other.
Page 6: Cooling Air
THE DRYING PROCESS T720/780: The condensing tumble drier has two circulation systems: one for drying air and one for cooling air. The black arrows show the warm drying air, and the white arrows the cooling air at room tem- perature. The ridges in the drum prevent the clo- thes from sticking to each other.
Page 7: Installation
850 mm. The width of the opening must be at least 600 C. Washing tower The tumble drier can be placed on top of an ASKO washing machine. The tumble drier is fastened securely and prevented from moving by the to- wer fasteners that come with the machine: 2 off angle pieces.
Page 8 INSTALLATION Install the tower configuration like this: 1. Unscrew and remove the outermost screws from each side of the rear of the washing machine. 2. Screw the angle pieces to the rear of the wash- ing machine. 3. Secure the two plastic cups to the front edge of the top cover.
Page 9: Adjusting The Feet
INSTALLATION ADJUSTING THE FEET Screw the feet in or out until the tumble drier is standing vertical and steady. Lock the feet by tight- ening their locking nuts. CONDENSATION WATER (T720/780) Alternative 1 (as delivered) Condensation water is pumped up into the con- densation water tank, which is pulled out and emptied manually.
Page 10 INSTALLATION AIR EXTRACTION (T700/760) The exhaust air from the tumble drier should be taken to an exhaust duct or a wall outlet with the aid of the accompanying air extraction hose. Connection to the tumble drier The tumble drier has three possible air extraction points: the rear, right or left side.
Page 11: Electrical Installation
The machine is supplied for 3-phase, 400 V, hea- stalling the tumble drier jointly with a single-phase ting power 2500/2620 W (see type label) and ASKO washing machine, the phases should be fused at 10 A. connected like this: If an earth fault breaker is installed, it should be of type A.
Page 12 DOORHANGING DOOR HANGING The tumble drier's front door can be adjusted to hang on either the left or the right. Tumble driers are normally delivered with the door hanging on the left. Left hanging to right hanging: 1. Keep the front door closed, it will be held in position by the door magnet.
Page 13 DOOR HANGING 13. Remove the screw that is securing the front panel at the bottom edge of the side where the hinge will be installed. 14. Keep the front door in place with the door magnet. 15. Install the hinge fixing in the order a,b,c,d. 16.
Page 14 DOOR HANGING Right hanging to left hanging: 1. Keep the front door closed, it will be held in position by the door magnet. 2. Remove the bottom cover. 3. T720/780: Open the condenser housing co- ver. 4. Remove the 3 screws that secure the hinge fixing and the lower screw that secures the front panel.
Page 15 DOOR HANGING 16. Install the hinge fixing in the order a,b,c. 17. T720/780: Close the condenser housing co- ver. 18. Refit the bottom cover.
Page 16: Fault Tracing
TUMBLE DRYING IS TAKING TOO LONG Thermistor error: Ring for service. (T700/760): Sensor error: Fault in the humidity sensor. This Check that the fluff filter is not blocked. error message may also appear if you run the...
Page 17 FAULT TRACING INCORRECT LANGUAGE ON THE DISPLAY If for some reason the language on the display has changed, you can go back to the original langua- Earlier models had two versions of the machine (Alternatives 1 and 2) but now all eleven langua- ges are present in all machines.
Page 18 PROBLEMS PROBLEMS COMMON QUESTIONS AND PROBLEMS The machine shows the Maximum program time fault indication. The washing will not dry? The indication means that the machine has been The machine only runs for 20 minutes? running for the maximum time (= 3 hours) that the control unit is allowed.
Page 19: Components And Measurement Values
HANNING gram. T720/780 THERMOSTAT Part no.: 80 638 09 111 Ω T700 Resistance: Part no.: 80 619 46 (44°C) PLASET Part no.: 80 014 45 (53°C) Part no.: 80 088 07 (115°C auto.) T720/780 Part no.:...
Page 20: Humidity Sensor
Part no.: 80 084 87 (150°C manual) 10A with heating power 2620W (T760) or 2500W (T700/720/780). The machine can be The 150°C thermostat stops the program if the rewired for single phase, 16A with heating power temperature rises too high and has to be manual- 2620W (T760) or 2500W (T700/720/780) or ly reset.
Page 21: Heating Element
COMPONENTS AND MEASUREMENT VALUES HEATING ELEMENT T700/760 2620 W Part no.: 80 618 33 66.7/25.7 Ω Resistance: The element has a maximum power rating of 2620W but consists of two loops of 1900W and 720W, which permits rewiring from 2620W to 1900W.
Page 22 COMPONENTS AND MEASUREMENT VALUES T720/780 2500 W Part no.: 80 637 71 79,7/25 Ω Resistance: The element has a maximum power rating of 2500W but consists of two loops of 1900W and 600W, which permits rewiring from 2500W to 1900W. Temperature ˚C (68) (67)
Page 23: Test Program And Fault Indications
TEST PROGRAM AND FAULT INDICATIONS TEST PROGRAM AND FAULT INDICATIONS TEST PROGRAM FAULT INDICATIONS The machine must be in its starting state (obtai- Overfill: Overfill condensation ned by pressing the main power button). water holder. Maximum running time: Maximum running Short-circuit the outputs ST4-1 and ST4-2.
Page 24: Consumption Values
800 to 1600 rpm (long spin drying) in an ASKO washing machine. Other garments (non-iron and acrylic) should, before tumble drying, be spun at 800 rpm (short spin drying) in an ASKO washing machine. T700 PROGRAM MATERIAL...
Page 25 800 to 1600 rpm (long spin drying) in an ASKO washing machine. Other garments (non-iron and acrylic) should, before tumble drying, be spun at 800 rpm (short spin drying) in an ASKO washing machine. LOAD PROGRAM MATERIAL...
Page 26 800 to 1600 rpm (long spin drying) in an ASKO washing machine. Other garments (non-iron and acrylic) should, before tumble drying, be spun at 800 rpm (short spin drying) in an ASKO washing machine PROGRAM MATERIAL ENERGY CONSUMPTION...
Page 27: List Of Tools
TOOLS TOOLS LIST OF TOOLS "Torx" spanners: Ring spanners: 11/16” 13 mm 8 mm Socket screwdriver: 10 mm Screwdrivers...
Page 28: Application Areas
TOOLS APPLICATION AREAS Humidity sensor: w torx T25 Top lid: w torx T20 w torx T25 w torx T10 w special tool (Part no. 88 011 54) Rear piece: w torx T25 Thermostat: w torx T20 w torx T25 w ring spanner 13 mm w torx T10 w special tool (Part no.
Page 29 TOOLS Condenser housing: w torx T25 w torx T20 w socket spanner 10 mm w special tool (Part no. 88 011 54) Water tank housing: w torx T25 w torx T20 Side panels/Bottom: w torx T25 w torx T20 w torx T10 w 6.5-7 mm wide blade screwdriver Front panel: w torx T25...
Page 30: Special Tools
SPECIAL TOOLS SPECIAL TOOLS INSTALLING THE DRUM TD20 Part no. 88 011 54 The tool hangs in one of the punched-out key- holes in the front rail, then the rear edge of the drum is rolled up on to the roller and the drum is held in place.
Page 31: Top Cover
SERVICE SERVICE TOP COVER Removing the top cover 1. Remove the 3 screws at the rear of the top cover. 2. Tilt the cover and pull it backwards. Installing the top cover 1. Ensure that the sealing strip is positioned along the edge of the top cover.
Page 32: Rear Panel
5. Take the cable bundle out of the cable clamp and pull the header block off its terminal pins. 6. Remove the wiring: T700/720: R1 a, R1 b, R1 13, R1 14, R1 34 on the contactor. T760/780: Ra, Rb, R13, R14, R34 on the contactor and F3 and F4 on the radio interfe- rence filter.
Page 33 SERVICE Removing the inner and outer rear panels 1. Remove the rear panel in accordance with the section "Rear panel - removing...". 2. Remove the screws that secure the inner rear panel to the outer, and the cable clamp. 3. Lift them apart. IMPORTANT The bearing is now free and can be removed.
Page 34 SERVICE Changing the foam rubber seal 1. Remove the 3 screws at the rear of the top cover and lift it off. 2. Remove the screws that secure the rear panel sides and bottom. 3. Remove the screws that secure the inner and outer rear panels.
Page 35 SERVICE Changing the rear felt strip seal 1. Remove the rear panel in accordance with the section "Rear panel - removing...". 2. Lift off the felt strip seal. 3. Thread the new felt strip into place. 4. Tighten the tensioning band around the felt strip, using the special tool.
Page 36 SERVICE Changing the overheating protection device 1. Remove the three screws at the rear edge and lift off the top cover. 2. Remove the screws that secure the rear panel to the sides and bottom. 3. Remove the screws that secure the inner and outer rear panels, along with the cable clamp.
Page 37: Input Terminal Block
SERVICE INPUT TERMINAL BLOCK Removing the input terminal block 1. Remove the three screws at the rear edge and lift off the top cover. 2. Remove the earth screw. 3. Remove all the wiring. 4. Press in the latches with a screwdriver and pull out the input terminal block.
Page 38 SERVICE RADIO INTERFERENCE FILTER (T760/780) Removing the radio interference filter 1. Remove the three screws at the rear edge and lift off the top cover. 2. Disconnect the wiring from the radio interfe- rence filter. 3. Unscrew the nut securing the filter. Installing the radio interference filter 4.
Page 39 SERVICE CONTACTOR Removing the contactor 1. Remove the three screws at the rear edge and lift off the top cover. 2. Remove the wiring to the contactor. 3. Unscrew the 2 screws that secure the contac- tor. Installing the contactor 4.
Page 40 SERVICE FUSE T760/780 Changing the fuse 1. Remove the fuse holder insert with a screw- driver (1/4 turn). 2. Change the fuse. IMPORTANT The fuse must be of 250V and 6.3 Ampere type. 3. Fit the fuse holder insert with the fuse into the fuse holder.
Page 41 SERVICE DRUM Removing the drum 1. Remove the rear panel in accordance with the section "Rear panel - removing...". 2. T720/780: Remove the external fan housing in accordance with the section " External fan housing - removing..." steps 2-4. 3. Remove the special tool. 4.
Page 42 SERVICE Changing the drum ridge 1. Remove the three screws at the rear edge and lift off the top cover. 2. Unscrew the 5 screws that secure the drum rid- NOTE Rotate the drum until you can gain access to the screws.
Page 43 SERVICE EXTERNAL FAN HOUSING (T720/780) Removing the external fan housing 1. Remove the rear panel in accordance with the section "Rear panel - removing...". 2. Unclip the external fan housing suction side. 3. Unscrew the external fan wheel and remove 4.
Page 44 SERVICE MOTOR Removing the motor 1. Remove the drum in accordance with the sec- tion "Drum - removing...". 2. Take off the bottom cover (snap fasteners). 3. Remove the fan housing cover (4 snap fasten- ers and 1 screw). 4. Unscrew the fan wheel. 5.
Page 45 SERVICE Changing the capacitor 1. Remove the rear panel in accordance with the section "Rear panel - removing...". 2. T720/780: Remove the external fan housing in accordance with the section "External fan housing - removing..." steps 2-4. 3. Unscrew the capacitor. 4.
Page 46: Air Extraction System
SERVICE AIR EXTRACTION SYSTEM Removing the exhaust air duct hook 1. Remove the bottom cover. 2. Take hold of the duct hook and twist it free. Installing exhaust air duct hook 3. Push one end into the exhaust air duct T-pie- 4.
Page 47 SERVICE HUMIDITY SENSOR Removing the humidity sensor 1. Remove the three screws at the rear edge and lift off the top cover. 2. Take off the bottom cover (snap fasteners). 3. Use a screwdriver to remove the plugs. 4. Remove the cover for the fan housing (4 snap fasteners and 1 screw).
Page 48 SERVICE THERMOSTAT (T700/T720) Removing the thermostat 1. Remove the three screws at the rear edge and lift off the top cover. 2. Take off the bottom cover (snap fasteners). 3. Unscrew the protection. 4. Unscrew the thermostats and remove the wi- ring.
Page 49 SERVICE THERMISTOR (T760/780) Removing the thermistor 1. Remove the three screws at the rear edge and lift off the top cover. 2. Take off the bottom cover (snap fasteners). 3. Remove the protection. 4. Take out the thermistor with the aid of flat- nose pliers.
Page 50: Front Frame
12. Install the fan housing cover (4 snap fasteners and 1 screw). 13. Put the cable bundle into the cable clamps. 14. T700/760: Install the exhaust duct hook by pressing it on to the front frame exhaust lip. 15. Install the motor in accordance with the sec- tion "Motor...
Page 51 SERVICE Changing the front felt seal 1. Remove the drum in accordance with the sec- tion "Drum - removing...". 2. Remove the seal. 3. Install the new seal evenly distributed around the groove. IMPORTANT The strip must be pressed firmly all around the groove.
Page 52 SERVICE Changing the lamp/glass 1. Open the front door. 2. Unscrew the lamp glass. 3. Change the lamp. 4. Screw the lamp glass back on. 5. Close the front door. Changing the lamp socket 1. Remove the drum in accordance with the sec- tion "Drum - removing...".
Page 53: Front Door
SERVICE FRONT DOOR Removing the front door NOTE The front door must remain closed during the entire removal procedure; the door magnet will hold it in place. 2. Unscrew and remove the 3 screws that secure the hinge fixture. 3. Lift down the front door. Installing the front door 4.
Page 54 SERVICE Changing the hinge socket 1. Remove the three screws that secure the lo- wer hinge and twisting it free, take off the front door. 2. Change the hinge socket. 3. Hang the front door back on with the aid of the door magnet and secure the hinge.
Page 55 SERVICE Changing the inner door 1. Remove the three screws that secure the lo- wer hinge and twist it free, lift off the front door. 2. Unscrew the handle. 3. Unscrew the 2 screws at the side of the front door and the 3 at the lower edge.
Page 56 SERVICE Changing/cleaning the filter holder 1. Open the front door. 2. Pull out the filter holder and take out the double filter. 3. Squeeze the snap fasteners inwards while at the same time lifting the filter holder out of the inner door. IMPORTANT Take care when lifting the filter holder out not to damage it.
Page 57 SERVICE Changing the door switch pin 1. Drill a 4 mm diameter hole where the old pin was. 2. Fit a hinge pin (part no.: 80 618 04) into the hole. IMPORTANT Fit the pin so that it projects by 11 mm.
Page 58: Front Panel
SERVICE FRONT PANEL Removing front panel 1. Remove the three screws at the rear edge and lift off the top cover. 2. Remove the three screws that secure the lo- wer hinge and twist it free, lift off the front door.
Page 59 3. Install a new clip. 4. Install the bottom cover. Changing the fixing clip for the bottom cover (male) T700/760, Left T720/780: 1. Remove the bottom cover. 2. Squeeze the snap fasteners and pull or push out the clip. 3. Install a new clip.
Page 60 3. T720/780: Pull out the water tank. 4. T720/780: Unscrew the 2 screws that secure the panel to the front rail. 5. T700/760: Unscrew the 2 screws securing the front rail. 6. Remove the 4 snap fasteners at the bottom edge by bending the clips apart with a screw- driver with a 6.5 to 7 mm wide blade.
Page 61 2. Fit the new knobs. Changing the panel handle 1. Remove the three screws at the rear edge and lift off the top cover. 2. T700/760: Unscrew the 2 screws securing the front rail. 3. Pull the handle off. 4. Fit the handle.
Page 62 SERVICE Changing the programming buttons (T700/ 720) 1. Remove the panel in accordance with the sec- tion "Panel - removing..." 2. Change the buttons. NOTE The buttons sit free on the push-button switches. 3. Install the panel in accordance with the sec- tion "Panel - installation...".
Page 63 SERVICE Changing the push-button switches 1. Remove the panel in accordance with the sec- tion "Panel - removing...". 2. Get hold of the switch inside the machine and pull on it, while at the same time bending the wings at the front of the switch inwards with a screwdriver.
Page 64 SERVICE Changing the push-buttons (T760/780) WARNING An earthed EMC wristband must be worn at all times when working with electronic components to prevent damage to them. 1. Remove the three screws at the rear edge and lift off the top cover . 2.
Page 65 SERVICE PROGRAMMER Removing the programmer 1. Remove the three screws at the rear edge and lift off the top cover. 2. Remove the outermost knob by first turning it until the markings are upright, then pulling it off. NOTE It is possible to use a polygrip (mole wrench) to remove the knobs, but in that case remember to put some soft material in the jaws so as not to scratch the plastic.
Page 66 SERVICE Changing the buzzer 1. Remove the panel in accordance with the sec- tion "Panel - removing...". 2. Unscrew the buzzer. 3. Fit a new buzzer. 4. Install the panel in accordance with the sec- tion "Panel - installation...". Changing the rotary selector 1.
Page 67: Electronic Control Unit
SERVICE ELECTRONIC CONTROL UNIT WARNING An earthed EMC wristband must be worn at all times when working with electronic components to prevent damage to them. Changing the electronic control unit 1. Remove the three screws at the rear edge and lift off the top cover.
Page 68 SERVICE Removing the electronic control unit with its holder 1. Remove the three screws at the rear edge and lift off the top cover. 2. Remove the panel in accordance with the sec- tion "Panel - removing...". 3. Press in the 2 snap fasteners. 4.
Page 69 SERVICE CONDENSER HOUSING (T720/780) Removing the condenser housing 1. Remove the drum in accordance with the sec- tion "Drum - removing...". 2. Remove the external fan housing in accordance with the section "External fan housing - remo- ving...". 3. Remove the snap fasteners with the aid of a screwdriver.
Page 70 SERVICE Changing the microswitch for the condensed water pump 1. Remove the rear panel in accordance with the section "Rear panel - removing...". 2. Remove the wiring and the microswitch. 3. Fit the new microswitch. 4. Install the rear panel in accordance with the section "Rear panel - installation...".
Page 71 SERVICE Changing the float 1. Remove the drum in accordance with the sec- tion "Drum - removing...". 2. Remove the external fan housing in accordance with the section "External fan housing - remo- ving...". 3. Remove the snap fasteners with the aid of a screwdriver and lift out the condenser assem- bly.
Page 72 SERVICE WATER TANK HOUSING (T720/780) Removing water tank housing 1. Pull out the water tank. 2. Remove the three screws at the rear edge and lift off the top cover. 3. Remove the hoses. 4. Unscrew the 2 screws in the panel and the screws in the rear panel.
Page 73: Side Panels
SERVICE SIDE PANELS Changing the side panels 1. Remove the front panel in accordance with the section "Front panel - removing...". 2. Remove the panel in accordance with the sec- tion "Panel - removing...". 3. Early models: the hole is marked out on the bottom.
Page 74: Front Rail
SERVICE BOTTOM Changing the bottom 1. Remove the condenser housing in accordance with the section " Condenser housing - remo- ving..." 2. Early models: the hole is marked out on the bottom. 3. Cut off the rivets between the bottom and side panels.
Page 75 PROGRAMS AND OPTIONS T700 PROGRAMS AND OPTIONS T700 Temperature selection Options Program selection Start PROGRAMS IMPORTANT If an excessively long drying time is set, the result Which program you choose depends on what you may be that garments shrink, crease or be stret- want to do with your laundry after tumble dry- ched.
Page 76: Drying Time
PROGRAMS AND OPTIONS T700 TEMPERATURE You can select Normal ( ) or Low ( ) tempera- ture. DRYING TIME The Drying time depends on many different fac- tors, such as the amount of laundry, the degree of dampness in the fabric, the type of fabric, the heating power, the temperature of the incoming air and its humidity.
Page 77 PROGRAMS AND OPTIONS T720 PROGRAMS AND OPTIONS T720 Temperature selection Options Program selection Start PROGRAMS OPTIONS Quick cooling The length of program that you choose depends Quick cooling provides 9 minutes of cooling. on what you want to do with your laundry after Normal cooling continues for 18 minutes, (this tumble drying.
Page 78 PROGRAMS AND OPTIONS T760 PROGRAMS AND OPTIONS T760 LC-Display Main power Program selection Start Stop Menu Enter Start/Stop Options PROGRAMS Timer program Extra dry With the Timer program you can decide the pro- This program is for fabrics that are particularly gram length yourself, to find the best times for difficult to dry, such as jeans with very thick different materials.
Page 79 PROGRAMS AND OPTIONS T760 OPTIONS Cooling You can choose between Normal cooling and Quick cooling. Normal cooling runs for 20 minu- tes and Quick cooling runs for 15 minutes. Buzzer Sounds an audible signal when the drying pro- gram is complete. The signal sounds for 3 seconds. Anti-crease This program prevents creasing of garments after tumble drying by turning the drum for 3 seconds...
Page 80 PROGRAM AND OPTIONS T780 PROGRAMS AND OPTIONS T780 LC-Display Main power Program selection Start Stop Menu Enter Start/Stop Options PROGRAMS Timer program With the Timer program you can decide the pro- Extra dry gram length yourself, to find the best times for This program is for fabrics that are particularly different materials.
Page 81 PROGRAMS AND OPTIONS T780 OPTIONS Cooling You can choose between Normal cooling and Quick cooling. Normal cooling runs for 20 minu- tes and Quick cooling runs for 15 minutes. Buzzer Sounds an audible signal when the drying pro- gram is complete. The signal sounds for 3 seconds. Anti-crease This program prevents creasing of garments after tumble drying by turning the drum for 3 seconds...
Page 82 MAKING YOUR OWN DRYING PROGRAMS (T760/780) MAKING YOUR OWN DRYING PROGRAMS (T760/780) You can make your own drying programs that The buttons that you will need to use for ma- would perhaps suit your own needs better than king your own programs are the Menu the four preset programs.
Page 83 MAKING YOUR OWN DRYING PROGRAMS (T760/780) SELECT THE INITIAL PROGRAM Airing program: Start by choosing one of the preset drying pro- You can use the Airing program when you just grams: want to shake the dust out of garments, air them 1.
Page 84 MAKING YOUR OWN DRYING PROGRAMS (T760/780) Anti-crease Next time you want to run this personal drying This program means that the drum will turn program, you only need to press the program for three seconds every minute, after the drying button you chose when you started making these program is completed.
Page 85 PROGRAM OVERVIEW T760/780 PROGRAM OVERVIEW T760/780...
Page 86 TUMBLE DRYING T700/720 TUMBLE DRYING T700/720 1. Sort the laundry. 2. Set the main power switch to on, 3. Put the laundry into the tumble drier. 4. Close the door. 5. Select the settings and time. 6. Press the Start button.
Page 87 TUMBLE DRYING T760/780 TUMBLE DRYING T760/780 1. Sort the laundry. 2. Set the main power switch to on, 3. Put the laundry into the tumble drier. 4. Close the lid. 5. Select the program. The machine has four preset drying programs , see the table.
Page 88: Cleaning And Maintenance
CLEANING AND MAINTENANCE CLEANING AND MAINTENANCE CLEANING the fluff filter The fluff filter should be cleaned after every tum- ble-drying session. If you have very hard water the fluff filter may collect a layer of scale. Check when you are clea- ning fluff out of the filter if scale is present, and if so, wash the scale off by hand.
Page 89: Cleaning The Outside Of The Machine
CLEANING AND MAINTENANCE CLEANING THE OUTSIDE OF THE MACHINE Clean the outside and the program panel with a mild detergent. NOTE Don't use any king of solvent, this can damage the machine. Don't drench the machine in water, either. IMPORTANT Don't let dust collect around the machine.
Page 90 CLEANING AND MAINTENANCE CLEANING THE CONDENSER (T780) The condenser should be cleaned at least three times a year. NOTE If you have pets at home the condenser should be cleaned more often. 1. Set the main power switch to off. 2.
Page 91 ASKO Cylinda AB / A S K O A P P L I A N C E S SE-534 82 VARA • Sweden Part. no. 63 003 42 Phone +46 512 320 00 • Fax +46 512 320 10...
