Summary of Contents for Nuvico EasyNet Series

  • Page 2: Table Of Contents

    QUICK SETUP GUIDE – OVERVIEW This manual is intended for initial setup only. The user should read the entire instructions manual before using this product. The user instructions manual can be downloaded via NUVICO website. www.nuvico.com TABLE OF CONTENTS QUICK SETUP GUIDE – OVERVIEW ............................ 1 TABLE OF CONTENTS ..............................

  • Page 3: Installation Diagram

    INSTALLATION DIAGRAM EN-U3000 SAMPLE INSTALLATION DIAGRAM 1. You will notice that the diagram illustrates using 2 PoE Network Switches. 8 Port PoE Switch and 24 Port PoE Switch. That’s because the diagram is illustrating 30 EasyNet HD cameras installation since EN-U3000 is a 30- channel NVR.

  • Page 4: How To Mount The Hdd To The Nvr

    HOW TO MOUNT THE HDD TO THE NVR 1. When you unpack the NVR box, locate the removable HDD tray, shown below. 2. The removable HDD tray, shown below needs to be inserted into the empty slot of the NVR. EN-U3000...
  • Page 5 HOW TO MOUNT THE HDD TO THE NVR 3. With the latch pointing upwards, slide the tray into the slot. 4. Lock the tray in the slot by applying downward pressure to the latch. ENU-3000...
  • Page 6 HOW TO MOUNT THE HDD TO THE NVR 5. Finally, use the supplied tray key to lock the HDD tray into the chasis to prevent unauthorized removal. EN-U3000...

  • Page 7: Getting Started

    GETTING STARTED IMPORTANT NOTE: Prior to staring the NVR, make sure that the PoE Network Switches are powered on, initialized, and are providing power to the EasyNet HD Cameras. HOW TO START THE NVR 1. Connect the supplied USB mouse into any available USB port on the front NVR panel. 2.
  • Page 8 GETTING STARTED 1. Follow the instructions below. • Using Mouse: Click on the [Log In] icon. 2. You need to input admin password, which is [0 0 0 0 0 0]. • Using Mouse: Click on the [Keyboard] icon. EN-U3000...
  • Page 9 GETTING STARTED 3. On screen keyboard should now appear. The default admin password for the NVR is [0 0 0 0 0 0]. • Using Mouse: Highlight [0] and click six times, then, highlight [↵] and click. 4. Lastly, when you select [OK] you are now logged on as admin. •...

  • Page 10: Monitor Setup

    MONITOR SETUP CONFIGURE NVR’S MONITOR OUTPUT TO 1920 x 1080 To take full advantage of the EasyNet NVR, you want to make sure that you have a 1080p capable monitor. Follow the instructions below. 1. Follow the instructions below. • Using Mouse: Click on the [Setup Menu] icon. 2.
  • Page 11 MONITOR SETUP 3. Select [MONITOR] under DISPLAY option. • Using Mouse: Click on the [DISPLAY], then, click on [MONITOR]. 4. Select 1920 x 1080 which is true 1080p resolution. • Using Mouse: Select and click on the 1920 x 1080. ENU-3000...

  • Page 12: If You Are Using A Bnc Monitor

    MONITOR SETUP 5. Save the changes. • Using Mouse: Click on [Save] to save. 6. To exit out to the Live screen. • Using Mouse: Right click on your mouse twice. IF YOU ARE USING A BNC MONITOR IMPORTANT NOTE: If you are ONLY using a BNC type monitor, which is [Main 2] output, •...

  • Page 13: How To Disable Main 2 Bnc Output

    MONITOR SETUP HOW TO DISABLE MAIN 2 BNC OUTPUT IMPORTANT NOTE: This step is extremely important if you use only 1 monitor such which is connected either HDMI/DVI or VGA. The factory default setting for 2 Monitor is turned “On”. However, should you NOT want to take advantage of the 2 Monitor “Main 2”, follow these instructions.
  • Page 14 MONITOR SETUP 3. Access the sub-menu of SYSTEM. • Using Mouse: Click on the [SYSTEM]. 4. Uncheck to turn off [Monitor Key], and define which monitor you would solely like to use. Since HDMI/VGA is Main 1, you want to make sure that Main 1 is displayed next to the [Use] checkbox. •...
  • Page 15 MONITOR SETUP 5. Save the changes. • Using Mouse: Click on [Save] to save. 6. To exit out to the Live screen. • Using Mouse: Right click on your mouse twice. ENU-3000...

  • Page 16: How To Initialize The Hdd For Recording

    HOW TO INITIALIZE THE HDD FOR RECORDING 1. Follow the instructions below. • Using Mouse: Click on the [Setup Menu] icon. 2. Select Advanced Setup. • Using Mouse: Click on the [Advanced Setup]. EN-U3000...
  • Page 17 HOW TO INITIALIZE THE HDD FOR RECORDING 3. Select Utility. • Using Mouse: Click on the [UTILITY]. 4. Select Disk Manager. • Using Mouse: Click on the [Disk Manager]. ENU-3000...
  • Page 18 HOW TO INITIALIZE THE HDD FOR RECORDING 6. Disk Manager will alert with caution message. • Using Mouse: Click on the [OK]. 7. Select INT-1 HDD. • Using Mouse: Click on the [Off] status of the INT-1. EN-U3000...
  • Page 19 HOW TO INITIALIZE THE HDD FOR RECORDING 8. Select Add • Using Mouse: Click on the [Add]. 9. You are finished. To exit out to the Live screen. • Using Mouse: Right click on your mouse twice. ENU-3000...

  • Page 20: How To Set Date/Time

    HOW TO SET DATE/TIME When the NVR is powered on for the very first time, the time and date may be incorrect. Before any other operation of the NVR is started, it is important to setup the time and the date. 1.
  • Page 21 HOW TO SET DATE/TIME 3. Change to the desired value. • Using Mouse: Click on the desired value and modify. Time Sync: When checked, it will synchronize the NVR’s time to its regional NTP (Network Time Server) if an active internet connection is maintained.

  • Page 22: Camera Setup

    CAMERA SETUP 1. Follow the instructions below. • Using Mouse: Click on the [Setup Menu] icon. 2. Select Advanced Setup. • Using Mouse: Click on the [Advanced Setup]. EN-U3000...
  • Page 23 CAMERA SETUP 3. Select Devices. • Using Mouse: Click on the [CAMERA MANAGER]. 4. NVR will automatically discover EasyNet cameras and will display them on this screen. There are no specific orders since the NVR is broadcasting to the network switch for any available EasyNet cameras. NOTE: If you do not see all of your cameras being displayed on this screen, try one of the following.
  • Page 24 CAMERA SETUP 5. Now, since there were no specific orders of the cameras, you would want to start assigning the channel number to the cameras so that the cameras can be identified with specific channel ID going forward. • Using Mouse: Click on the channel drop down menu, and choose from 1 through 30. Tip: It is possible that the Camera Manager Window can block some of the cameras.
  • Page 25 CAMERA SETUP 6. If all of your camera’s Channel ID is set, click on “Save” to exit out of this menu. ENU-3000...

  • Page 26: Record Setup

    RECORD SETUP 1. Follow the instructions below. • Using Mouse: Click on the [Setup Menu] icon. 2. Click on the [Advanced Setup] • Using Mouse: Click on the [Advanced Setup]. EN-U3000...
  • Page 27 RECORD SETUP 3. Click on the [RECORD] • Using Mouse: Click on the [RECORD]. 4. For CONTINUOUS Record, change to the desired value. CONTINUOUS Record means that the cameras are recording 24/7. • Using Mouse: Click on the desired value and modify. When finished, click on [Save] to exit out of the menu. CONTINUOUS: On or Off.
  • Page 28 RECORD SETUP IMPORTANT: Should you wish the NVR to record ONLY when the motion is detected, follow these further instructions. 5. Uncheck CONTINUOUS Record option to all of the cameras that you wish to record ONLY on motion. • Using Mouse: Uncheck CONTINOUS Record on desired cameras. 6.
  • Page 29 RECORD SETUP 6. Check Record under the MOTION. Again, you can use the [Apply to All] shortcut to apply the setting to all cameras. • Using Mouse: Click on [Record] to activate Motion Recording. 7. Save and exit out to the Live screen. 8..

  • Page 30: Network Setup

    NETWORK SETUP HOW TO SETUP IP ADDRESS UNDER THE NETWORK SETUP The network menu allows for adjustment to the TCP/IP settings for viewing video across a local area network or through the internet. 1. Follow the instructions below. • Using Mouse: Click on the [Setup Menu] icon. 2.
  • Page 31 NETWORK SETUP 3. Select Network and access the sub-menu of NETWORK. • Using Mouse: First, click on the [NETWORK] icon, and then click on the [NETWORK] text. 4. Make necessary changes. Note: To change the parameters of IP, Netmask, Gateway, DNS1, DNS2, Port, follow the instructions below. (These parameters are given by your Internet Service Provider or Network Administrator.) ENU-3000...
  • Page 32 NETWORK SETUP Highlight and click the IP portion on the screen. Virtual numeric keypad will pop up on the screen. Use your mouse to click on the desired value such as 0 ~9, Backspace, Enter and Clear button to enter your values.. EN-U3000...
  • Page 33 NETWORK SETUP DHCP: Obtains IP, Netmask, Gateway, DNS1, DNS2 automatically from your internet device or Router. Only enable this when you know that DHCP is supported by your network. IP Address Netmask: Subnet Mask Gateway: Gateway, usually referred to as IP Address of your router on the network. DNS1: Primary Domain Name Server Address, given by your Internet Service Provider or Network Administrator.

  • Page 34: Video Search & Playback

    VIDEO SEARCH & PLAYBACK HOW TO SEARCH FOR VIDEO USING “TIME SEARCH” METHOD 1. Follow the instructions below. • Using Mouse: Click on the [Search] icon. 2. Select Time Search. • Using Mouse: Click on the [Time Search] icon. EN-U3000...
  • Page 35 VIDEO SEARCH & PLAYBACK 3. Enter your desired Date and Time. • Using Mouse: Click on the desired group such as Month/Day/Year/Hour/Minute/Second and click on the [] [] part of the screen to change the value. Then, highlight and click on [Start]. Your desired video will start playing.
  • Page 36 VIDEO SEARCH & PLAYBACK HOW TO SEARCH FOR VIDEO USING “CALENDAR SEARCH” METHOD 1. Follow the instructions below. • Using Mouse: Click on the [Search] icon. 2. Select Calendar Search. • Using Mouse: Click on the [Calendar Search] icon. EN-U3000...
  • Page 37 VIDEO SEARCH & PLAYBACK 3.Select Year, then Month, and Finally the day of the month. • Using Mouse: Click on either the Year/Date or Day and change to the desired value. 4.Select your desired time of the day. • Using Mouse: Click on the desired time of the day. Your desired video will start playing. ENU-3000...
  • Page 38 VIDEO SEARCH & PLAYBACK 5. To exit out to the Live screen. • Using Mouse: Click on the X (Close). EN-U3000...

  • Page 39: How To Copy Videos Into Cd/Dvd/Usb

    HOW TO COPY VIDEOS INTO CD/DVD/USB 1. Follow the instructions below. • Using Mouse: Click on the [Copy] icon. ENU-3000...
  • Page 40 NOTE: When “EXE” is checked, NVR will make self executable file where it can be played on any PC without the need of installing NUVICO player software to view the file. Extremely useful if you want to give the copied video to law enforcement and etc.

  • Page 41: How To View Copied Video

    HOW TO VIEW COPIED VIDEO 1. Insert the copied medium such CD/DVD or USB Thumbdrive into the NVR. 2. Follow the instructions below. • Using Mouse: Click on the [Search] icon. 3. Choose your desired medium such as DVD or USB. •...
  • Page 42 HOW TO VIEW COPIED VIDEO 4.NVR will search for video from your desired medium. 5. NVR will display videos that are available on your desired medium. 6. Follow Time Search method that is explained on pages above. EN-U3000...
  • Page 43 NOTES ENU-3000...
  • Page 44 50303136A...
