Samsung SRP-500 Integrator's Manual
Dot matrix receipt printer
Hide thumbs
Also See for SRP-500:
- Programmer's manual (45 pages) ,
- Operator's manual (41 pages) ,
- Command manual (27 pages)
Related Manuals for Samsung SRP-500
Summary of Contents for Samsung SRP-500
- Page 1 Samsung SRP-500 Dot Matrix Receipt Printer Integrator’s Manual CRS, Inc. 2909 Anthony Lane Minneapolis, MN 55418 (612) 781-3474 © 2002, Cash Register Sales, Inc. All specifications are subject to change without notice...
-
Page 2: Table Of Contents
Add/Edit an Image......................14 Image Views........................15 Image Cartridge Selection....................16 Convert Image ........................17 Print & Download Image to SRP-500 Flash ROM.............. 18 Direct Print Setup ......................18 Direct Print Communications..................... 19 Direct Print Resolution ...................... 20 Vertical Alignment ......................21 MSPaint.......................... -
Page 3: Driver Installation Information
Visual Basic font test Visual Basic 6 code samples Receipt Sample Program and Code Visual Basic 6 status API code & program Visual C 6 status API code & program Driver Installation Information • 3 Samsung SRP-500 Setup & Service Information... -
Page 4: Srp-500 Driver Installation
Select the appropriate driver (i.e. srp500.inf for Windows98) and click OK. 7. The Install From Disk dialog box displays, click OK. 8. The Add Printer Wizard now displays with the SAMSUNG SRP-500 selected. Click Next. The printer driver files are now installed. -
Page 5: Windows 98 Driver Settings
Windows 98 Driver Settings 1. From your Windows desktop, select Start, then Settings, and then Printers. 2. From the printers dialog, right click the SRP-500 driver and choose Properties. 3. From the Generic / Text Only dialog box, click the Additional Commands tab: Type command to print a logo here. -
Page 6: Hexadecimal Dumping
The first column contains the hexadecimal codes and the second column gives the ASCII characters that correspond to the codes. 5. When the printing finishes, turn off the printer. 6 • Hexadecimal Dumping Samsung SRP-500 Setup & Service Information... - Page 7 SRP-270 Hexadecimal Dump It may be useful to compare hexadecimal dumps with a known printer, such as the Samsung SRP-270. To print a hexadecimal dump on the SRP-270: 1. After you make sure that the printer is off, open the front cover of the printer.
-
Page 8: Hexadecimal Dump Sample Printout
The first column contains the hexadecimal codes. The second column prints the ASCII characters that correspond to the codes. • A period is printed for each code that has no ASCII equivalent. 8 • Hexadecimal Dumping Samsung SRP-500 Setup & Service Information... -
Page 9: Troubleshooting
Troubleshooting If you are connecting an SRP-500 to a specific software application for the first time, you may encounter printing differences from a printer model you are currently supporting. You can isolate the commands causing the print difference by comparing hex dumps from a working printer the printer with a problem print format. -
Page 10: Cash Drawer
0 ≤ t1 ≤ 255, 0 ≤ t2 ≤ 255 [Description] Outputs the pulse specified by t1 & t2 to connector pin m as follows: Connector pin 0,48 Drawer kick-out connector pin 2 0,49 Drawer kick-out connector pin 5 10 • Cash Drawer Samsung SRP-500 Setup & Service Information... -
Page 11: Connection Information
2 (yellow) Solenoid Drawer open/close signal 3 (green) Drawer open switch +24V 4 (red) Solenoid Drawer kick-out drive signal 2 5 (black) Not used Signal ground 6 (white) Drawer open switch Cash Drawer • 11 Samsung SRP-500 Setup & Service Information... -
Page 12: Logo Creation Instructions
This procedure states how to save bit map files made using the Microsoft Paint software. Bit Map File Specification • Maximum total file size to be downloaded to the SRP-500 is 256K bytes. • Maximum total images = 10 •... -
Page 13: Srp-500 Storemaker Utility
The Samsung SRP-500 StoreMaker utility converts true color images to 2-color images that are ready for use as logos by the Samsung SRP-500 printer. After conversion, the image’s color and value can be controlled to achieve the best results. In addition, the utility supports image printing, storing and downloads images to the SRP-500 flash ROM. -
Page 14: Add/Edit An Image
You can see 2-color converted Image under default cartridge setting and the image item inserted in list box. The image item list automatically saved in your computer and you can remove an item by Delete Image button. 14 • SRP-500 StoreMaker Utility Samsung SRP-500 Setup & Service Information... -
Page 15: Image Views
Click the Image Editer button to load the Windows MSPaint utility for image editing. (If your OS is different, other utilities are supported. For example, Windows 98 loads Paintbrush.) SRP-500 StoreMaker Utility • 15 Samsung SRP-500 Setup & Service Information... -
Page 16: Image Cartridge Selection
• If custom ink colors are used, you can click the R Cartridge or L Cartridge buttons and select the appropriate color from the color palette. 16 • SRP-500 StoreMaker Utility Samsung SRP-500 Setup & Service Information... -
Page 17: Convert Image
The scrollbars controls the right and left cartridge values. Color Swapping The RBG control allows color swapping. Use the Invert Color check box to exchange the two available colors. The remaining checkboxes will exchange the colors indicated. SRP-500 StoreMaker Utility • 17 Samsung SRP-500 Setup & Service Information... -
Page 18: Print & Download Image To Srp-500 Flash Rom
Click the Print button to print the Image. • Click the Store button to download the image to your SRP-500 printer. If running DOS, the Store to File command is recommended. This command will download data to a binary file. Then at the DOS prompt, run the command: C:\>... -
Page 19: Direct Print Communications
Select the appropriate port (serial or parallel), Baud Rate, Parity, Data bits, ‘stop bit, Flow Control. Settings must match the SRP-500 printer to produce desirable print. SRP-500 StoreMaker Utility • 19 Samsung SRP-500 Setup & Service Information... -
Page 20: Direct Print Resolution
The Resolution Selection can be any of the four displayed. Single density is the fastest but prints with the least quality. The Quad Density is the best quality, but is the slowest. Double density 100x196 is a good compromise. 20 • SRP-500 StoreMaker Utility Samsung SRP-500 Setup & Service Information... -
Page 21: Vertical Alignment
Adjust the radio buttons for the highest print quality Click the Setup button to change the settings in you printer. After setting, you can test print by clicking the Check Setup button. SRP-500 StoreMaker Utility • 21 Samsung SRP-500 Setup & Service Information... -
Page 22: Mspaint
Click the Download button. Warning : After initiating the download, please wait until the download is complete and the printer LED in fully on. 22 • SRP-500 StoreMaker Utility Samsung SRP-500 Setup & Service Information... -
Page 23: System Setup Guides
Initialize command should be deleted. NOTE: Use the start command 1B6701 to print the first image loaded into the SRP-500. Use the sequential commands, 1B6702 to 1B6710 to print the remaining 9 images that may be stored in the SRP-500. - Page 24 Use the Serial Port Device Selections program to define the type of device that is attached to each serial port. In this case, define the port where the SRP-500 is attached as “PRINTER” with a printer type of “SAM SRP-270”.
- Page 25 4. At the LOGO SIZE field, select 0= Normal, 1= Double Wide, 2 = Double Height, 3 = Double Height and Width. 5. Press ESC to return to the S-MODE PROGRAMMING MENU. System Setup Guides • 25 Samsung SRP-500 Setup & Service Information...
-
Page 26: Samsung Srp-500/Maitre'd Logo Setup Guide
Samsung SRP-500/Maitre’D Logo Setup Guide The Maitre’D Point of Sale system from Poisera can take advantage of the two-color graphic logo printing capabilities of the Sansung SRP-500. This document provides the Maitre’D settings required to print the SPS-500 graphic logo. - Page 27 3. Select the code tab and enter 1B6701 into the page set up command line. NOTE: Use the page setup command 1B6701 to print the first image loaded into the SRP-500. Use the sequential commands, 1B6702 to 1B6710 to print the remaining 9 images that may be stored in the SRP-500.
