DISASSEMBLY INSTRUCTIONS

Unplug the dryer before servicing.
TOP PLATE
WARNING !
When you disassemble the top plate, be
sure to disconnect the dryer from its
electrical supply. Protect your hands and
arms from sharp edges when working.
To reduce the risk of Injury to persons
adhere to all industry recommended
safety procedures including the use of
long sleeved gloves and safety glasses.
1.
Remove 3 screws on the upper plate.
2.
Push the top plate backward.
3.
Lift the top plate.
WARNING !
THE DRYER TOP PLATE IS VERY LARGE
AND HEAVY. Fallure to follow
instructions can result in damage to the
dryer, property damage or Injury to persons.
