SPLIT TYPE AIR CONDITIONER CASSETTE TYPE (50Hz) Indoor unit Outdoor unit AUYG36LRLA AOYG36LATT AUYG45LRLA AOYG45LATT AUYG54LRLA AOYG54LATT C ON T EN T S SPECIFICATIONS ....
D IME NS ION S Drain pipe INDOOR UNIT DECORATION PANEL (Unit : mm) Gas pipe Liquid pipe Side view Bottom view 795 (Hanging bolt position) Top view 2012.04.26...
Page 4
OUTDOOR UNIT (unit : mm) air flow 2008.11.13...
OUTDOOR UNIT TEST RUN CAUTION Always turn on the power 6 hours prior to the start of the operation in order to protect the compressor. 1. Check items before performing the test run 2.1. Operating procedures for the test run Make sure to perform the test run.
OUTDOOR UNIT ERROR CODE DISPLAY Display when an error occurs TEST PUMP POWER LOW NOISE PEAK CUT DOWN ERROR MODE (L1) (L2) (L3) (L4) (L5) (L6) (L7) Blinks (Hi-speed) Check that the ERROR LED blinks, and then short-press the [ENTER] switch once. Display mode : ON The number of blinks of the LED indicates the type of error.
2. Pump down procedure OUTDOOR UNIT PUMP DOWN (Refrigerant collecting operation) (1) Check the 3-way valves (both at the liquid side and gas side) are opened. (2) Turn the power on. Perform the following procedures to collect the refrigerant when moving the indoor unit or outdoor unit TEST PUMP POWER...
PARTS DECORATION PANEL UTG-UGYA-W Ref. Description Part number Intake Grille Assy 9378565012 Intake Grille 9378249011 Long Life Filter 9378252011 Filter Guide 9378253018 Hook Bracket 9378435018 Grille Hook 9378250017 2012.04.26...
Page 23
DECORATION PANEL UTG-UGYA-W Ref. Description Part number Decoration Panel 9378242012 Corner Panel A 9378243019 Corner Panel (FUJITSU) 9378243026 Panel Cover A 9378261013 Panel Cover B 9378262010 Drain Cover 9378359017 2012.03.16...
Page 24
DECORATION PANEL UTG-UGYA-W Ref. Description Part number Flap 9378254015 Poli Slider 9375541019 Joint C 9378357013 Step motor 9900467005 Gear A 9378256019 Motor Holder 9378255012 Joint A 9378258013 Joint B 9378259010 Gear B 9378257016 Joint Shaft 9378260016 Flap Spring 9378356016 2012.03.16...
PARTS INDOOR UNIT Ref. Description Part number Ref. Description Part number Top Plate Assy 9378395015 Motor, DC Brushless 9602716005 Cabinet A Sub Assy 9378594012 Motor Rubber 9378223011 Cabinet B Sub Assy 9378595019 Turbo Fan Assy 9378228016 Cabinet C Sub Assy 9378570016 Turbo Fan Washer 9378394018...
Page 26
INDOOR UNIT Ref. Description Part number Evaporator Total Assy 9378580053 Coupling Pipe Assy 9373038627 Wind Guide Board 9378236011 2012.03.16...
Page 27
INDOOR UNIT Ref. Description Part number Sensor Holder 9378329010 Float Switch 9900465018 Pump Assy 9900464011 Drain Pump Holder B 9375518011 Pump Rubber 9378426016 Drain Hose 9378212015 Drain Port 9378213012 Drain Pan Assy 9378207011 Bell Mouth 9378227019 Terminal Wire Cover 9378548015 Drain Cap 9375502010 Drain Hose...
Page 28
INDOOR UNIT Ref. Description Part number PCB Holder 9378205017 Power Supply PCB 9707398366 Main PCB (36) 9709245460 Main PCB (45) 9709245477 Main PCB (54) 9709245484 Terminal 3P 9306489045 Terminal 3P 9703345012 Thermistor Holder A 9378206014 Thermistor Holder B 9378330016 Room Thermistor 9900445010 Pipe Thermistor 9900470012...
PARTS OUTDOOR UNIT Ref. Description Parts number Ref. Description Parts number Top Panel Sub Assy 9374417032 Reactor Assy 9900641016 Front Panel Sub Assy 9374414130 Motor, DC Brushless 9602843046 Sevice Panel Sub Assy 9374415076 Propeller Fan Assy 9366378020 Emblem Rear 9351355005 Condenser A Sub Assy 9374420261 Pipe Cover Front...
