15.6" LCD Color Monitor
Service
Service
Service
Description
Table of Contents.....................................................1
Revision List................................................................2
Important Safety Notice.............................................3
1. Monitor Specifications................................................4
2. LCD Monitor Description............................................5
3.1General Instructions...........................................6
3.2 Control buttons................................................6
3.3 OSD Menu.........................................................7
4. Input/Output Specification......................................10
4.1 Input Signal Connector.........................................10
4.2 Factory Preset Display Modes................................10
4.3 Pixel Defect Policy..........................................11
4.4 Failure Mode of Panel .....................................12
5. Block Diagram.................................................13
5.1 Software Flow Chart.............................................13
5.2 Electrical Block Diagram....................................15
6. Schematic Diagram..................................................17
ANY PERSON ATTEMPTING TO SERVICE THIS CHASSIS MUST FAMILIARIZE HIMSELF WITH THE
CHASSIS AND BE AWARE OF THE NECESSARY SAFETY PRECAUTIONS TO BE USED WHEN
SERVICING ELECTRONIC EQUIPMENT CONTAINING HIGH VOLTAGES.
CAUTION: USE A SEPARATE ISOLATION TRANSFOMER FOR THIS UNIT WHEN SERVICING
REFER TO BACK COVER FOR IMPORTANT SAFETY GUIDELINES
Copyright 2008 Philips Consumer Lifestyle
Page
Page
SAFETY NOTICE
Subject to modification ○
160VW9FB/78
Description
6.1 Main Board......................................................17
6.2 Power Board...............................................21
6.3 Key Board.........................................................23
7. PCB Layout.........................................................24
7.1 Main Board........................................................24
7.2 Power Board...................................................26
7.3 Key Board.........................................................28
8. Wiring Diagram...................................................29
9. Scalar Board Overview........................................30
10. Mechanical Instructions........................................31
11. Repair Flow Chart...............................................35
12. ISP Instructions...........................................................41
13. DDC Instructions.........................................................44
15. Monitor Exploded View................................................53
16. Recommended & Spare Parts List............................54
17. General Product Specification................................56
Oct. 22, 2008
K
Chassis: HUDSON 9
Page
GB
312278518240

Advertisement

Table of Contents
loading

Related Manuals for Philips 160VW9FB/78

Summary of Contents for Philips 160VW9FB/78

  • Page 1: Table Of Contents

    CHASSIS AND BE AWARE OF THE NECESSARY SAFETY PRECAUTIONS TO BE USED WHEN SERVICING ELECTRONIC EQUIPMENT CONTAINING HIGH VOLTAGES. CAUTION: USE A SEPARATE ISOLATION TRANSFOMER FOR THIS UNIT WHEN SERVICING REFER TO BACK COVER FOR IMPORTANT SAFETY GUIDELINES Copyright 2008 Philips Consumer Lifestyle Subject to modification ○ Oct. 22, 2008 312278518240...

  • Page 2: Revision List

    HUDSON 9 Revision List Version Release Date Revision History Oct.22.2008 Initial release, Draft Version...

  • Page 3: Important Safety Notice

    HUDSON 9 Important Safety Notice Proper service and repair is important to the safe, reliable operation of all Philips Company Equipment. The service procedures recommended by Philips and described in this service manual are effective methods of performing service operations. Some of these service operations require the use of tools specially designed for the purpose.

  • Page 4: Monitor Specifications

    HUDSON 9 1. Monitor Specifications Model number 160VW Driving system TFT Color LCD Viewable Image Size 395mm diagonal Pixel pitch 0.252mm(H) x 0.252mm(V) LCD Panel Video R, G, B Analog lnterface Separate Sync. H/V TTL Display Color 16.7M Colors Dot Clock 85.5 MHz Horizontal scan range 30 kHz - 60 kHz...

  • Page 5: Lcd Monitor Description

    HUDSON 9 Operating 0~ 3000m (0~ 10000 ft ) Non-Operating 0~ 5000m (0~ 15000 ft ) 2. LCD Monitor Description The LCD monitor will contain a main board, a power board and a key board which house the flat panel control logic, brightness control logic and DDC.

  • Page 6: Operating Instructions

    HUDSON 9 3. Operating Instructions 3.1 General Instructions Press the power button to turn the monitor on or off. The other control knobs are located at front panel of the monitor (see figure). By changing these setting, the picture can be adjusted to your personal preference. ﹡...

  • Page 7: Osd Menu

    HUDSON 9 3.3 OSD Menu OSD Setting Press the MENU-button to activate the OSD window. Press – or + to navigate through the functions. Once the desired function is highlighted, press the MENU-button to activate sub-menu. Once the desired function is highlighted, press MENU-button to activate Press –...
  • Page 8 HUDSON 9 Function Control Illustration Luminance Adjust Range Description Brightness 0-100 Backlight Adjustment Contrast 0-100 Contrast from Digital-register. Standard Standard Mode Text Text Mode Internet Internet Mode Eco mode Game Game Mode Movie Movie Mode Sports Sports Mode Gamma1 Adjust to Gamma1 Gamma Gamma2 Adjust to Gamma 2...
  • Page 9 HUDSON 9 on or off Disable or Enable Demo Demo icture Boost Frame Size 0-14 Adjust Frame Size Brightness 0-100 Adjust Frame Brightness Contrast 0-100 Adjust Frame Contrast 0-100 Adjust Frame Hue Saturation 0-100 Adjust Frame Saturation H. position Adjust Frame horizontal Position Position V-position Adjust Frame vertical Position...

  • Page 10: Input/Output Specification

    HUDSON 9 4. Input/ Output Specification 4.1 Input Signal Connector Analog connectors Pin No. Description Pin No. Description Video-Red Video-Green Detect Cable Video-Blue Ground Ground DDC-Serial data Ground H-sync GND-R V-sync GND-G DDC-Serial clock GND-B 4.2 Factory Preset Display Modes Stand Resolution Horizontal frequency(kHz)

  • Page 11: Pixel Defect Policy

    HUDSON 9 4.3 Pixel Defect Policy Bright Dot Defects Max. 5 red, green or blue bright dots (sub-pixels) Max. 3 green dots Max. 1 joined bright dots Min. distance between 2 bright dots: 10 mm. Bright dots are tested with full screen black pattern (R.G.B. = 0, 0, 0) Black Dot Defects Max.

  • Page 12: Failure Mode Of Panel

    HUDSON 9 4.4 Failure Mode Of Panel Quick reference for failure mode of LCD panel this page presents problems that could be made by LCD panel. It is not necessary to repair circuit board. Simply follow the mechanical Polarizer has bubbles instruction on this manual to eliminate failure by replace LCD panel.

  • Page 13: Block Diagram

    HUDSON 9 5. Block Diagram 5.1 Software Flow Chat...
  • Page 14 HUDSON 9 1) MCU initializes. 2) Is the EPROM blank? 3) Program the EPROM by default values. 4) Get the PWM value of brightness from EPROM. 5) Is the power key pressed? 6) Clear all global flags. 7) Are the AUTO and SELECT keys pressed? 8) Enter factory mode.

  • Page 15: Electrical Block Diagram

    HUDSON 9 5.2 Electrical Block Diagram 5.2.1 Main Board Flash Memory (U402) Panel Interface SST25LF020A-33-4C-SAE (CN403) Scalar IC TSUM1PFR-LF Crystal 14.31818MHz Keypad Interface (Include MCU, ADC, OSD) (X401) (CN401) (U401) H sync V sync H_Sync VGA_R+ ESD (U103) D-Sub Connector ESD (U102) V_Sync VGA_G+...
  • Page 16 HUDSON 9 5.2.2 Inverter/Power Board AC input Bridge Rectifier Transformer Rectifier Diodes EMI filter and Filter Start Circuit: R904、R932, R933 CN902 Feedback Circuit Control IC ON/OFF Output MOSFET Transformer Circuit Lamp Over Voltage Feedback ON/OFF Circuit Control Control IC...

  • Page 17: Schematic Diagram

    HUDSON 9 6. Schematic 6.1 Main Board 715G2904-1-2 INPUT CN101 C101 H_Sync R101 0R05 1/10W 5% R102 100R 1/16W 5% DSUB_H V_Sync R103 100R 1/16W 5% FB102 C102 DSUB_V R104 C101 C103 VGA_B+ DSUB_B+ VCC3.3 C104 R105 R106 C102 C103 BEAD 2K2 1/16W 5% 2K2 1/16W 5%...
  • Page 18 HUDSON 9 POWER ESD_5V ESD_5V DSUB_5V DSUB_5V 5 D403 CMVCC CN404 D401 C422 BAT54C BAV99 5, 6 CMVCC C423 VCC3.3 VCC3.3 C425 C426 CN404 C427 VCC3.3 R437 R439 CMVCC1 C428 SM340A D402 10K 1/16W 5% 10K 1/16W 5% C432 CMVCC CMVCC1 VCC1.8 D401...
  • Page 19 HUDSON 9 SCALAR AVDD VDDP VDDC CN401 VCC3.3 VDDP AVDD FB401 FB401 CN402 C401 U401 U401 VCC3.3 C403 300OHM 300OHM C404 VCTRL VCTRL C403 C403 C404 C404 C406 LVA3P C407 0.1uF/16V 0.1uF/16V 0.1uF/16V 0.1uF/16V DSUB_R+ RIN0P LVA3M C408 DSUB_R- RIN0M PA[0..1] C409 DSUB_G+...
  • Page 20 HUDSON 9 OUTPUT CN403 PA[0..1] PB[0..9] PA[0..1] PB[0..9] LVB0P LVB0M LVB1P LVB1M LVB2P LVB2M LVBCKP LVBCKM PA[4..9] LVB3P LVB3M PA[4..9] CN403 CONN C419 C420 C421 FB402 VCC3.3 Q404 CMVCC PANEL_VCC Q405 R433 R438 R443 R434 0R05 1/16W NC/0ohm R435 VCC3.3 8 R436 CMVCC R434...

  • Page 21: Power Board

    HUDSON 9 6.2 Power Board 715G2852-2 POWER R918 R918 100 OHM 1/4W 100 OHM 1/4W L904 L904 R919 R919 +12V 1.0uH 1.0uH 100 OHM 1/4W 100 OHM 1/4W C912 C912 ZD902 ZD902 0.001uF 0.001uF C930 C930 RLZ13B RLZ13B R920 R920 C922 C922 R946...
  • Page 22 HUDSON 9 CN801 CN801 INVERTER CN801 CN802 C839 C839 T801 T801 R821 R821 C801 1500PF/50V 1500PF/50V POWER X'FMR POWER X'FMR R817 R817 1K 1/8W 1K 1/8W CONN CONN C802 10K 1/10W 1% 10K 1/10W 1% R855 R855 D805 D805 C803 15R 1/4W 15R 1/4W LL4148...

  • Page 23: Key Board

    HUDSON 9 6.3 Key Board 715G2835-1 LED_RED# LED_GRN# LED001 LED001 CN001 CN001 LBADC1 R002 R002 2K OHM 1/4W 2K OHM 1/4W LBADC2 DC_POWERON R003 R003 0R05 1/10W 1% 0R05 1/10W 1% LED_GRN# LED_RED# C001 C001 C002 C002 C003 C003 C004 C004 C005 C005...

  • Page 24: Pcb Layout

    HUDSON 9 7. PCB Layout 7.1 Main Board 715G2904-1-2 C101 C413 FB101 C4 R113 R419 R449 C102 C414 FB102 C3 R114 R420 R450 C103 C415 FB103 C3 R115 R421 R451 C104 C416 FB401 C3 R116 R424 R452 C105 C417 FB402 B4 R117 R425 R453...
  • Page 25 HUDSON 9...

  • Page 26: Power Board

    HUDSON 9 7.2 Power Board 715G2852-2 BD901 D4 CN601 D5 IC903 C3 J906 C604 CN602 B5 J601 J907 C801 CN801 A1 J602 J908 C802 CN802 D1 J605 J909 C803 CN803 A1 J801 J910 C900 CN804 D1 J802 J911 C901 CN901 D2 J803 J912 C902...
  • Page 27 HUDSON 9 C601 C910 IC801 A2 R802 R841 R922 C602 C911 IC901 C3 R803 R850 R923 C603 C912 JR801 A2 R804 R851 R924 C606 C924 JR901 C3 R805 R853 R925 C608 C925 JR902 C3 R806 R854 R926 C609 C928 Q801 R807 R855 R927...

  • Page 28: Key Board

    HUDSON 9 7.3 Key Board 715G2835-1 CN001 B5 D001 GND1 GND2 SW001 B2 SW002 B3 SW003 B1 SW004 B3 SW005 B4 C001 R002 C002 R003 C003 R004 C004 R005 C005 ZD001 B2 C006 ZD002 B4 C007 ZD003 B1 C008 ZD004 B3 C009 ZD005 B3 C010...

  • Page 29: Wiring Diagram

    HUDSON 9 8. Wiring Diagram Panel CN902 CN801 14 Pin CN403 Power Board CN404 Main Board CN802 CN602 TSUM1PFR-LF (U401) AC IN CN601 CN401 CN101 CN901 D-SUB 6 Pin Key Board CN001...

  • Page 30: Scalar Board Overview

    HUDSON 9 9. Scalar Board Overview Flash ROM MSTAR chip DC-DC Converters...

  • Page 31: Mechanical Instructions

    HUDSON 9 10. Mechanical Instructions Place the monitor face down on a smooth surface .Be careful to avoid scratch and injury during the process of uninstall. Remove three screws remarked in red to remove the Stand-Base ASS’Y.
  • Page 32 32 32 HUDSON 9 Use disassembly tool to open 5 latches at the bottom of BACK COVER as below, and open the other latches along the edge of the BACK COVER, then lift dismounts BACK COVER. Remove Bezel. 5. Disconnect KEY BOARD CABLE. 6.
  • Page 33 HUDSON 9 7. Remove main frame cover A. Disconnect the two connectors marked in blue B. Remove the four screws marked in red. C. Press to release left and right latches of LVDS CABLE, and then disconnect it.
  • Page 34 34 34 HUDSON 9 8. Remove power board and main board A. Remove the two screws marked in red. B. Remove three screws marked in red to remove the Power Board and Main Board from Main Frame. C. Disconnect the connector marked in blue MB-KB Connector MB-PB Connector LVDS Connector...

  • Page 35: Repair Flow Chart

    HUDSON 9 11. Repair Flow Chart 11.1 Main Board (1). No Power No power Press power key and look if the picture is normal Please reinsert and make sure the AC of 100-240 is normal Reinsert or check the Adapter/Inverter section Measure U404 PIN2=3.3V Check C426 and C428 X401 oscillate waveforms...
  • Page 36 36 36 HUDSON 9 (2). No Picture No picture The button if X401 oscillate Replace X401 under control waveform is normal Check reset circuit of Check Correspondent component U401 is normal Measure U404 PIN2=3.3V Replace U401 Check C426 and C428 X401 oscillate waveform is normal Replace X401...
  • Page 37 HUDSON 9 (3). White screen White screen Measure Q404 base X401 oscillate waveform is normal is low level? Replace X401 Check Q404, Q405 is broken or CN403 solder? Check reset circuit of U401 is normal Check Correspondent Check Correspondent component. component.
  • Page 38 38 38 HUDSON 9 11.2. Power/Inverter Board (1) No power Check ZD902 ＝12V Check AC line volt 100V or 240V Check AC input Check the voltage of C907 (+) Check bridge rectified circuit and F901 circuit Check start voltage for the pin3 of IC901 Check R904, R932, R933 and Change IC901 Check the auxiliary voltage is bigger than 16V and smaller than 32V...
  • Page 39 HUDSON 9 (2) W / LED, No Backlight Check ZD902 ＝12V Check adapter or MB Check ON/OFF signal Check Main Board Check IC801 PIN12=12V Check Q805, Q808 Check IC801 PIN8, 9 or PIN10, 11 have the output of square Change IC801 Check Q809 have the output of square wave at short time.
  • Page 40 40 40 HUDSON 9 11.3 Key Board OSD is unstable or not working Is Key Pad Board connecting normally? Connect Key Pad Board Replace Button Switch Is Button Switch normally? Replace Key Pad Board Is Key Pad Board normally? Check Main Board...

  • Page 41: Isp Instruction

    D. Software ISP SN Alignment kits The kit contents: a. ISP BOARD x1 b. Printer cablex1 c. VGA cable x1 Connect the ISP board as follow: Connect to Connect to the the PC LPT Philips 160VW9 The process of ISP write is as follows.
  • Page 42 42 42 HUDSON 9 a) Double-click ，running the program as follows: b) Click icon, and click to search the program “Philips_160VW9_TSUM16AWR_M156B1L01_080731-V001-F0AB”, and click save:...
  • Page 43 HUDSON 9 Click icon, it will show “Load Message: Loading OK.” d) Click icon, then click . If it burns successfully, it will show as the follow picture:...

  • Page 44: Ddc Instruction

    VGA cable x1 d. Digital cable x1 e. 12V DC power source Connect the DDC board as follow: Connect to the PC LPT When you write analog EDID, Connect this port to the Philips 160VW9’s VGA port 12V Input...
  • Page 45 HUDSON 9 Take analog DDC write for example, as follow Double-click ，appear as follow Figs：...
  • Page 46 46 46 HUDSON 9 b. Choose “Analog”, click to search the program and click “OK”:...
  • Page 47 HUDSON 9 c. Key the same 14 numbers in the Input SN blank and Verify SN blank, then click “Program”. Now analog DDC Write completes, as follow:...
  • Page 48 48 48 HUDSON 9 160VW9 EDID 128 bytes EDID Data (Hex): x0 x1 x2 x3 x4 x5 x6 x7 x8 x9 xA xB xC xD xE xF 00 FF FF FF FF FF FF 00 41 0C 75 08 EB D9 01 00 10: 17 0B 01 03 68 22 13 78 2A B3 70 A2 55 48 98 27 20: 15 50 54 BF EE 00 31 0A 61 4C 01 01 01 01 01 01 30: 01 01 01 01 01 01 66 21 56 AA 51 00 1E 30 46 8F...
  • Page 49 HUDSON 9 Composite Sync Support: No Sync. on green video supported:No Serration of the Vsync.Pulse is not required. Max. H. Image Size: 34cm. Max. V. Image Size: 19cm. Display Gamma: DPMS Features, Stand-by: DPMS Features, Suspend: DPMS Features, Active off: Display Type: R.G.B color display.
  • Page 50 Detailed Timing: 1366x768 @ 60Hz <-x-Detailed Timing Descriptions-x-> <---Detailed Timing Descriptions---> Detailed Timing: FF (Monitor SN) '312312312132' Detailed Timing: FC (Monitor Name) 'Philips 160VW' Detailed Timing: FD (Monitor limits) Min. V. rate: 55Hz Max. V. rate: 75Hz Min. H. rate: 30 KHz Max.

  • Page 51: White Balance, Luminance Adjustment

    = 313 ±30, y = 329 ±30, Y>150cd/m2 3. Into Factory mode of Philips 160VW9FB/78: Press the MENU button, pull out the power cord, and then plug the power cord. Then the factory OSD will be at the left top of the panel.
  • Page 52 52 52 HUDSON 9 2. Switch the MEM. Channel to Channel 9 (with up or down arrow on chroma 7120) 3. The LCD-indicator on chroma 7120 will show x = 283 ±30, y = 297 ±30, Y>150cd/m2 (typ) 4. Adjust the RED on factory window until chroma 7120 indicator reached the value R=100 5.

  • Page 53: Monitor Exploded View

    HUDSON 9 15. Monitor Exploded View...

  • Page 54: Recommended & Spare Parts List

    HUDSON 9 54 54 16. Recommended & Spare Parts List 160VW9FB/78 Item Location Philips 12NC PCM Codes Description Remark FQ101 Q34G0273ABJB2B0130 BEZEL(L156W-8Q2) FQ405 Q33G0170ABJ 1L0100 KEY PAD FQ004 KEPC8QAD KEY BOARD ASSY FQ001 750GLM56B1112N PANEL M156B1-L01 NB CMO FQ003 PWPC8521MQCK...
  • Page 55 U102 056G 662 13 IC AZC099-04S SOT23-6L U103 056G 662 13 IC AZC099-04S SOT23-6L Service Kit Description Part No. Philips 12NC Remark DDC KIT 715L2005C2 9965 000 43197 FOR ALL MODEL OSD SN KIT 715GT033 C 9965 000 43252 FOR ALL MODEL...

  • Page 56: General Product Specification

    56 56 HUDSON 9 17. General Product Specification TABLE OF CONTENTS SCOPF 1.1 PRODUCT FEATURES 1.2 MAIN DIMENSIONS/WEIGHT 1.3 LOADING QUANTITY ELECTRICAL PERFORMANCE 2.1 STANDARD TESTING CONDITIONS 2.2 VIDEO-SINGALS 2.3 DDC SIGNALS 2.4 PRESET TIMING 2.5 DIGITAL CONTROL OPERATION 2.6 POWER SUPPLY 2.7 CONNECTORS/CONTROLS/INDICATORS 2.8 VESA DDC 2B VISUAL PERFORMANCE...
  • Page 57 HUDSON 9 QUALITY 9.1 DISPLAY DEFECT REQUIREMENTS 9.2 ACCESSORIES ONE AUDIO ELECTRICAL PERFORMANCE 10.1 STANDARD TESTING CONDITIONS 10.2 AMPLIFIER CHARACTERISTIC...

  • Page 58: Product Features

    58 58 HUDSON 9 This short specification describes the electrical, optical and functional performance requirements for a 395mm (15.6”) TFT LCD color monitor with VGA compatible interface. 1.1 Product Features 395mm(15.6”) a-si TFT Active matrix LCD panel, 0.252mm pixel pitch Microprocessor controlled scan technology 19 factory presets Vertical refresh rate 55Hz to 75Hz...

  • Page 59: Ddc Signals

    HUDSON 9 2.2.2 TTL Inputs (Sync-Signals) Level: L = 0V ~ 0.8V H = 2.4V ~ 5V Separate sync. Polarity: positive or negative The Monitor has to operate up to the following specified TTL-input signals < 200ns < 0.7V 2.4V 2.4V 0.8V 0.8V...

  • Page 60: Power Supply

    60 60 HUDSON 9 IBM Modes Horizontal Vertical 720x400@70Hz 900 x 449 31.469 70.087 28.322 640x400@70Hz 800 x 449 31.469 70.087 25.175 1024x768@72Hz 1304 x 798 57.515 72.1 75.000 MAC Modes 640x480@67Hz 864x525 35.000 66.667 30.240 SVGA 832x624@75Hz 1152x667 49.725 74.551 57.2832 1024x768@60Hz...
  • Page 61 HUDSON 9 2.7 Connectors/Controls 2.7.1 Connectors (for analog) Power : Monitor rear side : 3-pin IEC R, G, B, H, V /DDC : Monitor rear side / Data Cable : 15-pin D-sub Pin – Assignment of 15-pin D-sub: Red Video +5V Supply Green Video Logic Ground...
  • Page 62 62 62 HUDSON 9...
  • Page 63 HUDSON 9 2.7.2.2 The Description for Control Function: Main Main Sub Menu 2nd Sub Adjust Description Reset Value Menu Item Menu Icon Item Menu Item Range Contrast from Digital-register. Recall Warm Contrast Each step will 0-100 Contrast Value increase/decrease value by 1 Backlight Adjustment Recall Warm Brightness...
  • Page 64 64 64 HUDSON 9 Each step will increase/decrease value by 1 Red/Blue Gain from Digital-register. User-M 0-100 Each step will increase/decrease value by 1 Full Enhance Full Enhance ON/OFF Recall OFF Value Nature Skin Red Gain from Digital-register. ON/OFF Recall OFF Value Green Gain from Color Green Field...
  • Page 65 HUDSON 9 2.7.2.3 OSD Message: △ Outline: Auto Config OSD Input Not Supported OSD Cable Not Connected OSD No Signal OSD (LOGO color : R=255, G=255, B=255) △ The description for OSD Message Item Description When Analog signal input, if User Press Hot-Key “Auto”, will show this message, and the Auto Config monitor do the auto configuration function.

  • Page 66: Vesa Ddc2B

    66 66 HUDSON 9 2.8 VESA DDC2B This monitor is equipped with VESA DDC2B according to VESA DISPLAY DATA CHANNEL STANDARD V.1.0 Rev.1 (tt.mm.199j). As an alternative, it sends the EDID-File upon request by the host-system (Read EDID, Device A0h Start address 00h) in an I C compatible format (DDC 2).

  • Page 67: Picture Size And Centering

    HUDSON 9 3.2 Picture Size and Centering The display is centered with respect to the front bezel opening with a tolerance of 0.5mm. 3.2.1 Position Control Range The picture position can be adjusted that a complete picture can be displayed centered. 3.2.2 Max.

  • Page 68: White Color Coordinates

    68 68 HUDSON 9 3.4 White Color Coordinates 6500 7300 9300 SRGB 0.313 0.302 0.283 0.313 0.329 0.318 0.297 0.329 >150 >150 >150 >150 The measurement position is the center of the display (5). Brightness, Contrast set to reset. The tolerance of the color coordinates should be less than ± 0.030. 3.5 White Color Uniformity The deviation to the white color coordinates at the 5 position 1….4 should not exceed ±...

  • Page 69: Instruction Manual

    HUDSON 9 4.4 Instruction Manual Languages : 8 Language selected (English, Chinese Simplify) (Only for reference, According to the customer's demand!) Colors : Black on white only Size : DIN A5 Paper : Recycled paper (inside and outside) Packed : Brown or clear paper envelope (PE bag) 4.5 Guarantee Card Packed : Together with instruction manual...

  • Page 70: Environmental

    70 70 HUDSON 9 7.2.1 The model is designed to reach following approvals: EN 55022 Class B and E 55024 FCC Class B part 15 Requirements Test procedures Standards Remarks Frequency range EN55022 Class B Conducted emission 150KHZ～30MHZ FCC Part15，Class B EN55022 Class B 30MHZ~1GHZ 30MHZ~2GHZ...

  • Page 71: Environmental Conditions (Mechanical)

    HUDSON 9 Temperature -20°C ~ + 60°C Relative Humidity 5% ~ 85% Absolute Air Humidity 1 ~ 25 g/m Max. Change of Temperature 0.5°C/min. (max. 10°C/30min.) Air pressure 700~1060 mbar (70~106Kpa) Radiation Solar heat 700 W/m Transport (according to IEC 721 / EN 60721 Class 2K2): (packed for a short time*) Temperature -20°C ~ + 60°C Relative Humidity...
  • Page 72 72 72 HUDSON 9 8.2.2 Storage and Transport ( according to IEC 721/EN60721 Class 2Ms) Test Procedure IEC 68/EN 60068 Freq. range 5~10 10~100 100~500 Change db/oct Vibration Spectral 0.75 (random vibration) IEC 68-2-64 Accel. RMS 11.4 EN 60068-2-64 Axis Duration/Axis Minutes Pulse...
  • Page 73 HUDSON 9 Accessories One: THE COMPARISON FORM OF VARIOUS PANELS’ PARAMETER Luminance Response Viewing Parameter of white Contrast Time angle (Units:Cd/m ratio (Units: (Units :degree) Typic Typic H-left H-Right V-Up V-Down Panel (Typ) (Typ) (Typ) (Typ) ical 750GLM5 M156B1-L01 6B1112N Remark: Refer to other Panel SPEC about the parameter, please...
  • Page 74 4. When the HV circuitry is operating properly there is no possibility of an x- tube must be the same type as the original, including suffix letter, or a Philips radiation problem. High voltage should always be kept at the manufacturer's approved type.
