2. ADJUSTING THE TRIMMER

Adjusting the Height
1 Loosen the shaft
adjustment collar.
2 Extend to the
desired height and
then retighten the
shaft adjustment
collar to secure in
place.
Adjusting the Cutter Head
The grass trimmer head has 2 adjustments to allow for the
optimal angle and position for grass trimming or edging.
Head Tilt
1 Press and hold the head tilt
button.
2 Tilt the cutter head to the
desired angle.
3 Ensure the head has
clicked into a secure
position before operating.
Head Angle
1 Pull the telescopic shaft
away from the cutter head.
2 Rotate the head into the
desired position.
3 Ensure the head has
clicked into a secure
position before operating.
Adjusting the Handle
1 Release the adjustable
handle lever.
2 Rotate the handle
into the desired
position and then
lock in place with
the lever.
Attaching a Blade
1 Place the big hole in the
blade onto the blade mount
on the bottom of the
spindle plate.
2 Pull the blade
outwards so that the
small hole is fitted
into the mount.
3 To remove the blade push
the blade towards the
centre of the spindle and
then slide off.
