Sharp ER-A520 Programming Manual

Electronic
Hide thumbs Also See for ER-A520:

Advertisement

Quick Links

Download this manual See also: Service Manual, Instruction Manual
q
ER-A520
CHAPTER 1. SERVICE (SRV) MODE . . . . . . . . . . . . . . . . . . . . . . 1 - 1
CHAPTER 3. SERVICE MODE PROGRAMMING . . . . . . . . . . . . . 3 - 1
CHAPTER 4. OP X/Z, X1/Z1, X2/Z2 MODE . . . . . . . . . . . . . . . . . . 4 - 1
* For settings related to the USER PROGRAMMING mode, please refer to the
applicable Instruction Manual provided for the ER-A520 and ER-A530 model
cash registers.
Parts marked with "!" are important for maintaining the safety of the set. Be sure to replace these parts with specified
ones for maintaining the safety and performance of the set.

PROGRAMMING MANUAL

ER-A530
CONTENTS
SHARP CORPORATION
CODE : 00Z
ELECTRONIC

CASH REGISTER

ER-A520
ER-A530
MODEL
(For "U/A" version)
ERA520UPME
This document has been published to be used
for after sales service only.
The contents are subject to change without notice.

Advertisement

loading

Related Manuals for Sharp ER-A520

Summary of Contents for Sharp ER-A520

  • Page 1: Programming Manual

    CHAPTER 4. OP X/Z, X1/Z1, X2/Z2 MODE ....4 - 1 * For settings related to the USER PROGRAMMING mode, please refer to the applicable Instruction Manual provided for the ER-A520 and ER-A530 model cash registers.

  • Page 2: Chapter 1. Service (Srv) Mode

    CHAPTER 1. SERVICE (SRV) MODE ■ PROGRAM RESET A SRV-key is required to perform the 2 types of RESET procedures: MASTER RESET : Clears the entire memory and resumes Please use “Procedure A”, “Procedure B” or “Procedure C” initial values. Prodecure A: 1) Set the mode switch to the (SRV’) position.

  • Page 3: Chapter 2. Reading Of The Srv Mode Program

    CA/AT File allocation report SSP report Note: Program reports are printed on the RECEIPT & JOURNAL. * This following sample program readings are based on the ER-A520. [JOB# 900] Reading the contents of the SRV mode programming Key operation. @/FOR...
  • Page 4 [JOB# 951] Reading the contents of the SRV mode programming for FREE KEY LAYOUT setting. (Dept. & PLU keys) Key operation @/FOR CA/AT Date/Time/Cashier code Machine No./CC-No./Cashier name Cashier code/Cashier name Job code Key No./Key label/Location No. ER-A520U/A530U Reading of the SRV mode program 2 –...
  • Page 5 [JOB#990] Reading the contents of the SRV mode programming for the SSP set- tings. Key operation @/FOR CA/AT Date/Time/Cashier code Machine No./CC-No./Cashier name Cashier code/Cashier name Job code 520/530U 520/530U SSP No. (Reading report only) ER-A520U/A530U Reading of the SRV mode program 2 –...

  • Page 6: Chapter 3. Service Mode Programming

    2ID (3ID) + 2DD Allowed 1ID (2ID) + 3DD Note: The ★ mark indicates the MRS default setting. #903-D: 1. Food stamp system [JOB#901] ER-A520: MRS = 0002 1. Food stamp system 903-D ER-A530: MRS = 0002 ★ No food stamps #901-A: Not used (Fixed at “0”)
  • Page 7 [JOB#905] ER-A520: MRS = 0005 [JOB#906] ER-A520: MRS = 0021 ER-A530: MRS = 0005 ER-A530: MRS = 0021 #905-A: 1. Taxable 4 subtotal printing on X/Z report. #906-A: 1. Printing of Dept. and PLU/UPC (EAN) codes 2. Gross Tax 4 and refund Tax 4 total print on X/Z report.
  • Page 8 [JOB#907] ER-A520: MRS = 0010 #908-C: 1. Void mode adds to the Hourly Report totals ER-A530: MRS = 0010 2. X1/Z1 report at X2/Z2 mode #907-A: Not used (Fixed at “0”) 3. Resetting of consecutive number in Z1 #907-B: 1. UPC (EAN) code printing on journal 1.
  • Page 9 [JOB#910] ER-A520: MRS = 0204 [JOB#912] ER-A520: MRS = 0061 ER-A530: MRS = 0204 ER-A530: MRS = 0060 #910-A: 1. Overlapped server/cashier function #912-A: 1. Date print format Date format 912-A 1. Overlapped server/cashier function 910-A ★ Month/Day/Year ★ Day/Month/Year...
  • Page 10 [JOB#913] ER-A520: MRS = 0104 [JOB#914] ER-A520: MRS = 3100 ER-A530: MRS = 0104 ER-A530: MRS = 1100 #914-A: 1. Receipt issuing at no-sale #913-A: 1. Validation Total amount contents 2. [NS] key is separate separation from [CA/AT] key for no-sale 1.
  • Page 11 [JOB#916] ER-A520: MRS = 1400 [JOB#917] ER-A520: MRS = 0000 ER-A530: MRS = 1400 ER-A530: MRS = 0000 #916-A: 1. Print format when text and amount overlaps each other in #917-A: 1. Printing of Taxable 1 subtotal on the General X/Z report REG mode 2.
  • Page 12 Skip Print Skip Skip Compulsory [JOB#918] ER-A520: MRS = 2000 #919-D: 1. Conversion SBTL printing of native SBTL ER-A530: MRS = 2000 2. Foreign currency format #918-A: 1. Printing the text of a tied PLU in set PLU 1. Conversion SBTL print 2.
  • Page 13 Printed Check & Credit #922-C, D: Not used (Fixed at “00”) [JOB#923] NOT USED ER-A520: MRS = 0000 ER-A530: MRS = 0000 #928-C: 1. Printing of PLU on BILL/SLIP when it is $0.00 2. Printing the text of a tied PLU of a set PLU on BILL/SLIP [JOB#924] NOT USED ER-A520: MRS = 0000 1.
  • Page 14 [JOB#929] ER-A520: MRS = 0000 [JOB#942, 943, 969] ER-A520: MRS = 0000000000000 ER-A530: MRS = 0000 ER-A530: MRS = 0000000000000 #929-A: 1. Media Key KP print format when finalizing (Expeditor) GT COUNTER PRESETTING 1. Media Key KP print format when finalizing 929-A ★...
  • Page 15 [JOB#951] MRS = STANDARD KEY LAYOUT KEY TEXT FUNCTION (8 Char.) Free key layout (Direct department keys and PLU keys) TAX2 SHIFT T A X 2 S F TAX3 SHIFT T A X 3 S F Key number is manually entered TAX4 SHIFT T A X 4 S F...
  • Page 16 ER-A520/A530 KEYBOARD KEY POSITIONS KEY TEXT FUNCTION (8 Char.) ■ ER-A520 FINAL F I N A L DEPOSIT D E P O RECEIPT JOURNAL DEPOSIT REFUND D E P . R F FS TEND F S T E N D...
  • Page 17 [JOB#996, 998] RAM DATA BACKUP function FILE TABLE (ECR ECR: 01FD/02FD.exe Protocol) GROUP FILE TABEL NO. FILE NAME TYPE NUMBER (CREATE/ERASE) • Sending ECR RAM data DEPT ALL DATA @/FOR CA/AT DEPT TEXT (8) DEPT TEXT (16) SSR data only PLU/UPC PLU/UPC PRICE 1 •...
  • Page 18 1 = Euro symbol JOB#, PACKET NO. MRS = 0 (Space) [JOB#986] ER-A520: MRS = “ $” At the end of the job, one of the following messages is printed. ER-A530: MRS = “ $” • Normal termination of a send operation...
  • Page 19 SERVER (ALL) CCD ENTRY * 2, * 5, * 7 SERVER (INDIVIDUAL) CCD ENTRY SERVER CODE, CCD ENTRY * 6, * 7 HOURLY (ALL) HOURLY (RANGE) TIME DAILY NET ER-A520/ER-A530 REPORT MODES (OP X/Z, X1/Z1 and X2/Z2) 4 – 1...

  • Page 20: Chapter 4. Op X/Z, X1/Z1, X2/Z2 Mode

    JOB# @/FOR DATA CA/AT Resetting Reading Assigned server/cashier (Z report) JOB# SERVER CODE @/FOR CA/AT (DATA): GROUP No. (2 digit) Resetting 4 digit DEPT CODE (2 digit) ER-A520/ER-A530 REPORT MODES (OP X/Z, X1/Z1 and X2/Z2) 4 – 2...
  • Page 21 <Print sample of Report cancel> For example: Consecutive number: The counter is incremented by one. Z report: Data is reset to zero. 1 the report cancel symbol 123456789012345678901234 ER-A520/ER-A530 REPORT MODES (OP X/Z, X1/Z1 and X2/Z2) 4 – 3...
  • Page 22 © COPYRIGHT 2004 BY SHARP CORPORATION All rights reserved. Printed in Japan. No part of this publication may be reproduced, stored in a retrieval system, or transmitted. In any form or by any means, electronic, mechanical, photocopying, recording, or otherwise, without prior written permission of the publisher.

This manual is also suitable for:
