4 DIAGNOSTICS
Field
ID
LO

Memory Configuration

This diagnostic displays the DCX3200 memory configuration. The information is updated
when you display the diagnostic.
The Memory Configuration fields are:
Field
System RAM
Flash
NVRAM

Audio/Video Status

Audio/Video Status diagnostics display information regarding audio and video content
and settings configured for the set-top.
Description
DIS-NOT RUN Disabled_Not_ Runnable
DELETING Deleting
POSTPONED Postponed
CONNECTED Connect
PEND CONNECT TryingToConnect
The object identifier
The Local Origination states whether the object is located locally on the set-
top.
Description
The allocated system RAM in MB
The allocated flash memory in MB
The allocated NVRAM in KB
Object is disabled and cannot
run
Object is being deleted
Object cannot run on the
current system; it will be
enabled during the next boot
Connected to download PID
— awaiting data
Trying to connect
48
