Replacing The Oven Light Bulb - Bosch HMT35M653B Instruction Manual

Replacing the oven
light bulb
28
The oven light bulb is replaceable. Heat resistant 25
V, 240 W halogen bulbs can be obtained from the
after sales service or a specialist retailer.
Always remove the new halogen bulb from the
packaging using a dry cloth. This increases the
service life of the bulb.
1. Unplug the appliance from the mains or switch off
the circuit breaker in the fuse box.
2. Open the appliance door.
Undo the two screws from the right and left of the
oven.
3. Place a tea towel in the cold oven to prevent
damage.
Carefully lift out the appliance.
4. Undo the screw from the lamp cover on the
left hand side wall and remove the cover. (Fig. A)
Pull out the halogen bulb. (Fig. B).
5. Insert the new halogen bulb. (Fig. C)
6. Screw the lamp cover in place.
Reassemble the appliance in the reverse order.
7. Remove the tea towel. Switch the circuit breaker in
the fuse box back on or plug in the mains plug.
