Specifications - YORKVILLE ef500p Service Manual

Active or Passive
Program Power (Watts)
Biamp Operation Only
Frequency Response (Hz +/- 3db)
Crossover Frequency (Hz)
Driver Configuration
HF Program Power (Watts)
HF Impedance (ohms)
HF Dispersion (degrees-H x degrees-V)
LF Program Power (Watts)
LF Impedance (ohms)
Total Power (Watts)
HF Power Amplifier (Watts)
HF Amplifier Type
LF Power Amplifier (Watts)
LF Amplifier Type
Inputs - 1/4-inch Jacks
Input Impedance (Bal/UnBal)
Input Sensitivity (Vrms Sine)
Included Hardware
Pole Mount Adapter (1 3/8-inches/3.5 cm)
Enclosure Materials
Covering / Finish
Optional Covering / Finishes
Dimensions (DWH x back W, inches)
Dimensions (DWH x back W, cm)

Specifications

2-Way
System Type
Active
800
Yes
Biampable
Yes
127
Max SPL (dB)
50 - 16k
2100
15 inch, 2 inch
2 inch, ceramic magnet, 3 inch Titanium voicecoil
HF Driver(s)
150
8
60x40
Thermal / Peak Limiter
HF Protection
15 inch ceramic magnet, 4 inch voicecoil
LF Driver(s)
650
8
Thermal / Peak Limiter
LF Protection
800
150
Class H
650
Class D
Yes
Power Cable
Yes
Power Switch
2 line inputs, 2 link (in/out)
1 mic, 2 link (in/out)
Inputs - XLR
95KOhms / 90kOhms
+4dBv / 1.23V (+/-6dB with trim control)
+/- 6dB Trim control Mic Input w/level 2x 1/4" Line Input
Mixer Controls
Black Metal
Corners
Plastic Glides
Feet
3/8 inch x 9 (All Corners)
2 Side
Bar Handles
1 Bottom
3/4 inch 7-ply Spruce
Heavy gauge perforated metal
Grille
Black Ozite (Carpet)
Black Ultrathane Paint (EF500PB) 18mm Birch
14.5 x 18.6 x 28.2 x 11.1
71.6 x 36.8 x 47.2 x 28.1
89 / 40.4
Weight (lbs/kg)
