Colour CCTV Camera

Operating Instructions

WV-CS850B
Model No.
WV-CS854BE
Before attempting to connect or operate this product,
please read these instructions carefully and save this manual for future use.

Advertisement

Table of Contents
loading

Related Manuals for Panasonic WV-CS850B

Summary of Contents for Panasonic WV-CS850B

  • Page 1: Operating Instructions

    Colour CCTV Camera Operating Instructions WV-CS850B Model No. WV-CS854BE Before attempting to connect or operate this product, please read these instructions carefully and save this manual for future use.
  • Page 2 Model No. WV-CS850B/CS854BE Serial No. WARNING: To prevent fire or electric shock hazard, do not expose this appliance to rain or moisture. The apparatus shall not be exposed to dripping or splashing and that no objects filled with liquids, such as vases, shall be placed on the apparatus.

  • Page 3: Table Of Contents

    CONTENTS PREFACE .......................... 4 FEATURES ........................4 I Camera Cleaning ....................... 5 I Preset Data Uploading or Downloading ..............5 PRECAUTIONS ......................... 5 CONSTRUCTION ......................7 SETUP ..........................8 I Setup Menu ....................... 8 I Setup Menu Description .................... 11 SETTING PROCEDURES ....................

  • Page 4: Preface

    PREFACE Panasonic presents highly advanced CCTV technology A newly developed 1/4-inch CCD is employed for use that meets the demands of new and ever-changing under extremely low light conditions: 0.06 lx for mono- applications. chrome and 1 lx for colour.

  • Page 5: I Camera Cleaning

    • Uploading of WV-CS850B Series preset data to To download the preset data from the camera to the other models (e.g. WV-CS850 Series, WV-CS850A controller or upload the downloaded data to the cam- Series, WV-CS320 Series and WV-NS320 Series) era, set the following functions to OFF.
  • Page 6 9. Do not operate the camera beyond the specified 14. Prevention of blooming and smear temperature, humidity or power source ratings. When the camera is aimed at a bright light source, Do not use the camera in an extreme environment such as a spotlight, or a surface that reflects bright where high temperature or high humidity exists.

  • Page 7: Construction

    Alarm Input Connector y Camera Mounting Base w Alarm Output Connector u Panning Start Point e Video Output Connector i Fall Prevention Wire r Data Port o Decoration Cover t Power Cable for WV-CS850B !0 Dome Cover t* Power Cable for WV-CS854BE...

  • Page 8: Setup

    SETUP I Setup Menu Setup menus are shown in the diagram below. You can adapt the camera to your requirements by setting up the respective items in these menus. Menus are incorporated in a hierarchical structure, from the setup menu at the top to manual mask area selection at the bottom.
  • Page 9 Position Setting (P. 16) Preset ID Editing (P. 16) Manual Level Adjustment Preset Identification Setting Super-D2 OFF (P. 33) (Contrast) (P. 34) (P. 18) Manual Mask Area Selection Super-D2 ON (P. 33) Light Control Setting (P. 19) (P. 33) Manual Iris Adjustment (P. 33) Dwell Time Setting (P.
  • Page 10 The keys (switches) to be used for setup are shown in the table below. The joystick on the connected controller may also be used for setup. The table also shows the functions and the operations of the individual controllers. For details, see the manual for the controller to be used.

  • Page 11: I Setup Menu Description

    I Setup Menu Description SQ: Starts the sequence function. SR: Starts the sort function. G Presetting PT: Starts the patrol function. (1) Position (POSITION SET) See page 21 for the setting. Aligns the camera position and focal point by pan- ning, tilting, zooming and focusing.
  • Page 12 (2) Proportional Pan-Tilt Speed (PROPO. P/T) (9) Image Hold (IMAGE HOLD) If ON is selected, the pan-tilt speed changes auto- The camera picture remains as a still image on the matically corresponding to the zoom ratio. For monitor screen or until the camera reaches the pre- example, the pan-tilt speed slows down when the set position.
  • Page 13 Generally, when a light from the background is too (6) Synchronization (SYNC) strong such as a spotlight, all objects except the You can select the internal sync (INT) mode or the main object in the picture are displayed darker line-lock sync (LL) mode. Additionally, this model because the lens iris is adjusted with respect to accepts the VD2 signal from a specified component.

  • Page 14: Rs485 Communication

    (9) Auto Focus (AF MODE) The camera adjusts the focus automatically by sens- ing the centre of the picture. S, M and L stand for the size of the sensing area: Small, Middle and Large. See page 38 for details. MANUAL S, M, L: Auto-focus is activated only when the AF key on the controller is pressed.

  • Page 15: Setting Procedures

    SETTING PROCEDURES G Submenu Display The following setting procedures are described on the assumption that this model is used in combination with The items marked O can be selected/changed on the WJ-SX550C Matrix Switcher WV-CU550C/CJ submenu. System Controller. In case a controller other than WV- CU550C is used, refer to the table on page 10.

  • Page 16: I Preset Menu

    I Preset Menu Notes: • The * mark indicates that the position number G Preset Menu Display has been preset. 1. Displaying the preset menu directly • The character H refers to the home position. (1) Move the cursor to PRESET 1 O and select the •...
  • Page 17 CS850B’s. WV-CS850B’s preset data will be PAN OFFSET SET ← −0.0 → destroyed if you upload the conventional data. If this happened, reset the WV-CS850B to the default settings. Download the factory settings FLOOR1 DOOR into the controller and upload the correct preset data newly to the initialized WV-CS850B.
  • Page 18 G Preset Identification Setting (PRESET (2) Display the most prospective ID. (3) Follow the step "To Change an Entered Preset ID" if necessary. 1. Move the cursor to PRESET ID on the preset setting menu and select ON or OFF with the joystick. To Change an Entered Preset ID The factory default setting is OFF.
  • Page 19 ** MANUAL CONT ** IRIS ••••|•••• CLOSE OPEN FLOOR 1 DOOR To Enter the Next ID without Returning to the G Dwell Time (DWELL TIME) Preset Setting Menu (1) In the preset ID setting menu, move the cursor • Move the cursor to DWELL TIME and set a dwell to the top line and select a desired position time with the joystick.

  • Page 20: I Deleting Preset Positions

    I Deleting Preset Positions See the pages below for the settings respectively. Shutter speed: page 34 1. Move the cursor to PRESET 1 and select the posi- AGC: page 34 tion number to be deleted with the joystick. Electronic sensitivity enhancement: page 34 White balance: page 36 Motion detector: page 37 ** SET UP MENU **...

  • Page 21: I Home Position Setting (Home Position)

    I Home Position Setting (HOME I Auto Mode Selection (AUTO POSITION) MODE) 1. To set a position number for the home position 1. To set auto mode Move the cursor to HOME POSITION and select a Move the cursor to AUTO MODE and select a mode desired position number with the joystick.
  • Page 22 This determines the starting point and the cursor OFF: The camera pans from the starting point to moves to END. the endpoint, and rotates backward to the start- ing point. This movement is repeated over and over. ** AUTO PAN ** POSITION START 6.

  • Page 23: I Auto Pan Key Setting (Auto Pan Key)

    AUTO PAN: Assigns the auto panning function to (2) Move the cursor to ZOOM, press the CAM (SET) the key. key, move the joystick to settle the ZOOM posi- SEQ: assigns the SEQUENCE function to the key. tion and return to the AUTO PAN menu. The SORT: assigns the SORT function to the key.
  • Page 24 G Password Lock (PASSWORD LOCK) 3-5 To return to the SET UP MENU menu without verifying the password, move the cursor to RET, Caution: For security, do not operate your VTR for and press the CAM (SET) key. recording while the password menus are displayed on the monitor.

  • Page 25: I Special 1 Menu Setting (Special 1)

    I Special 1 Menu Setting • The privacy zone may appear on the monitor screen depending on the direction of the camera. (SPECIAL 1) • The privacy zone function will not work at start-up G Privacy Zone (PRIVACY ZONE) immediately after turning the power on. Up to 8 unwanted zones can be masked on the moni- 3.
  • Page 26 G Area Title (AREA TITLE) ** ZONE NUMBER 3*/8 ** →PUSH SET PAN/TILT Up to 8 area titles can be added in specific positions. →PUSH SET ZOOM/FOCUS 1. Select ON (NESW), ON (USER) or OFF with the joy- stick. ZONE SCALE ••••|••••...
  • Page 27 3. Move the cursor to PUSH SET for ZOOM/FOCUS, ** AREA TITLE(USER) ** and press the CAM (SET) key. ZOOM/FOCUS is NORTH highlighted and "U ZOOM D/L FOCUS R" appears. EAST SOUTH-EAST SOUTH SOUTH-WEST ** DIRECTION(NESW) ** NORTH-WEST →PUSH SET PAN/TILT →PUSH SET ZOOM/FOCUS...
  • Page 28 To Quit Editing • IMAGE HOLD • To return to the AREA TITLE menu, move the cursor • AREA TITLE to RET, and press the CAM (SET) key. • DIGITAL FLIP • To cancel one area title, move the cursor to RESET •...
  • Page 29 G Alarm Input/Output (ALARM IN/OUT) 3. Open the SET UP menu to stop learning. Notes: Move the cursor to ALARM IN/OUT, and press the CAM • It is recommended to set PAN LIMIT to ON for (SET) key. The ALARM IN/OUT submenu appears. patrol-learn.
  • Page 30 G Cleaning (CLEANING) CNT-CLS 1, 2 (Output) Two contact closure signals (Open collector type) are With CLEANING in the ON position, the camera’s built- output through the Alarm Output connector. in electromechanical contacts are cleaned at regular intervals (approx. every 7 days). 1.
  • Page 31 G Image Hold (IMAGE HOLD) ON: 10 - fold electronic zoom is available with the ZOOM switch on the controller. The camera picture remains as a still image on the OFF: The electronic zoom function is not used. monitor screen until the camera reaches the preset Notes: position.

  • Page 32: I Camera Setting

    I Camera Setting CAMERA ID 0123456789 G To Display the Camera Setting Menu ABCDEFGHIJKLM NOPQRSTUVWXYZ Move the cursor to CAMERA O, and press the CAM ().,'":;&#!?= +-*/%$ÄÜÖÆÑÅ (SET) key. The camera setting menu appears. SPACE POSI RET RESET CAM1.... ** SET UP MENU ** PRESET 1 HOME POSITION 3-2 Decide the position of the camera ID with the...
  • Page 33 G Light Control Setting (ALC/MANUAL) (2) ALC Mode with SUPER-D2 OFF 1. Move the cursor to SUPER-D2 and select OFF. 1. Move the cursor to ALC/MANUAL and select ALC (When you select MANUAL, SUPER-D2 is not avail- or MANUAL with the joystick. When you select ALC, able.) MASK SET appears on the menu.
  • Page 34 6. If you want to change the picture contrast, move the • In the AUTO mode, an object is clearly imaged "I" cursor for LEVEL and adjust the level. under highlighted conditions by using the combina- tion technology of iris and shutter functions. Note: When the selected shutter speed caused ** ALC CONT ** flicker on condition that fluorescent lamps stay...
  • Page 35 • When ON is selected for SUPER-D2 on the ALC ** SET UP ** CONT menu CAMERA ID ALC/MANUAL SHUTTER AUTO ON(MID) X2 AUTO X4 AUTO X6 AUTO X10 AUTO SENS UP SYNC WHITE BAL ATW1 X32 AUTO X16 AUTO MOTION DET AF MODE AUTO L...
  • Page 36 8. Match the vertical phase for both video output sig- 2. For fine adjustment of ATW1/ATW2, press the CAM nals as closely as possible with the joystick. (SET) key. The ATW1/ATW2 fine adjustment menu appears on the monitor screen. ** SYNC ** V PHASE ** ATW1 ** COARSE...
  • Page 37 G Motion Detector (MOTION DET) 8. Dwell Time Move the cursor to DWELL TIME, and select a time 1. Move the cursor to MOTION DET and select ON or with the Joystick. OFF with the joystick. When the time specified here elapses after motion detection, the camera will notify the connected device of the alarm activation.
  • Page 38 For WV-RM70, hold down the right and left Therefore, when this camera is not used in a switches simultaneously for 2 seconds or more. Panasonic Intelligent CCTV System, select OFF to prevent the above from occurring. ** SET UP **...
  • Page 39 Note: Selecting the colour mode is disabled if NORMAL: Sets the horizontal resolution to more ALARM IN 4 is set to B/W on the special 1 than 480 lines. menu. HIGH: Sets the horizontal resolution to more than 2. If you have selected AUTO, press the CAM (SET) 510 lines.
  • Page 40 • PIX OFF Setting (PIX OFF) ** SPECIAL2 ** CHROMA GAIN – •••• •••• In this setting, you can assign a blemish position AP GAIN – •••• •••• and compensate the blemish. PEDESTAL – • ••••••• 1. Move the cursor to PIX OFF and press the CAM RESOLUTION NORMAL LOW2...

  • Page 41: I Rs485 Setup

    NOT USE). The factory default setting is NOT USE. protocol and parameters prior to setting the communi- cation parameters for the camera. The initial communication parameters for WV-CS850B Wait Time (WAIT TIME) and WV-CS854BE are shown on the RS485 setup Specifies the time to wait until retrying after confirming menu below.

  • Page 42: Factory Default Setting

    Factory Default Setting Menu Item Setting Menu Item Setting HOME POSITION PRESET ID TOP MENU PRESET MENU SELF RETURN ALC/MANUAL AUTO MODE SUPER-D2 AUTO PAN KEY AUTO PAN DWELL TIME DIGITAL FLIP SCENE FILE PASSWORD LOCK PRESET SPEED • • • • • • • • SPECIAL 1 PRIVACY ZONE SCENE FILE...

  • Page 43: Installation

    INSTALLATION Precautions • The following steps of installation and connection work should be done by qualified service personnel or sys- tem installers and should conform to all local codes. • Be sure to switch the camera off before installation and connection. •...
  • Page 44 8-bit DIP SW Switch 1, an 8-bit DIP switch, specifies the unit number or restores the factory default settings when using the Panasonic protocol. When the switch position corresponding to the unit number 1 - 96* is selected, setting should be made on the RS485 SET UP menu (see page 41).
  • Page 45 Unit Unit Unit Switch position Switch position Switch position number number number -45-...
  • Page 46 • Defaults are marked with *. • BP stands for Bit Position. • Full duplex is not available in a daisy chain connec- tion. (Panasonic system controllers only) 3. Assemble the Camera Reverse the disassembly procedure. Take care not to cut any cables.
  • Page 47 3. Hook the fall prevention wire on the camera mount- 5. Tighten the fixing screw M3 (provided). ing base. Notes: (1) Tighten the camera fixing screw with a screw- driver. (2) Follow the instructions given here to ensure that the camera and camera mounting base are installed safely.

  • Page 48: Connections

    • The following connections should be made by qualified service personnel or system installers in accordance with all local codes. • See the reverse side of the cover page for main lead connection. 220 V - 240 V AC (WV-CS850B) 24 V AC cable 24 V AC (WV-CS854BE)
  • Page 49 • RS485 Connection Brown T (B) Data transmission Orange T (A) Yellow R (B) Data reception Green R (A) Alarm OUT (4-pin) Note: Use the cable that is described below for RS485 Wire colour Function site communication. Grey OUT 1 •...

  • Page 50: System Connections

    SYSTEM CONNECTIONS Combination camera Max. 64 cameras Matrix Personal computer switcher RS-232C port Alarm inputs Printer System status monitor Digital Disk Recorder WJ-HD Digital Disk Recorder WJ-HD Digital Disk Monitors (up to 16) Recorder WJ-HD Digital Disk Recorder WJ-HD Digital Disk Recorder ALARM BUSY ALARM...

  • Page 51: Specifications

    SPECIFICATIONS WV-CS854BE WV-CS850B Effective Pixels 752 (H) x 582 (V) Scanning Area 3.65 mm (H) x 2.71 mm (V), 1/4 in. Synchronization internal/line-lock / multiplexed vertical drive (VD2) Horizontal Scanning 15.625 kHz Frequency Vertical Scanning 50.00 Hz Frequency 1.0 V [P-P] PAL composite/75 Ω...

  • Page 52: Accessories

    Panning Range 360 ° endless Panning Angle Setting possible (in auto-pan mode) Panning Mode manual/sequential position/sort position/auto pan manual : approx. 0.1 °/s - 120 °/s 8-steps/64-steps Panning Speed sequence position : maximum approx. 300 °/s Tilting Range 0 ° to 180 ° (–5 ° to 185 ° at 5 ° tilt angle setting) Tilting Mode manual/sequential position/sort position manual : approx.

  • Page 53: Appendix

    APPENDIX Shortcuts Shortcut operations are available for controllers having the CAM FUNCTION key. Entering from one to three digits with the numeric key(s) and pressing the CAM FUNCTION key will create a shortcut to the respective functions. The CAM FUNCTION key is abbreviated as [CAM FUNC] in the table below. Function Function Selecting a PRESET position From #1 to #64...
  • Page 54 Printed in Japan Gedruckt in Japan Imprimé au Japon Impreso en Japón Stampato in Giappone 在日本印刷 N0703-1083 3TR001738BAA 2003 © Matsushita Electric Industrial Co., Ltd. All rights reserved. ç‡Ô˜‡Ú‡ÌÓ ‚ üÔÓÌËË...
