Onkyo BD-SP309 Service Manual
  1. Manuals
  2. Brands
  3. Onkyo Manuals
  4. Blu-ray Player
  5. BD-SP309
  6. Service manual

Onkyo BD-SP309 Service Manual

Hide thumbs Also See for BD-SP309:

Advertisement

Quick Links

Download this manual See also: Instruction Manual
B CUP2BP
100~240V AC, 50/60Hz
B CUA4BP
B CUR6CP
B CUT3AP
120V AC, 60Hz
B CDC1AN
100~240V AC, 50/60Hz
S CUP2BP
S CUR6CP
NO Repair Parts Availavility.
BLU-RAY DISC PLAYER
BD-SP309(B)/(S)
MODEL
Black and Silver models
EU
AUSTRALIA/NEW ZEALAND
RUSSIA
HONG KONG/SINGAPORE/MALAYSIA/THAILAND/KOREA
US/CANADA
EU
RUSSIA
BD-SP309
Ref. No. 4289
042011
RC-825DV
RC-826DV
(CDC only)
(except CEC)

Advertisement

loading
Need help?

Need help?

Do you have a question about the BD-SP309 and is the answer not in the manual?

Questions and answers

Related Manuals for Onkyo BD-SP309

Summary of Contents for Onkyo BD-SP309

  • Page 1 BD-SP309 Ref. No. 4289 042011 NO Repair Parts Availavility. BLU-RAY DISC PLAYER BD-SP309(B)/(S) MODEL RC-825DV RC-826DV (CDC only) (except CEC) Black and Silver models B CUP2BP 100~240V AC, 50/60Hz B CUA4BP AUSTRALIA/NEW ZEALAND B CUR6CP RUSSIA B CUT3AP HONG KONG/SINGAPORE/MALAYSIA/THAILAND/KOREA...

  • Page 2: Service Procedure

    BD-SP309 SERVICE PROCEDURE - 1 This Player is classified as a CLASS 1 LASER product. The CLASS 1 LASER PRODUCT label is located on the rear cover. This product contains a low power laser device. To ensure continued safety do not remove any cover or attempt to gain access to the inside of the product.

  • Page 3: Important Service Notice

    BD-SP309 SERVICE PROCEDURE - 2 Service work should be performed only by qualified service technicians who are thoroughly familiar with all safety checks and the servicing guidelines which follow: WARNING Use an AC voltmeter having with 5000 ohm per volt, or higher, sen- sitivity or measure the AC voltage drop across the resistor.

  • Page 4: Upgrade Firmware

    BD-SP309 UPGRADE FIRMWARE Consult with your Services Company as we cannot provide the upgrading software. 1. Procedure with a CD 1. Write the updated software on a CD to prepare the version-upgrading CD. 2. Connect the set to the monitor with an HDMI cable. (Keep the HDMI cable connected until the version-upgrading has been completed.) 3.

  • Page 5: Exploded View

    BD-SP309 EXPLODED VIEW A010 A007 A008 Z001 BD DRIVE Unit A001 A013 U001 Except MAIN Unit A014 US, EU. U002 POWER Unit A004 A005 U003 A012 DISPLAYUnit x 3 pcs. A016 A003 A015 A012 A002 A006...
  • Page 6 BD-SP309 SCHEMATIC DIAGRAMS - 1 BLOCK DIAGRAM (MAIN)
  • Page 7 BD-SP309 SCHEMATIC DIAGRAMS - 2 MAIN1 2SA1530AR NOT USE Q7203 L7201 10uH J7201 TOTX177L Q7202 R7247 RT1N241C TL7204 R7250 TL7209 R7246 C7352 100u C7353 0.1u 6.3V TL7214 TO POWER AT_5V AT_5V MAIN_P-CON MAIN_P-CON D_3.3V D_3.3V D_GND D_GND TP7202 A_GND GPIO3 D_1.8V...
  • Page 8 BD-SP309 SCHEMATIC DIAGRAMS - 3 MAIN2 TO POWER DDR2 D_1.8V D_GND NOT USE FL7804 FL7810 NA119WJ NA119WJ R7810 FL7805 FL7811 D0CLKB MEM0_DCKB NA119WJ NA119WJ D0CLK R7811 MEM0_DCK R7812 C7802 D0ODT MEM0_DODT D0CKE R7813 MEM0_DCKE C7832 C7852 R7814 0.1u 0.1u D0BA2...
  • Page 9 BD-SP309 SCHEMATIC DIAGRAMS - 4 MAIN3 TO POWER NAND D_3.3V NOT USE D_GND IC8502 BOOT STRAP C8501 IXC598WJQZ R8507 0.1u 3.3K NDATA0 NAND_INFO[0] NAN_DATA0 NDATA1 NAND_INFO[1] NDATA2 NAND_INFO[2] NDATA3 NAND_INFO[3] R8508 R8501 3.3K NDATA4 NAND_INFO[4] NAN_DATA1 NDATA5 NAND_INFO[5] NDATA6 BOOT_MODE[0]...
  • Page 10 BD-SP309 SCHEMATIC DIAGRAMS - 5 MAIN4 To POWER NOT USE AT_12V AT_12V 6.8K 3.3K R2503 R2504 AT_5V AT_5V TO HDMI DRIVE_P-CON FR_HDMI_SDA MAIN_P-CON FR_HDMI_SCL SUB_SHORT_DET F_HDMI_HPD FR_CECIN_1 DRIVE_12V DRIVE_12V FR_CECOUT_1 D_GND FR_CECINOUT F_AT_3.3V TO EMMA3PF3 FRONT_RXD FRONT_RXD FRONT_TXD FRONT_TXD IC2504...
  • Page 11 BD-SP309 SCHEMATIC DIAGRAMS - 6 MAIN5 TO F-uCOM POWER DRIVE_12V AT_12V D_GND D9015 D9014 DRIVE_5V RB551V30 RB551V30 CONVERTOR: Q9012 C9031 C9032 RTQ035P02 C9039 DRIVE_P-CON 470P 100P 100u 6.3V MAIN_P-CON DRIVE_12V R9029 Q9014 270K SUB_SHORT_DET COMP C9027 RTQ035P02 Q9013 1000P IC9004...
  • Page 12 BD-SP309 SCHEMATIC DIAGRAMS - 7 MAIN6 HDMI TO POWER D_GND D_3.3V TO EMMA3PF3 AT_5V HDMI_SDA HDMI_SDA HDMI_SCL HDMI_SCL HDMI_HPD TO F_uCON HDMI_HPD HDMI_TXCP HDMI_TXCP F_AT_3.3V HDMI_TXCN HDMI_TXCN HDMI_TX0P HDMI_TX0P HDMI_TX0N HDMI_TX0N HDMI_TX1P HDMI_TX1P HDMI_TX1N HDMI_TX1N HDMI_TX2P HDMI_TX2P HDMI_TX2N HDMI_TX2N D_GND...
  • Page 13 BD-SP309 SCHEMATIC DIAGRAMS - 8 MAIN7 USB_Ether NOT USE TO POWER D_3.3V DRIVE_5V D_GND TO EMMA3PF3 USB_DM1 USB_DP1 C7019 C7018 L7001 SG7005 SG7006 220u 0.1u 6.3V FA112WJ R7015 R7013 Vout C7009 MP62055 BD6538G IC7004 USB_OCI1 IC7003 R7025 1.8K USB_PPON1 CN7001...
  • Page 14 BD-SP309 SCHEMATIC DIAGRAMS - 9 MAIN8 FRONT_END TO POWER DRIVE_12V L3001 NOT USE 4.7uH F3003 DRIVE_5V C3006 C3012 QFS-LA075WJPZY 0.1u DRIVE_3.3V D_GND SC3002 R3074 IC3001 R3075 NA480WJQZ AZ1117HA TL3001 VO7V R3076 R3077 TL3002 GNDO TL3003 R3002 GNDO FE_OEIC_SW2 TL3004 VO5V...
  • Page 15 BD-SP309 SCHEMATIC DIAGRAMS - 10 DISPLAY CIRCUIT DTA114YU (DUMMY) Q1303 R1352 R1302 R1304 RT1P141M 3.9K PAUSE PLAY STOP DTC144EU (DUMMY) STBY EJECT S1307 S1302 S1303 S1301 S1306 Q1304 K0003AJ K0003AJ K0003AJ K0003AJ K0003AJ RT1N441M R1315 R1317 R1351 R1303 R1373 R1372 12K F 2.2K F...
  • Page 16 Technical Support, Service Dept.: 2-1, Nisshin-cho, Neyagawa-shi, OSAKA 572-8540, JAPAN Tel: 072-831-8023 Fax: 072-831-8163 ONKYO U.S.A. CORPORATION 18 Park Way, Upper Saddle River, N.J. 07458, U.S.A. Tel: 800-229-1687, 201-785-2600 Fax: 201-785-2650 http://www.us.onkyo.com/ ONKYO EUROPE ELECTRONICS GmbH Liegnitzerstrasse 6, 82194 Groebenzell, GERMANY Tel: +49-8142-4401-0 Fax: +49-8142-4401-555 http://www.eu.onkyo.com/...
