Field
Aspect Ratio
HD/SD
HD Format
Wayside State
Wayside Baud
Audio A and Audio B
Type
Mode
Input
Auto-align Dolby E
Encryption
Type
1 Key
E Key
E ID
PID Info
PCR
AUD-A
DAT
AUD-B
VID
Default PID
Spectrum Polarity
3-8 Operating the PTX-PRO
When HD/SD is SD, you can choose 4:3 or 16:9. This field is inactive for
HD.
Choose HD or SD.
When HD/SD is HD, you can choose 720p50, 720p59, 720p60, 1080i25,
1080i29, or 1080i30.
Choose OFF, IRD Compatible, or Strata Compatible.
When Wayside State is not OFF, choose 1200, 2400, 9600, 19200, or
38400.
Choose OFF, MPEG or Dolby E.
CAUTION
When Type is not OFF, choose Stereo or Dual Mono.
When Type is not OFF, choose Test Tone, Analog, SDI EMB, or
AES EBU. (Note: Test Tone is used only for audio testing and antenna
alignment testing.)
When Type is Dolby E, you can check this box.
Requires a license. Select OFF, BISS - 1, or BISS - E.
If you selected BISS - 1, then also specify the BISS-1 key value.
If you selected BISS - E, then also specify the BISS-E key value.
If you selected BISS - E, then also specify the BISS-E identifier.
Specify a value (
32
Specify the Audio A value (
Specify the Data value (
Specify the Audio B value (
Specify the video identifier value (
Check this box to set the default values.
Select Normal or Reversed.
Option
If you choose MPEG or Dolby E, ensure
that Input is not set to Test Tone (unless
you mean to save a preset to use for testing
the audio or antenna alignment).
to ) for the Program Clock Reference (PCR).
8190
32 to 8190 ).
to ).
32 8190
to ).
32 8190
to
32 8190
