Service
Manual
MULTI-CD/DAB CONTROL HIGH POWER MD PLAYER WITH RDS TUNER
MEH-P7100R
MULTI-CD/DAB CONTROL HIGH POWER MD PLAYER WITH FM/AM TUNER
MEH-P7150
- This service manual should be used together with the following manual(s):
Model No.
Order No.
CX-683
CRT2441
- US and foreign patents licensed from Dolby Laboratories Licensing Corporation.
CONTENTS
1. SAFETY INFORMATION ............................................2
2. EXPLODED VIEWS AND PARTS LIST .......................3
4. PCB CONNECTION DIAGRAM ................................36
5. ELECTRICAL PARTS LIST ........................................49
6. ADJUSTMENT..........................................................63
PIONEER CORPORATION
PIONEER ELECTRONICS SERVICE INC.
PIONEER EUROPE N.V.
Haven 1087 Keetberglaan 1, 9120 Melsele, Belgium
PIONEER ELECTRONICS ASIACENTRE PTE.LTD. 253 Alexandra Road, #04-01, Singapore 159936
C PIONEER CORPORATION 2000
MEH-P7100R/EW
Mech. Module Remarks
MD-4
MD Mech. Module:Circuit Description, Mech.Description, Disassembly
4-1, Meguro 1-Chome, Meguro-ku, Tokyo 153-8654, Japan
P.O.Box 1760, Long Beach, CA 90801-1760 U.S.A.
ES
7. GENERAL INFORMATION .......................................67
7.1 DIAGNOSIS ........................................................67
7.1.1 TEST MODE ..............................................67
7.1.2 DISASSEMBLY .........................................71
7.2 IC ........................................................................74
7.3 OPERATIONAL FLOW CHART ...........................82
8. OPERATIONS AND SPECIFICATIONS.....................83
ORDER NO.
CRT2471
EW
K-ZZU. MAR. 2000 Printed in Japan
