Factory Decathlon SEA 83 Assembly Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
"Graphics and specfications may change without notice".

Specifications

Wingspan---------------------------------------- 78.7 in---------------------------- 200cm.
Wing area-------------------------------------- 1032.8 sq.in---------------- 66.6 sq.dm.
Approximate flying weight-------------------10.6 lbs-----------------------------4.8kg.
Length-------------------------------------------- 52.9in--------------------------- 134.4cm.
Recommended engine size---------------- .1.20 cu.in--------------------- 4-stroke.
Radio System required 4 channels with 6 servos
Flying skill level Intermediate/advanced.
Kit features.
•
Ready-made—minimal assembly & finishing required.
•
Ready-covered covering.
•
Photo-illustrated step-by-step Assembly Manual.
Made in Vietnam.
ASSEMBLY MANUAL
MS: 83

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Decathlon SEA 83 and is the answer not in the manual?

Questions and answers

Related Manuals for Factory Decathlon SEA 83

Summary of Contents for Factory Decathlon SEA 83

  • Page 1: Specifications

    MS: 83 ASSEMBLY MANUAL “Graphics and specfications may change without notice”. Specifications Wingspan---------------------------------------- 78.7 in---------------------------- 200cm. Wing area-------------------------------------- 1032.8 sq.in---------------- 66.6 sq.dm. Approximate flying weight-------------------10.6 lbs-----------------------------4.8kg. Length-------------------------------------------- 52.9in--------------------------- 134.4cm. Recommended engine size---------------- .1.20 cu.in--------------------- 4-stroke. Radio System required 4 channels with 6 servos Flying skill level Intermediate/advanced.
