- Page 1 KX6000S premium digital alcohol breath detector Please read this user manual before use. Result of this unit for reference only. Use ALKALINE batteries only. DO NOT DRINK AND DRIVE! Owner’s Manual...
-
Page 2: Components Diagram
The AlcoSafe KX6000S is a premium grade digital alcohol breath detector that quickly screens for the presence of alcohol in breath. The LCD-LED Dual display indicates the Blood Alco- hol Content (BAC) in forms of numeric result (LCD) and alert lights in Green/Yellow/Red (LED) for the test subject in seconds. -
Page 3: Installing The Batteries
Wait 20 minutes after the subject drinks, smokes or eats before testing. Failure to wait 20 minutes can give inaccurate BAC readings. Insert mouthpiece: Insert the KX6000S mouthpiece firmly into Step 1 the mouthpiece slot on the upper left hand side of the unit. - Page 4 Press Right button to show the last test record. Press Right button again to return to Welcome screen. Note: KX6000S stores a maximum of 64 test records. Refer to ‘Display test result records’ for guidance for retrieving previous test records...
- Page 5 Illustration of BAC result KX6000S detects BAC within the range 0.0 to 4.0 ‰BAC (i.e: 0.00 to 0.40%BAC or 0.00 to 2.00 mg/l). Different system alert messages would be displayed on different measured BAC level as below: LOW - Green LED light ‰BAC (g/l)
- Page 6 On Screen Menu - Navigation path On Welcome screen, Press Right button for 2 seconds to enter the menu structure of : - SET (Temperature display format, BAC display format, Alert level, Beep sound) - REC (Display test result record) - TEST (Display cumulative test count) - CAL (Calibration) SET temperature display format...
-
Page 7: Set Temperature Display Format
Set temperature display format KX6000S displays temperature in format of Celsius °C / Fahrenheit °F. The display format could be set as below: On Welcome screen, press Right button for 2 seconds. SET mode is displayed. Press Power button 1 time to enter SET mode for setting temper- ature display format. - Page 8 / 0.3 / 0.4 / 0.5 / 0.8 / 1.0 ‰BAC. Press Power button to confirm setting. Set beep sound when blowing KX6000S could be configured to give beep sound / no sound when blowing as below: On Welcome screen, press Right button for 2 seconds. SET mode is displayed.
- Page 9 Display test result records KX6000S stores BAC test results up to 64 records. The stored records could be recalled as below: On Welcome screen, press Right button for 2 seconds. SET mode is displayed. Again press Right button to enter the REC (Record) mode.
- Page 10 / importer disclaims any legal responsibil- ity for the measured test value. Calibration The KX6000S is calibrated during manufacture using advanced alcohol simulation equipment. Known alcohol concentrations are passed through the sensor to set baseline values for testing. During testing, the unit compares users’ breath samples to these baseline values.
-
Page 11: Error Messages
Error messages Error message Cause and Course of Action This message means insufficient or uneven blowing is detected. Repeat ‘HOW TO USE’ steps 2 – 6. This message means Sensor Not Ready (Snr) and the unit needs another warm-up / autocleansing. It occurs when REP + Snr the unit has not been used for long time / occurs when there is alcohol residue on the sensor. -
Page 12: Specifications
Specifications BAC Detection Range 0.0 to 4.0 ‰BAC (i.e: 0.00 to 0.40%BAC or 0.00 to 2.00 mg/l) Accuracy +/- 0.1 ‰BAC or +/- 0.01 %BAC at cal. point Warmup Between 20-60 seconds Response time 5 seconds Sensor Premium Sensitive Semiconductor Operating temperature 10 - 40°C (50 - 104°F) Display panel... - Page 13 Don’t Risk It, Know Your Limit. Do Not Drink And Drive! KX6000S...
