Summary of Contents for Motorola DSR315

  • Page 1 DSR315 User Guide...
  • Page 2 (such as translation, transformation or adaptation) without written permission from Motorola, Inc. Motorola reserves the right to revise this publication and to make changes in content from time to time without obligation on the part of Motorola to provide notification of such revision or change.

  • Page 3: Important Safety Instructions

    Do not place near heat sources such as radiators, stoves, or other products (including amplifiers) that produce heat. DSR315 User Guide The exclamation point within an equilateral triangle is Before you operate the unit, read and...
  • Page 4 Regulatory Do Not Operate near Water. bath tub, wash bowl, kitchen sink, swimming pool, laundry tub, in a wet basement, or in similar situations. Objects or Liquid in the Unit. its openings because they may touch dangerous voltage points or short out the parts. This could cause a fire or any electrical shock.

  • Page 5: Note To The System Installer

    - Proper grounding of the mast and supporting structure. - Grounding of the lead-in wire to the antenna discharge unit. - Size of grounding conductors. - Location of antenna-discharge unit. - Connection to grounding electrodes. - Requirement for the grounding electrode. DSR315 User Guide IMPORTANT SAFETY INSTRUCTIONS...

  • Page 6: Programming Copyright Notice

    Regulatory Programming Copyright Notice Use of this device may violate Section 605 of the Communications Act of 1934, as amended, if that use consists of the unauthorized interception and divulgence of radio communications for one’s own benefit where there is no entitlement to its receipt. Changes or modifications to this device not expressly approved by the party responsible for compliance with FCC regulations (the manufacturer) could void the user’s authority to operate the equipment.

  • Page 7: Fcc Compliance

    (The telephone number provided may not be a 900 number or any other number for which charges exceed local or long-distance transmission charges.) DSR315 User Guide...

  • Page 8: User Instructions

    Connect the equipment into a different outlet so that the equipment and receiver are on different branch circuits. Consult the dealer or an experienced radio/TV technician for help. Changes or modifications not expressly approved by Motorola could void the user’s right to operate the equipment and/or the equipment warranty. Equipment Attachment Limitations Note: This product was FCC approved under test conditions that included the use of shielded I/O cables and connectors between system components.
  • Page 9 (such as translation, transformation or adaptation) without written permission from Motorola, Inc. Motorola reserves the right to revise this publication and to make changes in content from time to time without obligation on the part of Motorola to provide notification of such revision or change. Motorola provides this guide without warranty of any kind, either implied or expressed, including but not limited to, the implied warranties of merchantability and fitness for a particular purpose.
  • Page 10 Regulatory ATTENTION ® This consumer unit is intended for the decoding of DigiCipher II television signals for consumer use. Possession of this device does not enable or entitle the possessor to receive DigiCipher II television signals. Contact program providers to obtain appropriate authorization. WARNING The unauthorized modification of any decoder and the sale and use of any such decoder is prohibited by law.

  • Page 11: Table Of Contents

    Additional Features ...23 Viewing and Language Settings ...23 Audio Settings ...23 Installation Settings ...24 System Status ...25 Caller ID ...25 Authorization Screens ...25 TVPass Card ...26 Watching TV ...27 How to Select Menu Options ...27 Banners ...28 DSR315 User Guide...
  • Page 12 Interactive Program Guide (IPG) ...30 How to Display the Guide ...30 Interests and Favorites ...32 Purchasing Instant Pay-Per-View (IPPV) Events ...34 How to Purchase an IPPV Event ...34 Options ...37 How to Display and Use the Options Menu ...37 Opening Your Mail ...38 Setting Favorite Channels ...40 Setting Parental Controls &...

  • Page 13: Using Your Remote

    All around the world, people just like you are enjoying entertaining, educational, and informational programming with a Motorola digital satellite receiver. In addition to offering outstanding picture and sound quality, your receiver comes with a remote control that can be programmed to operate your receiver, TV and auxiliary equipment.

  • Page 14: Key Functions

    Key Functions Power. To turn the component on or off. SAT(mode). To change the remote to SAT mode so it can control the receiver for viewing satellite and cable TV signals as well as the OPTIONS menu. TV(mode). To change the remote to TV mode so it can control the TV. VCR(mode).
  • Page 15 "Remote Energy Saver". If you misplace your remote (i.e., it is stuck in your couch), and a key is inadvertently pressed, the remote will automatically turn itself off after three minutes. DSR315 User Guide Using Your Remote ), fast-forward (...

  • Page 16: Programming The Remote Control

    Programming the Remote Control The remote control is set at the factory to control all of the satellite receiver functions, but to use it to operate your TV, DVD, VCR and auxiliary components as well, you must "program" it for the brand you own. Follow these instructions to program the remote to control your TV, DVD, VCR and auxiliary (AUX) components.

  • Page 17: If Your Four-Digit Code Is Not In The Tables (Scanning)

    Master Power command. • If you wish to cancel the Master Power feature, just repeat the steps outlined above. DSR315 User Guide Using Your Remote key to scan key to return to the previous code.)

  • Page 18: Verifying Your Tv, Dvd, Vcr And Aux Mode Codes

    Verifying Your TV, DVD, VCR and AUX Mode Codes You can verify the accepted programming codes for each mode by following these steps. Press the TV key for at least three seconds—until the LED blinks. Press the "INFO" key. 3. The LED will blink, indicating the code of your TV in the following sequence.

  • Page 19: If You Have More Than One Satellite Receiver

    - Position each battery in the battery compartment so that the flat base (-) is against the spring and so that the raised contact (+) is against the terminal. Make sure the batteries are securely seated. - Replace the cover. DSR315 User Guide Using Your Remote key on the...
  • Page 20 TV Codes ABI ......1064 AOC..1005,1006,1019,1020,1023,1024 .
  • Page 21 Saba ......1051 Saisho....1032,1033,1109 Sampo ..1006,1019,1156,1163,1192,1194 DSR315 User Guide Using Your Remote Samsung . . .1005,1006,1016,1023,1026,1032 .

  • Page 22: Dvd Players

    DVD Players Aiwa .......3179 Akai ....... .3163 Apex .
  • Page 23 ....2124,2125,2140,2169,2178 Motorola ....2054,2158,2178 Multitech ..2088,2089,2091,2154,2174 NAD .

  • Page 24: Satellite Receivers

    ..... .0004,0005,0006,0007 Motorola ....0000,0001,0002,0003 ..... .0004,0005,0006,0007 Next Level .
  • Page 25 McIntosh ..... . . 41224172 MCS ....... 4021 DSR315 User Guide Using Your Remote MCS .
  • Page 26 Combination TV/VCRs, TV/DVD Aiwa....... 5251 Apex....... .5011 Audio Dynamics .

  • Page 27: Your Receiver

    4. MENU. Press this key to display the Menu screen. Press it again to turn off the Menu and return to a SAT mode. Press this key to control the receiver if you cannot find your remote control. DSR315 User Guide...

  • Page 28: Back Panel Connections

    5. ARROW KEYS. Press these keys to highlight selections from menu screens. keys also change the channel. 6. ENTER. Press this key to select a highlighted menu option. Back Panel Connections 1. POWER. Provides power to the unit. ® 2. TVPASS CARD.

  • Page 29: Installation

    • Press the keys or the select. Then press the ENTER key to select it. • If the options are numbered, simply press the number key for an option. DSR315 User Guide Installation keys to highlight the option you wish to...

  • Page 30: Choosing The Menu Language

    If you use the keys on the front panel of the receiver, there is only one way to select a menu option. • Press the MENU key on the front panel to first display the Menu screen. Then press the keys or the keys to highlight an option.

  • Page 31: Acquiring A Signal

    "Correct signal found". If you do not see this message within 5 to 10 minutes, the satellite dish may be pointed at the incorrect satellite. Contact your service provider for assistance. DSR315 User Guide Installation...

  • Page 32: Authorizing Your Receiver

    Authorizing Your Receiver • Press the EXIT key on the remote control. Then press the number keys for the authorization channel. • Press the OPTIONS key on the remote control. The Options menu will appear. • From the Options menu, select option 6 (Change System Settings), and the System Settings...

  • Page 33: Connections To Audio/Video Monitor And Vcr

    RCA cable and the other end of the orange RCA cable to your surround processor. After you complete the installation procedures, you may wish to use the on-screen menus to make adjustments to the satellite receiver's operation. DSR315 User Guide Installation...

  • Page 35: Additional Features

    Audio Connections. Select option 1 (Audio Connections), and you will be able to select either TV or HiFi (the default is TV). Select TV if the receiver’s AUDIO OUT port is connected to your TV. Select HiFi if it is connected to your stereo system. DSR315 User Guide...

  • Page 36: Installation Settings

    Satellite Audio. Select option 2 and then select Mono, Stereo, Surround or Dolby Digital (the default is Surround). The Dolby Digital selection will disable other audio ports. Installation Settings Tune in Satellite Signal. This option allows you to see the strength of the signal your antenna is receiving.

  • Page 37: System Status

    • A subscription is required to receive the program. • There is a program blackout in your area. • There is a technical problem. • You need to insert a TVPass card, or there are problems with your current TVPass card. DSR315 User Guide Installation...

  • Page 38: Tvpass Card

    TVPass Card In the event of certain types of data security problems, your distributor may decide to utilize an authorization feature called TVPass card. This plastic card "module" fits into a slot located on the back of the receiver.

  • Page 39: Watching Tv

    Guide), nothing appears on the left side of the header. After you select an interest such as movies, sports, Pay Per View, or music/radio, the name of the interest you selected will appear on the left side of the header. DSR315 User Guide Watching TV keys to highlight an option. Then press the...

  • Page 40: Banners

    • Channel name—NBC-W, BRAVO, HISTORY, etc. • Channel number—A number from 1 to 999. • Message—An envelope icon appears if a message is waiting for you. • Time—The current time automatically appears on the right side of the header. Banners Program banners appear at the bottom of the screen: On Now banner—When you...

  • Page 41: Caller Announcement Banner

    The banner is displayed until the call is answered or the caller hangs up. If it is available, the telephone number and name of the caller will be displayed. DSR315 User Guide Watching TV...

  • Page 42: Interactive Program Guide (Ipg)

    Interactive Program Guide (IPG) The Interactive Program Guide (IPG) provides access to current and future program information while you watch TV. It displays a 90-minute block of scheduled programs, and can be used as a starting point for purchasing IPPV programs and settings timers.
  • Page 43 Favorite Channels" to select the channels you want to include in your Favorites list.) • Future interest programming by day and time can be viewed by pressing the FUTURE key on the remote while in GUIDE. DSR315 User Guide Watching TV...

  • Page 44: Interests And Favorites

    Detailed Program Information Press the INFO key to display a program information banner that has a detailed description of the program, ratings, purchasing information, and information icons. Setting a Timer for a Future Program Using the Guide, you can set a timer to automatically display a program at a future time and date.
  • Page 45 8 Network Series. If you select this interest, you will be able to channel surf exclusively for network series programs. 9 Pay-Per-View. If you select this interest, you will be able to channel surf exclusively for Pay-Per-Viw (PPV) programs. DSR315 User Guide Watching TV...

  • Page 46: Purchasing Instant Pay-Per-View (Ippv) Events

    Purchasing Instant Pay-Per-View (IPPV) Events With DSR315 digital satellite receivers, you have opportunities to purchase Pay- Per-View hit movies, concerts, live sporting events, or adult entertainment in SAT mode. You can make a purchase in two ways: (1) telephone ahead to the...
  • Page 47 You will be unable to purchase a program if you miss a significant portion of it, but you may be able to purchase the next program. After you purchase the next program, a countdown timer displays how much time remains before the program begins. DSR315 User Guide Watching TV...
  • Page 48 Purchase a Future Program You can pre-purchase a program that starts hours or days ahead by using timers as explained in the section entitled "Options: Setting Timers". Changes in Purchase Options If a program provider changes the purchase options after you have pre-purchased a program using a timer, and if the change affects your purchase, your purchase will be canceled, and you must buy the program again.

  • Page 49: Options

    2. Set Guide & Favorites. This option allows you to select a future day and time for viewing IPG listings. It also allows you to create a list of favorite channels that can be used for selective channel surfing and to limit the programs displayed on the IPG to a particular group. DSR315 User Guide...

  • Page 50: Opening Your Mail

    3. Set Parental Control (and Passwords). Parental Control features and passwords allow you to control the programs, channels, and subject matter that can be viewed with your receiver. 4. Set Timers. This option allows you to set a timer to view (or record) a program at a future time and day up to one year in advance.
  • Page 51 • Select which day of the Guide you would like to display. A Choose Time menu will appear. • Select the time of day for the Guide programming you would like to view. Refer to the section entitled "Guide (IPG)" for more information. DSR315 User Guide Options...

  • Page 52: Setting Favorite Channels

    Setting Favorite Channels With this option, you can create a list of favorite channels using the Favorite Channels menu. Once you create this list you will be able to focus your channel surfing and find programs more quickly. How to Display the Favorite Channels Menu •...

  • Page 53: Setting Parental Controls & Passwords

    • Use the number keys to enter a password of up to 8 numbers. An asterisk (*) will appear each time you add a number. Press the and change a number. When you are finished, press the ENTER key. The Confirm Password screen appears. DSR315 User Guide Options key to move to the left...
  • Page 54 • Re-enter your password numbers and press the ENTER key. The Password Changed screen appears, letting you know that your password is now effective. Press the GO BACK key to return to the Parental Control menu. To Set a New Password. If you wish to change your password in the future, you must first enter your current...
  • Page 55 Locks is set to Off, the Locks option automatically re-sets itself to On. Each time you press the POWER key to turn on the receiver, the Locks Option resets itself to On. DSR315 User Guide Options...

  • Page 56: Setting Timers

    6. Lock Channel on "No Info" in Guide. This option will allow you to lock any programming that is listed as "No Info" in the Guide. Setting Timers With timers, you can schedule your viewing up to one year in advance—whether you want to schedule one-time-only events or daily programs.

  • Page 57: Maximum Number Of Timers

    Maximum Number of Timers The maximum number of timers is twenty-five (25). If all of the timers have been used you will have to erase an existing timer before a new timer can be set. DSR315 User Guide Options...
  • Page 58 Before a Timer Executes Two minutes before a timer executes a countdown screen will appear. You may either: (1) press the GO BACK key to remove the countdown screen, (2) press the ENTER key to return to the Timers menu so that you can erase the timer, or (3) wait until the timer executes.
  • Page 59 If you have purchased a program or have used parental control features to lock out channels, satellites, or program content, a Password screen will appear. You will have to enter your password to finish setting the timer. Refer to the section entitled "Setting Parental Controls and Passwords". DSR315 User Guide Options...

  • Page 60: List Purchases

    Setting a Timer Using the Guide To set a timer while you are using the Guide: • Highlight a future program. • Press the INFO key or the ENTER key. • The Confirm Timer menu will appear (follow the instructions for the Confirm Timer menu).

  • Page 61: Change System Settings

    English, Spanish, or French. The default setting is None. Language. the Language option allows you to select the language of the audio for your programs. Select the option of your choice—English, Spanish, or French. The default setting is English. DSR315 User Guide Options...
  • Page 62 TV Viewing. The TV Viewing option allows you to select the size of the viewing area. Select the Normal option if your TV screen is typical screen with 4:3 ratio of width to height. Select Wide if your TV screen is a wide screen with a 16:9 ratio. The default setting is Normal.

  • Page 63: Installation Settings

    This is a view-only screen that displays information about the status of the receiver. Trip Counter. Trip Counter displays the number of message updates from your service provider. Modem Status. Displays a number of messages that describe the current modem status. DSR315 User Guide Options...

  • Page 64: Caller Id

    Caller ID This receiver provides Caller ID so you can see who is calling. When your telephone rings, the caller’s identification is displayed on your television and stored into the memory of the DSR305. This feature is only available if the Caller ID feature is enabled by the telephone company.
  • Page 65 The banner is displayed until the call is answered or the caller hangs up. If it is available, the telephone number and name of the caller will be displayed. DSR315 User Guide...

  • Page 67: Specifications

    525 line CCIR Rec. 405-1 DigiCipher II (Digital) System Frequency response ±1.0 dB, 1kHz to 4.2 MHz Differential gain 5.0% p-p maximum Differential phase 5.0 deg. p-p maximum 57 dB minimum (unified weighting 100 kHz HPF, 5MHz LPF) DSR315 User Guide Specifications...

  • Page 68: Remodulator Output

    Component Video (DigiCipher II System Only) "S-Video Out" Output Level Luminance (Y) 1.0 Vpp ±15% into 75 ohm Chrominance (C) 286m Vpp ±15% into 75 ohm Connector 4-contact Mini-DIN, Black Frequency Response Y ±1.0 dB, 1 kHz to 4.2 MHz Frequency Response C + 1.25 to -4.25 dB (relative to 0 dB at 3.58 MHz)

  • Page 69: Warranty & Service

    • If it can’t be fixed over the phone, you’ll be given a Return Tracking Code # (RTC) needed to return the remote for warranty coverage. • We’ll have a replacement delivered to you. 366 days or more – not covered under warranty. Contact Star Choice for details. DSR315 User Guide Warranty & Service...
  • Page 70 RECEIVER/REMOTE CONTROL WARRANTY ENTITLEMENT WILL NOT APPLY IN THE FOLLOWING CASES Improper Handling – if the unit appears to have been dropped or otherwise damaged as a result of accident or neglect Opened Case – if the receiver cover has been opened, tampered with or altered in any way Liquid Spills –...
