Parts List - MasterCraft 054-1249-6 Owner's Manual

!
WARNING:
any other parts may create a safety hazard or cause damage to the cordless rotary tool.
Any attempt to repair or replace electrical parts on this cordless rotary tool may create a
safety hazard unless repairs are performed by a qualified technician. For more information,
call the Toll-free Helpline, at 1-800-689-9928.
Always order by PART NUMBER, not by key number.
Key #
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22

PARTS LIST

When servicing, use only Mastercraft
Part #
3120040003 Shaft locking button
2050080013 Shaft locking spring
2040160003 Shaft locking pin
3140110002 Spring clavier
1130070001 Switch
3150130015 Cover board of decoration plate
3110010007 Decoration plate
3160070001 Energy Indicator cover
3010180002 Housing
1180060002 Contact plate
4030010028 Screw
1260020001 Battery
1130030002 Variable speed PCB
1039010001 Motor
3190020004 Sponge
3140060007 Stage positioning ring of power
4010010013 Bearing 688Z
2050080014 Snap ring
2040050052 Shaft
3150100003 Head nut
2040280002 Collet
2040150013 Collet nut
®
replacement parts. The use of
Part Name
24
Quantity
1
1
1
1
1
1
1
1
1
1
5
1
1
1
1
2
1
1
1
1
1
1
