Preface
The purpose of this publication is to provide the service
technician with information for troubleshooting, testing
and repair of major systems and components on the
Sand Pro 2040Z.
REFER TO THE OPERATOR'S MANUAL FOR OPER-
ATING,
MAINTENANCE
INSTRUCTIONS. For reference, insert a copy of the
Operator's Manual and Parts Catalog for your machine
into Chapter 2 of this service manual. Additional copies
of the Operator's Manual and Parts Catalog are avail-
able on the internet at www.Toro.com.
The Toro Company reserves the right to change product
specifications or this publication without notice.
AND
ADJUSTMENT
E The Toro Company - 2014

Service Manual

Sand Pro 2040Z
This safety symbol means DANGER, WARNING,
or CAUTION, PERSONAL SAFETY INSTRUC-
TION. When you see this symbol, carefully read
the instructions that follow. Failure to obey the
instructions may result in personal injury.
NOTE: A NOTE will give general information about the
correct operation, maintenance, service, testing or re-
pair of the machine.
IMPORTANT: The IMPORTANT notice will give im-
portant instructions which must be followed to pre-
vent damage to systems or components on the
machine.
Part No. 14210SL
