Reflector dishes
The passive reflector arm is molded to receive the plastic housing of the backhaul module. Use
stainless steel hose clamps to secure the module to the arm. The module is now properly aligned
within the reflector. The following figure shows this installation.
Stainless steel
hose clamps
Reflector dish arm
