Page 1 SCENIC DRIVER’S HANDBOOK...
Page 2 Renault cars. Lasting protection and optimum performance for your engine – guaranteed. Whether changing the oil or simply topping up, to find the approved ELF lubricant best suited to your vehicle, ask your Renault dealer for a recommendation or consult your vehi- cle maintenance handbook.
Page 3: Driving
This handbook may also contain information about items of equipment to be introduced later in the model year. Throughout the manual, the “approved Dealer” is your RENAULT Dealer. Enjoy driving your new vehicle.
Page 5: Table Of Contents
Sections Getting to know your vehicle ....... Driving ..............Your comfort ............Maintenance ............Practical advice ............ Technical specifications ........Alphabetical index ..........
Page 7 Section 1: Getting to know your vehicle RENAULT cards: General information, use, deadlocking ....... . .
Page 8: Battery Life
“Keycard battery low” appears on the ment increases very quickly. instrument panel (refer to the informa- tion on the “RENAULT card: battery” in RISK OF DEATH OR SERIOUS section 5). INJURY. When the battery is flat, you can still lock/unlock and start your vehi- cle.
Page 9 Replacement: need for an Using the key additional RENAULT Card Refer to the information on “Locking/ If you lose your RENAULT card or unlocking the doors”. require another, you can obtain one Once you have accessed the vehicle from an approved dealer.
Page 10: Remote Control Card Use
If a door or the luggage compartment is open RENAULT card not detected or not properly shut, or if a RENAULT alarm card is still in the reader, the doors and If you open a door with the engine run-...
Page 11: Unlocking The Vehicle
RENAULT “HANDS-FREE” CARD: use (1/3) Unlocking the vehicle On equipped vehicles, in addition to RENAULT card in area 1, press the 3 the functions of the above-mentioned button: the vehicle will unlock. remote control RENAULT card, it can In some cases (leaving the vehicle...
Page 12: Locking The Vehicle
The vehicle will lock. If a door or the boot is open or not closed properly, the vehicle will quickly lock/unlock. Note: a RENAULT card must be within the vehicle's access zone (zone 1) to be able to lock the vehicle using the button.
Page 13 After locking/unlocking the vehicle or the tailgate only using the but- tons on the RENAULT card, remote locking and unlocking in hands-free mode are deactivated. To reactivate the hands-free mode: restart the vehicle.
Page 14 RENAULT CARD: deadlocking To deactivate deadlocking Unlock the vehicle using button 1 on the RENAULT card. The hazard warning lights flash once to indicate that the doors have been un- locked. If the vehicle is equipped with a dead- To activate deadlocking...
Page 15: Opening And Closing The Doors
They stop as soon as the driver’s door is opened. With the RENAULT card in the detec- is opened. tion zone, press the button 2 or, de- pending on the vehicle, place your handle behind the handle, then grip the handle 1 and pull it towards you.
Page 16: Doors
OPENING AND CLOSING THE DOORS (2/2) Driver’s responsibility when parking or stopping the vehicle Never leave an animal, child or adult who is not self-suffi- cient alone on your vehicle, even for a short time. They may pose a risk to themselves Child safety or to others by starting the engine, To make it impossible for the rear doors...
Page 17: Locking/Unlocking Doors
LOCKING/UNLOCKING THE DOORS (1/2) Locking/Unlocking the doors from the outside This is done using the RENAULT Card; see the “RENAULT Card” information in Section 1. In certain cases, the RENAULT card may not work: – when the RENAULT card battery is drained, flat battery, etc.
Page 18 Unlocking the vehicle from the outside is only possible with the RENAULT card in the vehicle's access zone or using Interior locking/unlocking the key integrated in the RENAULT card.
Page 19: Automatic Locking When Driving
AUTOMATIC LOCKING WHEN DRIVING Activating/deactivating the Operating faults function If you experience an operating fault (no automatic locking, the indicator light in- To activate: with the vehicle stopped corporated in button 1 does not light up and the engine running, press switch 1 when trying to lock the doors and tail- until a beep sounds.
Page 20: Front Headrests
FRONT HEADRESTS To adjust side supports B Depending on the vehicle, sections B can be adjusted independently to the desired position. To remove the headrest Raise it to its highest position (tilt the seatback backwards if necessary). Press button 1 on each rod 3 and lift it until it is released.
Page 21 FRONT SEATS WITH MANUAL CONTROL (1/2) To move the seat forwards or To tilt the seatback back Turn control knob 3 to the required po- sition. Lift handle 1 to release. Release the For safety reasons, make handle at the desired position and these adjustments only make sure that it is locked.
Page 22: Heated Seats
FRONT SEATS WITH MANUAL CONTROL (2/2) Table function Heated seats When the front seat is in (depending on vehicle) table position, the front pas- Depending on the vehicle, the passen- senger air bag must be dis- ger seatback may be folded down onto With the engine running, turn control 6 the seat base to create a table.
Page 23: Adjusting The Seat Position
DRIVER’S SEAT WITH ELECTRIC CONTROLS Switch 4 is used for adjusting the seat base and switch 3 is used for adjusting the seatback. On equipped vehicles, buttons 2 store the chosen driving posi- tion (refer to the following page). Adjusting the seat position To move the seat forwards or back Move switch 4 forwards or backwards.
Page 24 – with the “hands-free” card de- recall a driving position. tected or, depending on the vehicle, RENAULT card in the card reader; – when the driver’s door is opened. Storing your driving position – Adjust the seat using switches 4 and 5 (see previous page);...
Page 25: Seat Belts
SEAT BELTS (1/3) Always wear your seat belt when trav- Before starting, first adjust your driv- elling in your vehicle. You must also ing position, then ask all occupants comply with the legislation of the par- to adjust their seat belts to ensure ticular country you are in.
Page 26 SEAT BELTS (2/3) Driver’s seat belt reminder ß and, depending on the vehi- cle, front passenger seat belt re- minder This lights up on the instrument panel when the engine is started, then, if the driver’s or front passenger’s seat belt (if this seat is occupied) is not fastened and the vehicle has reached approxi- mately 12 mph (20 km/h), it flashes and...
Page 27 SEAT BELTS (3/3) The following information applies to the vehicle’s front and rear seat belts. – No modification may be made to the component parts of the originally fitted restraint system: belts, seats and their mountings. For special operations (e.g. fitting child seats), contact an authorised dealer. –...
Page 28: Rear Seat Belts
REAR SEAT BELTS Second row centre rear seat Unwind belt 2 slowly from its housing. On equipped vehicles, for your com- fort, you can pass the belt through belt guide 3. Click buckle 4 into black catch 5. Snap last sliding buckle 6 into the red catch 7.
Page 29: Methods Of Restraint In Addition To The Front Seat Belts
METHODS OF RESTRAINT IN ADDITION TO THE FRONT SEAT BELTS (1/4) Depending on the vehicle, they are – Have the entire restraint composed of: system checked following – seat belt inertia reel pretension- an accident. ers; – No operation whatso- –...
Page 30 METHODS OF RESTRAINT IN ADDITION TO THE FRONT SEAT BELTS (2/4) Load limiter Air bags for driver and front passenger Above a certain severity of impact, this mechanism is used to limit the force of Fitted to the driver and passenger side. the belt against the body so that it is at The presence of this equipment is in- an acceptable level.
Page 31 METHODS OF RESTRAINT IN ADDITION TO THE FRONT SEAT BELTS (3/4) Operation Special feature of the front air This system is only operational when the ignition is switched on. After a violent impact, it has two deploy- ment volumes and integrates a ventila- In a severe frontal impact, the air bags tion system: inflate rapidly, cushioning the impact...
Page 32 METHODS OF RESTRAINT IN ADDITION TO THE FRONT SEAT BELTS (4/4) All of the warnings below are given so that the air bag is not obstructed in any way when it is inflated and also to prevent the risk of serious injuries caused by items which may be dislodged when the air bag inflates. Warnings concerning the driver’s air bag –...
Page 33: Methods Of Restraint In Addition To The Rear Seat Belts
METHODS OF RESTRAINT IN ADDITION TO THE REAR SEAT BELTS Force limiter Above a certain severity of impact, this mechanism is used to limit the force of the belt against the body so that it is at an acceptable level. –...
Page 34: Side Protection Devices
SIDE PROTECTION DEVICES Side air bags These air bags are fitted to the front seats and are activated at the sides of the seats (door side) to protect the oc- cupants in the event of a severe side impact. Curtain air bags These are air bags fitted along the sides of the vehicle in the ceiling which trigger along the front and rear side windows...
Page 35: Additional Methods Of Restraint
ADDITIONAL METHODS OF RESTRAINT Operating faults All of the warnings below are given so that the air bag is not obstructed in any way when it is inflated and also to prevent the risk of serious injuries caused å by items which may be dislodged when the air bag inflates. This warning light comes on when the engine is started and then The air bag is designed to complement the action of the seat belt.
Page 36: Child Safety: General Information
CHILD SAFETY: General information (1/2) Carrying children Children, and adults, must be correctly seated and strapped in for all journeys. The children being carried in your vehi- cle are your responsibility. A child is not a miniature adult. Children are at risk of specific injuries as their muscles and bones have not yet fin- Driver’s responsibility ished growing.
Page 37 CHILD SAFETY: General information (2/2) Using a child seat Set a good example by always fas- The level of protection offered by the tening your seat belt and teaching child seat depends on its ability to re- your child: strain your child and on its installation. –...
Page 38 CHILD SAFETY: choosing a child seat Rear-facing child seats Forward-facing child seats Booster cushions A baby’s head is, proportionally, heavier The child’s head and abdomen need to From 15 kg or 4 years, the child can than that of an adult and its neck is very be protected as a priority.
Page 39: Choosing A Child Seat Mounting
CHILD SAFETY: choosing a child seat mounting (1/2) There are two ways of attaching child Attachment using the ISOFIX Before using an ISOFIX seats: via the seat belt or using the system child seat that you pur- ISOFIX system. Authorised ISOFIX child seats are ap- chased for another vehicle, proved in accordance with regulation check that its installation is...
Page 40 CHILD SAFETY: choosing a child seat mounting (2/2) The rings are located on the floor and indicated by markings on the luggage compartment carpet. To access these anchoring points, push the rear seat forward and lift the cover if necessary. Note: for 7-seater vehicles, the rings are located on the luggage compart- ment floor and are visible.
Page 41: Fitting A Child Seat
CHILD SAFETY: fitting a child seat (1/11) Some seats are not suitable for fitting In the front seat child seats. The diagram on the follow- The laws concerning children travel- ing page shows you how to attach a ling in the front passenger seat differ in child seat.
Page 42 CHILD SAFETY: fitting a child seat (2/11) In the rear seat In the rear centre seat When fitting a child seat A carrycot can be installed across the Some child seats are too wide to allow (Group 2 or 3 booster seat), vehicle and will take up at least two access to the seat belt buckles.
Page 43 CHILD SAFETY: fitting a child seat (3/11) Child seat attached using the ISOFIX mounting ü Seat which allows an ISOFIX child seat to be fitted. ± The rear seats are fitted with an anchorage point which allows a for- ward-facing ISOFIX child seat with uni- versal approval to be fitted.
Page 44 CHILD SAFETY: fitting a child seat (4/11) The table below summarises the information already shown on the diagram on the previous page, to ensure the regula- tions in force are respected. Seat size Weight of Front passenger Rear centre Type of child seat Rear side seats the child seat (1) (5)
Page 45 CHILD SAFETY: fitting a child seat (5/11) Child seat attached using the ISOFIX mounting ü Seat which allows an ISOFIX child seat to be fitted. ± The rear seats are fitted with an anchorage point which allows a for- ward-facing ISOFIX child seat with uni- versal approval to be fitted.
Page 46 CHILD SAFETY: fitting a child seat (6/11) The table below summarises the information already shown on the diagram on the previous page, to ensure the regula- tions in force are respected. Seat size Weight of Front passenger Rear centre Type of child seat Rear side seats the child seat (1) (5)
Page 47 CHILD SAFETY: fitting a child seat (7/11) Child seat attached using the ISOFIX mounting ü Seat which allows an ISOFIX child seat to be fitted. ± The rear seats are fitted with an anchorage point which allows a forward-facing ISOFIX child seat with universal approval to be fitted.
Page 48 CHILD SAFETY: fitting a child seat (8/11) The table below summarises the information already shown on the diagram on the previous page, to ensure the regula- tions in force are respected. Front Seat size Weight of Row 2 rear Row 2 rear Row 3 rear Type of child seat passenger...
Page 49 CHILD SAFETY: fitting a child seat (9/11) X = Seat not suitable for fitting child seats. U = Seat which allows a child seat with “Universal” approval to be installed using a seat belt; check that it can be fitted. IUF/IL = On equipped vehicles, seat which allows an approved “Universal/semi-universal”...
Page 50 CHILD SAFETY: fitting a child seat (10/11) Child seat attached using the ISOFIX mounting ü Seat which allows an ISOFIX child seat to be fitted. ± The rear seats are fitted with an anchorage point which allows a for- ward-facing ISOFIX child seat with uni- versal approval to be fitted.
Page 51 CHILD SAFETY: fitting a child seat (11/11) The table below summarises the information already shown on the diagram on the previous page, to ensure the regula- tions in force are respected. Seat size Weight of Front passenger Type of child seat Rear side seats the child seat (1) (5)
Page 52: Deactivating/Activating The Front Passenger Airbag
CHILD SAFETY: deactivating/activating the front passenger airbag (1/3) DANGER Since operation of the front passenger airbag is not compatible with the position of a rear-facing child seat, NEVER fit a restraint system for a rear-fac- ing child in a seat protected by an ACTIVATED front AIRBAG.
Page 53 CHILD SAFETY: deactivating/activating the front passenger airbag (2/3) The markings on the dashboard and labels B on each side of the passen- ger sun visor 2 (for example, the labels shown above) will remind you of these instructions. 1.47...
Page 54 CHILD SAFETY: deactivating/activating the front passenger airbag (3/3) Operating faults It is not permitted to fit a rear-facing child seat to the front passenger seat if the air bag activation/deactivation system is faulty. It is not recommended to allow any other passenger to sit in that seat if the ›...
Page 55: Steering Wheel
STEERING WHEEL/POWER-ASSISTED STEERING Power-assisted steering Operating faults The steering may become stiff when Variable power-assisted steering driving or when the steering wheel is The variable power-assisted steering turned repeatedly. This is due to the system is equipped with an electronic power assistance overheating.
Page 56: Driving Position
DRIVING POSITION: LEFT-HAND DRIVE (1/2) 5 6 7 8 10 11 1.50...
Page 57: Instrument Panel
7 Centre air vents. 28 Traction control. 18 Storage compartment, accessories socket or cigarette lighter/multime- 8 Hazard warning lights switch. 29 Control for some multimedia equip- dia socket. ment. 9 Instrument panel customisation 19 Gear lever. menu control. 20 RENAULT card reader. 1.51...
Page 58 DRIVING POSITION: RIGHT-HAND DRIVE (1/2) 6 7 8 1.52...
Page 59 12 Location for driver’s air bag and information, navigation system in- parking brake control. horn. formation, etc. 22 RENAULT card reader. 13 – Steering column stalk for wind- – Driver and front passenger seat screen and rear screen wash/ 23 Gear lever.
Page 60 WARNING LIGHTS (1/5) The presence and operation of the warning lights DEPEND ON THE EQUIPMENT AND COUNTRY. Instrument panelA: lights up when the Rear fog light tell-tale light ignition is switched on. In some cases, the appearance of a warning light is accompanied by a mes- sage.
Page 61 WARNING LIGHTS (2/5) The presence and operation of the warning lights DEPEND ON THE EQUIPMENT AND COUNTRY. Toxic Fume Filter System Handbrake “on” or elec- Ä Warning Light tronic parking brake warn- This lights up when the ignition is ing light switched on and goes out when the Refer to the information on the engine is started.
Page 62 WARNING LIGHTS (3/5) The presence and operation of the warning lights DEPEND ON THE EQUIPMENT AND COUNTRY. Rear seat belt reminder (depending Airbag warning light Hill start assistance warning å on vehicle) This lights up when the engine light is started and goes out after approxi- ß...
Page 63 WARNING LIGHTS (4/5) The presence and operation of the warning lights DEPEND ON THE EQUIPMENT AND COUNTRY. STOP light The following warning lights come ® ® on accompanied by the warn- This lights up when the ignition ing light. is switched on and goes out after ap- proximately three seconds.
Page 64 WARNING LIGHTS (5/5) The presence and operation of the warning lights DEPEND ON THE EQUIPMENT AND COUNTRY. Oil pressure warning light Lane departure system Tyre pressure monitoring À warning light system This lights up when the ignition is switched on and goes out after ap- Please refer to the information on “Lane Refer to the information on the “Tyre proximately three seconds.
Page 65: Fuel Gauge
DISPLAYS AND INDICATORS (1/2) Rev counter (rpm × 1,000) This is displayed according to how the instrument panel is customised. Speedometer (km/h or mph) Fuel gauge If the level is at the minimum, the warning light integrated in the indicator comes on, accompanied by a beep.
Page 66 DISPLAYS AND INDICATORS (2/2) Instrument panel in miles Overspeed buzzer (option to switch to km/h) Depending on the vehicle and country, – With the ignition off, press button 4 a buzzer sounds for approximately or 5 and the start button 6; 10 seconds every 40 seconds, as long –...
Page 67: Trip Computer And Warning System
TRIP COMPUTER: general information (1/2) c) mileage before service; d) tyre pressure monitor; e) trip log, operating faults and informa- tion message readout. Trip computer and warning Display selection keys 2 system 1 and 3 Depending on the vehicle, this includes Scroll through the following informa- the following functions: tion upwards (button 2) or downwards...
Page 68: Journey Record
ON-BOARD COMPUTER: general information (2/2) Interpreting some of the Automatic resetting of the values displayed after journey parameters resetting Resetting occurs automatically when the maximum value of any of the pa- The values showing average fuel con- rameters is exceeded. sumption and average speed will become more stable and reliable the further you have travelled since the last...
Page 69 ON-BOARD COMPUTER: trip settings (1/5) The display of information shown below DEPENDS ON THE VEHICLE EQUIPMENT AND COUNTRY. Examples of selections Interpreting the display selected a) Total mileage and trip mileage recorder. Fuel used b) Journey parameters. Fuel used. Fuel consumed since the last reset. Fuel consumption L/100 Current fuel consumption A.
Page 70 ON-BOARD COMPUTER: trip settings (2/5) The display of information shown below DEPENDS ON THE VEHICLE EQUIPMENT AND COUNTRY. Examples of selections Interpreting the display selected Range Estimated range with remaining fuel. The value is displayed after driving 400 metres. 541km Distance Distance travelled since the last reset.
Page 71 ON-BOARD COMPUTER: trip settings (3/5) The display of information shown below DEPENDS ON THE VEHICLE EQUIPMENT AND COUNTRY. Examples of selections Interpreting the display selected On-board computer with mileage- before-service message c) Mileage before service or oil change. Service in Mileage before service SERVICE With the ignition switched on and the engine not running,...
Page 72 ON-BOARD COMPUTER: trip settings (4/5) The display of information shown below DEPENDS ON THE VEHICLE EQUIPMENT AND COUNTRY. Examples of selections Interpreting the display selected On-board computer with distance before next service message (cntd.) c) Mileage before service or oil change. Mileage before service Oil change in With the ignition switched on and the engine not running,...
Page 73 ON-BOARD COMPUTER: trip settings (5/5) The display of information shown below DEPENDS ON THE VEHICLE EQUIPMENT AND COUNTRY. Examples of selections Interpreting the display selected d) Tyre pressure monitor Refer to the information under “Tyre pressure Tyre pressure monitor” in Section 2. No message e) Trip log.
Page 74 « Parking brake on » Indicates that the parking brake has been applied. « Please remove Request to remove the RENAULT card from the reader when you leave the vehicle. keycard » « Checking control Displayed with the ignition on when the vehicle is running self-diagnostics.
Page 75 TRIP COMPUTER AND WARNING SYSTEM: operating fault messages © These appear with the warning light and mean that you should drive very carefully to an authorised dealer as soon as possible. If you fail to follow this recommendation, you risk damaging your vehicle. They disappear when the display selection key is pressed or after several seconds and are stored in the computer log.
Page 76 TRIP COMPUTER AND WARNING SYSTEM: warning message ® These appear with the warning light and require you to stop immediately, for your own safety, as soon as traf- fic conditions allow. Stop your engine and do not restart it. Contact an approved Dealer. Examples of warning messages are given in the following pages.
Page 77: Vehicle Settings Customisation Menu
VEHICLE SETTINGS CUSTOMISATION MENU Adjusting the settings Once the function has been selected, activate or deactivate it using button Depending on the vehicle equipment, “OK” 2: press button 3 or 4 to select the func- tion to be modified: function activated a) Auto door locking while driving;...
Page 78: Clock And Exterior Temperature
CLOCK AND EXTERIOR TEMPERATURE Vehicles fitted with a navigation system For vehicles which are fitted with this equipment, please refer to the specific equipment instructions for details of their special features. External temperature indicator Special note: When the exterior temperature is be- tween -3°C and +3°C, the characters Ñ...
Page 79: Rear View Mirrors
REAR VIEW MIRRORS Folding door mirrors The door mirrors automatically fold in when the vehicle is locked (switch 2 in position D). In this case, they will fold out when the ignition is next switched In any case, you can make the door mirrors fold in (switch 2 in position E) or out (switch 2 in position C).
Page 80: Audible And Visual Signals
AUDIBLE AND VISUAL SIGNALS Direction indicators Move stalk 1 parallel to the steering wheel and in the direction you are going to turn it. One-touch mode When driving, it is possible that the steering wheel may not be turned suf- ficiently to return the stalk automatically to its starting position.
Page 81: Exterior Lighting And Signals
EXTERIOR LIGHTING AND SIGNALS (1/5) Main beam headlights á With the dipped beam head- lights lit, pull stalk 1 towards you. This indicator light on the instrument panel comes on. To return to the dipped headlight posi- tion, pull stalk 1 towards you again. Side lights Dipped beam headlights...
Page 82 EXTERIOR LIGHTING AND SIGNALS (2/5) Automatic main beam Activation Operating faults headlights Turn ring 3 until the AUTO symbol is op- When the message “Check auto light- posite mark 2. ing” appears on the instrument panel, Depending on the vehicle, this system Pull stalk 1 to activate main beam the system is deactivated.
Page 83: Daytime Running Lights
EXTERIOR LIGHTING AND SIGNALS (3/5) Directional headlights Operating faults Depending on the vehicle, when the Depending on the vehicle, with the message “Check lighting” appears on dipped beam headlights on and under the instrument panel along with the certain conditions (speed, steering ©...
Page 84 EXTERIOR LIGHTING AND SIGNALS (4/5) Lights-on reminder buzzer “See-me-home lighting” function If the lights are on after the engine is switched off, a warning beep sounds This function allows you to briefly switch when the driver’s door is opened to on the dipped beam headlights (to pro- warn you that the lights are still on.
Page 85: Front Fog Lights
EXTERIOR LIGHTING AND SIGNALS (5/5) Front fog lights Switching off the lights Turn centre ring 5 on stalk 1 Turn ring 5 again until mark 4 is oppo- until the symbol faces mark 4, then re- site the symbol for the fog light that you lease it.
Page 86 ADJUSTING THE HEADLIGHT BEAM HEIGHT For manual settings Examples of positions for adjusting control A according to the load 5 seater 7 seater Driver alone or with front passenger Driver with one front passenger and one rear passenger On vehicles fitted with this function, control A allows you to adjust the height of the beams according to the load.
Page 87: Windscreen Wash/Wipe
WINDSCREEN WASH/WIPE (1/4) Check the condition of the wiper blades. You are responsible for their service life: – they must remain clean: clean the blades, windscreen and rear screen regularly with soapy Vehicle fitted with intermittent Special note water; windscreen wipers When driving the vehicle, the wiping –...
Page 88 WINDSCREEN WASH/WIPE (2/4) – in the event of temperatures below zero, automatic wiping is not activated when the vehicle is started. It is automatically acti- vated as soon as the vehicle ex- ceeds a certain speed (5 mph (8 km/h)); –...
Page 89 WINDSCREEN WASH/WIPE (3/4) Operating fault Special note When driving the vehicle, the wiping In the event of a malfunction of the au- speed slows down whenever the vehi- tomatic wiping, the wiper is set to inter- cle stops. For example, fast wiping mittent wiping.
Page 90: Headlight Washers
WINDSCREEN WASH/WIPE (4/4) Headlight washers Headlights on In the event of obstacles present On equipped vehicles, hold stalk 1 on the windscreen (dirt, snow, ice, pulled towards you for about 1 second, etc.), clean the windscreen (inclu- and the headlight washers and winds- ding the central area located behind creen washers will be activated at the the interior rear-view mirror) and...
Page 91: Rear Screen Wiper
REAR SCREEN WASH/WIPE Activating/deactivating the rear screen wiper (depending on the vehi- cle) If your vehicle is fitted with a vehicle settings customisation menu, it is pro- grammed to activate the rear wipers when reverse gear is selected (if the windscreen wipers are on).
Page 92: Fuel Grade
FUEL TANK (1/3) Fuel grade Vehicles running on ethanol- based fuel Use a high-grade fuel that complies with the legislation in force in each It is essential to use unleaded petrol or country and which must conform to fuel containing a maximum of 85% eth- the specifications given on the label on anol (E85).
Page 93: Fuel Tank Filling With Fuel
FUEL TANK (2/3) Filling with fuel With the ignition off, insert the nozzle to open valve A and insert it fully before turning it on to fill the fuel tank (risk of splashing). Keep the nozzle in this position through- out the entire filling operation.
Page 94 FUEL TANK (3/3) Vehicles without priming bulb 2 Insert the RENAULT card into the card reader. Press the button without press- ing any of the pedals. Wait a few min- utes before starting. This will enable the fuel circuit to be primed. If the engine does not start, repeat the procedure.
Page 95 Section 2: Driving (Advice on use relating to fuel economy and the environment) Running in ..............Starting, stopping the engine .
Page 96: Running In
RUNNING IN Petrol version Diesel version For the first 600 miles (1,000 km), do For the first 1,000 miles (1,500 km), not exceed 78 mph (130 km/h) in the do not exceed 80 mph (130 km/h) in highest gear, or 3,000 to 3,500 rpm. the highest gear, or 2,500 rpm.
Page 97: Starting/Stopping The Engine
The RENAULT card must be inserted in card reader 2 or in detection zone 3. In this case, the RENAULT card must When you get into the vehicle, insert the not be located in the luggage compart- RENAULT card fully into card reader 2.
Page 98 RENAULT card, insert the card into free” card may not work: reader 2; – vehicles with a RENAULT “hands- – when the RENAULT card battery is free” card, with the card in the pas- drained, flat battery, etc. senger compartment or inserted in –...
Page 99 With the card in reader 2, press button 1: the engine will stop. Removing the card from the reader locks the steer- ing column. When you leave your vehicle, especially if you have your RENAULT card with you, check that the engine is completely switched off.
Page 100 FUNCTION STOP AND START (1/3) Preventing the engine from This system enables a reduced fuel For all vehicles: consumption and lower greenhouse standing by gas emissions. The system is acti- The warning light on the instru- In certain situations, such as negotiat- vated automatically when the vehicle is ment panel remains lit when the engine ing a crossroads for instance, it is pos-...
Page 101 Conditions for coming out of Special case for vehicles with – the difference between the vehicle interior temperature and the automa- engine standby a RENAULT card tic climate control instruction is too For manual gearboxes: With the engine on standby (traffic jam, high;...
Page 102 FUNCTION STOP AND START (3/3) Special feature of the automatic The system reactivates automati- engine re-start cally each time the vehicle is started using the start button (please refer Under certain conditions, the engine to “Starting, stopping the engine” in can restart on its own in order to gua- Section 2).
Page 103: Special Features Of Petrol Versions
SPECIAL FEATURES OF PETROL VERSIONS The following operating conditions If you notice any of the above operating should be avoided: faults, have the necessary repairs car- ried out as soon as possible by an ap- – driving for long periods when the low proved dealer.
Page 104: Special Features Of Diesel Versions
SPECIAL FEATURES OF DIESEL VERSIONS Diesel engine speed Precautions to be taken in winter Diesel engines are fitted with injection equipment which prevents the engine To avoid any faults in icy weather: speed being exceeded irrespective of – ensure that the battery is always fully the gear selected.
Page 105: Gear Lever
GEAR LEVER/HANDBRAKE Handbrake To release: Pull lever 2 up slightly, press button 3 and then lower the lever to the floor. To apply: Pull the lever 2 upwards and make sure the vehicle is immobilised. Make sure that the hand- Selecting reverse gear brake is properly released when driving (red indicator...
Page 106: Electronic Parking Brake
ELECTRONIC PARKING BRAKE (1/3) Note: To indicate that the electronic parking brake is released, a beep sounds: – with the engine running: when the driver’s door is opened; – with the engine switched off (eg. when the engine stalls): when a front door is opened.
Page 107: Manual Operation
Brief stop switch 3 at the same time; You can control the electronic parking To manually activate the electronic – remove the RENAULT card from the brake manually. parking brake, (when stopping at a red card reader. light, or stopping when the engine is Applying the electronic parking running, etc.): pull and release switch 3.
Page 108 ELECTRONIC PARKING BRAKE (3/3) Versions with an automatic Operating faults – If there is an electronic parking brake ® fault, the warning light comes gearbox © – If there is a fault, the warning on, accompanied by the “Parking light illuminates on the instrument For safety reasons, automatic release brake fault”...
Page 109: Driving Advice, Eco-Driving
DRIVING ADVICE, ECO-DRIVING (1/3) Journey record Fuel consumption is accredited in ac- cordance with a standard regulatory Once the engine is switched off, you method. Identical for all manufactur- will see “Journey record” displayed on ers, this enables vehicles to be com- the screen 1, enabling you to view in- pared with one another.
Page 110 DRIVING ADVICE, ECO-DRIVING (2/3) An overall rating from 0 to 100 is dis- – Avoid sudden acceleration. played to let you assess your eco driv- – Brake as little as possible. If you an- ing performance. The higher the score, ticipate an obstacle or bend in ad- the better your eco-driving perform- vance, you may then simply release...
Page 111 DRIVING ADVICE, ECO-DRIVING (3/3) – In vehicles fitted with air condi- tioning, it is normal to observe an increase in fuel consumption (es- pecially in urban conditions) when it is used. For vehicles fitted with manual air conditioning, switch off the system when it is not required.
Page 112: Maintenance And Antipollution Advice
MAINTENANCE AND ANTIPOLLUTION ADVICE Maintenance Exhaust gas monitoring Your vehicle complies with criteria for recycling and recovering vehicles at the system It is important to remember that fail- end of their service life, which will come ure to respect anti-pollution regulations The exhaust gas monitoring system will into force in 2015.
Page 113: Environment
This commitment is illustrated by the lation. less fuel (eg. 140 g/km, equivalent to Renault eco² signature. 5.3 l/100 km for a diesel vehicle). Recycling Our vehicles are also equipped with a Manufacture...
Page 114: Tyre Pressure Monitoring System
TYRE PRESSURE MONITORING SYSTEM (1/4) If the vehicle is equipped with the func- It should always be done after checking tion, this system monitors the tyre pres- the tyre pressure of all four tyres when sure. cold. Tyre pressures must correspond to the Operating principle current usage of the vehicle (empty, carrying a load, motorway driving, etc.).
Page 115 TYRE PRESSURE MONITORING SYSTEM (2/4) « Puncture » The affected wheel A appears red on the display 4 along with the warning light 3 and a beep. They indicate that the affected wheel is punctured or severely underinflated. Replace it or contact an authorised dealer if it is punctured.
Page 116 TYRE PRESSURE MONITORING SYSTEM (3/4) Readjustment of tyre Replacing wheels/tyres pressures This system requires specific equip- ment (wheels, tyres, hubcaps, etc.). The tyre pressures must be adjusted Contact an approved Dealer to fit new when cold (please refer to the label lo- tyres and to find out about available ac- cated on the edge of the driver’s door).
Page 117 TYRE PRESSURE MONITORING SYSTEM (4/4) To mark the correct position of the wheel, note the colour of the ring 6 (after cleaning, if necessary) on each valve: B yellow ring C black ring D red ring Each of the sensors incor- porated in the valves 5 is E green ring dedicated to a single wheel:...
Page 118: Driver Correction Devices/Aids
DRIVER CORRECTION DEVICES AND AIDS (1/5) Anti-lock braking system Depending on the vehicle, this is com- Operating faults: posed of: (ABS) – anti-lock braking system (ABS); © – lit up on the in- Under heavy braking, the ABS prevents – emergency brake assist; strument panel alongside mes- the wheels from locking, allowing the –...
Page 119: Emergency Brake Assist
DRIVER CORRECTION DEVICES AND AIDS (2/5) Emergency brake assist Braking anticipation Operating principle Depending on the vehicle, when you A sensor in the steering wheel detects This system supplements the ABS rapidly release the accelerator, the the direction selected by the driver. and helps reduce vehicle stopping dis- system anticipates the braking ma- Other sensors throughout the vehicle...
Page 120: Traction Control
DRIVER CORRECTION DEVICES AND AIDS (3/5) Traction control Operating faults When the system detects an operat- This system helps to limit wheelspin of ing fault the message “Check ESC” and the drive wheels and to control the ve- hicle when pulling away accelerating or ©...
Page 121: Grip Control
DRIVER CORRECTION DEVICES AND AIDS (4/5) Grip control “Soft ground” mode Turn the button 2: the integrated warn- If fitted on the vehicle, grip control makes it easier to control the vehicle on ing light comes on, along with low grip surfaces (soft ground, etc.). the instrument panel message “Non grip road mode on”.
Page 122 DRIVER CORRECTION DEVICES AND AIDS (5/5) Hill start assistance This device assists the driver when starting on hills (ascending or descend- The hill start assistance ing), and the warning light system cannot completely be displayed on the instrument panel. It prevent the vehicle from prevents the vehicle from rolling back- rolling backwards in all sit-...
Page 123: Lane Departure Warning
LANE DEPARTURE WARNING (1/2) This system notifies the driver when they accidentally cross a continuous or broken line. This function uses a camera attached to the windscreen, behind the rear-view mirror. This function is a driving aid in the event of the accidental crossing of a continuous or broken line in the road.
Page 124 LANE DEPARTURE WARNING (2/2) Adjustment The function sounds the alarm if: a line is crossed without activating the From the vehicle settings customisation indicator lights. The function alerts the menu (please refer to the information on the “Vehicle settings customisation driver through warning light menu”...
Page 125 CRUISE CONTROL/SPEED LIMITER: speed limiter function (1/3) The speed limiter function helps you Controls Switching on stay within the driving speed limit that Press switch 1 or 2 on the side 1 or 2 Main “On/Off” switch. you choose, known as the limit speed. Warning light comes on, lit orange, 3 Speed limiter activation, memory...
Page 126: Speed Limiter
CRUISE CONTROL/SPEED LIMITER: speed limiter function (2/3) Driving Exceeding the limit speed When a limited speed has been stored It is possible to exceed the limit speed and this speed is not reached, driving is at any moment. To do this: press the similar to driving a vehicle without the accelerator pedal firmly and fully speed limiter function.
Page 127 CRUISE CONTROL/SPEED LIMITER: speed limiter function (3/3) Putting the function on Recalling the limit speed Switching off the function standby If a speed has been stored, it can be re- The speed limiter function is deacti- called by pressing switch 6 (R). vated if you press switch 1 or 2: in this The speed limiter function is deacti- case a speed is no longer stored.
Page 128 CRUISE CONTROL/SPEED LIMITER: cruise control function (1/4) This function is an addi- tional driving aid. However, the function does not take the place of the driver. The cruise control function helps you to Controls Therefore, it can under no circum- maintain your driving speed at a speed stances replace the driver’s respon- 1 or 2 Main “On/Off”...
Page 129: Cruise Control
CRUISE CONTROL/SPEED LIMITER: cruise control function (2/4) Driving Once a cruising speed is stored and the cruise control function is active, you may lift your foot off the accelera- tor pedal. Switching on Activating cruise control At a steady speed (above approx. Press switch 1 or 2, side.
Page 130 CRUISE CONTROL/SPEED LIMITER: cruise control function (3/4) Exceeding the cruising speed Putting the function on standby The cruising speed may be exceeded at any time by depressing the accelera- The function is suspended when you: tor pedal. – 5 switch (O); The cruising speed flashes on the in- –...
Page 131 CRUISE CONTROL/SPEED LIMITER: cruise control function (4/4) Returning to the cruising speed Note: if the speed previously stored is Switching off the function If a speed is stored, it can be recalled, much higher than the current speed, The cruise control function is stopped once you are sure that the road condi- the vehicle will accelerate more rapidly if you press switch 1 or 2: in this case...
Page 132: Parking Distance Control
PARKING DISTANCE CONTROL (1/4) Rear parking distance control Operation When reverse gear is selected, most objects which are less than approxi- mately 1.20 metres from the rear of the vehicle are detected, a beep sounds and, depending on the vehicle, the dis- play 1 comes on.
Page 133 PARKING DISTANCE CONTROL (2/4) Front parking distance control (depending on vehicle) Operation The parking distance control system is only activated when the vehicle is driven at a speed below approximately 6 mph (10 km/h). Most objects located less than around 1 metre away from the front of the ve- hicle are detected and a beep sounds.
Page 134 PARKING DISTANCE CONTROL (3/4) Deactivating the system You may permanently activate or deac- tivate the front or rear parking distance control separately. From the customisation menu Select line “Front parking sensor” or “Rear parking sensor”, then activate or deactivate the system (refer to the in- formation on “Vehicle settings customi- sation menu”...
Page 135: Special Features
PARKING DISTANCE CONTROL (4/4) Operating faults When the system detects an operating fault, a beep sounds for approximately 3 seconds each time reverse gear is se- Check parking sensor lected and is accompanied by the mes- Rear parking sensor sage “Check parking sensor” shown on volume the instrument panel.
Page 136: Reversing Camera
REVERSING CAMERA (1/2) Operation 3 moving guide line: This gauge remains fixed and indicates the vehicle trajectory if the wheels are This is shown in blue on screen 2. It in- When reversing, the camera 1 on the in line with the vehicle. dicates the vehicle trajectory according boot lid transmits a view of the sur- to the position of the steering wheel.
Page 137 REVERSING CAMERA (2/2) Check parking sensor The screen shows a reverse image. Rear parking sensor The frames are a representation projected onto flat ground; this in- volume formation must not be taken into Rear camera view settings account when superimposed on a Image settings vertical object or an object on the ground.
Page 138: Automatic Gearbox
AUTOMATIC GEARBOX (1/3) Driving in automatic mode Select position D. In most traffic condi- tions, you will not have to touch the gear selector lever again: the gears will change automatically at the right time and at the most suitable engine speed because the automatic system takes into account the vehicle load and road contour and adjusts itself to the particu-...
Page 139: Parking The Vehicle
AUTOMATIC GEARBOX (2/3) Driving in manual mode Special circumstances Parking the vehicle With the selector lever in position D, – If the road contours and bends When the vehicle is stopped, move the move the lever to the left. Shifting the do not allow you to stay in automa- lever to position P while keeping your lever repeatedly allows you to change...
Page 140 AUTOMATIC GEARBOX (3/3) Operating faults – When driving, if the “Check auto gearbox” message appears on the instrument panel, it indicates a fault. Contact your approved Dealer as soon as possible. – When driving, if the message “Auto gearbox overheating” appears on the instrument panel, stop the vehicle to allow the gearbox to cool down.
Page 141: Your Comfort
Section 3: Your comfort Air Vents ..............Manual air conditioning .
Page 142: Air Vents
AIR VENTS: air outlets (1/2) 1 side air vent 2 side window demister outlet 3 windscreen demister outlets 7 rear air vents 4 centre air vents 8 passenger footwell heater outlets 5 side window demister outlet 9 automatic climate control/manual air 6 side air vent conditioning control panel.
Page 143: Front Seats
AIR VENTS: air outlets (2/2) Front seats To remove bad odours from your ve- Rear seats hicles, only use the systems designed Move tab 3 to the right or left to direct Air flow for this purpose. Consult an approved the air flow.
Page 144: Manual Air Conditioning
MANUAL AIR CONDITIONING (1/2) Distribution of air in the passenger compartment There are five air distribution options. Turn control 4 to choose the distribution option. The air flow is directed to the windscreen and the front side window demisting vents. The air flow is distributed be- tween all the air vents, the front side window demisting vents, the...
Page 145 MANUAL AIR CONDITIONING (2/2) Adjusting the ventilation speed Turn control 2 clockwise to increase the air flow in the passenger compartment. Passenger compartment ventilation is referred to as “blown air”. The ven- tilation fan determines the air flow. However, it is also affected by the ve- hicle speed.
Page 146: Automatic Climate Control
AUTOMATIC CLIMATE CONTROL (1/5) Automatic mode The automatic climate control system guarantees comfort in the passen- ger compartment and good visibility (except in the event of extreme condi- tions), whilst optimising consumption. The system controls the ventilation speed, air distribution, air recircula- tion, and starting and stopping the air conditioning and air temperature.
Page 147 AUTOMATIC CLIMATE CONTROL (2/5) Clear View function Press button 10: the integrated indica- tor light comes on. This function quickly demists and de- ices the windscreen, the rear screen, the front side windows, and the door mirrors (depending on the vehicle). The air conditioning and rear screen de- icing functions must be activated.
Page 148 AUTOMATIC CLIMATE CONTROL (3/5) The displayed temperature values show a comfort level. When starting the engine, in- creasing or decreasing the value displayed will not allow the com- fort level to be reached any more quickly. The system will always op- timise the temperature increase or decrease (the ventilation system does not start instantly at maximum...
Page 149 AUTOMATIC CLIMATE CONTROL (4/5) The air flow is directed to the Ø windscreen and the front side window demisting vents. The air flow is distributed be- × tween front side window de- misting vents, the windscreen demist- ing vents and the footwells. The air flow is directed mainly ¿...
Page 150 AUTOMATIC CLIMATE CONTROL (5/5) Recycling This function is managed automati- cally (operation is confirmed by warn- ing light 14 on display 12), but you can also activate it manually. Note: – during recirculation, air is taken from the passenger compartment and is recycled, with no air being taken from outside the vehicle;...
Page 151: Air Conditioning: Information And Advice On Use
AIR CONDITIONING: information and advice on use Advice on use In some situations, (air conditioning Operating faults off, air recirculation activated, venti- Fuel consumption lation speed at zero or low, etc.) you As a general rule, contact your ap- You will normally notice an increase may notice that condensation starts proved dealer in the event of an op- in fuel consumption (especially...
Page 152: Electric Windows/Electric Panoramic Sunroof
Never leave your vehicle with the Electric windows From the driver’s seat, use switch: RENAULT card inside and never 1 for the driver’s side; leave a child (or a pet) unsuper- Press or pull the switch to raise or lower 2 for the front passenger’s side;...
Page 153: Sun Blind
ELECTRIC WINDOWS/ELECTRIC SUNROOF (2/3) Driver’s responsibility Never leave your vehicle with the RENAULT card inside and never leave a child (or a pet) unsupervised, even for a short while. The reason for this is that the child may endanger himself or others by...
Page 154: Precautions During Use
Technical Department; RENAULT card twice in quick suc- (the window will close gradually), hold cession, or on the driver's door in – do not open the sunroof immedi-...
Page 155: Manual Window Winders/Interior Lighting
MANUAL WINDOW WINDERS/INTERIOR LIGHTING (1/2) Manual window winders Courtesy light Front door lights Turn handle 1. Tilt switch 3 to move it to the position On equipped vehicles, light 5 comes on for: when the door is opened. – permanent lighting; –...
Page 156 INTERIOR LIGHTING (2/2) Glove box light 6 Luggage compartment light 7 Light 6 comes on when the cover is Depending on the vehicle, light 7 opened. comes on when the luggage compart- ment is opened. 3.16...
Page 157: Vanity Mirror
SUN BLIND/MIRRORS Front sun visor Vanity mirror Child minder mirror Lower the sun visor 1 over the wind- Slide cover 3. Pull on recess 4 to open it. screen or unclip it and lower it over the Depending on the vehicle, light 2 is au- side window.
Page 158: Sun Visor
SUN VISOR Lateral sun visor Rear side sun blind Rear sun blind on the tailgate Pull the sun blind upwards using tab 1 Pull the sun blind upwards using hook 3 Pull the sun blind upwards using tabs 6 until hook 2 engages in its housing until it engages in housing 4 (make sure until they engage in hook 5 (make sure (make sure that the hook is correctly...
Page 159: Passenger Compartment Storage/Fittings
PASSENGER COMPARTMENT STORAGE/FITTINGS (1/6) Door pockets 1 Dashboard storage Storage compartment under compartment 2 the instrument panel 3 It can hold a 1.5 litre bottle. Nothing should be placed on the floor area in front of the driver as such objects may slide under the pedal during braking manoeuvres, thus Ensure that no hard, heavy or pointed objects are placed in the “open”...
Page 160 PASSENGER COMPARTMENT STORAGE/FITTINGS (2/6) Sunglasses holder 4 Sun blind storage 5 Central storage compartment or control 6 This can be used for storing motorway tickets, cards, etc. Depending on the vehicle, central con- trol 6 may be replaced by a storage compartment.
Page 161: Armrest Storage
PASSENGER COMPARTMENT STORAGE/FITTINGS (3/6) Central elbow rest 8 Centre console storage Armrest storage compartment C compartment D Depending on the vehicle, the central armrest slides to allow the length to be Lift up the armrest 8. With the armrest in the retracted posi- adjusted.
Page 162 PASSENGER COMPARTMENT STORAGE/FITTINGS (4/6) Passenger storage Cup holder 11 compartment It can hold a can, a cup or the ashtray. Pull handle 10 to open it. The glove box can hold A4-size docu- ments, a large bottle of water, etc. The storage compartment is ventilated and refrigerated.
Page 163 PASSENGER COMPARTMENT STORAGE/FITTINGS (5/6) Rear door storage Front seat storage Clothes hooks 14 compartment 12 compartments 13 Grab handle 15 This offers support and can be held when the vehicle is being driven. Do not use it for getting into or out of the vehicle.
Page 164 PASSENGER COMPARTMENT STORAGE/FITTINGS (6/6) Retaining hook 16 Storage drawer 17 under Front and rear underfloor front and rear seats storage 18 This is used to hold bags while the ve- hicle is moving. These drawers can hold a road atlas, These compartments can hold road the vehicle documentation, etc.
Page 165: Accessories Socket
ASHTRAY/CIGAR LIGHTER/ACCESSORIES SOCKET Cigar lighter 1 Accessories sockets With the ignition on, push in cigar You may use cigar lighter recess 1 or lighter 1; it will spring back with a click one of the sockets 3 (depending on the when it is ready.
Page 166: Rear Headrests
REAR HEADRESTS Position for use To adjust side supports A Lift the headrest to maximum height, Depending on the vehicle, sections A then lower it until it locks. can be adjusted independently to the desired position. To remove the headrest Storage position B Press the tab(s) 1, then remove the headrest.
Page 167: Adjusting The Rear Seats
ADJUSTING THE REAR SEATS To fold down a seatback (table posi- tion) Lower headrest 3. Lift handle 4 or, depending on the vehi- cle, pull tab 1. An occasional table position can be created by folding the seatback all the way down onto the seat cushion.
Page 168 REAR SEAT FUNCTIONS (1/2) Folding up a seat Note: it may be necessary to move Returning a seat to its normal the passenger and/or driver’s seats position Lower the headrest. forwards and to lower the seatback in Lower the seat until it locks in place at order to tilt the seat as far forwards as Seat with control 2 floor level (movement A).
Page 169 REAR SEAT FUNCTIONS (2/2) When fitting side seats, make sure that the seat belt buckle is inside the vehicle. When driving with the seats folded down: ensure you check that the seats are moved fully forward before folding them down and place the load as close as possible to prevent the seats from falling back when ac- celerating or during sudden braking.
Page 170: Luggage Compartment
REAR SEAT OPERATION: 7-seater version (1/2) Third row rear seats To unfold a seat When moving third row rear – From the luggage compartment, seats: Folding up a seat remove the luggage cover and store – check that no one is near –...
Page 171 REAR SEAT OPERATION: 7-seater version (2/2) Accessing the third row rear – pull the second row rear seat to put it Use restriction into the table position; seats It is not permitted to drive with a second – lift the seatback. row rear seatback or seat folded down –...
Page 172 TAILGATE To open Opening the doors manually from the inside Press button 1 and lift the tailgate. Special note To close If it is impossible to unlock the tailgate, Lower the tailgate using the handles 2 it can be done manually from inside: inside the tailgate to help you.
Page 173: Rear Parcel Shelf: Normal Chassis Versions
REAR PARCEL SHELF: normal chassis versions Rear parcel shelf To remove, unhook the two straps 1. Fold section A onto section B, then pull up and towards you. To refit it, proceed in reverse order to removal. Do not place any objects, especially heavy or hard objects, on the parcel shelf.
Page 174: Luggage Cover: Long Chassis Versions
LUGGAGE COVER: long chassis versions To remove the flexible Removing the luggage cover Luggage compartment cover section of the luggage cover storage Push the luggage cover to the right (movement A) and lift the left-hand side Using handle 1, pull it gently to release Housing 3 in the luggage compartment of the inertia reel (movement B).
Page 175: Luggage Compartment Storage Space/Fittings
LUGGAGE COMPARTMENT STORAGE SPACE AND FITTINGS (1/2) Side storage compartments 1 Storage compartment under luggage compartment Depending on the vehicle, this may be carpet 3 used to hold oil containers etc. Depending on the vehicle, to access Bag hooks 2 this, lift the luggage compartment carpet.
Page 176: Luggage Compartment Storage Space And Fittings
LUGGAGE COMPARTMENT STORAGE SPACE AND FITTINGS (2/2) Separating the luggage Anchorage points compartment Hooks 6 located on each corner of the (depending on the vehicle) luggage compartment, allow the load to be secured. The loading area can be separated. Lift divider 4. The elastic band 5 on the back is used to hold objects vertically.
Page 177 TRANSPORTING OBJECTS IN THE LUGGAGE COMPARTMENT Always place the objects to be trans- ported so that their largest side rests against the back of the rear bench seat, for normal loads (example A) or against Always position the hea- the back of the front seats B when the viest items directly on the rear bench seatbacks are folded down.
Page 178: Transporting Objects
TRANSPORTING OBJECTS towbar Normal chassis C = 832 mm Long chassisC: Permissible nose weight, maxi- 5 and 7 seats = 981 mm mum permissible towing weight, braked and unbraked: refer to the information on “Weights” in Section 6. Choice and fitting of towing equipment Maximum weight of towing equip- ment: 21 kg...
Page 179: Luggage Net
LUGGAGE NET (1/2) Depending on the vehicle, this may be Fitting the luggage net – attach the two hooks 3 on the net used when transporting animals or lug- straps 4 to the anchoring points 5; behind the front seats gage to isolate them from the passen- –...
Page 180 LUGGAGE NET (2/2) Fitting the luggage net – attach net strap hook 8 to the lower Depending on the vehicle, remove the ring; anchoring rings 11 before installing a behind the rear seats luggage net. (behind the second row rear seats on –...
Page 181: Roof Bars
ROOF BARS Access to the mounting points Open the doors to access the mount- For information on the range of ing points 1. equipment adapted to your vehi- cle, we advise you to consult an ap- proved Dealer. Refer to the fitting instructions for in- formation on how to fit roof bars and conditions of use.
Page 182: Multimedia Equipment
MULTIMEDIA EQUIPMENT Multimedia systems Hands-free telephone integrated control The equipment described below may or may not be fitted to the vehicle, and On equipped vehicles, use the steering its location may vary, depending on the column control 6 and microphone 7. vehicle navigation system version.
Page 183 Section 4: Maintenance Bonnet ............... . Engine oil level: general information .
Page 184: Bonnet
BONNET (1/2) To open, pull handle 1, located on the Unlocking the bonnet catch left-hand side of the dashboard. To release it, lift tab 2. The engine may be hot when carrying out opera- Opening the bonnet tions in close proximity. In addition, the engine cooling Lift the bonnet;...
Page 185: Closing The Bonnet
BONNET (2/2) Closing the bonnet Check that nothing has been left in the engine compartment. To close the bonnet again, hold the bonnet in the middle and guide it down, allowing a 30 cm gap before it is closed, then release it. It will latch automatically under its own weight.
Page 186: Engine Oil Level: General Information
ENGINE OIL LEVEL: general information It is normal for an engine to use oil for – remove the dipstick and wipe with a lubrication and cooling of moving parts clean, lint-free cloth; and it is normal to top up the level be- –...
Page 187: Engine Oil Level: Topping Up/Filling
ENGINE OIL LEVEL: topping up, filling (1/3) Topping up/filling – Unscrew cap 1; – top up the level (as a guide, the ca- The vehicle must be parked on level pacity between the minimum and ground and the engine should be cold maximum reading on the dipstick 2 (for instance, before the engine is is between 1.5 and 2 litres, depend-...
Page 188 ENGINE OIL LEVEL: topping up, filling (2/3) In order to prevent splashback, it is recommended that a funnel be used when topping up/filling with oil. Do not exceed the max level and do not forget to refit cap 1 and dip- stick 2.
Page 189: Oil Change
ENGINE OIL LEVEL: topping up, filling OIL CHANGE (3/3)/ Oil change Exceeding the maximum Service interval: refer engine oil level Maintenance Document for your vehi- Under no circumstances cle. must the maximum fill level be exceeded: risk of damage to the The engine may be hot Average capacity for oil engine and catalytic converter.
Page 190: Levels
LEVELS (1/3) Checking intervals Replacement intervals Check the coolant level regularly Refer to the Maintenance Document for (very severe damage is likely to be your vehicle. caused to the engine if it runs out of coolant). If the level needs to be topped up, only use products approved by our Technical Department which ensure: –...
Page 191: Brake Fluid Level
LEVELS (2/3) Level 2 Topping up It is normal for the level to drop as the After any operation on the hydraulic cir- brake shoes become worn, but it must cuit, a specialist must replace the fluid. never drop lower than the “MINI” warn- Only use fluids approved by our ing line.
Page 192: Windscreen/Headlight Washer Reservoir
LEVELS /FILTERS (3/3) Filters Liquid Windscreen washer fluid. In winter, use The replacement of filter elements (air anti-freeze product. filter, passenger compartment filter, diesel filter, etc.) is scheduled in the Jets maintenance operations for your vehi- cle. Use a tool such as a needle to adjust the height of the windscreen washer Replacement intervals for filter el- jets.
Page 193: Tyre Pressure
TYRE PRESSURE (1/2) Vehicle fitted with a tyre pressure monitoring system If under-inflated (puncture, low pres- sure, etc.), the warning light lights up on the instrument panel; please refer to “Tyre pressure loss warning” or “Tyre pressure monitoring system” in Section 2. Vehicle used fully laden (Maximum Permissible All-up Weight) and towing a trailer...
Page 194 TYRE PRESSURE (2/2) Tyre safety and use of snow chains: Refer to the information on “Tyres” in Section 5 for the servicing conditions and, depending on the version, the use of chains. For your safety, please re- spect the speed limit. When they need to be re- placed, only tyres of the same make, size, type and profile...
Page 195: Battery
BATTERY (1/2) Depending on the vehicle, a system continuously checks the battery charge status. If this decreases, the message “Battery low start engine” is displayed on the instrument panel. In this case, start the engine. Then the message “Battery charging” appears on the in- strument panel for the duration of the charging time.
Page 196 BATTERY (2/2) Replacing the battery Before performing any As this operation is complex, we advise action in the engine com- you to contact an approved Dealer. partment, the ignition must be switched off by pressing Vehicle fitted with the Stop and Start the engine stop button (please see function the information on “Starting, stop-...
Page 197: Bodywork Maintenance
BODYWORK MAINTENANCE (1/2) What you should not do You should A well-maintained vehicle will last longer. It is therefore recommended to Do not degrease or clean mechani- Wash your car frequently, with the maintain the exterior of the vehicle reg- cal components (e.g.
Page 198 BODYWORK MAINTENANCE (2/2) Vehicles with a matte paint Using a roller type car wash Respect local regulations about wash- ing vehicles (e.g. do not wash your ve- finish Return the windscreen wiper stalk to hicle on a public highway). the Park position (refer to the informa- This type of paint requires certain pre- Observe the vehicle stopping distances tion on the “Windscreen washer, wiper”...
Page 199: Interior Trim Maintenance
INTERIOR TRIM MAINTENANCE (1/2) Glass instrument panel Textiles (seats, door trim, etc) A well-maintained vehicle will last longer. It is therefore recommended to (e.g.: instrument panel, clock, exterior Vacuum-clean the textiles regularly. maintain the interior of the vehicle re- temperature display, radio display, mul- gularly.
Page 200 INTERIOR TRIM MAINTENANCE (2/2) Removal/replacing removable You should not: equipment originally fitted in You are strongly advised not to po- the vehicle sition objects such as deodorants, scents, etc. near air vents, as this could If you need to remove equipment in damage your dashboard trim.
Page 201: Practical Advice
RENAULT card: battery ........
Page 202: Puncture
PUNCTURE/EMERGENCY SPARE WHEEL (1/2) In case of puncture Special note The Tyre Pressure Monitor function Depending on the vehicle, a tyre infla- does not check the emergency spare tion kit or emergency spare wheel is wheel (the wheel replaced by the emer- provided (refer to the following pages).
Page 203 PUNCTURE/EMERGENCY SPARE WHEEL (2/2) As the punctured wheel is wider than the emer- gency spare wheel, when Emergency spare wheel B To refit emergency spare wheel B you place the punctured Stand the wheel up with the valve to- It is located under the vehicle. In the wheel in the emergency spare wards you.
Page 204: Tyre Inflation Kit
TYRE INFLATION KIT (1/5) Do not attempt to use the The kit is only approved for inflation kit if the tyre has inflating the tyres of the ve- been damaged as a result hicle originally equipped of driving with a puncture. with the kit.
Page 205 TYRE INFLATION KIT (2/5) If a minimum pressure of 1.8 bar is 2 3 4 not reached after 15 minutes, repair is not possible; do not drive the ve- hicle but contact an approved dealer. Before using this kit, park the vehicle at a sufficient distance from traffic, switch on the hazard warning...
Page 206 TYRE INFLATION KIT (3/5) – affix driving recommendation label 9 Precautions when using the kit to the dashboard where it can easily The kit should not be operated for more be seen by the driver; than 15 consecutive minutes. – store the kit; –...
Page 207 TYRE INFLATION KIT (4/5) – after a maximum of 15 minutes, stop inflating and read the pressure (on pressure gauge 14). Note: while the container is empty- ing (approximately 30 seconds), the pressure gauge 14 will briefly indi- cate a pressure of up to 6 bar. The pressure will then drop.
Page 208 TYRE INFLATION KIT (5/5) Once the tyre is correctly inflated, Precautions when using the kit remove the kit: slowly unscrew the in- The kit should not be operated for more flation adapter 10 to prevent any repair than 15 consecutive minutes. product from escaping and store the container in plastic packaging to pre- vent the product from escaping.
Page 209: Towing Hitch
TOOLS (1/2) Hubcap tool 4 This tool is used to remove the wheel trims. Wheel bolt guide 5 For tightening/loosening wheel bolts on vehicles fitted with alloy wheels Towing hitch 6 Please see “Towing: breakdown recov- ery” in Section 5. Do not leave the tools un- secured inside the vehicle Lever 7...
Page 210: Wheel Trim
TOOLS /WHEEL TRIM (2/2) 7-seater version 5-seater version Wheel trim The tools are in the compartment 9 of Lift the boot carpet 10, and secure it Remove it using the hubcap tool 4 by the boot: lift the third row rear right- with the hook.
Page 211: Changing A Wheel
CHANGING A WHEEL (1/2) Vehicles equipped with a jack Offer up the jack 1 horizontally; the jack head must be lined up with the and wheelbrace sill, closest to the wheel concerned, as If necessary, remove the wheel trim. shown by arrow 2. Use the wheelbrace 3 to slacken off the Start cranking the jack up by hand to wheel bolts.
Page 212 CHANGING A WHEEL (2/2) Undo the bolts and take off the wheel. Fit the emergency spare wheel onto the hub and rotate it until the mounting holes in the wheel coincide with those of the hub. If bolts are supplied with the emergency spare wheel, only use these bolts for the emergency spare wheel.
Page 213 TYRES (1/3) Tyre and wheel safety When the tread has worn down to the wear warning strips, these strips will The tyres are the only contact between become visible 2: it is then necessary the vehicle and the road, so it is essen- to replace your tyres because the tread tial to keep them in good condition.
Page 214: Tyre Pressures
TYRES (2/3) Tyre pressures Pressures should be checked when the Vehicle fitted with a tyre pressure tyres are cold; ignore higher pressures monitoring system Adhere to the tyre pressures (including which may be reached in hot weather If under-inflated (puncture, low pres- the emergency spare wheel).
Page 215: Tyres (Tyre And Wheel Safety, Use In Winter)
TYRES (3/3) Fitting new tyres Use in winter Studded tyres This type of equipment may only be Chains used for a limited period and as laid For safety reasons, this op- For safety reasons, fitting snow down by local legislation. It is neces- eration must be carried out chains to the rear axle is strictly for- sary to observe the speed specified by...
Page 216: Headlights (Changing Bulbs)
FRONT HEADLIGHTS: changing bulbs (1/3) The engine may be hot when carrying out opera- tions in close proximity. In addition, the engine cooling fan can come on at any moment. Risk of injury. The bulbs detailed below can be re- Discharge bulb main beam placed.
Page 217: Halogen Headlights
FRONT HEADLIGHTS: changing bulbs (2/3) Main beamA/dipped B Refitting Direction indicator lights halogen headlights Carry out the operations in reverse Unscrew the bulb holder 2 to release it order. Ensure that the bulb is correctly and then replace the bulb. Removal repositioned (pay attention to the direc- Bulb type: PY21W.
Page 218 FRONT HEADLIGHTS: changing bulbs (3/3) Front fog lights 9 The front bumper needs to be removed; consult an approved Dealer. Daytime running lights and side lights 10 Any operation on (or modi- fication to) the electrical (Depending on the vehicle) system must be performed Please see an authorised dealer.
Page 219: Rear Lights (Changing Bulbs)
REAR LIGHTS AND INDICATOR LIGHTS: changing bulbs (1/4) From the outside, undo screw 2 using LED lighting Long chassis version a flat-blade screwdriver or similar and The lights are equipped with an LED pull the light unit towards you. Direction indicator lights/brake and lighting system as soon as the side side lights Unclip the bulb holder a quarter of a...
Page 220 REAR LIGHTS AND INDICATOR LIGHTS: changing bulbs (2/4) Normal chassis version Unclip the bulb holder by pressing on Refitting the tabs 6. To refit, proceed in the reverse order, Direction indicator lights and brake Replace the bulb. taking care not to damage the wiring. lights Note: do not remove seal 9.
Page 221 REAR LIGHTS AND INDICATOR LIGHTS: changing bulbs (3/4) Side light From the outside of the vehicle, pull on Rear fog light and reversing the light unit to remove it then unscrew light From the luggage compartment, unclip bulb holder 11 a quarter of a turn. (depending on the vehicle) the cover.
Page 222: Indicator Lights (Changing Bulbs)
REAR LIGHTS AND SIDE LIGHTS: changing bulbs (4/4) High level brake light 13 Number plate lights 14 Indicator lights 16 Consult an approved Dealer. Unclip light 14 by pressing tab 15. Unclip indicator light 16 using a flat- blade screwdriver or similar. Position Remove the light cover to gain access it to A to tilt the rear indicator light to- to the bulb.
Page 223 INTERIOR LIGHTING: changing bulbs (1/2) Courtesy light Door lights Sliding central console light – Set the three switches to the central Unclip light 2 (using a flat-blade screw- Unclip bulb 3 from its support. position; driver or similar). Bulb type: W5W. –...
Page 224 INTERIOR LIGHTING: changing bulbs (2/2) Luggage compartment lights Disconnect the light. Press tab 5 to release lens 7 and Unclip lights 4 using a flat-blade screw- access bulb 6. driver or similar. Bulb type: W5W. The bulbs are under pres- sure and can break when replaced.
Page 225: Fuses
FUSES (1/2) Fuse box Tweezers 1 If any electrical component does not Remove the fuse using tweezers 1, lo- work, check the condition of the fuses. cated at the back of flap A or B. Unclip cover A or B (depending on ve- To remove the fuse from the tweezers, Check the fuse in question hicle).
Page 226 FUSES (2/2) Allocation of fuses 8 Interior rear-view mirror; Some accessories are protected by fuses located in the engine compart- (the presence of certain fuses depends 9 Rear screen wiper; ment in fuse box C. on the vehicle equipment level) 10 and 11 Rear electric windows;...
Page 227: Connecting A Battery Charger
BATTERY: troubleshooting (1/2) To avoid all risk of sparks: Connecting a battery charger – Ensure that any consumers (cour- The battery charger must be com- tesy lights, etc.) are switched off patible with a battery with nominal before disconnecting or reconnect- voltage of 12 volts.
Page 228 BATTERY: troubleshooting (2/2) Starting the vehicle using the battery from another vehicle If you have to use the battery from an- other vehicle to start, obtain suitable jump leads (with a large cross section) from an approved dealer or, if you al- ready have jump leads, ensure that they are in perfect condition.
Page 229: Replacing The Battery
(insert the the next time the vehicle is started, the replace the RENAULT card battery, RENAULT card in the card reader) and message will disappear. press button 1 pulling on emergency lock/unlock the vehicle (refer to the in-...
Page 230: Accessories
ACCESSORIES Electrical and electronic accessories Before installing this type of accessory (particularly for transmitters/receivers: frequency bandwidth, power level, po- sition of the aerial, etc.), make sure it is compatible with your vehicle. You can get advice from an authorised dealer. Connect accessories with a maximum power of 120 watts only.
Page 231: Windscreen Wiper Blades
WIPER BLADES: replacing Check the condition of the wiper blades. You are responsible for their service life: – clean the blades, windscreen and rear screen regularly with soapy water; – do not use them when the wind- screen or rear screen are dry; –...
Page 232 If your vehicle is the towing or R for vehicles with automatic gear- vehicle, do not exceed the maximum boxes), insert the RENAULT card in the towing weight for your vehicle (refer to card reader, then press the engine start the information on “Weights”...
Page 233 Unclip cover 6 or 7 by sliding a flat tool These towing points may only be used (or the key integrated in the RENAULT for towing: never use them for lifting the card) under the cover.
Page 234 Dealer as soon as possible. Using the RENAULT card POSSIBLE CAUSES WHAT TO DO The RENAULT card does not lock or Card battery is flat. Replace the battery. You can still lock/ unlock the doors. unlock and start your vehicle (refer to the in- formation on “Locking, unlocking the open-...
Page 235: Operating Faults
Starting conditions are not ful- Please refer to the information on “Starting, stopping filled. the engine” in Section 2. The RENAULT “hands-free” card Insert the card in the card reader in order to start does not work. the engine. Please refer to the information on “Starting, stopping the engine”...
Page 236 OPERATING FAULTS (3/6) On the road POSSIBLE CAUSES WHAT TO DO Vibrations. Tyres not inflated to correct pres- Check the tyre pressures: if this is not the sures, incorrectly balanced or dam- problem, have them checked by an ap- aged. proved Dealer.
Page 237 OPERATING FAULTS (4/6) On the road POSSIBLE CAUSES WHAT TO DO Steering becomes heavy. Assistance overheating. Consult an approved dealer. The engine is overheating. The cool- Engine cooling fan not working. Stop the vehicle, switch off the engine and ant temperature indicator is in the contact an approved dealer.
Page 238 OPERATING FAULTS (5/6) Electrical equipment POSSIBLE CAUSES WHAT TO DO The wipers do not work. Wiper blades stuck. Free the blades before using the wipers. Faulty electrical circuit. Consult an approved dealer. Fuse damaged. Replace the fuse, refer to the information on “Fuses”.
Page 239 OPERATING FAULTS (6/6) Electrical equipment POSSIBLE CAUSES WHAT TO DO Traces of condensation in the lights. Traces of condensation may be a nat- ural phenomenon caused by varia- tions in temperature. In this case, the traces will disappear slowly once the lights are switched The front seat belt reminder light An object is stuck between the floor Remove all objects from underneath the...
Page 240 5.40...
Page 241: Technical Specifications
Section 6: Technical specifications Vehicle identification plates ............Engine identification plates .
Page 242: Vehicle Identification Plates
VEHICLE IDENTIFICATION PLATES The information shown on the ve- 4 MAM (Maximum Authorised hicle identification plate should be Mass). quoted on all correspondence or 5 GTW (Gross train weight: vehicle orders. fully loaded, with trailer). 6 MPAW (Maximim Permissible The presence and location of the in- Weight) for front axle.
Page 243: Engine Identification Plates
ENGINE IDENTIFICATION PLATES (1/2) Please quote the information on the engine plate or label A in all corre- spondence or orders. (Location varies depending on engine) 1 Engine type. 2 Engine suffix. 3 Engine number.
Page 244 ENGINE IDENTIFICATION PLATES (2/2) Please quote the information on the engine plate or label A in all corre- spondence or orders. (Location varies depending on engine) 1 Engine type. 2 Engine suffix. 3 Engine number.
Page 245: Dimensions
DIMENSIONS (in metres) (1/2) Standard chassis All terrain 0,911 0,912 2,702 2,704 0,753 0,756 4,366 4,372 1,546 1,547 1,559 2,077 1,624 1,683 (unladen)
Page 246 DIMENSIONS (in metres) (2/2) Long chassis 0,901 2,769 0,903 1,536 4,573 1,675* 1,539 2,077 Unladen...
Page 247: Engine Specifications
ENGINE SPECIFICATIONS Versions 1.2 TCe 1.6 16V 2.0 16V 1.5 dCi 1.6 dCi 1.9 dCi 2.0 dCi Engine type H5F Turbo (see engine plate) Cubic capacity (cc) 1 197 1.598 1.995 1.461 1 598 1.870 1.995 It is essential that you use unleaded petrol of the octane rating stated on the label inside the fuel filler flap.
Page 248: Weights
WEIGHTS (in kg) The weights indicated are for a basic vehicle without options: they may vary depending on your vehicle’s equipment. Consult an approved Dealer. Maximum Permissible All-Up Weight (MMAC) Weights are indicated on the vehicle identification plate (refer Gross Train Weight (MTR) to the information on “Vehicle identification plates”...
Page 249: Replacement Parts And Repairs
REPLACEMENT PARTS AND REPAIRS Original parts are based on strict specifications and are subject to highly-specialised tests. Therefore, they are of at least the same level of quality as the parts fitted originally. If you always fit genuine replacement parts to your vehicle, you will ensure that it performs well. Furthermore, repairs carried out within the manufacturer’s Network using original parts are guaranteed according to the conditions set out on the reverse of the repair order.
Page 250: Service Sheets
SERVICE SHEETS (1/6) VIN: .................. Date: Miles (km): Invoice number: Comments/miscellaneous Type of operation: Stamp Service □ ........□ Anticorrosion check: OK □ Not OK* □ *See specific page Date: Miles (km): Invoice number: Comments/miscellaneous Type of operation: Stamp Service □...
Page 251 SERVICE SHEETS (2/6) VIN: .................. Date: Miles (km): Invoice number: Comments/miscellaneous Type of operation: Stamp Service □ ........□ Anticorrosion check: OK □ Not OK* □ *See specific page Date: Miles (km): Invoice number: Comments/miscellaneous Type of operation: Stamp Service □...
Page 252 SERVICE SHEETS (3/6) VIN: .................. Date: Miles (km): Invoice number: Comments/miscellaneous Type of operation: Stamp Service □ ........□ Anticorrosion check: OK □ Not OK* □ *See specific page Date: Miles (km): Invoice number: Comments/miscellaneous Type of operation: Stamp Service □...
Page 253 SERVICE SHEETS (4/6) VIN: .................. Date: Miles (km): Invoice number: Comments/miscellaneous Type of operation: Stamp Service □ ........□ Anticorrosion check: OK □ Not OK* □ *See specific page Date: Miles (km): Invoice number: Comments/miscellaneous Type of operation: Stamp Service □...
Page 254 SERVICE SHEETS (5/6) VIN: .................. Date: Miles (km): Invoice number: Comments/miscellaneous Type of operation: Stamp Service □ ........□ Anticorrosion check: OK □ Not OK* □ *See specific page Date: Miles (km): Invoice number: Comments/miscellaneous Type of operation: Stamp Service □...
Page 255 SERVICE SHEETS (6/6) VIN: .................. Date: Miles (km): Invoice number: Comments/miscellaneous Type of operation: Stamp Service □ ........□ Anticorrosion check: OK □ Not OK* □ *See specific page Date: Miles (km): Invoice number: Comments/miscellaneous Type of operation: Stamp Service □...
Page 256: Anticorrosion Check
ANTICORROSION CHECK (1/6) If the continuation of the warranty is subject to repair, it is indicated below. VIN: ............Corrosion repair operation to be carried Stamp out: Date of repair: Repair to be carried out: Stamp Date of repair: Repair to be carried out: Stamp Date of repair: 6.16...
Page 257 ANTICORROSION CHECK (2/6) If the continuation of the warranty is subject to repair, it is indicated below. VIN: ............Corrosion repair operation to be carried Stamp out: Date of repair: Repair to be carried out: Stamp Date of repair: Repair to be carried out: Stamp Date of repair: 6.17...
Page 258 ANTICORROSION CHECK (3/6) If the continuation of the warranty is subject to repair, it is indicated below. VIN: ............Corrosion repair operation to be carried Stamp out: Date of repair: Repair to be carried out: Stamp Date of repair: Repair to be carried out: Stamp Date of repair: 6.18...
Page 259 ANTICORROSION CHECK (4/6) If the continuation of the warranty is subject to repair, it is indicated below. VIN: ............Corrosion repair operation to be carried Stamp out: Date of repair: Repair to be carried out: Stamp Date of repair: Repair to be carried out: Stamp Date of repair: 6.19...
Page 260 ANTICORROSION CHECK (5/6) If the continuation of the warranty is subject to repair, it is indicated below. VIN: ............Corrosion repair operation to be carried Stamp out: Date of repair: Repair to be carried out: Stamp Date of repair: Repair to be carried out: Stamp Date of repair: 6.20...
Page 261 ANTICORROSION CHECK (6/6) If the continuation of the warranty is subject to repair, it is indicated below. VIN: ............Corrosion repair operation to be carried Stamp out: Date of repair: Repair to be carried out: Stamp Date of repair: Repair to be carried out: Stamp Date of repair: 6.21...
Page 262 6.22...
Page 263: Alphabetical Index
ALPHABETICAL INDEX (1/5) central door locking ........1.8, 1.11 → 1.13 ABS ..............1.56, 2.24 → 2.28 changing a bulb .............5.16 → 5.22 accessories................ 5.30 changing a wheel............ 5.11 – 5.12 accessories socket ............3.25 changing gear ..........2.11, 2.44 → 2.46 additional methods of restraint .....1.23 → 1.26, 1.29 child restraint/seat ......1.30 –...
Page 264 ALPHABETICAL INDEX (2/5) driving recommendations ........2.15 → 2.17 front seat adjustment ..........1.15 – 1.16 front seats adjustment ............1.15 – 1.16 electric beam height adjustment ........1.80 with electric controls ............ 1.17 electric windows ............3.12 → 3.14 with manual controls ............ 1.15 electronic parking brake .......1.55, 2.12 →...
Page 265 ALPHABETICAL INDEX (3/5) Hill Start Assist..........1.56, 2.24 → 2.28 lights horn ................... 1.74 adjustment ..............1.80 horn: changing bulbs ..........5.16 → 5.18 flash ................1.74 front ..............5.16 → 5.18 sounding the horn ............1.74 mobile directional ............1.77 hubcap tool ............... 5.9 – 5.10 lights: adjusting ..............
Page 266 ............ 2.42 – 2.43 sun visor ................3.17 rear view mirrors ..............1.73 sunroof..............3.12 → 3.14 RENAULT ANTI-INTRUDER DEVICE (RAID) ....1.13 switching on the vehicle ignition .......... 2.4 RENAULT card battery ................5.29 use ...............1.2 → 1.8 tailgate ..........
Page 267 ALPHABETICAL INDEX (5/5) telephone ................3.42 wheelbrace ............... 5.9 – 5.10 temperature regulation ..........3.6 → 3.10 wheels (safety) ............5.13 → 5.15 tool kit ............... 5.9 – 5.10 windscreen de-icing/demisting ........3.5, 3.9 towing windscreen washer ........1.84 – 1.85, 4.10 breakdown ............
Page 270 à999106050Rë ò ï ä RENAULT S.A.S. SOCIÉTÉ PAR ACTIONS SIMPLIFIÉE AU CAPITAL DE 533 941 113 € / 13-15, QUAI LE GALLO 92100 BOULOGNE-BILLANCOURT R.C.S. NANTERRE 780 129 987 — SIRET 780 129 987 03591 / TÉL. : 0810 40 50 60 NU 1095-6 –...

This manual is also suitable for:

Scenic 2016

Renault Scenic Driver's Handbook Manual

Table of Contents

Section 2: Driving

Section 3: Your Comfort

Section 4: Maintenance

Section 5: Practical Advice

Section 6: Technical Specifications

Quick Links

Chapters

Need help?

Questions and answers

Related Manuals for Renault Scenic

Summary of Contents for Renault Scenic

This manual is also suitable for:

Table of Contents
