- Page 1 PA 4080 KB keyboard combo user manual...
- Page 2 Musikhaus Thomann e.K. Treppendorf 30 96138 Burgebrach Germany Telephone: +49 (0) 9546 9223-0 E-mail: info@thomann.de Internet: www.thomann.de 28.07.2014, ID: 147171...
-
Page 3: Table Of Contents
Table of contents Table of contents General information..........................5 1.1 Further information........................... 6 1.2 Notational conventions........................7 1.3 Symbols and signal words....................... 7 Safety instructions............................. 9 Features and scope of delivery ......................14 Installation and starting up........................ 15 4.1 Pin assignment..........................16 4.2 Tips on handling speakers...................... - Page 4 Table of contents Protecting the environment......................33 keyboard combo...
-
Page 5: General Information
General information General information This manual contains important instructions for the safe operation of the unit. Read and follow the safety instructions and all other instructions. Keep the manual for future reference. Make sure that it is available to all those using the device. If you sell the unit please make sure that the buyer also receives this manual. -
Page 6: Further Information
General information 1.1 Further information On our website (www.thomann.de) you will find lots of further information and details on the following points: Download This manual is also available as PDF file for you to download. Use the search function in the electronic version to find the topics of Keyword search interest for you quickly. -
Page 7: Notational Conventions
General information 1.2 Notational conventions This manual uses the following notational conventions: Letterings The letterings for connectors and controls are marked by square brackets and italics. Examples: [VOLUME] control, [Mono] button. 1.3 Symbols and signal words In this section you will find an overview of the meaning of symbols and signal words that are used in this manual. - Page 8 General information Signal word Meaning DANGER! This combination of symbol and signal word indicates an immediate dangerous situation that will result in death or serious injury if it is not avoided. CAUTION! This combination of symbol and signal word indicates a pos‐ sible dangerous situation that can result in minor injury if it is not avoided.
-
Page 9: Safety Instructions
Safety instructions Safety instructions Intended use This device is intended to be used for amplification and playback of signals from musical instruments and microphones. Use the unit only as described in this manual. Any other use or use under other operating conditions is considered to be improper and may result in personal injury or property damage. - Page 10 Safety instructions Safety DANGER! Danger for children Ensure that plastic bags, packaging, etc. are disposed of properly and are not within reach of babies and young children. Choking hazard! Ensure that children do not detach any small parts (e.g. knobs or the like) from the unit.
- Page 11 Safety instructions DANGER! Electric shock caused by short-circuit Always use proper ready-made insulated mains cabling (power cord) with a pro‐ tective contact plug. Do not modify the mains cable or the plug. Failure to do so could result in electric shock/death or fire. If in doubt, seek advice from a regis‐ tered electrician.
- Page 12 Safety instructions NOTICE! Risk of fire Do not cover the device nor any ventilation slots. Do not place the device near any direct heat source. Keep the device away from naked flames. NOTICE! Operating conditions This device has been designed for indoor use only. To prevent damage, never expose the device to any liquid or moisture.
- Page 13 Safety instructions NOTICE! Power supply Before connecting the device, ensure that the input voltage (AC outlet) matches the voltage rating of the device and that the AC outlet is protected by a residual current circuit breaker. Failure to do so could result in damage to the device and possibly injure the user.
-
Page 14: Features And Scope Of Delivery
Features and scope of delivery Features and scope of delivery Special features of this four-channel keyboard combo: 80 watt RMS output power Built-in spring reverb, foot-switchable (FS not included) 1 × MIC input (XLR, balanced) and 1 × LINE input (1/4" phone socket) per channel Volume, tone and reverb control per channel 2 additional CD/Tape in and outputs Master section with 3-band EQ... -
Page 15: Installation And Starting Up
Installation and starting up Installation and starting up Unpack and carefully check that there is no transportation damage before using the unit. Keep the equipment packaging. To fully protect the device against vibration, dust and moisture during transportation or storage use the original packaging or your own packaging material suitable for transport or storage, respectively. -
Page 16: Pin Assignment
Installation and starting up 4.1 Pin assignment You can use XLR plugs with balanced or unbalanced wiring. In the following, we will give you an overview of the various options. XLR connections for signal Balanced XLR mounting sockets are used for signal inputs. Drawing and table indicate the XLR inputs pin assignment for plugs to be used. - Page 17 Installation and starting up Unbalanced wiring: Ground, shielding Signal Bridged to pin 1 1/4" phone sockets for signal Drawing and table indicate the pin assignment of a 1/4" phone jack to be used. inputs TS jack, unbalanced: Signal Ground, shielding PA 4080 KB...
- Page 18 Installation and starting up TRS jack, unbalanced: Signal 2, 3 Ground, shielding TRS jack, balanced: 1 (Tip) Positive signal (+) 2 (Ring) Negative signal (–) 3 (Sleeve) Ground, shielding keyboard combo...
-
Page 19: Tips On Handling Speakers
Installation and starting up 4.2 Tips on handling speakers We recommend you to set up the speakers in a way, that the sound signals can reach the audi‐ ence unobstructedly. It will often be helpful to mount the speakers on tripods. Thus, the sound will be evenly spread with maximum range throughout the audience area. -
Page 20: Connections And Operating Elements
Connections and operating elements Connections and operating elements Top panel keyboard combo... - Page 21 Connections and operating elements 1 [Tone] Tone control to set the desired sound in the respective channel. 2 [Reverb] Reverb control to adjust the reverb level in the respective channel. 3 [Mic] Low-impedance XLR microphone input, balanced. 4 [Line] High-impedance 1/4" line input, unbalanced. 5 [Volume] Volume control to set the desired volume in the respective channel.
- Page 22 Connections and operating elements 7 [Mid] Mids control of the 3-band master EQ. 8 [High] Treble control of the 3-band master EQ. 9 [Power On] This indicator lights up when the unit is switched on. 10 [Tape] Use this control to set the playback volume for the CD/TAPE input signals. 11 [Foot Switch] Here you can connect a foot switch (not supplied) with a 1/4"...
- Page 23 Connections and operating elements 13 [Effects Send] This outlet provides the combined effect signal that is tapped from the channels with the [Reverb] controls (2). 14 [Main Output] Use this outlet to feed the line level master signal into e.g. an external power amp. 15 [Reverb] Use this control to set the overall reverb level.
- Page 24 Connections and operating elements Rear panel keyboard combo...
- Page 25 Connections and operating elements 17 [Power] Use this mains switch to turn the device on or off. 18 [CD/Tape Rec] Use these connections to record the line out signal of the device with a tape device or the like. 19 [CD/Tape Play] Here you can connect the line output of tape devices, CD or MP3 players for additional audio input.
-
Page 26: Operation
Operation Operation Wiring Connect microphones to the low-impedance XLR inputs [Mic] or to the high-impedance 1/4" inputs [Line]. Connect musical instruments to the 1/4" inputs [Line]. If desired, connect one or more speaker boxes via a suitable speaker cable to the [External Speaker] socket on the rear panel of the unit. - Page 27 Operation If you route the effect signal from the [Effects Send] output into an external effects device, con‐ nect its outlet to the [Aux Input] to lead the processed signal back into the signal path. You can connect a foot switch (not supplied) to the two-pole [FOOT SW] socket to turn the internal reverb function on or off.
- Page 28 Operation Turning off If you no longer want to use the device, turn it off with the [POWER] switch. The [Power On] LED then turns off. keyboard combo...
-
Page 29: Cleaning
Cleaning Cleaning Cleaning plastic housing Do not use aggressive cleaners. Wipe the casing only with a slightly damp cloth. PA 4080 KB... -
Page 30: Troubleshooting
Refit the fuse holder cap and reconnect the device to the mains power supply. If the procedures recommended above do not succeed, please contact our Service Center. You can find the contact information at www.thomann.de. keyboard combo... -
Page 31: Technical Specifications
Technical specifications Technical specifications Output power 80 watt RMS Input impedance MIC inputs 1 kΩ LINE inputs 10 kΩ CD/Tape input 10 kΩ Maximum gain MIC inputs 76 dB LINE inputs 56 dB CD/Tape input 42 dB ±15 dB @ 5 kHz Channel tone control ±15 dB @ 10 kHz Master section EQ... - Page 32 Technical specifications Dimensions (W × H × D) 500 × 620 × 320 mm Weight 19.0 kg keyboard combo...
-
Page 33: Protecting The Environment
Protecting the environment Protecting the environment Disposal of the packaging mate‐ rial For the transport and protective packaging, environmentally friendly materials have been chosen that can be supplied to normal recycling. Ensure that plastic bags, packaging, etc. are properly disposed of. Do not just dispose of these materials with your normal household waste, but make sure that they are collected for recycling. - Page 34 Notes keyboard combo...
- Page 36 Musikhaus Thomann e.K. · Treppendorf 30 · 96138 Burgebrach · Germany · www.thomann.de...
