W.MACHINE/WASHER-DRYER
31000443 HF7150MUK
Service Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HF7150MUK and is the answer not in the manual?

Questions and answers

Related Manuals for Hoover HF7150MUK

Summary of Contents for Hoover HF7150MUK

  • Page 1 W.MACHINE/WASHER-DRYER 31000443 HF7150MUK Service Manual...
  • Page 2 2003 Range Washing Machines HF7130M ,HF7150M UK © PAGE 6 2003 GIAS U.K. / Hoover Ltd.
  • Page 3 2003 Range Washing Machines HF7130M ,HF7150M UK © PAGE 7 2003 GIAS U.K. / Hoover Ltd.
  • Page 4 2003 Range Washing Machines HF7130M ,HF7150M UK © PAGE 8 2003 GIAS U.K. / Hoover Ltd.
  • Page 5 2003 Range Washing Machines HF7130M ,HF7150M UK © PAGE 9 2003 GIAS U.K. / Hoover Ltd.
  • Page 6 31000443 HF7150MUK 0339 (22/09/2003) Ricambio Inizio Fine Part No. Beginning Ending Piece Debut E-Teil Begin Ref. Descrizione - Description - Beschreibung - Descripcion Pieza Inicio Programs disc 03841547 Buffer with spring service pack 97917116 Temp.regulation knob 03841476 Therm/potent. knob spring...
  • Page 7 31000443 HF7150MUK 0339 (22/09/2003) Ricambio Inizio Fine Part No. Beginning Ending Piece Debut E-Teil Begin Ref. Descrizione - Description - Beschreibung - Descripcion Pieza Inicio Water injector nozzle 92149327 Distribution connecting rod 92884212 Lever 97910582 Driving lever 92152800 114a Hose clip...
  • Page 8 31000443 HF7150MUK 0339 (22/09/2003) Ricambio Inizio Fine Part No. Beginning Ending Piece Debut E-Teil Begin Ref. Descrizione - Description - Beschreibung - Descripcion Pieza Inicio 161d Drain/recycle pump complete 91941771 Door safety device 90489300 Anti jamming filter radio 91200098 Motor connector...
  • Page 9 31000443 HF7150MUK 0339 (22/09/2003) Ricambio Inizio Fine Part No. Beginning Ending Piece Debut E-Teil Begin Ref. Descrizione - Description - Beschreibung - Descripcion Pieza Inicio Door gasket 41008852 Discharge pipe 41001241 Fill pipe 91620033 Pressure switch air chamber 06012804 5x8 hose...
  • Page 10 31000443 HF7150MUK 0339 (22/09/2003) Ricambio Inizio Fine Part No. Beginning Ending Piece Debut E-Teil Begin Ref. Descrizione - Description - Beschreibung - Descripcion Pieza Inicio Therm.press.push b. supp. 03870756 618c Unipolar NA+P.A. switch 90489683 Control support plate 91802090 Screw for motor...
  • Page 11 2003 Range Washing Machines CIRCUIT DIAGRAM HF7 150M © PAGE 16 2003 GIAS U.K. / Hoover Ltd.
  • Page 12 2003 Range Washing Machines WIRING DIAGRAM HF7 150 M © PAGE 17 2003 GIAS U.K. / Hoover Ltd.
  • Page 13 TO SETUP DISPENSER ACTUATING ARM, Program 1 pointer at 1 notch Program 2 pointer at 2 notch Program 5 Pointer at 3 notch Program 6 pointer at 4 notch © PAGE 2 2003 GIAS U.K. / Hoover Ltd.
  • Page 14 • There are three types of motor fitted to this range of machines, CESET,SOLE and the HOOVER MOTOR. • Where the HOOVER motor is fitted all component parts will be made available, as shown in the main parts listings. MOTOR ASSY REMOVAL •...
  • Page 15 • Earth Continuity Earth pin on plug top to 1. Door Hinge Max 1Ω 2. Drum Inner Max 1Ω Insulation CCP Bonded to Earth spin selected, door shut, Switched On Minimum 1MΩ © PAGE 4 2003 GIAS U.K. / Hoover Ltd.

  • Page 16: Specifications

    EXTRA RINSE ENERGY WASHING SPINING 0.95 0.95 KWh/Cycle WATER CONS LOAD (washing/drying kg) PROGRAMMES No. of Programmes EXPRESS WASH ECONOMY PRE-WASH SELECT SPIN DELAY START TOT. BUTTON HAND WASH SPORTSWEAR SPEED WASH © PAGE 5 2003 GIAS U.K. / Hoover Ltd.
