Summary of Contents for Outdoor Tech Big Turtle Shell
- Page 1 BIG TURTLE SHELL ® R U G G E D W I R E L E S S B O O M B O X By Outdoor Tech ® · H I – F I S O U N D ·...
- Page 3 Welcome to total sonic freedom.
- Page 4 outdoortech.com...
-
Page 5: Table Of Contents
CONTENTS SHELL ANATOMY POWER UP PAIR WIRED POWERBANK LISTEN & TALK SPECIFICATIONS... -
Page 6: Shell Anatomy
ANATOMY Power Button Multifunction Button (MFB) Press once to Play/Pause OR Answer/Hang up. Hold down for 4 seconds to enter pairing mode. Volume/Track Control Raise volume by pressing >> Lower volume by pressing << Skip forward by holding >> for 2 seconds Skip backward by holding <<... - Page 7 ANATOMY 3.5mm Audio Input/Output Big Turtle Shell Charge Port ® USB Device Charge Port Built in Microphone...
- Page 8 ANATOMY Grab Handles/ Mounting Bars Strap them to your bike and them on a stroll or hold two on each hand and have them play anywhere! Passive Bass Port...
-
Page 9: Power Up
POWER For best audio experience, fully charge your Big Turtle Shell before use. ® *NOTE: It takes about 3 hours to fully charge the Big Turtle Shell. Power On: Press & hold the power button. LED Light Indicator Indicator Light... -
Page 10: Pair
Pair the first device Power on Big Turtle Shell ® then it will in the pairing mode. Use your device to search for the "ODT Big Turtle Shell " ® when successfully paired the Big Turtle Shell will prompt "Successful"... - Page 11 PAIR Pairing by NFC* Place the NFC device over the NFC logo on the Big Turtle Shell ® It will connect your device via bluetooth automatically. *When bluetooth is turned off Plug & Play - 3.5mm stereo line in No Bluetooth? The Big Turtle Shell also connects via 3.5mm stereo input.
-
Page 12: Wired
WIRED Connect via 3.5mm stereo input. 3.5mm stereo input (Wired audio) When using the Big Turtle Shell as a speaker-phone, please note that the built-in microphone ® only works while connected via Bluetoooth. Your Big Turtle Shell can wirelessly stream audio from any Bluetooth device up to 32 feet away. -
Page 13: Powerbank
POWERBANK Power Out: CHARGES THE CHARGES THE GO PRO 7.5X IPHONE 4X The Big Turtle Shell supports ® POWER OUT (5V 1A) and can be used as a power bank. Use your CHARGES THE cable and charge your device GALAXY 3.5X... -
Page 14: Listen & Talk
LISTEN YOU CHOOSE TRADITIONAL DIRECTIONAL SOUND 360° ROOM FILLING SOUND... - Page 15 ® When connected wirelessly via Bluetooth, it's best to turn the volume on your phone/device fully up and when you use the volume control (<</>>) on the Big Turtle Shell ® When connected via 3.5mm stereo input, your phone/device may distort the audio signal if...
- Page 16 Decline Call: Press and hold the MFB button for 2 seconds. Make a Call: Use your phone to dial as usual. Listen and talk through the Big Turtle Shell ® Redial Last Number: Press << button and MFB simultaneously.
-
Page 17: Specifications
SPEC Battery Life: Music playing for 16 hours/ Standby time about 325 hours *Battery life varies subject to different playing circumstances such as music type or volume. Speaker: 4Ω, rated power 3W/maz power 5W x2 Input: DC14.5V 2.48A Output: 5V/1000mA Weight: About 2.2lbs (1020 grams) Bluetooth Range: Up to 32 feet from device... -
Page 18: Faq
® Make sure its charged up. Check for low battery, then charge if necessary. Not Loud Enough Turn up the volume on your phone/device or your Big Turtle Shell ® Make sure it's charged up. Plug the Big Turtle Shell in to your phone/device via 3.5mm stereo cable. - Page 19 Re-pair: Follow pairing instructions in this guide. Signal Loss or Dropouts via Bluetooth Move Big Turtle Shell closer to your phone/device. ® Make sure it's charged up. Turn off your Big Turtle Shell and phone/device, then power up and reconnect. ®...
- Page 20 DON’T BE SO ANTISOCIAL Facebook.com/outdoortech Twitter & Instagram: @outdoortech Questions, comments, complaints, secret desires, or just to say what’s up: email info@outdoortech.com outdoortech.com K bye.
