- Page 1 LIVSLÅGA...
- Page 3 ENGLISH...
-
Page 4: Table Of Contents
Safety information Injector table Product description Technical Data Daily use Installation Helpful hints and tips Environmental concerns Maintenance and cleaning IKEA GUARANTEE What to do if Safety Information Your safety and the safety of supply before carrying out any others are very important. installation work. This manual and the appliance Installation and maintenance itself provide important safety... - Page 5 ENGLISH supplier from a neighbor’s be performed by a qualified phone. Follow the gas electrician. supplier’s instructions. - The manufacturer cannot - If you cannot reach your be held responsible for any gas supplier, call the fire injury to persons or animals or department.
- Page 6 ENGLISH kept away unless continuously hob with fat or oil can be supervised. This appliance dangerous and may result in can be used by children aged fire. NEVER try to extinguish a from 8 years and above and fire with water, but switch off persons with reduced physical, the appliance and then cover sensory or mental capabilities...
-
Page 7: Product Description
ENGLISH Product description Removable panstand grids Semirapid burner Semirapid burner Power burner Auxiliary burner Power burner control knob Semirapid burner control knob Semirapid burner control knob Auxiliary burner control knob Symbols Solid disc Tap closed Large flame Maximum opening/delivery and star and electric ignition Minimum opening... -
Page 8: Daily Use
ENGLISH Daily use Do not let the burner flame extend The knob must not be pressed for beyond the edge of the pan. more than 15 sec. If, after that time has Important: when the hob is in use, the entire elapsed, the burner does not remain lit, hob area may become hot. -
Page 9: Maintenance And Cleaning
ENGLISH Maintenance and cleaning necessary, clean them with a damp Disconnect power before servicing. cloth. Any baked-on food should be All the enamelled and glass parts removed with a toothpick or needle. should be cleaned with warm water and neutral solution. Stainless steel surfaces may be stained by calcareous water or aggressive detergents if left in contact for too long. -
Page 10: What To Do If
ENGLISH What to do if ... Problem Possible cause Solution The electric ignition does not There is no electrical Check the unit is plugged in work supply and the electrical supply is switched on. The burner fails to ignite The gas tap could be Check that the gas tap is closed open The gas ring burns unevenly... -
Page 11: Injector Table 1
ENGLISH Injector table Model HBT L80S Gas Type NATURAL @ 1.00 kPa PROPANE @ 2.75 kPa (test point pressure) (inlet pressure) Burner Nominal Gas Nominal Injector Nominal Gas Nominal Injector Consumption (MJ/h) Size (mm) Consumption (MJ/h) Size (mm) Auxiliary 4. 1 0.90 0.53 Semi-Rapid 1.25 0.73 13.6 1.68 13.0 1.03 Electric Power: 220 - 240 V ~ 50/60 Hz... -
Page 12: Technical Data
ENGLISH Technical data Product Dimensions Width (mm) Height (mm) Length (mm) Voltage (V) 220 - 240 The technical information are situated in the rating plate on the bottom side of the appliance. Note: A duplicate Data Plate provided with the appliances should be affixed adjacent to the appliance nearby on a cabinet or area where it is easily accessible for reference. - Page 13 ENGLISH This appliance is not connected to a fume exhaust device. It shall be installed in accordance with current installation regulations. Particular attention shall be given to the relevant requirement regarding ventilation. Combustion products are discharged outdoors through specific hoods or wall and/or window mounted electrical fans.
- Page 14 ENGLISH Electrical connection If the appliance is intended to operate with a different gas from the gas type stated on WARNING the rating plate and information label on This operation must be performed by the top of the hob, change the injectors. a qualified technician or authorised Remove the information label and keep it person.
- Page 15 ENGLISH Adjusting minimum gas setting of taps To ensure that the minimum setting is correctly adjusted, remove the knob (E) and proceed as follows: tighten screw to reduce the flame height (-); loosen screw to increase the flame height (+). The adjustment must be performed with the tap in minimum gas setting position (small flame ) .
- Page 16 ENGLISH SERVICE INSTRUCTIONS Service and maintenance only to be carried out by an authorised person. To replace parts such as burners, valve and electric components, the hotplate must be removed from the bench top by releasing the attachment hooks, loosening the attachment screws of each burner, unscrewing the hotplate attachments nuts which are visible at the bottom of the surface, removing the hotplate top, taking...
- Page 17 ENGLISH KNOBS REPLACEMENT Push each of knob on the valve shaft until Be sure that your hob is switched-off! you feel the end of sliding (sparking may All knobs must be in closed position. occur). Pull upwards each knob of the cooktop and Make sure that all the knobs are in the right store together after removal.
-
Page 18: Environmental Concerns
The services will be in-home service for from the original date of purchase of your domestic appliances, and must to be done appliance at IKEA, unless the appliance is by official Whirlpool service network. named LAGAN in which case two (2) years Goods presented for repair may be of guarantee apply. - Page 19 • Internal or external damage as a result another address, IKEA is not liable for of excessive use of cleaning products or any damage that may occur during cleaning agents.
- Page 20 IKEA appliance in the dedicated IKEA the time of call registration. kitchen furniture; • ask for clarification on functions of IKEA Do you need extra help? appliances. For any additional questions not related • Call our authorized service network to After Sales of your appliances please partner Whirlpool on 1300 363 344 contact your nearest IKEA store call centre.
- Page 24 © Inter IKEA Systems B.V. 2014 19069 AA-1 186004-1...
