Press this button to validate email settings after setup is completed.

Control Projector with the PJLink Protocol

PJLink is a standard designed by Japan Business Machine and Information System Industries Association
(JBMA) for controlling projectors with genuine commands. A PJLink standard compliant projector from any
supplier can be controlled with these genuine commands. This product supports PJLink control commands.
Please set up password for PJLink connection in this page.
PJLink Security : Select On to enable PJLink password or Off to disable it.
Password : Set up password at length up to 32 characters.
For details on PJLink standard commands and connection methods, please visit the PJLink official web site.
Control Projector with TCP/IP Communication Protocol
This projector supports TCP/IP communication protocol. It enables you to send RS-232 operation commands
or simulated IR commands to control projectors which connected with RJ45 cable via terminal connection
application software, e.g. Tera Term. Please set up IP address and port number with the terminal connection
application software before controlling your projector with TCP/IP communication protocol:
IP Address : IP address of projector
Port : Please set transmission port number to 7000
See the section on serial interface RS-232 control commands for details on RS-232 operation commands or
simulated IR commands.
58
Control the projector through a network Specifications and Support
Specificatons and Support
Specifications
Model Name DU9000
Technology DLP
Resolution WUXGA(1920x1200)
Max. Resolution WUXGA(1920x1200)@60Hz
Contrast 1250:1 / with DB 5000:1
Lamp Life and Tye 1500/2000 hours（Standard/Eco mode），465Wx2
Projection Lens 1.85-2.4:1 (Standard)
0.8-1.03:1
Projection distance 2.5-9.0m (Standard lens)
F# F=2.17-2.46, f=39-50.7mm(Standard Lens)
Zoom Ratio（Standard Lens) 1.3X
Asppct Ratio 16:10 Normal
4:3 and 16:9 Compairable
Lens Shift Vertical: 12.5%~15%,Horizontal: 37.5%~50%
Keystone correction Vertical:：+/-30° , Horizontal: +/-20°
Sync Vertical: 48-120Hz
Horizontal: 15-108kHz
Edge Blending / Warping Yes
Video Compatibility SDTV(480i/576i)， EDTV (480p/576p)， HDTV (720p，1080i/p)
I/O Ports HDMI v1.4 x 2、3D Sync Out x 1、 HDBaseT (Lan Control) x 1、VGA x 1、
Component (YPbPr) x 2, RS-232C、Screen Trigger x 2、 Wire Remote x 1、
USB x 1
Projction Table top and ceiiing (Front and rear)
Size (W x D x W) 630 x 500 x 250mm
Weight (Not included Lens） 30kg
Noise Level 44dB/47dB（Eco Mode / Standard Mode）
Power AC110-240V，50/60Hz
Standby Power Standby Power：< 2W（No RJ-45 active）
Power consumption 1200 Watt
Standard Accessory Power cord x3, HDMI x1, Remote Contorl, lens cap ,CD
®
1.56-1.86:1
2.4-4.0:1
