  • Page 1 EW-38 www.ewheelsdealers.com (888) 305-0881...

  • Page 2: Table Of Contents

    Table of Contents Before y ..Technic Safety Instru Environ Seat A Instru Storage Compa 10-11...

  • Page 3: Before Y

    Before you operate the scooter Locate the below listed materials in rear basket: Set of mirrors Electric charger Scooter Key (Charger Box and underneath the seat) Inspection Form IT IS VERY IMPORTANT TO READ OPERATION Scooter Initial Operation Buckle seat belt (Some models) Insert key into ignition (or activate scooter using key fob) Set variable speed dial to lowest setting Turn lights on...

  • Page 4: Technical Specifications

    Technical Specifications Model EW-38 Weight Capacity 500Lbs. Seat: Type/Size Front & Rear Wheel Maximum Speed 15 MPH Battery Specifications 48 Volt , 20AH Battery Range 43 Miles Charger Type Off Board Motor Type 700 Watt Drive System Brushless motor Weight w/ Battery 200 lbs.
  • Page 5 Mirror Assembly Your power scooter is shipped partially disassembled for protection during shipping. After unpacking, please check whether you have received the following main components as our standard specification (See Fig 1) 1. Mirrors Mirror Post Fig 1 To attach the mirrors simply place each mirror threaded end into the mirror post.

  • Page 6: Safety Instru

    Operation of Scooter: 1. To prevent injury to yourself or others, always ensure that the power is switched off when getting on or off the scooter. Always check that the variable speed switch is set to the desired speed setting. Speed Switch: Slow / Fast Forward / Reverse Switch 3.

  • Page 7: Environ

    General 1. Always use a seatbelt, and keep your feet on the scooter all the time. 2. Do not exceed weight capacity of 350lbs. 3. Do not attempt to lift or move a power scooter by any of its removable parts.

  • Page 8: Seat A

    Warranty For valid warranty claims E-Wheels will, at their discretion, replace/repair/refund items mutually agreed to be defective. E-Wheels warranty as following: 1. Frame: (3) Year limited warranty 2. Electronic components: (1) Year limited warranty 3. Controllers: (1) Year limited warranty 4.

  • Page 9: Instrument Panel

    Instrument Panel Speedometer and Battery level indicator Battery Indicator Speedometer Running Light and Low headlight Running Lights only Headlight On Fast/ Slow Switch Forward / Reverse Switch High / Low beam light Left / Right turn signal Horn...

  • Page 10: Storage Compa

    Insert Key into lock mechanism (as shown above) and turn while lifting so seat will lift and tilt forward to gain access to storage compartment and master fuse shut off. Trunk Key Key Fob Press once to turn scooter off Press once to turn alarm off Panic Button Press once to activate alarm...

  • Page 11: Batteries And Charger

    Batteries and Charger We recommend that you use deep-cycle batteries that are sealed and maintenance free for your power scooter. Lead acid (SLA) and gel cell are Deep cycle batteries that are similar in performance. Deep-cycle batteries are specifically designed to provide power, drain down, and then accept a relatively quick charge.
  • Page 12 Recharge Battery only when the key is in off position and when indicator is showing low status this confirms battery needs recharge. Charger Use 1. Plug charger into Electric wall outlet 2. Insert charger port into scooter charging plug in located directly in front of scooter main body directly under seat.
  • Page 13 ELECTROMAGNETIC INTERFERENCE (EMI) FROM RADIO WAVE SOURCES electric vehicle may be susceptible to electromagnetic interference (EMI), which is interfering electromagnetic energy (EM) emitted from sources such as radio stations, TV stations, amateur radio (HAM) transmitters, two-way radios, and cellular phones. The interference (from radio wave sources) can cause the powered vehicle to release its brakes, move by itself, or move in unintended directions.
  • Page 14 those used in police cars, fire trucks, ambulances and taxis. These usually have the antenna mounted on the outside of the vehicle; and 2. Long-range transmitters and transceivers, such as commercial broadcast Transmitter (radio and TV broadcast antenna towers) and amateur (HAM) radios.
  • Page 15 2. Be aware of nearby transmitters, such as radio or TV stations, and try to avoid coming close to them; 3. If unintended movement or brake release occurs, turn the powered vehicle OFF as soon as it is safe; 4. Be aware that adding accessories or components, or modifying the powered vehicle, may make it more susceptible to EMI ( Note: There is no easy way to evaluated their effect on the overall immunity of the powered vehicle)
