UPort 1100 Series User's Manual
Seventh Edition, January 2015
www.moxa.com/product
© 2015 Moxa Inc. All rights reserved.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the UPort 1110 and is the answer not in the manual?

Questions and answers

Related Manuals for Moxa Technologies UPort 1110

Summary of Contents for Moxa Technologies UPort 1110

  • Page 1 UPort 1100 Series User’s Manual Seventh Edition, January 2015 www.moxa.com/product © 2015 Moxa Inc. All rights reserved.

  • Page 2: Technical Support Contact Information

    UPort 1100 Series User’s Manual The software described in this manual is furnished under a license agreement and may be used only in accordance with the terms of that agreement. Copyright Notice © 2015 Moxa Inc. All rights reserved. Trademarks The MOXA logo is a registered trademark of Moxa Inc.

  • Page 3: Table Of Contents

    Table of Contents Introduction ............................1-1 Overview ............................1-2 ARDC (Automatic Recovery Data Communication) ................1-2 Package Checklist ..........................1-2 Product Features ..........................1-2 Product Specifications ......................... 1-3 LED Indicators ............................ 1-4 Adjustable Pull High/low, Terminator Resistors for the RS-485 Port ........... 1-6 Installation and Configuration ......................

  • Page 4: Introduction

    The UPort 1100 Series of USB-to-serial converters provide an easy way to add COM ports to your computer. The UPort 1110 provides one RS-232 port, the UPort 1130 and UPort 1130I each provide one RS-422/RS-485 port, and the UPort 1150 and UPort 1150I each provide one RS-232/422/485 port. As a plug and play USB device, the converters are perfect for mobile, instrumentation, and point-of sale applications.

  • Page 5: Overview

    IRQs, configuring a board, power requirements, or connection schemes. The UPort 1100 series provides single COM port expansion. The UPort 1110 adds one RS-232 port to your computer, which is the same type of COM port that is built into most PC motherboards. The UPort 1130/1130I adds one port that is configurable for RS-422, 2-wire RS-485, and 4-wire RS-485 modes.

  • Page 6: Product Specifications

    UPort 1150I: Metal Weight: Product only: UPort 1110/1130/1130I/1150: 60 g (0.13 lb) UPort 1150I: 80 g (0.17 lb) Dimensions (L x W x H): UPort 1110/1130/1130I/1150: 37.5 x 20.5 x 60 mm UPort 1150I: 52 x 80 x 22 mm...

  • Page 7: Led Indicators

    61000-4-8, IEC-61000-4-11 Green Product: RoHS, CRoHS, WEEE Power Requirements Power Consumption: UPort 1110: 30 mA @ 5 VDC UPort 1130: 60 mA @ 5 VDC UPort 1130I: 65 mA @ 5 VDC UPort 1150: 77 mA @ 5 VDC UPort 1150I: 260 mA @ 5 VDC...
  • Page 8 UPort 1100 Series Introduction UPort 1150I LED description: Name Color Description Active Steady: The UPort is operational. Off: Fault condition exists. There may be a problem with the converter, driver installation, or PC configuration. Green Blinking: Serial device is transmitting data. Yellow Blinking: Serial device is receiving data.

  • Page 9: Adjustable Pull High/Low, Terminator Resistors For The Rs-485 Port

    UPort 1100 Series Introduction Adjustable Pull High/low, Terminator Resistors for the RS-485 Port In some critical environments, you may need to add termination resistors to prevent the reflection of serial signals. When using termination resistors, it is important to set the pull high/low resistors correctly so that the electrical signal is not corrupted.

  • Page 10: Installation And Configuration

    Installation and Configuration Installation of the converter is a simple process. First install the driver, then plug the converter into a USB port. When the converter is plugged in, Windows will load the correct drivers for the converter and the new COM port. In this chapter, basic installation and configuration procedures are explained.

  • Page 11: Initial Driver Installation

    UPort 1100 Series Installation and Configuration Initial Driver Installation The Documentation and Software CD contain the drivers for the converter. You may also download the drivers at www.moxa.com. The installation procedure is the same for all Windows operating systems. Use Windows Explorer to locate the driver installation file, which will be Setup or Install. On the Documentation and Software CD, this file will be located in the UPort 1100/Software folder, filed by operating system.
  • Page 12 UPort 1100 Series Installation and Configuration 3. Click Install to proceed with the installation. 4. Click Finish to complete the installation of the driver.

  • Page 13: Hardware Installation

    UPort 1100 Series Installation and Configuration Hardware Installation After installing the driver, plug the converter into any upstream USB port, such as a USB port on your computer. Windows will automatically detect the converter and begin installing the driver. When the Windows finishes installing the driver for the converter, it will then detect a new COM port, and will then install another driver for the new COM port.

  • Page 14: Windows Xp, Windows 2003/Vista, And Windows 2008 And 2012 (32-Bit And 64-Bit)

    UPort 1100 Series Installation and Configuration Windows XP, Windows 2003/Vista, and Windows 2008 and 2012 (32-bit and 64-bit) Case 1: The UPort Driver is Certified If the UPort driver that you installed has been certified by Microsoft, the UPort and the UPort’s serial ports will be installed automatically when you plug the UPort into your computer’s USB port.
  • Page 15 UPort 1100 Series Installation and Configuration 3. On the next window that appears, select Install the software automatically (Recommended), then click Next. 4. The installation wizard will search for the correct drivers. After a moment, a window will pop up cautioning you that this software has not passed Windows logo testing.
  • Page 16 UPort 1100 Series Installation and Configuration 6. The next window indicates that Windows has completed the installation. Click Finish to continue with installation procedure. 7. After Windows has completed installing the converter, it will automatically detect the new COM port. The Found New Hardware balloon will appear in the bottom right corner of the Windows desktop.
  • Page 17 UPort 1100 Series Installation and Configuration 9. After a moment, the Found New Hardware Wizard will open. Select Install the software automatically (Recommended), then click Next. 10. The installation wizard will search for the correct drivers. After a moment, a window will pop up cautioning you that this software has not passed Windows logo testing.
  • Page 18 UPort 1100 Series Installation and Configuration 11. Windows will spend a few moments installing the driver. 12. The next window indicates that Windows has completed the installation. Click Finish to proceed with installation procedure. 13. The Found New Hardware balloon will reappear, indicating that the installation was successful.

  • Page 19: Configuring The Com Port

    UPort 1100 Series Installation and Configuration Configuring the COM Port After the driver and hardware have been successfully installed, the new COM port will have a COM number and can be accessed and controlled just like your PC’s built-in COM ports. If you need to change the baud rate, parity, or other COM port settings, you may use your serial communication application to make those changes.

  • Page 20: Configuring The Converter

    UPort 1100 Series Installation and Configuration Configuring the Converter If you need to change the COM number that the converter assigns to the COM port, or adjust other advanced settings, you may go to Device Manager and right-click the UPort converter, which will be listed under Multi-port serial adaptors.
  • Page 21 UPort 1100 Series Installation and Configuration ATTENTION Before modifying these settings, make sure that you have closed any applications that may be accessing the COM port, such as HyperTerminal. You may change the Port Number and enable or disable the Fast Flush function. For the UPort 1130/1130I, you may also select between RS-422, 2-wire RS-485, and 4-wire RS-485 modes.

  • Page 22: Removing The Converter

    UPort 1100 Series Installation and Configuration Removing the Converter The converter is a plug and play device. No special procedures are required to remove the converter; you may simply pull the converter out of the USB port. You should verify that no data is being transmitted before removing the converter.

  • Page 23: Uninstalling The Driver

    UPort 1100 Series Installation and Configuration Uninstalling the Driver The UPort driver may be removed through Add/Remove Programs in the Windows Control Panel. Click Remove next to MOXA UPort 1110/1130/1150 Windows Driver Verx.x. 2-14...

  • Page 24: Advanced Uport 1100 Driver Functions

    UPort 1100 Series Installation and Configuration Advanced UPort 1100 Driver Functions The utilities of Moxa’s UPort 1100 Series give users a convenient tool for configuring and maintaining UPort series products. In this section, we introduce the “Fixed-base COM Mode” function that enables users to set COM names on the host PC.

  • Page 25: Install Linux Driver

    These drivers have been designed and tested for the majority of Linux distributions, including Linux kernel version 2.4.20 and above. Please check Moxa’s website (http://www.moxa.com) for the latest Linux kernel support. The Linux drivers support the following models: UPort 1110: 1-port RS-232 USB-to-Serial Converter. • UPort 1130: 1-port RS-422/485 USB-to-Serial Converter. •...

  • Page 26: Linux Kernel 2.6.X

    2.6.x and follow. Please check Moxa’s website (http://www.moxa.com. ) for the latest Linux kernel support. The Linux drivers support the following models: • UPort 1110: 1-port RS-232 USB-to-Serial Converter. • UPort 1130: 1-port RS-422/485 USB-to-Serial Converter. • UPort 1130I: 1-port RS-422/485 USB-to-Serial Converter with isolation Protection.
  • Page 27 UPort 1100 Series Installation and Configuration In this section, we provide four procedures to introduce the Moxa Linux Driver. 1. Installing Linux Driver File 2. Loading/Unloading the Moxa Driver 3. Setting the Serial Parameters 4. Removing the Moxa Linux Driver Installing Linux Driver Files Obtain the driver file from the Document and Software CD, or from the Moxa website at http://www.moxa.com.

  • Page 28: Installing The Windows Ce Driver

    “x86” for the WinCE 6.0 operating system. Note that this process will take a couple of hours and the folder size is around 3GB. The Win CE drivers support the following models: UPort 1110: 1-port RS-232 USB-to-Serial Converter. UPort 1130: 1-port RS-422/485 USB-to-Serial Converter. UPort 1150: 1-port RS-232/422/485 USB-to-Serial Converter.

  • Page 29: Installation With An Installation Package For Win Ce 6.0

    UPort 1100 Series Installation and Configuration Installation with an installation package for Win CE 6.0 Installation procedure Copy the UPort 1100 WinCE 6.0 driver package onto your computer and extract. Double click on the installation package and it will automatically copy the Mxser folder to C:\ MOXAUP1100\wince600\U1100.
  • Page 30 UPort 1100 Series Installation and Configuration 2. The WinCE 6.0 OS Design Wizard will start, click “Next” to continue. In the “Board Support Packages” page, select the “CEPC: x86.” Click “Next.” 2-21...
  • Page 31 UPort 1100 Series Installation and Configuration 3. Under Design Templates and Design Template Variants, select your environment, such as PDA Device or Mobile Handheld, and then click Next. In Application & Media and Networking & Communication, also select your environment, such as .NET Compact Framework 2.0, ActiveSync, Quarter VGA Resources-Portrait Mode, or TCP/IPv6 Support.
  • Page 32 UPort 1100 Series Installation and Configuration 2-23...
  • Page 33 UPort 1100 Series Installation and Configuration 4. When the OS Design Project Wizard Complete screen appears, click Finish. The notification will pop up. Click “Acknowledge” to finish the project. 2-24...
  • Page 34 UPort 1100 Series Installation and Configuration 5. Open the project you created. Click Project on top of the screen, and then select Add Existing Subproject. Switch the folder to “C:\ MOXAUP1100\wince600\U1100” and add subprojects into your OS Design. Assign the pbpxml file to a different folder (i.e. mxu11x0.pbpxml). 6.
  • Page 35 UPort 1100 Series Installation and Configuration 7. Open “Build”, select “Advanced Build Commands” and “Build Sysgen”. This operation will take you a few minutes. 8. After building sysgen, select “Build” and “Make Run-Time Image” to create the WinCE OS image. Finally, copy your image file to the target Host.

  • Page 36: Installation With An Installation Package For Win Ce 5.0

    In this section, we show how to install the Moxa WinCE 5.0 driver on a Windows CE 5.0 operating system directly. 1. Obtain a copy of the UPort 1110/1130/1150 WinCE 5.0 driver package and extract it to your computer. Double click the installation package to copy the files automatically to the UPort folder \WINCE500\PLATFORM\ (e.g., C:\WINCE500\PLATFORM\U11x0) and import the UPort...
  • Page 37 UPort 1100 Series Installation and Configuration 2-28...

  • Page 38: Removing The Moxa Wince 5.0 / Ce 6.0 Driver

    UPort 1100 Series Installation and Configuration Removing the Moxa WinCE 5.0 / CE 6.0 Driver For WinCE 6.0 Driver: 1. Select driver to Remove. 2. Switch the folder to C:\ MOXAUP1100 \ and double click “unins000.exe” to remove installation folder. For WinCE 5.0 Driver: 1.

  • Page 39: Installation With A Cab File

    UPort 1100 Series Installation and Configuration Installation with a CAB File Install the UPort 1100 series WinCE driver to target host. 1. First install Microsoft ActiveSync on the source PC. Before running ActiveSync on the source PC, use an RS-232 null modem cable to connect the WinCE device (CEPC) to the PC. 2.
  • Page 40 UPort 1100 Series Installation and Configuration 3. Click on the “Explore” button in the ActiveSync window, and then copy the UP1100_COM_v1.0_Setup.CAB (For WinCE 6.0) or UP1100_COM_v1.1_Setup.CAB (For WinCE 5.0) file to the Mobile/Target Device. 4. Double click on the CAB file to start installing the UPort 1100 series WinCE driver. After installing the driver, plug the UPort 1100 series device into the USB port of the WinCE Device.

  • Page 41: Removing The Moxa Wince 5.0 / Ce 6.0 Driver

    Installation and Configuration Removing the Moxa WinCE 5.0 / CE 6.0 Driver 1. Enter Control Panel  Remove Programs. 2. Select MOXA UPort 1110/1130/1150 Windows CE6 Driver Ver1.0 (For WinCE 6.0) MOXA UPort 1110/1130/1150 Windows CE5 Driver Ver1.1 (For WinCE 5.0) 3.

  • Page 42: Pin Assignment

    Pin Assignment UPort DB9 Pin Assignments The UPort 1100 series uses male DB9 connectors. Pin assignments are shown in the following diagram: RS-422 4-wire DB9 (male) RS-232 2-wire RS-485 RS-485 DCD (in) TxD-(A) – RxD (in) TxD+(B) – TxD (out) RxD+(B) Data+(B) DTR (out)

  • Page 43: Emi Notices

    EMI Notices EMI Notices (Class B) Electromagnetic Compatibility Notices This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (U.S. Only) (2) This device must accept any interference received, including interference that may cause undesired operation.
