Specifications; Overture - Infinity Overture 3 Compositions Series Service Manual

Overture 3

Overture 3 Frequency Response:
Recommended Amplifier Power Range
Amplifier Peak Output:
Maximum Output:
Sensitivity:
Nominal Impedance:
Crossover Frequencies:
Low-Frequency Driver:
Midrange Driver:
High-Frequency Driver:
Dimensions (H x W x D):
Weight:
Power Consumption:
* The maximum recommended amplifier power rating will ensure proper system headroom to allow
for occasional peaks. We do not recommend sustained operation at these maximum power levels.

Specifications

3
25Hz - 20,000Hz (±3dB)
10-200 watts*
500VA
115 dB SPL
94 dB 2.83V @ 1 meter
8Ω
350 and 3,000Hz
(4) 6-1/2" (165mm) high efficiency,
dynamically balanced, magnetically
shielded woofers.
(2) 5-1/4" (125mm) high-efficiency,
magnetically shielded midrange drivers.
(1) 1" (25mm) soft dome, high-
efficiency, neodymium magnet,
magnetically shielded tweeter.
46" x 6-7/8" x 15-3/4"
(1,168mm x 175mm x 400mm)
59 lb/(26.8 kg)
300 watts (Maximum)
