half of the switch to turn it off. When activated, a red
indicator light in the switch is illuminated. See
Fig. 5.4.

Interior Lighting Controls

Interior light controls are listed here in alphabetical
order.
The interior lights include panel lights, dome lights,
red map lights, clear reading lights, and courtesy
lights. Vehicles come pre-set from the factory with
theater lighting, which ramps up lights from low
power to full power when activated.
Sleepers have rear dome lights, bunk reading lights,
sleeper floor lights, and baggage compartment lights.
Baggage Compartment Lights
Baggage compartment lights are located on the un-
derside of the lower bunk, on both sides. Both lights
turn on when either baggage compartment door is
opened to illuminate the baggage compartment. The
lights also come on when the lower bunk is raised.
Foot Well Lights
When the driver or passenger doors are opened, red
lights illuminate both foot wells. These lights can also
be activated with the foot well light switch. See
Fig. 5.4. Press the upper half of the switch to turn
the foot well lights on, press the lower half of the
switch to turn them off.
Overhead Console Lights
The overhead console includes a clear reading light,
a clear dome light, and a red map light. See
The dome lights illuminate when a door opens, then
stay on for a short time after both doors are closed.
Press the lens of the reading light, dome light, or
map light to activate each one independently of the
others.
Panel Lights
The panel lights illuminate when the headlights are
turned on. To adjust the brightness of the panel
lights, use the panel lights switch, usually located in
the master module next to the hazard flasher switch.
See Fig. 5.4. The panel lights brighten and dim in
5% increments, depending on whether the upper half
or the lower half of the switch is pressed. When the
11/21/2006
1. Clear Reading Lamp
2. Clear Dome Lamp
headlights are turned on, the panel lights setting will
default to the intensity that was last set.
Rear Dome Light
A rear cab dome light is located on the roof, between
the bunk and the cab on sleeper vehicles. See
Fig. 5.10. The rear cab dome light will activate with
the dome lights when a door is opened, then stay on
for a short time after both doors are closed.
Use the dash-mounted switch or the switch in the
sleeper panel to activate the rear cab dome light.
See Fig.
Fig. 5.9.
11/21/2006
Driver Controls
1
2
3. Red Map Lamp
Fig. 5.9, Overhead Console Lights
5.4.
Fig. 5.10, Rear Cab Dome Light
3
f544907
f544908
5.6
