Colour Television
Service Manual
Model CE32WN5F-C
Service Ref. No. CE32WN5F-C-04
PRODUCT CODE: 111356910
ORIGINAL VERSION: Chassis No. EB7-A
Please use Schematic Diagram SKP20370 with
this Service Manual.
Give complete "SERVICE REF. NO." for parts
order or servicing, it is shown on the rating sheet
on the cabinet back of the TV set.
Note
This TV receiver will not work properly in foreign
countries where the television transmission
system and power source differ from the design
specifications. Refer to the specifications for the
design specifications
Contents
Safety precautions/Specifications ..................................................................................................................2
Cabinet Disassembly ......................................................................................................................................4
Adjustment and Repair Procedures............................................................................................................5~9
Component Locations ............................................................................................................................12~13
IC Block Diagrams ..................................................................................................................................14~18
Pin description of semiconductors ................................................................................................................19
Part Description and reading of schematic diagram ....................................................................................20
Cabinet Parts List/TV Stand parts list ..........................................................................................................21
Electric Parts List ....................................................................................................................................22~26
Part No.
SKSM0613
CE32WN5F-C-06
C3YFV
OCTOBER 2002
32WN5F
CE
-C
Advertisement
Table of Contents
Related Manuals for Sanyo CE32WN5F-C
Summary of Contents for Sanyo CE32WN5F-C
-
Page 1: Table Of Contents
Colour Television 32WN5F Service Manual Model CE32WN5F-C Service Ref. No. CE32WN5F-C-04 CE32WN5F-C-06 PRODUCT CODE: 111356910 ORIGINAL VERSION: Chassis No. EB7-A Please use Schematic Diagram SKP20370 with this Service Manual. Give complete "SERVICE REF. NO." for parts order or servicing, it is shown on the rating sheet on the cabinet back of the TV set. -
