Summary of Contents for D-Link Mini 3G 21 Mbps
-
Page 1: User Manual
Version 1.0 | August 6, 2012 User Manual Mini 3G 21Mbps USB Router DWR-710... -
Page 2: Preface
Preface D-Link reserves the right to revise this publication and to make changes in the content hereof without obligation to notify any person or organization of such revisions or changes. Manual Revisions Revision Date Description August 6, 2012 • Initial release... -
Page 3: Table Of Contents
Network Setup ................16 Configure WPA-PSK ............42 SIM Settings ..................17 MAC Filter ..................18 Troubleshooting...............44 Advanced Internet Settings ............19 Wireless.Basics..............46 Advanced Wireless ..............20 What is Wireless? .................47 Administrator Settings .............21 Wireless Modes ................50 SMS Messages................22 Factory Reset ................23 D-Link DWR-710 User Manual... - Page 4 Table of Contents Networking.Basics............51 Check your IP address ...............51 Statically Assign an IP address ..........52 Warnings.and.Declarations..........53 Technical.Specifications...........57 D-Link DWR-710 User Manual...
-
Page 5: Product.overview
• Computers with Windows , Macintosh , or Linux-based operating systems ® ® • Internet Explorer 6 or higher, Firefox 2.0 or higher, or another Java-enabled browser (for configuration) Subject to services and service terms available from your carrier. D-Link DWR-710 User Manual... -
Page 6: Introduction
Section 1 - Product Overview Introduction The D-Link DWR-710 Mini 3G 21Mbps USB Router is a palm sized 3G router, slim and small enough to carry in your pocket. It allows you to access and share your 3G mobile Internet connection anywhere and anytime. -
Page 7: Hardware Overview
Blinking Status LED Purple HSPA+ Network connection Transmitting Blue WCDMA/HSDPA/HSUPA network Transmitting Green GSM/GPRS network Transmitting SIM error or No service Amber Roaming operator found, but service not active Transmitting WiFi LED Green WiFi active Transmitting D-Link DWR-710 User Manual... -
Page 8: Back
Section 1 - Product Overview Hardware Overview Back Removable.Cover USB.Connector Port/LED Function USB.Connector Connects to a PC through a USB port. D-Link DWR-710 User Manual... -
Page 9: Wireless Installation Considerations
1. Minimize the number of walls and ceilings between the D-Link router and other network devices. Each wall or ceiling can reduce your adapter’s range from 3 to 90 feet (1 to 30 meters). -
Page 10: Product Setup
3. The Driver Installation program will open automatically. Follow the prompts until driver installation completes. 4. When Driver Installation is completed, a D-Link HSPA+ Router shortcut will placed on your on desktop. Double-click the shortcut to automatically launch your web browser and begin using the web-based configuration utility. -
Page 11: Web-Based.configuration.utility
Note: The web-based configuration utility and its associated features are for both Modem and Router modes. To access the configuration utility, double-click the D-Link HSPA+ Router shortcut or open a web browser such as Internet Explorer or Firefox, and then enter the IP address of the router (192.168.0.1 by default). -
Page 12: Internet Connection Setup Wizard
Once logged into the web interface of the router, the Setup.>.Internet page will appear. Click the Internet.Connection.Setup.Wizard button to quickly configure your router using the setup wizard. If you want to enter your settings without running the wizard, click Manual.Internet.Connection.Setup and skip to “Manual Internet Configuration”. D-Link DWR-710 User Manual... - Page 13 Section 3 - Configuration Click Next to continue. Create a new password and then click Next to continue. Configure your 3G Internet Connection settings and then click Next to continue. D-Link DWR-710 User Manual...
- Page 14 Section 3 - Configuration Click Connect to save your settings. Once the router has finished rebooting, click Continue. Please allow 1-2 minutes to connect. D-Link DWR-710 User Manual...
-
Page 15: Internet Setup
You may incur usage fees based on your Internet service provider plan. Maximum Idle Time: Enter a maximum idle time in minutes before disconnecting from your mobile Internet service. Choose 0 to disable automatic disconnection. D-Link DWR-710 User Manual... -
Page 16: Wireless Settings
If you want to manually configure the wireless settings on your router click Manual Wireless. Connection. Setup. and refer to “Manual.Wireless.Connection.Setup”. Click the Wireless.Connection.Setup.Wizard button to view the Wireless.Security.Setup.Wizard menu. The Welcome menu lists the steps used for setup. Click on the Next button to continue. D-Link DWR-710 User Manual... - Page 17 It is recommended that you tick the checkbox to use WPA wireless encryption to secure your wireless network. Click Next.to continue. Type a password that you would like to use for your wireless network in the Network.Key:.entry.field. Click Next to continue. D-Link DWR-710 User Manual...
- Page 18 The final menu appears to indicate that setup is complete. You should write down the Wireless.Network.Name.(SSID) and Network.Key.for future reference when connecting other wireless devices to your wireless network. Click Save to finish the Security Wizard. D-Link DWR-710 User Manual...
-
Page 19: Manual Wireless Setup
Section 3 - Configuration Manual Wireless Setup Use this section to configure the wireless settings for your D-Link router. Wireless Network Check box to enable (Router mode); Settings : Uncheck to disable (Modem mode) Wireless Network Name: Enter a wireless network name. -
Page 20: Network Setup
Enable DHCP Server: If you want to enable DHCP Server, check Enabled. Otherwise, check Disabled. It is recommended that you leave this setting Enabled. DHCP IP Address Range: Enter values for the DHCP IP address range. D-Link DWR-710 User Manual... -
Page 21: Sim Settings
Enable/ Disable PIN If you would like to enable or disable the PIN Function: authentication function, click Enable/Disable. PIN.Function. Modify PIN Code: If you want to modify the current or default PIN value, click Modify.PIN.Code to change it. D-Link DWR-710 User Manual... -
Page 22: Mac Filter
MAC addresses. Select Enabled to enable MAC filtering, and then enter the MAC addresses of the computers and devices you want to have access. Select Disabled if you do not wish to filter MAC addresses. D-Link DWR-710 User Manual... -
Page 23: Advanced Internet Settings
SMS messages. Network Type: Allows you to determine whether the router will connect via 2G only, 3G only, or 2G and 3G(whichever is available) D-Link DWR-710 User Manual... -
Page 24: Advanced Wireless
Set the transmit power and strength of your wireless network. A higher setting will boost coverage area, but uses more battery power. Max. Associated Number: Determines the maximum number of wireless PCs, devices, and other clients that can connect to your wireless network. D-Link DWR-710 User Manual... -
Page 25: Administrator Settings
Section 3 - Configuration Administrator Settings Use this section to change the password for the Administrator account. Password: Enter a password. Verify Password: Verify the password. D-Link DWR-710 User Manual... -
Page 26: Sms Messages
Section 3 - Configuration SMS Messages The DWR-710 allows you to read, write, and send SMS messages directly from the user interface. Note:.You must insert a SIM card to use this feature. D-Link DWR-710 User Manual... -
Page 27: Factory Reset
Section 3 - Configuration Factory Reset Use this section to restore the router to the factory default settings. Restore To Factory Click this button to restore all settings to the Default: factory defaults. D-Link DWR-710 User Manual... -
Page 28: Firmware Upgrade
After downloading a firmware file to your computer, click Choose.File to select the firmware file, then click Upgrade to start the upgrade process. Note:.Do not turn off or disconnect the power during the upgrade process, or you may cause damage to your device. D-Link DWR-710 User Manual... -
Page 29: Device Information
All of your Internet and network connection details are displayed on this page. The firmware version is also displayed here. General: Displays the firmware version. WAN: Displays information about the WAN. LAN: Displays information about the LAN. D-Link DWR-710 User Manual... -
Page 30: Statistics
Section 3 - Configuration Statistics All of your Internet traffic details are displayed on this page. Clear History: Clears the traffic statistics information D-Link DWR-710 User Manual... -
Page 31: Wireless Information
Section 3 - Configuration Wireless Information All of your wireless connection details are displayed on this page. Number of wireless Displays the wireless clients and their clients: MAC addresses. D-Link DWR-710 User Manual... -
Page 32: Support
Section 3 - Configuration Support This screen gives you more information about the various parts of the configuration interface. Click on a link to learn more about that topic. D-Link DWR-710 User Manual... -
Page 33: Wireless.security
– alphanumeric characters) format. ASCII format is provided so you can enter a string that is easier to remember. The ASCII string is converted to HEX for use over the network. Four keys can be defined so that you can change keys easily. D-Link DWR-710 User Manual... -
Page 34: Configure Wep
Your wireless signal may degrade when enabling encryption due to the added overhead. 1. Log into the web-based configuration by opening the D-Link HSPA+ application or a web- browser and entering the IP address of the router (192.168.0.1). Then click on.Wireless.Settings on the left side. -
Page 35: What Is Wpa
The password can include symbols (!?*&_) and spaces. This key must be the exact same key entered on your wireless router or access point. WPA/WPA2 incorporates user authentication through the Extensible Authentication Protocol (EAP). EAP is built on a more secure public key encryption system to ensure that only authorized network users can access the network. D-Link DWR-710 User Manual... -
Page 36: Configure Wpa-Psk/Wpa2-Psk
Your wireless signal may degrade when enabling encryption due to the added overhead. 1.. Log into the web-based configuration by opening opening the D-Link HSPA+ application or a web-browser browser and entering the IP address of the router (192.168.0.1). -
Page 37: Connect.to.a.wireless.network
1. Click on the wireless icon in your system tray (lower-right corner). 2. The utility will display any available wireless networks in your area. D-Link DWR-710 User Manual... - Page 38 If you get a good signal but cannot access the Internet, check your TCP/IP settings for your wireless adapter. Refer to the Networking Basics section in this manual for more information. 4. The following window appears while your computer tries to connect to the router. D-Link DWR-710 User Manual...
- Page 39 It may take 20-30 seconds to connect to the wireless network. If the connection fails, please verify that the security settings are correct. The key or passphrase must be exactly the same as on the wireless router. D-Link DWR-710 User Manual...
-
Page 40: Connect.to.a.wireless.network
(displayed using the SSID) and click the Connect button. If you get a good signal but cannot access the Internet, check the TCP/IP settings for your wireless adapter. Refer to the Networking.Basics section in this manual for more information. D-Link DWR-710 User Manual... -
Page 41: Configure Wireless Security
™ Wireless Utility by right-clicking on the wireless computer icon in your system tray (lower right corner of screen). Select Connect.to.a.network. 2.. Highlight the wireless network (SSID) you would like to connect to and click Connect. D-Link DWR-710 User Manual... - Page 42 It may take 20-30 seconds to connect to the wireless network. If the connection fails, please verify that the security settings are correct. The key or passphrase must be exactly the same as on the wireless router. D-Link DWR-710 User Manual...
-
Page 43: Using Windows Xp
(displayed using the SSID) and click the Connect button. If you get a good signal but cannot access the Internet, check the TCP/IP settings for your wireless adapter. Refer to the Networking.Basics section in this manual for more information. D-Link DWR-710 User Manual... -
Page 44: Configure Wep
XP Wireless Utility by right-clicking on the ® wireless computer icon in your system tray (lower-right corner of screen). Select View.Available.Wireless. Networks. 2.. Highlight the wireless network (SSID) you would like to connect to and click Connect. D-Link DWR-710 User Manual... - Page 45 It may take 20-30 seconds to connect to the wireless network. If the connection fails, please verify that the WEP settings are correct. The WEP key must be exactly the same as on the wireless router. D-Link DWR-710 User Manual...
-
Page 46: Configure Wpa-Psk
XP Wireless Utility by right-clicking on the ® wireless computer icon in your system tray (lower-right corner of screen). Select View.Available.Wireless. Networks. 2.. Highlight the wireless network (SSID) you would like to connect to and click Connect. D-Link DWR-710 User Manual... - Page 47 It may take 20-30 seconds to connect to the wireless network. If the connection fails, please verify that the WPA-PSK settings are correct. The WPA-PSK passphrase must be exactly the same as on the wireless router. D-Link DWR-710 User Manual...
-
Page 48: Troubleshooting
1..Why.can’t.I.access.the.web-based.configuration.utility? When entering the IP address of the D-Link router (192.168.0.1 for example), you are not connecting to a website on the Internet or have to be connected to the Internet. The device has the utility built-in to a ROM chip in the device itself. Your computer must be on the same IP subnet to connect to the web-based utility. - Page 49 Close your web browser (if open) and open it. • Access the web management. Open your web browser and enter the IP address of your D-Link router in the address bar. This should open the login page for your the web management.
-
Page 50: Wireless.basics
D-Link wireless products are based on industry standards to provide easy-to-use and compatible high-speed wireless connectivity within your home, business or public access wireless networks. Strictly adhering to the IEEE standard, the D-Link wireless family of products will allow you to securely access the data you want, when and where you want it. -
Page 51: What Is Wireless
D -Link is the worldwide leader and award winning designer, developer, and manufac turer of net work ing produc ts. D-Link delivers the performance you need at a price you can afford. D-Link has all the products you need to build your network. - Page 52 Appendix A - Wireless Basics Who.uses.wireless?. Wireless technology as become so popular in recent years that almost everyone is using it, whether it’s for home, office, business, D-Link has a wireless solution for it. Home • Gives everyone at home broadband access •...
- Page 53 The wireless connection in public places is usually called “hotspots”. Using a D-Link Cardbus Adapter with your laptop, you can access the hotspot to connect to Internet from remote locations like Airports, Hotels, Coffee Shops, Libraries, Restaurants, and Convention Centers.
-
Page 54: Wireless Modes
An Infrastructure network contains an Access Point or wireless router. All the wireless devices, or clients, will connect to the wireless router or access point. An Ad-Hoc network contains only clients, such as laptops with wireless cardbus adapters. All the adapters must be in Ad-Hoc mode to communicate. D-Link DWR-710 User Manual... -
Page 55: Networking.basics
Check your IP address After you install your new D-Link adapter, by default, the TCP/IP settings should be set to obtain an IP address from a DHCP server (i.e. wireless router) automatically. To verify your IP address, please follow the steps below. -
Page 56: Statically Assign An Ip Address
Set Primary DNS the same as the LAN IP address of your router (192.168.0.1). The Secondary DNS is not needed or you may enter a DNS server from your ISP. Step.5 Click OK twice to save your settings. D-Link DWR-710 User Manual... -
Page 57: Warnings.and.declarations
Changes or modifications not expressly approved by the party responsible for compliance could void the user‘s authority to operate the equipment. The antenna(s) used for this transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. D-Link DWR-710 User Manual... - Page 58 For body worn operation, this device has been tested and meets the FCC RF exposure guidelines for use with an accessory that contains no metal and the positions the handset a minimum of 1.0 cm from the body. Use of other accessories may not ensure compliance with FCC RF exposure guidelines. D-Link DWR-710 User Manual...
- Page 59 For the latest requirements, see http://www.art-telecom.fr. Wireless LAN Module’s Maximum EIRP Frequency Ranges (MHz) Indoors Outdoors 2400 MHz ~ 2446.5 MHz 10mW Not Permitted 2446.5 MHz ~ 2483.5 MHz 100mW 100mW on private property with Ministry of Defense approval. D-Link DWR-710 User Manual...
- Page 60 EN 55022:2006/A1:2007 Class B EN55024: 1998/A1:2001/A2:2003 Caution -Users have to use the connection to USB interfaces with USB 2.0 version or higher. -Please make sure the temperature for the DWR-710 will not be higher than 55 ˚C. D-Link DWR-710 User Manual...
-
Page 61: Technical.specifications
Maximum wireless signal rate derived from IEEE Standard 802.11g specifications. Actual data throughput will vary. Network conditions and environmental factors, including volume of network traffic, building materials and construction, and network overhead, lower actual data throughput rate. Environmental factors will adversely affect wireless signal range. D-Link DWR-710 User Manual...
