Nokia 6650 FOLD Service Schematics

Introduction
Important:
This document is intended for use by authorized service centers only.
"Service Schematics" was created with focus on customer care.
The purpose of this document is to provide further technical repair information for
NOKIA mobile phones on Level 3/4 service activities.
It contains additional information such as e.g. "Component finder".
Saving process time and improving the repair quality is the aim of this document.
It is to be used additionaly to the service manual and other training
or service information such as Service Bulletins.
While every endeavour has been made to ensure the accuracy of this document, some
errors may exist. If the reader finds any errors, NOKIA should be notified in writing.
Please send E-Mail to: TrainingAndVendor.Development@nokia.com
Customer Care / Service Operations / Training and Vendor Development
Confidential Copyright © 2008 NOKIA Only for training purposes
Service Schematics
RM-400
Version: 1.0 | 29.05.2008 | 6650 Fold |
Table of contents
Frontpage
AVILMA, BETTY. Micro USB, Audio, SIM
RAPIDOYAWE, Combo memory & SD-Card 3
GPS & Bluetooth
User interface
RF - part
Upper part (2fz_06)
Component finder/Upper part (2fz_06)
Component finder/Lower part(2ga_07d)
Copyright © NOKIA
This material , including documentation and any related computer programs is
protected by copyright, controlled by NOKIA. All rights are reserved. Copying,
including reproducing, modifying, storing, adapting or translating any or all of this
material requires the prior written consent of NOKIA. This material also contains con-
fidential information, which may not be disclosed to others whitout the prior written
consent of NOKIA.
Board version: 2ga_07d |
1
2
4
5
6
7
8
9
