Operating instructions
RDH10RF/SET consists of a RDH10RF wireless temperature controller and a RCR10/433 receiver. The RDH10RF
allows you to set the desired room temperature (setpoint) at the time you want. The unit features an ergonomic
setting knob for ease of temperature control.
Display
Actual room temperature in ºC
The unit is controlling to the selected
comfort temperature
Indicates when there is demand for
heat
Replace batteries
Appears on the screen when the
RF
TEST
transmitter is being tested.
Battery compartment
Two alkaline batteries type AA, 1.5 V
Commissioning before start-up
Commissioning
•
Remove the black transit tabs from the alkaline batteries.
•
Check to see if the battery holder is in the correct position.
•
If no batteries are inserted, fit 2 alkaline batteries type AA in the battery compartment.
CE1B3070en / 01.03.2010
RDH10RF/SET
Setting knob
Warmer/colder knob for
selecting the temperature
setpoint
Subject to alteration
Initial power-up
Once batteries are fitted, all symbols will appear on
the display as shown for about two seconds.
Selecting the required temperature
• Turn the setting knob counter clockwise to
decrease the setpoint, or clockwise to increase the
setpoint in increments of 0.5 °C
• The required temperature is displayed next to
the comfort temperature symbol
Changing the batteries
1. Get two new batteries of type AA alkaline, 1.5 volts.
2. Remove the battery holder, then the batteries, insert new batteries and
replace the battery holder.
The old, set values must be checked!
3. Make certain the old batteries are disposed of properly, in
compliance with environmental requirements.
Energy saving tips without sacrificing comfort
● Never allow room temperatures to exceed 21˚C.
● Air out rooms: Air out rooms for short periods with open windows and
doors.
