- Page 1 Television Reference Guide KDL-55W807B / 55W800B...
-
Page 2: Table Of Contents
Introduction Table of Contents Thank you for choosing this Sony product. Before operating the TV, please read this manual thoroughly and retain it for future reference. Note • Before operating the TV, please read “Safety Information” (page 2). • Instructions about “Installing the TV to the Wall” are included within this TV’s instructions manual. - Page 3 AC power cord (mains lead) Wall-Mount Bracket with the plug that fits into the AC power outlet (mains socket). Use only Sony supplied AC power cords (mains lead), not those of other brands. Transporting Insert the plug fully into the AC power outlet (mains socket).
- Page 4 Turn off the TV set and unplug the AC power cord (mains lead) immediately if any of the following problems occur. Ask your dealer or Sony service centre to have it checked by qualified service personnel. • For best picture quality, do not expose the screen to direct When: illumination or sunlight.
-
Page 5: Precautions
3D video images or playing • Do not operate this unit near medical equipment (pacemaker, stereoscopic 3D games. Sony recommends that all viewers take etc.), as malfunction of the medical equipment may result. regular breaks while watching 3D video images or playing •... -
Page 6: Connecting Other Devices
To connect with AV composite cables Connecting Other Devices To connect with an HDMI cable < 21 mm < 12 mm To VIDEO OUT To HDMI OUT To connect with component cables To AUDIO OUT To COMPONENT OUT (P Picture Quality •... -
Page 7: Installing The Tv To The Wall
To Sony Dealers and Contractors Sufficient expertise is required for installing this product. Be sure to read this instruction manual thoroughly to do the installation work safely. Sony is not liable for any damages or injury caused by mishandling or improper installation. -
Page 8: Wall
Installing the Wall-Mount Adapter on the wall Prepare necessary items. Wall-Mount Attachment J (supplied) Wall-Mount Adapter K (supplied) Paper Template Wall-Mount Base (2) Pulleys (2) Screws (3) Spacers (2) Band Screws for Wall-Mount Base (8 mm in diameter, not supplied) (8) - Page 9 Make sure that the wall has enough space for the TV and is capable of supporting a weight of at least four times that of the TV. Refer to the following table on installing the TV to the wall. See page 18-19 (Specifications) for the TV’s weight.
- Page 10 Make a mark on the Paper Template A that indicates the centre of the screen for your TV. Scale on Paper Template A Tape the Paper Template A to the wall and drill holes according to the numbering on the Paper Template A using an electric drill.
-
Page 11: Preparing For The Installation Of The Tv
Preparing for the installation of the TV Remove screws from the rear of the TV. Be sure to store the removed screws in a safe place, keeping them away from children. Soft cloth Attach the Wall-Mount Attachment J (supplied with the TV) to the rear of the TV. Attach the Pulleys C using the supplied screws D. -
Page 12: Installing The Tv On The Wall
Installing the TV on the wall Install the TV on the wall. Confirm the Pulleys C are firmly latched into the Wall-Mount Base B. Then, attach the Band F to the wall using a screw (6 mm in diameter, not supplied). -
Page 13: Su-Wl450
Sufficient expertise is required for installing this product, especially to determine the strength of the wall for withstanding the TV’s weight. Be sure to entrust the attachment of this product to the wall to Sony dealers or licensed contractors and pay adequate attention to safety during the installation. Sony is not liable for any damage or injury caused by mishandling or improper installation. - Page 14 Make sure that the wall has enough space for the TV and is capable of supporting a weight of at least four times that of the TV. Refer to the following table on installing the TV to the wall. See page 18-19 (Specifications) for the TV’s weight.
- Page 15 Remove screws from the rear of the TV. Be sure to store the removed screws in a safe place, keeping them away from children. Soft cloth Attach the Wall-Mount Attachment J (supplied with the TV) to the rear of the TV. Attach the Attachment parts for Wall-Mount Bracket.
- Page 16 Slim mounting Note • You cannot use some of the terminals on the rear of the TV when using this mounting style. Screw (+PSW 6 x 20) Screw (+PSW 6 x 20) Pulley Spacer (20 mm) E Belt ...
-
Page 17: Troubleshooting
TV. If the problem persists, contact your dealer or Rear of TV Sony service centre with the number of times the illumination LED flashes red (interval time is three seconds). Press / on the TV to turn it off, disconnect the AC power cord (mains lead), and inform your dealer or Sony service centre. -
Page 18: Specifications
MHL (common with HDMI IN 1) Video (2D): 1080p (30 Hz), 1080/24p, Specifications 1080i (50, 60 Hz), 720p (30, 50, 60 Hz), 720/24p, 576p, 576i, 480p, 480i System Video (3D): Side-by-Side: 1080/24p, 1080i (50, 60 Hz), Panel system 720p (50, 60 Hz) LCD (Liquid Crystal Display) Panel, LED backlight Over-Under: 1080p (30 Hz), 1080/24p, TV system... -
Page 19: Trademark Information
DVB-T/DVB-T2 (MPEG-2 and H.264/MPEG- Wi-Fi Alliance. 4 AVC) digital terrestrial signals are • “Sony Entertainment Network logo” and broadcast. Please confirm with your local “Sony Entertainment Network” are dealer if you can receive a DVB-T/DVB-T2 trademarks of Sony Corporation. - Page 20 • The Bluetooth® word mark and logos are owned by the Bluetooth SIG, Inc. and any use of such marks by Sony Corporation is under license. Other trademarks and trade names are those of their respective owners.
- Page 24 Customer Support and Contact: ©2014 Sony Corporation Printed in Malaysia 4-536-804-12(1)
