Specifi Cations - Sony KDF-46E2000 Service Manual

Power Requirements 120V AC, 60Hz
Power Consumption (W)
In Use (Max) 200W
In Standby Less than 0.8W
Inputs/Outputs HDMI IN
2 Video - 1080i, 720p, 480p, 480i
1 Audio - Two channel linear PCM 32, 44.1 and 48 kHz,
Video (IN)
3 total (1 on side panel)
1Vp-p, 75ohms unbalanced, sync negative
S Video (IN)
1 total
Y: 1Vp-p, 75ohms unbalanced, sync negative
C: 0.286Vp-p (Burst signal), 75ohms
Audio (IN)
5 total (1 on side panel)
500 mVrms (100% modulation)
Impedance:47 kilo ohms
Speaker Output (W)
Dimensions (W x H x D)
Mass
Trademark Information
As an ENERGY STAR
Corporation has determined that this product
meets the ENERGY STAR
energy efficiency.
ENERGY STAR
TruSurround XT, SRS and the ( )
trademarks of SRS Labs, Inc. TruSurround XT
technology is incorporated under license from SRS Labs, Inc.
This TV is manufactured under license from Dolby
Laboratories. "Dolby" and the double-D symbol are
trademarks of Dolby Laboratories.
KDF-46E2000/50E2000/55E2000
WEGA, Grand WEGA, WEGA GATE, Steady Sound,
Digital Reality Creation and CineMotion
are registered trademarks of Sony Corporation.
KDF-46E2000/46E2010/50E2000/50E2010/55E2000/55E2010
SPECIFICATIONS
16, 20, and 24 bit
KDF-46E2000
KDF-46E2010
mm 1096 x 766 x 382 mm
1/4 1/4
in 43 x 30 x 15
kg 27 kg
lbs 59 lbs 5 oz
®
Partner, Sony
®
guidelines for
®
is a U.S. registered mark.
® symbol are
KDF-46E2000/46E2010/50E2000/50E2010/55E2000/55E2010
Component Video Input
3 (Y, P /C ) (1 on Side Panel)
B B
Y: 1.0 Vp-p, 75 ohms unbalanced, sync negative
P : 0.7 Vp-p, 75 ohms;
B
P : 0.7 Vp-p, 75 ohms
R
Audio (VAR/FIX) Out
1 total
500 mVrms at the maximum volume setting
(Variable)
500 mVrms (Fixed)
Impedance (Output):2 kilo ohm
RF Input
2 total
Digital Audio Optical Output (PCM/Dolby Digital)
1 total
Optical Rectangular
KDF-50E2000
KDF-50E2010
12W (L), 12W (R)
1184 x 827 x 408 mm
1/8 5/8 5/8
in 46 x 32 x 16
29.3 kg
64 lbs 7 oz
BBE and BBE Symbol are trademarks of BBE Sound,
Inc. and are licensed by BBE Sound, Inc. under U.S.
Patent No. 4,638,258 and 4,482,866.
This TV incorporates High-
Definition Multimedia Interface
™
(HDMI ) technology. HDMI, the HDMI logo and High-
Definition Multimedia Interface are trademarks or
registered trademarks of HDMI Licensing LLC.
Macintosh is a trademark licensed to Apple Computer, Inc.,
registered in the U.S.A and other countries.
KDF-46E2010/50E2010/55E2010
"BRAVIA" and
Design and specifi cations are subject to change without notice.
KDF-55E2000
KDF-55E2010
1301 x 907 x 442 mm
1/8 1/4 3/4
in 51 x 35 x 17
34 kg
75 lbs
are trademarks of Sony Corporation.
1/2
in
4
