SERVICE MANUAL
MICROFILM
SPECIFICATIONS
Radio Section
FM :87.6 – 108MHz
AM :530 – 1,710kHz
Power Requirements
3V DC Batteries AA (R6) x 2
External DC 3V power sources
Battery Life
(approximate hours when using the batteries specified below)
Battery
Sony Alkaline LR6 (SG)
Sony R6P (SR)
Dimensions
94.2x 119.0 x 36.0 mm
Mass
260g incl. batteries and tape
Supplied Accessories
• Stereo headphones (1)
• Belt clip (1)
Design and specifications are subject to change without notice.
WM-PA1
Model Name Using Similar Machanism
Tape Transport Mechanism Type
Playback
Radio
16 hours
48 hours
4.5 hours
16 hours
RADIO CASSETTE PLAYER
E Model
WM-FX123
MF-WMFX103-48CY
