GE MultiSync 100 Instruction Manual page 12

SPECIFICATIONS
6
IEEE 1613 (37.90.X) EMI IMMUNITY TYPE TESTS
Test Description
IEEE 37.90.3 ESD
IEEE 37.90.2 Radiated RFI
IEEE 37.90.1 Fast Transient
IEEE 37.90.1 Oscillatory
IEEE 37.90 H.V. Impulse
IEEE 37.90 Dielectric Strength
ENVIRONMENTAL TYPE TESTS
Test Description
IEC 60068-2-1 Cold Temperature
IEC 60068-2-2 Dry Heat
IEC 60068-2-30 Humidity (Damp Heat,
Cyclic)
IEC 60255-21-1 Vibration
IEC 60255-21-2 Shock
CHAPTER 1: PRODUCT DESCRIPTION
Test Levels
Enclosure Contact +/-2 kV, +/-4 kV, +/- 8 kV
Enclosure Air +/-4 kV, +/-8 kV, +/- 15 kV
Enclosure Ports 35 V/m
Signal Ports +/-4 kV @2.5kHz
D.C. Power Ports +/-4 kV
Signal Ports 2.5kV common mode
@1MHz
D.C Power ports 2.5 kV common, 1 kV diff.
mode @1MHz
Signal Ports 5 kV (fail-safe relay output)
D.C. Power ports 5 kV
Signal Ports 2 kVAC
D.C. Power ports 2 kVAC
Test Levels
Test Ad -40°C, 16 hours
Test Bd +85°C, 16 hours
Test Db 95% (non-condensing),
55°C, 6 cycles
2 g at 10-150 Hz
30 g @ 11 mS
MULTISYNC 100 GPS CLOCK – INSTRUCTION MANUAL
