Electrolux 588050 Dimensions And Specifications

Modular Cooking Range Line
thermaline 80 - 4-Burner Gas
Top with Ecoflam, 1 Side
Modular Cooking Range Line
thermaline 80 - 4-Burner Gas Top with
Ecoflam, 1 Side
588050 (MAGGAAHOPI)
Short Form Specification
Item No.
Unit constructed according to DIN 18860_2 with 20 mm drop nose top. Internal
frame for heavy duty sturdiness in 2 mm and 3 mm in 1.4301 (AISI 304). 2 mm
top in 1.4301 (AISI 304). Flat surface construction, easily cleanable.
THERMODUL connection system enables seamless worktop when units are
connected and avoids soil penetrating. 4 gas burners with optimized
combustion, flame failure device, thermocouple safety hand valve and protected
pilot flame. Triple ring "flower" flame burners with anti-clogging design. Manual
gas valves allow precise flame intensity control. Large pan support in cast iron
with long center fins for various pan sizes. ECOFLAM pan detection system to
save energy and to reduce unnecessary heat radiation in the kitchen. Deep flat
spillage tray with rounded corners and drain hole. Metal knobs with embedded
hygienic silicon "soft" grip enable easier handling and cleaning.
IPX4 water resistant certification.
Configuration: One-side operated top. The base is supplied by the factory
APPROVAL:
4-burner gas top, ecoflam,
one-side operated
Electrolux Professional
www.electrolux.com/professional
professional@electrolux.com
ITEM #
MODEL #
NAME #
SIS #
AIA #

Main Features

• Flame failure device on each burner protects against gas
leakage when accidental extinguishing of the flame
occurs.
• Large sized pan support in cast iron with long center fins
to allow the use of the largest down to the smallest pans.
• Manual gas valves allow precise control of the flame
intensity between high and low positions.
• Pans can easily be moved from one area to another
without lifting.
• IPX4 water resistance certification.
• All major components may be easily accessed from the
front.
• THERMODUL connection system creates a seamless work
top when units are connected to each other thus avoiding
soil penetrating vital components and facilitating the
removal of units in case of replacement or service.
• Metal knobs with embedded hygienic silicon "soft" grip for
easier handling and cleaning. The special design of the
controls prevent infiltration of liquids or soil into vital
components.
• Burners with optimized combustion. Triple ring flower
flame burners with anti-clogging design.
• Deep flat spillage tray with rounded corners and drain hole
to facilitate cleaning.
• Model is supplied with Ecoflam pan detection system,
which reduces energy consumption and unnecessary heat
dispersion in the kitchen.
Construction
• Each burner equipped with thermocouple safety hand
valve and protected pilot flame.
• 2 mm top in 1.4301 (AISI 304).
• Flat surface construction with minimal hidden areas to
easily clean all surfaces
• Internal frame for heavy duty sturdiness in 2 mm and 3
mm in 1.4301 (AISI 304).
• Unit constructed according to DIN 18860_2 with 20 mm
drop nose top.
• Unit constructed according to DIN 18860_2 with 20 mm
drop nose top and 70 mm recessed plinth.
