Page 1
IMPORTANT SAFETY INSTRUCTIONS ... 2-3 FIRST TIME USE ... 4-19 THE REMOTE CONTROL ... 20-32 ON-SCREEN DISPLAY... 33-64 CARE OF YOUR HITACHI TV AND REMOTE CONTROL ...65 RECEPTION PROBLEMS...66 USEFUL INFORMATION ... 67-70 57” / 65” DISASSEMBLY/ASSEMBLY INSTRUCTIONS ...71-76 INDEX ...77 END USER LICENSE AGREEMENT FOR HITACHI DTV SOFTWARE...78-79...
HITACHI television. Please fill out your warranty card and mail it to HITACHI. This will enable HITACHI to notify you promptly in the improb- able event that a safety problem should be discovered in your product model.
Page 3
Continuous on-screen displays such as video games, stock market quotations, computer generated graphics, and other fixed (non-moving) patterns can cause permanent damage to television receivers. Such “SCREEN BURNS” constitute misuse and are NOT COVERED by your HITACHI Factory Warranty. • PUBLIC VIEWING OF COPYRIGHTED MATERIAL Public viewing of programs broadcast by TV stations and cable companies, as well as programs from other sources, may require prior authorization from the broadcaster or owner of the video program material.
Model No. Part No. SLF10 CAUTION: This SLF10 TV Top Shelf for use only with Hitachi 51F710, 51F710S and 57F710, 57F710S. Use with other apparatus is capable of resulting in instability causing possible injury. 1. Remote Control Unit CLU-4341UG2 (Part No. HL02071) or CLU4351UG2 (Part No. HL02072).
The sound of moving air from the fan is normal and maybe noticeable in very quiet environments. VIEWING The major benefit of the HITACHI Projection Television is its large viewing screen. To see this large screen at its best, test various locations in the room to find the optimum spot for viewing.
Most video/audio connections between components can be made with shielded video and audio cables that have phono connectors. For best performance, video cables should use 75-Ohm coaxial shielded wire. Cables can be purchased from most stores that sell audio/video products. Below are illustrations and names of common connectors. Before purchasing any cables, be sure of the output and input connector types required by the various components and the length of each cable.
FRONT PANEL CONTROLS MENU/SELECT button This button allows you to enter the MENU, making it possible to set TV features to your preference without using the remote. This button also serves as the SELECT button when in MENU mode. INPUT/EXIT button Press this button to display the input menu, Ant A/B, INPUT:1,2,3,4 and 5.
Page 8
The front panel jacks are provided as a convenience to allow you to easily connect a camcorder or VCR as shown in the following examples: INPUT 5 AUDIO S-VIDEO VIDEO L/MONO NOTE: 1. Completely insert connection cord plugs when connecting to front panel jacks. If you do not, the played back picture may be abnormal.
REAR PANEL JACKS MONITOR OUT S-VIDEO VIDEO AUDIO Antenna Input ANT A- A 75-Ohm RF antenna or CATV (Cable TV) input. ANT A can be displayed as a main picture or sub-picture. ANT B- A 75-Ohm RF antenna input. ANT B can only be displayed as a main picture. ANT B cannot be displayed as a sub-picture.
Page 10
NOTE: *Manufactured under license from Dolby Laboratories. Laboratories. Upgrade Card This card slot is for future software upgrades. Hitachi will notify you if a software upgrade is required for your TV. In order to receive written notification, please complete and return your warranty card. RS232C Input For use with third party home Audio/Video control systems which are commercially available.
Page 11
REAR PANEL JACKS CableCARD Slot This slot is for the CableCARD that will be provided by your local cable operator to gain access to chosen cable channels. The CableCARD will allow you to tune digital and high definition cable channels. Please call your local cable operator if this service is available before requesting a CableCARD (also known as Point of Deployment (POD) module).
Outside antenna or digital cable MONITOR OUT S-VIDEO VIDEO AUDIO AUDIO TO HI-FI INPUT OUTPUT S-VIDEO S-VIDEO VCR #2 Laserdisc player, VCR, camcorder, etc. NOTES: Connect only 1 component to each input jack. Follow connections that pertain to your personal entertainment system. Inputs 1 and 2 can accomodate Composite and Component video signals.
TIPS ON REAR PANEL CONNECTIONS • S-VIDEO, Y-PbPr and HDMI connections are provided for high performance laserdisc players, VCRs etc. that have this feature. Use these connections in place of the standard video connection if your device has this feature. •...
Match the numbers below to the diagram for speaker placement. The television’s internal speakers will act as center speaker (select Audio-Internal Speakers-TV as Center). These FRONT left and right speakers are connected to the FRONT output of a separate audio amplifier. These REAR left and right speakers are connected to the REAR output of a separate audio amplifier.
CONNECTING EXTERNAL VIDEO SOURCES The exact arrangement you use to connect the VCR, camcorder, laserdisc player, DVD player, or HDTV Set Top Box to your TV set is dependent on the model and features of each component. Check the owner’s manual of each component for the location of video and audio inputs and outputs.
Page 16
CONNECTING A STEREO SOURCE TO INPUT1~INPUT5 Connect the cable from the VIDEO OUT of the VCR or the laserdisc player to the INPUT (VIDEO) jack, as shown on the TV set below. Connect the cable from the AUDIO OUT R of the VCR or the laserdisc player to the INPUT (AUDIO/R) jack. Connect the cable from the AUDIO OUT L of the VCR or the laserdisc player to the INPUT (AUDIO/L) jack.
Page 17
CONNECTING EXTERNAL VIDEO SOURCES CONNECTING AN S-VIDEO SOURCE TO INPUT 3, 4 AND 5 Connect the cable from the S-VIDEO OUT of the VCR or the laserdisc player to the INPUT (S-VIDEO) jack, as shown on the TV set below. Connect the cable from the AUDIO OUT R of the VCR or the laserdisc player to the INPUT (AUDIO/R) jack.
Page 18
CONNECTING A COMPONENT SOURCE WITH HDMI or DVI CAPABILITY TO INPUT 1 Connect the HDMI or DVI to HDMI connection cable from the output of the HDTV set top box or DVD player to the HDMI input as shown on the TV set below. When using a component with DVI output, you also have to connect the AUDIO OUT (R/L) of the component to the AUDIO IN (R/L) of INPUT 1.
Page 19
CONNECTING EXTERNAL VIDEO SOURCES CONNECTING A COMPONENT SOURCE TO INPUT 1 OR 2: Y-P B P R . Connect the cable from the Y OUT of the Laserdisc/DVD player or HDTV set top box to the INPUT (Y) jack, as shown on the TV set below.
THE REMOTE CONTROL In addition to controlling all the functions on your HITACHI Projection TV, the new remote control is designed to operate different types of VCRs, CATV (Cable TV) converters, set-top-boxes, satellite receivers (SAT) and DVD players with one touch. Basic oper- ation keys are grouped together in one area.
HOW TO USE THE REMOTE TO CONTROL YOUR TV POWER button Press this button to turn the TV set on or off when the remote is in TV mode. (See page 20 for instructions on how to set the remote control to TV mode.) MODE buttons These buttons allow the remote to control your TV, VCR, DVD, Cable box/Satellite box depending on which button is pressed.
Page 22
ASPECT button Press this button to quickly change the picture format ASPECT ratio. Depending on the input signal format received, the picture format ratio allows you to adjust the images through the following options. 4:3 STANDARD Use this aspect mode to display conventional (4:3) images. Side panels (gray areas) are placed to the left and right of the image to preserve the original aspect ratio of the source.
Page 23
HOW TO USE THE REMOTE TO CONTROL YOUR TV INPUTS button When the remote control is in TV mode, press this button to access the INPUTS menu. Use the CURSOR and SELECT buttons to select the inputs that are being used. Pressing the INPUTS button repeatedly will also cycle through the Inputs menu items. Then press the SELECT button to select.
Page 24
PICTURE-IN-PICTURE button See separate section on pages 26-28 for a description. MENU button The MENU button will start the On-Screen Display. GUIDE button [Cable Box (CBL), Satellite Receiver (SAT)/Set-Top-Box (STB) mode only] The use of this button is only applicable when the remote control is in (CBL) and (SAT/STB) mode. Press this button to access the Channel Guide of the (CBL), and (SAT/STB).
Page 25
HOW TO USE THE REMOTE TO CONTROL YOUR TV VOLUME (VOL), MUTE button Press the VOLUME button ( ) until you obtain the desired sound level. To reduce the sound to one half of normal volume (SOFT MUTE) to answer the telephone, etc., press the MUTE button. Press the MUTE button again to turn the sound off completely (MUTE).
Your HITACHI Projection TV incorporates Two Tuner technology designed for improved viewing enjoyment. This Two Tuner feature allows you to view antenna inputs on both the main picture and sub-picture simultaneously, with separate tuning control for each. ANT A input can be viewed as both the main picture and the sub-picture simultaneously. ANT B can only be viewed as a main picture.
Page 27
PICTURE-IN-PICTURE (PIP) PIP MODE PICTURE-IN-PICTURE This feature is only available with a 1080i signal. To prevent a pattern burn, occasionally move the sub-picture using the CURSOR buttons. SPLIT MODE PICTURE-IN-PICTURE Split Mode PIP displays the main picture and sub-picture evenly on the screen. Main Picture SURF MODE PICTURE-IN-PICTURE Surf Mode PIP automatically scans all active channels (those set in memory) and displays them as PIP sub-pictures or...
Page 28
PAUSE button If you wish to freeze the sub-picture, press the PAUSE button. This is convenient when trying to write down the address for a mail order company, recording statistics for a sporting event, etc. To return the picture to motion, press the EXIT button. Press the PAUSE button repeatedly to toggle between FREEZE modes (Main Freeze, SPLIT and STROBE).
USING THE REMOTE TO CONTROL CABLE BOX FUNCTIONS Operating the precoded function for your cable box. This remote is designed to operate different types of cable boxes. You must first program the remote to match the remote system of your cable box (refer below for pre-codes).
ON-SCREEN DISPLAY (OSD) 1. Press MENU on the remote control to display the different features on your HITACHI Projection TV. 2. Press the CURSOR buttons to navigate and highlight a different feature of the On-Screen Display menu. Press the SELECT button to select.
Page 34
Picture Mode Contrast Brightness Color Tint Sharpness Color Temperature Video Black Enhancement Edge Enhancement Reset Video Settings Color Management Color Decoding Auto Color Noise Reduction Auto Movie Mode Treble Bass Balance Audio Audio Source Internal Speakers Auto Noise Cancel Perfect Volume Loudness Language Digital Output...
Page 35
ON-SCREEN DISPLAY (OSD) Channel Set the Antenna Manager Auto Channel Scan Signal Meter Channel List Change Access Code Engage Lock TV Time Lock Movie Ratings Locks TV Ratings Canadian Ratings (ENG) Canadian Ratings (FRN) Timers Set the Clock Set Sleep Timer Set Day/Night Timer Set Event Timer Magic Focus Tune Up...
Video Select VIDEO to adjust picture settings and improve picture quality. You can independently customize each of the Video Inputs to your preference to increase viewing performance and pleasure depending upon the video program being viewed. If RESET is selected, only the selected input will reset to initial conditions. Picture Mode Use this function to choose from automatic picture settings to optimize your TV’s performance.
VIDEO Use the CURSOR buttons to highlight the function to be adjusted. Press the CURSOR buttons to adjust the function. Press the SELECT button to select the function settings. Press MENU to return to main menu or select PICTURE MODE to return to previous menu. Press EXIT to quit menu.
Reset Video This function allows you to Reset the Video Menu Settings of the present input and return it to the Day VIDEO Settings mode. Video Picture Mode Contrast Brightness Color Tint Sharpness Color Temperature Black Enhancement Edge Enhancement Reset Video Settings Move Select Use the CURSOR buttons to highlight functions.
Page 39
This involves a process known as 3:2 pulldown. When Auto Movie Mode is turned ON from the VIDEO menu, your Hitachi Projection Television will activate the circuitry for this special feature to improve video performance when watching film based sources.
Page 40
Sound reproduction quality enhancement system. The BBE technology produces sound that is natural and crisp from just two speakers or the two internal speakers found in your HITACHI television. If your HITACHI television is connected to an external audio system, BBE will also create an incredible crisp sound experi- ence from two speakers.
AUDIO Audio Source Multi-Channel Television Sound will allow you to select STEREO (a stereo broadcast), MONO (monaural sound) used when receiving a weak stereo broadcast or 2nd Audio Prog (SAP) which may be a secondary language, weather report, etc. The sources received will be displayed at the top right edge of the TV. The source you select will be displayed above the sources received.
Page 42
Use the functions below if your TV is connected to an amplifier/receiver with optical digital input with Dolby Digital or PCM decoder capabilities. Audio Treble Bass Balance Sound Enhancement Audio Source Internal Speakers Auto Noise Cancel Perfect Volume Loudness Move Change Value Language Some programs transmit more than one DTV language option.
Page 43
ASPECT Aspect Use this function to select the Picture Format Aspect Ratio. Video Audio Aspect Chan. Manager Locks Timers Setup Move Auto Aspect Automatically adjust the Aspect Ratio depending on the input signal to fill the screen. Press THE CURSOR buttons Press THE SELECT button to select.
Chan. Manager Select Channel Manager to set your Antenna options, run Auto Channel Scan, Check Signal Meter and Set Channel List. Video Audio Aspect Chan. Manager Locks Timers Setup Move Press the CURSOR buttons to highlight function, the press the SELECT button to select. Set The Antenna This feature will select Antenna options.
CHANNEL MANAGER Signal Meter Select Signal Meter when using an indoor or outdoor antenna. This feature will show the signal strength and peak values of the Antenna signal to help you adjust your antenna to optimize signal reception. Chan. Manager Set The Antenna Auto Channel Scan Signal Meter...
Page 46
Locks This function will block out the picture and sound of the selected channel or video input. It can also be used to keep the TV from being viewed for a scheduled time period that you set. The code to enter the Locks feature is a four digit access code number. The factory preset code is 0000. Use the number buttons to enter the access code.
When you receive such messages, the Projection Television will immediately tune to an EAS channel as directed by the EAS message. Please be advised that if the EAS channel is blocked using the Locks feature, you will not be able to tune to that channel.
Page 48
When you receive such mes- sages, the Projection Television will immediately tune to an EAS channel as directed by the EAS message. Please be advised that if the EAS channel is blocked using the Locks feature, you will not be able to tune to that channel.
LOCKS Canadian Ratings Use Canadian Ratings (Eng) to block any type of movie and television program in Canada that (Eng) you feel might be inappropriate in its content. Locks Change Access Code Engage Lock TV Time Lock Movie Ratings TV Ratings Canadian Ratings (Eng) Canadian Ratings (Frn) Move...
Page 50
Canadian Ratings Use CANADIAN RATINGS (FRN) to block Canadian French programs according to various pro- (Frn) gram ratings that you feel might be inappropriate in its content. Locks Change Access Code Engage Lock TV Time Lock Movie Ratings TV Ratings Canadian Ratings (Eng) Canadian Ratings (Frn) Move...
TIMERS Timers Select Timers to set your Clock, Sleep Timer, Event Timer and Day/Night Timer Recordings. Video Audio Aspect Chan. Manager Locks Timers Setup Move Set The Clock The Clock must be adjusted before you can use the “Set Event Timer” or Day/Night Timer” feature. Timers Set The Clock Set Sleep Timer...
Set Sleep Timer Select this feature to set your Sleep Timer from 30 minutes to 3 hours (30 minute increments). Timers Set The Clock Set Sleep Timer 0:00 Set Day/Night Timer Set Event Timer Move Press the CURSOR button repeatedly to set your Timer from 0:00, 0:30, 1:00, 1:30, 2:00, 2:30 and 3:00. Set Day/Night Timer Select this feature to activate and set your TV’s Day/Night Picture Mode automatically.
TIMERS Set Event Timer This function will automatically operate the Projection TV viewing reservation of a program. If the clock is not set, you can not use this function and the screen below will appear. The message on the screen will dis- appear after 3 seconds, then the screen automatically goes to the clock setup mode (see page 51).
Page 54
Setup Select SETUP when setting your TV up for the first time. Use the CURSOR buttons the function desired. Video Audio Aspect Chan. Manager Locks Timers Setup Move Setup Magic Focus Tune Up Menu Preference Set The Inputs Set Virtual HD Set Black Side Panel Set Closed Captions Set Monitor Out...
The Magic Focus button on control panel will not work when adjustment mode is set to Manual (see page 56 or 57). Your HITACHI Projection TV has three color projection tubes: one for red, one for green, one for blue. When mixed together in the proper proportion, the output of these three color tubes can produce any color.
Page 56
Manual Convergence Adjustment Mode (9 Point Manual Adjustment) NOTES: 1. Please turn ON your television for at least 20 minutes before using this feature. Auto Adjustment Mode is recommended. If convergence is still not acceptable, use the Manual Adjustment Mode. If Auto Adjust mode is selected or the Magic Focus button is pressed, all manual adjust mode settings will be erased.
Page 57
SETUP Manual Convergence Adjustment Mode (117 Point Manual Adjustment) NOTES: 1. Please turn ON your television for at least 20 minutes before using this feature. Auto Adjustment Mode is recommended. If convergence is still not acceptable, use the Manual Adjustment Mode. If Auto Adjust mode is selected or the Magic Focus button is pressed, all manual adjust mode settings will be erased.
Menu Preference This feature will allow you to select any one of three different languages for all on-screen displays. Setup Magic Focus Tune Up Menu Preference Set The Inputs Set Virtual HD Set Black Side Panel Set Closed Captions Set Monitor Out About Your TV Move Select...
SETUP Menu Background This function allows you to choose from two menu backgrounds. Use the CURSOR buttoms to highlight SET THE MENU BACKGROUND (shaded or solid), and press the SELECT button to select setting. Press EXIT to quit menu or the CURSOR buttons Select SOLID for a black background (no picture can be seen behind menu screen), or select SHADED for a light background.
Page 60
Video 2 Auto Link Use this function to automatically turn the TV on and tune to Video2 when it detects a video signal to input 2. Setup Set The Inputs Rename List Video1 DVD2 PVR2 Video2 DVD3 Video3 CBL2 Video4 Reset Video5 Move...
Page 61
SETUP Set Virtual HD Use this feature to select between 1080i and 540p. NOTE: Set Virtual HD is not available (grayed out) in Digital Channels and 1080i input. Set Black Side The BLACK SIDE PANEL function turns the gray side bars on/off when watching 4:3 signals in Panel Standard mode.
Page 62
Font Size Style Move to return to previous menu. SETUP Auto Mode: Captions Text Return program. [1 2 3 4 5 6] : [Default 1 2 3 4 5 6 7 8] Standard Small Large Standard High Visibility [HITACHI] Return...
(non-moving) patterns cause permanent damage. Such “SCREEN BURNS” are not covered by your Hitachi Factory Warranty. Move Return CableCARD Info Select this feature to access your CableCARD ID and HOST ID. Please have this information ready when you call your cable operator (see also page 11).
It shows software information and easy upgrade procedure. This function allows the TV software to be upgraded by using a flash card (MMC Card). If a future software upgrade is required for your TV, Hitachi will notify and provide you with a flash card. In order to receive written notification and the flash card, please com- plete and return the warranty card.
Page 65
CARE OF YOUR HITACHI TELEVISION AND YOUR REMOTE CONTROL Dust the screen and cabinet with a soft cloth. Clean the screen with a soft cloth moistened in warm water and dry with a soft cloth. A mild soap may be used if the screen is extremely dirty.
NOTE: The TV set can generate sound distortion in external devices such as a radio. Please separate radio equipment from the TV set to a considerable distance. RECEPTION PROBLEMS • IGNITION NOISE: Black spots or horizontal streaks may appear, picture may flutter or drift. Usually caused by interference from automobile ignition systems, neon lamps, electrical drills, and other electrical appliances.
3. If there is still no power, unplug the power cord from the wall. Wait 30 seconds and plug the power cord back in. Press the power switch again. This protective technology should provide for years of lasting entertainment from your HITACHI Projection Television.
Page 69
Home Electronics Division Hitachi has made every effort to assure you hours of trouble free operation from your unit. However, should you require service, a network of Hitachi Authorized Service Facilities has been established in all 50 states and Puerto Rico. Each facility will provide you with convenient and expedient assistance.
Page 70
Hitachi Canada, LTD. Digital Media Division Should you have any questions regarding warranty, service, operation, or technical assistance, please contact: Look for your French Manual on the outside of the box. If the manual is missing, call for a copy.
(b). Disconnect the connector with the brown wires (PDSE), see (c) and (d). (Make sure to push the center lock on the connector at the unplug time.) HITACHI assumes no responsibility or liability for injury/damage as a result of con- sumer installation and handling. Be advised that improper consumer installation/han- dling is not covered by manufacturer’s warranty.
Page 72
1 - SEPARATION PROCEDURE CONTINUED STEP 4 Cont. STEP 5 Remove the joint connector bolts from each side of the back cover using the allen wrench that is provided inside of the instruction bag, see (a) and (b). Remove from the back side of the TV set only the top 4 screws of the lower rear cover, see (b), as shown by the arrows on the rear cabinet label, STEP 6 see (a).
57” DISASSEMBLY/ASSEMBLY INSTRUCTIONS 2 - RE-ASSEMBLY PROCEDURE STEP 8 To re-assemble the set, lift the top portion and align onto the bottom cabinet. Gently lower the top portion until it sits flush on the bottom. STEP 10 Re-install the top (4) four screws into the lower rear cover, see (a). Re-install the (4) four side screws that hold the back cover to the cabinet, see (b).
Page 74
(b). Disconnect wires (PDSE), see (c) and (d). (Make sure to push the center lock on the con- nector at the unplug time.) 65” DISASSEMBLY/ASSEMBLY INSTRUCTIONS HITACHI assumes no responsibility or liability for injury/damage as a result of con- sumer installation and handling. Be advised that improper consumer installation/han- dling is not covered by manufacturer’s warranty.
Page 75
65” DISASSEMBLY/ASSEMBLY INSTRUCTIONS 1 - SEPARATION PROCEDURE CONTINUED STEP 3 Cont. STEP 4 Remove the joint connector bolts from each side of the TV set using the allen wrench that is provided inside of the instruction bag, see (a) and (b). Remove from the back side of the TV set only the top 4 screws of the lower rear cover, see (b), as shown by the arrows on the rear cabinet label, STEP 5 see (a).
Page 76
2 - RE-ASSEMBLY PROCEDURE STEP 7 To re-assemble the set, lift the top portion and align onto the bottom cabinet. Gently lower the top portion until it sits flush on the bottom. STEP 9 Re-install the top (4) four screws into the lower rear cover, see (a). STEP 10 Re-connect the sensor connector to the sensor board, see (a).
1. LICENSE GRANT. Subject to all of the terms, conditions and restrictions of this License Agreement, HAL-HED grants to you a limited, revocable, non-exclusive right to use one copy of the Software only on one Hitachi labeled DTV owned by you.
Page 79
END USER LICENSE AGREEMENT FOR HITACHI DTV SOFTWARE 7. LIMITATION OF LIABILITY. IN NO EVENT SHALL HAL-HED OR ANY OF ITS PARENT OR AFFILIATE COMPA- NIES BE LIABLE TO YOU OR ANY THIRD PARTY FOR ANY DIRECT, INDIRECT, INCIDENTAL, SPECIAL, EXEM- PLARY, OR CONSEQUENTIAL DAMAGES (INCLUDING, BUT NOT LIMITED TO, PROCUREMENT OF SUBSTITUTE GOODS OR SERVICES;...
