Yamaha VMAX Assembly Instructions Manual page 13

Please use the dots on each component as reference when gluing surfaces.
Assembly Instructions
glue the assembled parts in numerical
order through .
Glue the right and left parts of the engine to the body.
Glue the right and left parts of the intake to the body.
Glue the rear tire to the body.
Glue the right and left side covers to the body.
Glue the rear fender to the right and left frame covers.
Glue the right and left rear suspensions to the rear tire
and the right and left side covers.
Glue exhaust C to the rear tire.
Insert the right and left exhaust B into the engine.
After inserting the right and left exhaust A into the engine,
insert exhaust pipes A and B into exhaust C.
Glue the seat to the body.
Glue the fuel top cover to the body and seat.
Glue the radiator to the body.
Glue the front tire to the steering column.
Glue the part completed in to the body.
Front tire
11 Finish
Top cover
Intake (Right)
Engine (Right)
To the Right intake.
Body
To the Right engine.
Steering column
Radiator
Side cover (Right)
Seat
Intake (Left)
Exhaust A
- 13 -
Side cover (Left)
Rear fender
Engine (Left)
Exhaust C
Exhaust B
Rear suspensions
To the right frame
cover.
Rear tire
