Lt4H-W Digital Timer - Panasonic LT4H/-L Manual

Applicable standard
Safety standard
(EMI)EN61000-6-4
Radiation interference electric field strength
Noise terminal voltage
(EMS)EN61000-6-2
Static discharge immunity
RF electromagnetic field immunity
EMC EFT/B immunity
Surge immunity
Conductivity noise immunity
Power frequency magnetic field immunity
Voltage dip/Instantaneous stop/Voltage fluctuation immunity
Dimensions

• LT4H-W digital timer

48
1.890
TIMER
T1
T2
T1
OP.
T2
LOCK h m s
UP
RESET
SET/LOCK
LT4H-W
DOWN
• Dimensions for flush mount (with adapter installed)
Screw terminal type
Rubber gasket
ATC18002 ( supplied )
TIMER
T1
T2
T1
48 50
OP.
T2
1.890 1.969
LOCK
h m s
UP
RESET
SET/LOCK
LT4H-W
DOWN
48
1.890
• Dimensions for front panel installations
DIN rail terminal block
( 8-pin type AT8-DF8K
sold separately )
( 11-pin type AT8-DF11K
sold separately )
Device installation rail
AT8-DLA1
( sold separately )
95.5
(90.0)
3.760
(3.543)
( ) dimension is for 8-pin type.
EN61812-1
Screw terminal type
(Flush mount)
5.5
.217 2.539
7.5
.295
Panel
Mounting frame
for flush mount
AT8-DA4 ( supplied )
44.5
66
1.752
2.598
1 63.5
2.500
• Installation panel cut-out dimensions
The standard panel cut-out dimensions are shown
below. Use the mounting frame (AT8-DA4) and rub-
ber gasket (ATC18002).
80min.
3.150min.
All Rights Reserved © COPYRIGHT Matsushita Electric Works, Ltd.
EN55011 Group1 ClassA
EN55011 Group1 ClassA
EN61000-4-2 4 kV contact
8 kV air
EN61000-4-3 10 V/m AM modulation (80 MHz to 1 GHz)
10 V/m pulse modulation (895 MHz to 905 MHz)
EN61000-4-4 2 kV (power supply line)
1 kV (signal line)
EN61000-4-5 1 kV (power line)
EN61000-4-6 10 V/m AM modulation (0.15 MHz to 80 MHz)
EN61000-4-8 30 A/m (50 Hz)
EN61000-4-11 10 ms, 30% (rated voltage)
100 ms, 60% (rated voltage)
1,000 ms, 60% (rated voltage)
5,000 ms, 95% (rated voltage)
64.5
44.5
1.752
Pin type
Rubber gasket
ATC18002 ( supplied )
TIMER
T1
T2
T1
48
OP.
T2
1.890
LOCK
h m s
UP
RESET
SET/LOCK
LT4H-W
DOWN
48
1.890
80min.
3.150min.
+0.6
45
0
+.024
1.772
0
+0.6
45
0
+.024
1.772
0
Pollution Degree 2/Overvoltage Category II
Pin type
(Flush mount/Surface mount)
5.5 55.6
.217 2.189
7.5
( Same for 8-pin type )
.295
Panel
Mounting frame
for flush mount
AT8-DA4 ( supplied )
50
66
1.969
2.598
1 90
3.543
• For connected installations
+0.6
45
0
+.024
1.772
0
When n timers are continuously installed , the dimension
( A ) is calculated according to the following formula ( n:
the number of the timers to be installed ) :
A= ( 48 × n – 2.5 ) +0.6
Note) 1: The installation panel thickness should be between 1
and 5 mm .039 and .197
Note) 2: For connected installations, the waterproofing ability
between the unit and installation panel is lost.
LT4H-W
(units: mm inch)
Tolerance: ±1.0 ±.039
14.5
.571
44.5
1.752
8-pin type
( 8p cap AD8-RC
sold separately )
11-pin type
( 11p cap AT8-DP11
sold separately )
A
A= ( 1.890 × n – .098 ) +.024
0 0
inch.
