DGS-3100 Series Gigabit Stackable Managed Switch User Manual
2. Click
Figure 3–12. IGMP Snooping and Static Router Ports Settings Page
The IGMP Snooping and Static Router Ports Settings Page contains the following fields:
Field
VLAN ID
VLAN Name
Leave Timer
Host Timeout
Router Timeout
State
77
. The IGMP Snooping and Static Router Ports Settings Page opens:
Description
Specifies the VLAN ID
Displays the user-defined VLAN name.
Defines the time a host waits to receive a Join message from another station after
requesting to leave the IGMP group, prior to timing out. If a Leave Timeout occurs,
the switch notifies the Multicast device to stop sending traffic The Leave Timeout
value is either user-defined, or an immediate leave value. The default timeout is 10
seconds. The field range is 0-16711450 seconds.
Defines the time the host waits to receive a message before timing out. The default
time is 260 seconds. The field range is 60-16711450 seconds.
Defines the time the Multicast router waits to receive a message before it times out.
The default value is 300 seconds. The field range is 1-16711450 seconds.
Indicates if IGMP snooping is enabled on the VLAN. The possible field values are:
