Chapter 5

Remote Control Card

The HP Netserver LP 1000r supports the HP Remote Control (PCI) card, which
makes use of the HP TopTools remote management software. The Remote
Control card requires an I
2
the I C connector on the daughter board (Integrated Remote Assistant circuitry)
installed onto the system board. See Figures 5-1 and 5-2.
Figure 5-1. Integrated RA Board Connector (I
NOTE The daughter board has the circuitry for Integrated Remote
Assistant (Integrated RA) and the I
to a Remote Control board. For more information on the use of
the HP TopTools function, refer to Chapter 10, "Configuring
the HP Netserver," and Chapter 11, "HP Netserver Online
Documentation CD-ROM."

Installing the Accessory Board

Use this procedure to install the accessory board and observe the installation
guidelines listed earlier.
1. If the Netserver is already installed and working, power down the
Netserver.
Refer to Chapter 1, "Controls, Ports, and Indicators."
2. Disconnect the power cable and any external cables connected to the
Netserver.
If necessary, label each one to expedite re-assembly.
2
C connection to the system board, which is provided by
Integrated Remote Assistant
Board (daughter board)
2
I C
Connector
Installing Additional Boards
2
C)
2
C connector for connection
